BJM9UBTMO19AHMicrowave Oven

Tatung Company

Click to zoom

Application Details

Equipment Class: 8CC - Part 18 Consumer Device
Date of Grant: Dec 14, 2000
Application Purpose: Original Equipment
Date of Application: Dec 14, 2000
Equipment Note: Microwave Oven
Frequency Range: 2450.00000000 - 2450.00000000
Company: Tatung Company
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Block Diagram

TMO-1960M Block Diagram POWER CONTROL CIRCUIT (TIMER) (TURN) (FAN) HIGH VOLTAGE TRANSFORMER MAGNETION

External Photos

A. EUT front side view B. EUT back side view C. EUT front side view D. EUT back side view

ID Label/Location Info

Sample of FCC ID Label

Internal Photos

A. EUT left side open case view B. EUT right side open case view C. EUT case inside whole view D. Capacitor top side view E. Capacitor bottom side view F. Microwave radiation generator top side view G. Microwave radiation generator bottom side view H. Timekeeper top side view I. Timekeeper bottom side view J. Transformer top side view K. Transformer bottom side view L. Fan top side view M. Fan bottom side view

Test Setup Photos

A. Open site test front view (30MHz – 1GHz : High power) B. Open site test front view (30MHz – 1GHz : Median power) C. Open site test front view (30MHz – 1GHz : Low power) D. Open site test front view (1GHz – 24.5GHz : High power) E. Open site test front view (1GHz – 24.5GHz : Median power) F. Open site test front view (1GHz – 24.5GHz : Low power)
