This is a mobile Internet device with Android4.0 operation system, can support 26 countries of the language. The machine CPU A13 Cortex A8@1GHZ (CPU + GPU + VPU + APU), RAM for DDR3 512 M, Nand Flash for optional 2-16G With built in WiFi module. (Protocol802.11b/g /n), The display is 7 inch LCD, the resolution is 800 * 480, 5 points touch. Battery capacity is 2800 MAH, 4 hours working time, can support a variety of video and audio file format. Tune Up

FCC ID : BPO-DOPO-D7015 WLAN(Portable device) According to §15.247(e)(i)and§1.1307(b)(1),systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498D01 Frequency Range Low Frequency(MHz) High Frequency(MHz) Center frequency (MHz) SAR Limitation(mw) 2412 2462 2441 10 Maximum measured transmitter average power:802.11b Conducted Power(dBm) Max Antenna Gain (dBi)EIRP(mw) 6.861 2.0 7.69 Maximum measured transmitter average power:802.11g Conducted Power(dBm) Max Antenna Gain (dBi)EIRP(mw) 7.729 2.0 9.39 Maximum measured transmitter average power:802.11n HT20 Conducted Power(dBm) Max Antenna Gain (dBi)EIRP(mw) 7.875 2.0 9.71 Threshold at which no SAR required is 10 mw. Maximum Tx power is 9.71mw EIRP. Conclusion:No SAR is required.
