BVCAMS9050Anti-Pilferage Device

AMS-9050 CONTROLLER 8200-0537-02, REV. B INSTALLATION AND SERVICE GUIDE 1 of 16 AMS-9050 Controller Installation and Service Guide ZE9050 Contents To the Installer.......................................................1 About the Product..................................................2 Device Connections ...........................................3 Installation Features...........................................7 Service Features ................................................8 Installation Requirements......................................9 Controller Installation...........................................11 Troubleshooting...................................................13 Fuse Replacement ..............................................15 Specifications ......................................................15 Declarations ........................................................16 © 2006 Sensormatic Electronics Corp. To the Installer This installation and service guide explains how to install, setup, and service the AMS-9050 controller. Parts required to install this system are: - AMS-9050 controller - AMS-1100/1101 exit antenna(s) or AMS-1080 aisle antenna(s) Other documents that may be required for installation are: - AMS-9050 Planning Guide, 8200-0537-01. Note: There may be installation restrictions on antennas in certain countries. See antenna installation guides for restrictions, if any. Regulatory Restriction: This device is only intended to be installed as described in the installation guide. - Because customer requirements dictate the placement of system components, your Sensormatic representative will supply this information separately. - If this product was installed in a European Union or European Free Trade Association member state, please give the Declaration of Conformity included with this product to the manager or user. By law, this information must be provided to the user. - Because of the number of antennas and accessories that can connect to this controller, methodically install this system to avoid problems. See “System Setup” in this guide for guidance on how to setup antennas. AMS-9050 CONTROLLER 8200-0537-02, REV. B INSTALLATION AND SERVICE GUIDE 2 of 16 About the Product The AMS-9050 controller is part of an EAS system that: - Includes pedestal type antennas. - Deters theft by activating an alarm when it detects the unique response of an active Ultra•Max hard plastic tag or disposable label when its signal is picked up by an antenna. Installation Features - Built-in mounting flange enables the controller to mount to a wall or inside a checkout counter. The controller can also rest on a shelf or attach to a ceiling. - Six knockouts receive exposed cables or cables in conduit. Knockouts are available for Class 2 wiring from antennas and low voltage devices. Setup Features - Supports various pedestal antennas used to detect tags/labels at exits or in food store checkout aisles. - Supports up to four AMS-1100/-1101 unicoil transceiver exit pedestals, or up to four AMS- 1080 aisle pedestals, each with separate transmit and receive coils. - Antennas can be set up as four transceivers, or four transmit/receive pairs, or combina- tions of both using a laptop computer and ADS 4 service configurator software. Two receivers can be noise canceling coils. Automatic configuration is available for the commonly used system configurations. - Antenna coils can be set for phase flipping (default), aiding, or figure-8 operation. Note: Phase flipping is unavailable when noise canceling coils are used. - Supports auto synchronization - Supports the following alarm devices: - Built-in alarm in the antenna (if used) - Up to two externally-powered remote alarms - Externally-powered Sensormatic alarm management or traffic flow device - Up to two relays for devices such as security cameras. - Connection for hardwired sync and transmit inhibit function. - Supports RS-232 (local diagnostics) and RS- 485 (remote diagnostics). - Supports RS-485 network communication to antennas (if supported by antenna). Service Features - The controller detaches from its cable access panel to facilitate servicing. - System status LED on controller displays error codes used for troubleshooting. Basic Operation and Setup To detect a tag: - Antenna(s) connected to the controller emit a 58kHz magnetic field close to the tag/label’s natural frequency causing it to vibrate or “ring” at the frequency of the field. When the field is removed, energy in the tag/label dissipates causing an exponential ring down. - The controller processes signal inputs picked up by the antennas to determine if they are indicative of a tag/label signal. - If the controller detects a tag/label signal, it activates audio-visual indicators on each antenna that picked up the signal and/or activates remote alarm devices, if used. ADS 4 service configurator software enables the field technician to: - Adjust the system - Synchronize the controller to other EAS systems using the ac line, or wired synchronization - Monitor and adjust for noise interference and use of a 58kHz jammer device - Download software application updates - Monitor internal temperature of the controller - Perform diagnostic tests and read error codes. AMS-9050 CONTROLLER 8200-0537-02, REV. B INSTALLATION AND SERVICE GUIDE 3 of 16 Device Connections RS-232 SERVICE (J2) Pin 1 - Rx Pin 2 - Tx Pin 3 - Ground Pin 4 - Ground AC IN (120Vac/ 240Vac) System Status LED RS-485 NETWORK (P8) Pin 1 - Black Pin 2 - Red Pin 3 - X (Shield) WIRED Tx SYNC (P2) Pin 1 - Black (Tx Burst High) Pin 2 - Red (Tx Burst Low) Pin 3 - Green (Arm High) Pin 4 - White (Arm Low) Pin 5 - 'X' (Shield) RMT ALARM 1 (P64) Pin 1 - Orange Pin 2 - Violet Pin 3 - X (Shield) RMT ALARM 2 (P63) Pin 1 - Orange Pin 2 - Violet Pin 3 - X (Shield) RELAYS (P54) Pin 1 - Common 1 Pin 2 - NC 1 Pin 3 - NO 1 Pin 4 - ‘X’ (shield) Pin 5 - Common 2 Pin 6 - NC 2 Pin 7 - NO 2 Pin 8 - ‘X’ (shield) Tx A TRANSMIT ANTENNA (P58) Pin 1 …

Text truncated - open the document above for the full version.

Tyco / Sensormatic February 2, 2006 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Re: Request for withholding from public disclosure proprietary information submitted pursuant to an application for certification for a anti-pilferage device FCC ID: BVCAMS9050 Dear Sir or Madam: Sensormatic Electronics Corporation requests certain materials submitted with this application for certification be withheld from public disclosure. This request is made under the provision of 47 CFR 0.457 (d) and 5 USC 552(b)(4) Freedom of Information Act, Trade Secrets. The items for which confidentiality is requested include the Operational Description, Block Diagram and Schematic Diagrams. This information contains proprietary information (trade secrets) regarding the circuit operation and capabilities (specific values of components, circuit design details and system architecture) that are the result of our extensive investment in research and development. Without the disclosed information, competitive organizations would take considerable more time to assess and develop a workable competitive product. As a result, we believe that disclosure of these company-guarded materials would compromise our leading position in this market. We therefore formally request that the materials identified “Confidential” be kept strictly confidential and not made available for inspections by any other party, except on a need to know basis for the sole purpose of the certification process. Sincerely, William D. Owsley Principal EMC Engineer, Compliance Engineering Tyco / Sensormatic 6600 Congress Ave. Boca Raton, FL. 33487

FCC ID: BVCAMS9050 IC: 3506A-AMS9050 External Photos See next page. FCC ID: BVCAMS9050 IC: 3506A-AMS9050 Note label placement.

FCC ID: BVCAMS9050 IC: 3506A-AMS9050 2412-0226-43 TYPE: AMS-9050 MFD:12-05 P/N: 0319-0011-01 REV : A SERIAL NO: ccctyyww123456 RATING: 100-120/200-240V~ 50-60Hz 2.5A ASSEMBLED IN PUERTO RICO-0105 BARCODE FCC ID: BVCAMS9050 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est confrome á la norme NMB-003 du Canada. IC: 3506A-AMS9050 CANADA 310 EMC Class II transmitter NEC Class 2, Limited Power Source outputs N205 ® NRTL

FCC ID: BVCAMS9050 IC: 3506A-AMS9050 Internal photos FCC ID: BVCAMS9050 IC: 3506A-AMS9050 FCC ID: BVCAMS9050 IC: 3506A-AMS9050

FCC ID: BVCAMS9050 IC: 3506A-AMS9050 Setup Photos Conducted DUT Antennas located outside the shielded room. FCC ID: BVCAMS9050 IC: 3506A-AMS9050 DUT on left corner, accessory layout, antenna cables routed to exit chamber through waveguide. FCC ID: BVCAMS9050 IC: 3506A-AMS9050 Measuring LISN, Accessory LISN and connections FCC ID: BVCAMS9050 IC: 3506A-AMS9050 H-field measurements DUT and measuring antenna FCC ID: BVCAMS9050 IC: 3506A-AMS9050 DUT
