BY4TR24702.4GHz Wireless Audio/Video Sender

2.4GHz Wireless, Audio/Video/S-Video Sender With Built-in Remote Control Extender MODEL: TR-2470 OWNERS MANUAL Made in China TABLE OF CONTENTS ● About the TR-2470 ......................................................................1 ● Location of controls and accessories .........................................2 ● User Guide ......................................................................3 ● Installation .....................................................................4 ● Trouble Shooting ...............................................................5-6 ● Referring Pictures ..................................................................7-9 ● Further applications .............................................................. 10-12 ● Caution ..................................................................13 ● Specification ..................................................................14 ABOUT THE TR-2470 The TR-2470 is a powerful wireless A/V/S-Video signal sender and receiver system which can operate with satellite and cable receivers, camcorders, stereo systems, televisions , laser disc players and VCRs, and provide superior reception at distances of up to 250 feet (clear line of sight) from the transmitter.. And this system can support S-Video This system can be used in many different ways: ● Enables you to watch a movie on any television in your home without moving your VCR or Laser Disc Player, and without the hassle of running wires. ● Enables you to watch your favourite cable or satellite programs on any television in your home. ● Extends the listening enjoyment of your stereo receiver to any powered speakers in your home, even if they are not wired into your stereo system. ● Enables you to use your camcorder with a remote television as a closed circuit monitoring system; ideal for baby's room, or for security. 1 LOCATION OF CONTROLS The TR-2470 has been carefully engineered and manufactured to give you dependable operation. Read this manual before operating this unit to become familiar with its features and obtain the performance that will bring you enjoyment for many years. Please retain this manual for future reference. Transmitter and Transmitter and Transmitter Back Receiver Side Receiver Front Receiver Back ● Transmitter and Receiver 1. Channel Selector 2. 2.4 GHz Antenna 3. ON / OFF Switch 4. AC Adaptor Port ● Transmitter 5. Infrared Remote Output 6. Audio L 7. Audio R 8. Video 9. S-Video 2 ● Receiver 10. Audio L 11. Audio R 12. Video 13. S-Video ● Accessory 1. DC 12V 300mA, AC 110V or 230V Adaptor x 1 (For Transmitter) 2. DC 12V 300mA, AC 110V or 230V Adaptor x 1 (For Receiver) 3. Infrared Extender Mouse x 1 4. A/V Cable x1 Remote Control Indicators DC 12 V AC 120V 300mA Infrared Extender USER GUIDE 1. Make sure your input AC voltage conforms to the adaptor specifications. ( Tolerance never more than 5%, such as 120 VAC +/- 10 VAC ) 2. Only use the power adapter provided with the TR-2470. If you use your own adaptor, make sure the power output is 12V DC, 300 mA centre positive. 3. With direct line-of-sight, the maximum range of A/V signal transmission can reach up to about 250 feet, and this distance would be shortened by obstacles or walls placed between transmitter and receiver. (The optimum indoor range is under 25 M) 4. To ensure good infrared remote control operation aim your remote control at the I/R Sensor Window on the TR 2470 and press the buttons firmly. ( With some remote controls it may be necessary to press and hold each button for about a second). The working angle of the I/R Sensor Window is +/- 15 degrees. (see Pictures 7,8,) 5. The remote controller has to be used within the distance of ( from remote control to receiver )not less than 0.3M and no more than 4.5M (working angle +/- 15 degrees). (see Pictures 9) 6. Be sure the ON / OFF switch on both the transmitter and receiver is in the OFF position before making any connections. 3 INSTALLATION TRANSMITTER (Tx-2470) a. By Composite Video(RCA) 1. Take a RCA to RCA cable(included),take one end connected to the AV In socket of Tx-2470.(see Pictures 1 ) 2. Connect the other end to the Audio / Video Out port of VCR, DVD, VCD, Satellite receiver .Etc. (see Pictures 1) b. by S-Video 1. Take a RCA to RCA cable(included),take Audio RL connected to the Audio RL In socket of Tx-2470. Take a S-Video to S-Video cable connect one end to S-Video input socket of Tx-2470. (see Pictures 1 ) 2.connect the other end of Audio RL to the Audio RL Output Port of VCR, DVD, VCD, Satellite receiver .Etc. and also connect other end of S-video to S-Video Output of of VCR, DVD, VCD, Satellite receiver .Etc. (see Pictures 1 ) 3. Connect the power adaptor to the power outlet. Turn power ON. ** DC 12V 300mA, AC 120V Adaptor. (see Pictures 1 ) 4. Stick the IR mouse in front of the sensor receiving window of the device i.e. VCR, DVD, VCD,.. Satellite receiver . Etc. under effective range and working angles. (see Pictures 2 ) 5. Choose one of the 4 channels by sliding the selection button ( must be set to same Channel on both transmitter & receiver) (see Pictures 4 ) RECEIVER (Rx-2470) a. by Composite Video (RCA) 1. Take a suitable RCA to RCA(included) cable and connect one end to A/V socket of Rx-2470.(see Pictures 3 ) 2. Connect the other end to the Audio / Video In port of TV. (see Pictures 3 ) b. by S-Video 1. Take a RCA to RCA cable(included),take Audio RL connected to the Audio RL In socket of Rx-2470. Take a S-Video to S-Video cable connect one end to S-Video input socket of Rx-2470. (see Pictures 3 ) 2. Connect the other end of Audio RL to the Audio RL Input Port of Television and also connect other end of S-video to S-Video Input Port of Television (see Pictures 3 ) 3. Connect the power adaptor to the power outlet. Turn power ON. **DC 12V 300mA, AC 120V Adaptor (see Pictures 3 ) 4. Choose one of the 4 channels by sliding the selection button ( must be set to same Channel on both transmitter & receiver) (see Pictu…
