CASTBBA4ABase Station Transceiver

TB7100 base station Installation Guide MBB-00003-01 Issue 1 May 2005 2TB7100 Installation Guide © Tait Electronics Limited May 2005 Contents 1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.1 Personal Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.2 Equipment Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.3 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1.4 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1.5 Grounding and Lightning Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1.6 Recommended Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 1.7 Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 1.8 Installing the Base Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 2 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 2.1 Overview of Inputs and Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 2.2 Power Supply Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 2.3 RF Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 2.4 Base Station Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Associated Documentation MBB-00001-xx TB7100 Installation and Operation Manual. MBB-00002-xx TB7100 Specifications Manual. All available TB7100 product documentation is provided on the Product CD supplied with the base station. Updates may also be published on the Tait support website. Consult your nearest Tait Dealer or Customer Service Organisation for more information Tuning and Configuration If your TB7100 base station has not been tuned to your requirements at the factory, you will need to tune the base station before operating it. To do this you will need to use the Calibration Application software included on the Product CD, plus the TBA0ST1 calibration test unit including the TB7100 adapter board. The TB7100 base station has been programmed with a default software configuration and default passwords at the factory. You will need to use the Program Application software to configure your base station to suit the requirements of your radio system. Refer to the Calibration Application and Program Application documentation for full details on these procedures. If a duplexer has been ordered, it will be tuned at the factory. TB7100 Installation GuideInstallation3 © Tait Electronics Limited May 2005 1Installation This chapter describes how to install the TB7100 base station in a standard 19 inch rack or cabinet. It also provides some general information on safety precautions and site requirements. We recommend that you read the entire chapter before beginning the installation. 1.1Personal Safety 1.1.1Explosive Environments Warning!!Do not operate TB7100 base station equipment near electrical blasting caps or in an explosive atmosphere. Operating the equipment in these environments is a definite safety hazard. 1.1.2Proximity to RF Transmissions Do not operate the transmitter when someone is standing within 90 cm (3ft) of the antenna. Do not operate the transmitter unless you have checked that all RF connectors are secure. 1.1.3High Temperatures Take care when handling a TB7100 base station which has been operating recently. Under extreme operating conditions (+ 60°C [+140° F] ambient air temperature) or high duty cycles the external surfaces of the TB7100 base station can reach temperatures of up to + 80°C (+176°F). 1.2Equipment Safety 1.2.1ESD Precautions ImportantThis equipment contains devices which are susceptible to damage from static charges. You must handle these devices carefully and according to the procedures described in the manufacturers’ data books. 4InstallationTB7100 Installation Guide © Tait Electronics Limited May 2005 We recommend you purchase an antistatic bench kit from a reputable manufacturer and install and test it according to the manufacturer’s instructions. Figure 1.1 shows a typical antistatic bench set-up. You can obtain further information on antistatic precautions and the dangers of electrostatic discharge (ESD) from standards such as ANSI/ESD S20.20-1999 or BS EN 100015-4 1994. 1.2.2Antenna Load The TB7100 base station has been designed to operate safely under a wide range of antenna loading conditions. However, damage will occur if the load is removed while the base station is transmitting. Transmitting into a low VSWR will maximise the power delivered to the antenna. 1.2.3Equipment Grounding To ensure safe operation the TB7100 base station must be correctly grounded as described in these installation instructions. 1.2.4Installation and Servicing Personnel The TB7100 base station should be installed and serviced only by qualified personnel. Figure 1.1Typical antistatic bench set-up common point ground (building ground or mains ground via 1 M ohm series resistor) conductive wrist strapdissipative rubber bench mat TB7100 Installation GuideInstallation5 © Tait Electronics Limited May 2005 1.3Regulatory Information 1.3.1Distress Frequencies The 406 to 406.1MHz frequency range is reserved worldwide for use by Distress Beacons. Do not program transmitters to operate in this frequency range. 1.3.2FCC Compliance 1 This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. 1.3.3Unauthorised Modifications Any modifications you make to this equipment which are not autho…

Text truncated - open the document above for the full version.

TB7100 base station Specifications Manual MBB-00002-01 Issue 1 May 2005 2TB7100 Specifications Manual © Tait Electronics Limited May 2005 Tait Contact Information Tait Radio Communicationshttp:// www.taitworld.com Corporate Head Office New Zealand Tait Electronics Ltd P.O. Box 1645 Christchurch New Zealand E-mail: [email protected] We b s i t e : http://www.taitworld.com Technical Support: E-mail: [email protected] We b s i t e : http://support.taitworld.com Tait North America Regional Head Office - United States of America Tait North America Inc. E-mail: [email protected] Canada Tait North America Inc. E-mail: [email protected] Latin America Tait Latin America E-mail: [email protected] Tait Europe Regional Head Office - United Kingdom Ta i t E u ro p e L t d E-mail: [email protected] Tait North Asia Regional Head Office - Hong Kong Tait Mobile Radio (Hong Kong) Ltd E-mail: [email protected] Beijing Tait Mobile Radio (Hong Kong) Ltd E-mail: [email protected] Tait South Asia Regional Head Office - Singapore Tait Electronics (Far East) Pte Ltd E-mail: [email protected] Thailand Tait Mobile Radio Ltd E-mail: [email protected] Oceania New Zealand Tait Communications Ltd E-mail: [email protected] Australia Tait Electronics (Aust) Pty Ltd E-mail: [email protected] Note: For the addresses and phone numbers of the above regional offices refer to the Tait- World website. TB7100 Specifications Manual3 © Tait Electronics Limited May 2005 Contents Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Scope of Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Enquiries and Comments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Updates of Manual and Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Associated Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Publication Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1 System Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Power Consumption @ 13.8 VDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Power Consumption Band B1, 25 W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Power Consumption Band B1, 50 W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Power Consumption Band H5, 25 W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Power Consumption Band H5, 40 W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Power Consumption Band H6, 25 W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Power Consumption Band H7, 40 W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Transmitting into 5:1 VSWR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Channel Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Isolation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 1.2 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 RF Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 EMC Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Safety Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 1.3 System Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 2 Receiver Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Receiver RF Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Receiver Audio Section - Gating Operation . . . . . . . . . . . . . . . . . . . . . . . . . 19 Receiver Audio Section - General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Receiver Audio Section - CTCSS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 3 Transmitter Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Transmitter RF Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Transmitter Audio Section - Modulation Characteristics . . . . . . . . . . . . . . . . 28 Transmitter Audio Section - CTCSS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 4TB7100 Specifications Manual © Tait Electronics Limited May 2005 TB7100 Specifications Manual5 © Tait Electronics Limited May 2005 Preface Scope of Manual Welcome to the TB7100 Base Station Specifications Manual. This manual provides general, performance and physical…

Text truncated - open the document above for the full version.

20/10/05 FCC ID: [CASTBBA4A] Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, (Tait Electronics Limited), hereby request confidentiality for the [Block diagrams, Schematics, Parts Lists, Tune up and Operational Description] presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. [Steve Crompton] [Tait Electronics Limited]

TELTEST Laboratories Tait Electronics Limited Report Number 2292 TELTEST Laboratories – A Division of Tait Electronics LimitedTelephone: 64 3 358 3399, Fax: 64 3 358 0432 PO Box 1645, 558 Wairakei Road, Christchurch, New Zealand Page 1 of 38 Laboratory Test Report For the TBBA4A4-A00-00 Base Station Transceiver Tested In accordance with FCC 47 CFR Parts 22 and 90 Report Revision:1 Issue Date:21-Sep-2005 FCC ID:CASTBBA4A PREPARED BY:Marcus Ludwig___________________ Test Technician CHECKED & APPROVED BY:Hamish Newton___________________ Senior Technician All tests reported herein have been performed in accordance with the laboratory's scope of accreditation This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. TELTEST Laboratories Tait Electronics Limited Report Number 2292 Page 2 of 38Report Revision: 1 Issue Date: 21-Sep-2005 TABLE OF CONTENTS REVISION HISTORY ........................................................................................................................... 3 INTRODUCTION .................................................................................................................................. 4 REPORT PREPARED FOR ................................................................................................................. 4 DESCRIPTION OF SAMPLE .............................................................................................................. 4 STATEMENT OF COMPLIANCE...................................................................................................... 4 TEST CONDITIONS ............................................................................................................................. 4 NECESSARY BANDWIDTH AND EMISSION DESIGNATORS ................................................... 5 TEST RESULTS..................................................................................................................................... 6 TRANSMITTER OUTPUT POWER (CONDUCTED) ...................................................................... 6 TRANSMITTER AUDIO FREQUENCY RESPONSE - PRE-EMPHASIS ....................................... 7 TRANSMITTER MODULATION LIMITING ................................................................................... 8 OCCUPIED BANDWIDTH ................................................................................................................ 9 ANALOGUE VOICE.....................................................................................................................10 FFSK..............................................................................................................................................12 THSD.............................................................................................................................................14 SPURIOUS EMISSIONS (CONDUCTED)....................................................................................... 16 SPURIOUS EMISSIONS (RADIATED)........................................................................................... 19 TRANSMITTER FREQUENCY STABILITY (TEMPERATURE) ................................................. 22 TRANSMITTER FREQUENCY STABILITY (VOLTAGE) ........................................................... 23 TEST EQUIPMENT USED................................................................................................................. 24 ANNEX A.............................................................................................................................................. 25 TEST SETUP DETAILS.................................................................................................................... 25 ANNEX B .............................................................................................................................................. 27 P RODUCT IDENTIFICATION FORM........................................................................................................ 27 TELTEST Laboratories Tait Electronics Limited Report Number 2292 Page 3 of 38Report Revision: 1 Issue Date: 21-Sep-2005 REVISION HISTORY DateRevisionComments 21-Sep-051Initial test report TELTEST Laboratories Tait Electronics Limited Report Number 2292 Page 4 of 38Report Revision: 1 Issue Date: 21-Sep-2005 INTRODUCTION Type Approval Testing of the TBBA4A4-A00-00 (Serial No 18013477) in accordance with: FCC CFR 47 Parts 22 & 90 REPORT PREPARED FOR Tait Electronics Ltd PO Box 1645 558 Wairakei Rd Christchurch New Zealand DESCRIPTION OF SAMPLE Equipment:Base Station Transceiver Type:TBBA4A Product code:TBBA4A4-A00 Serial Numbers:18013477 Quantity:1 A detailed description can be found in the Production Identification Form in Annex B STATEMENT OF COMPLIANCE The TBBA4A4-A00.00 Base Station transceiver as tested in this report was found to conform to the following standards: FCC CFR 47 Parts 22 & 90 TEST CONDITIONS All testing was performed at the following conditions. Ambient Temperature15 o C to 30 o C Relative Humidity20% to 75% Standard Test Voltage13.8Vdc TELTEST Laboratories Tait Electronics Limited Report Number 2292 Page 5 of 38Report Revision: 1 Issue Date: 21-Sep-2005 NECESSARY BANDWIDTH AND EMISSION DESIGNATORS SPECIFICATION:FCC 47 CFR 2.202 The Necessary Bandwidth is the minimum value of the occupied bandwidth sufficient to ensure the transmission of information at the rate and with the quality required for the system employed. This is calculated using the following formula. Bn = 2M + 2DKWhere: Bn = Necessary Bandwidth M = Maximum modulation frequency For Data transmission M = B/2 Where: B = Modulation rate in Baud D = Peak deviation K = Constant For Analogue transmission this is 1 For Data transmission this is typically 1.2 1. Analogue Voice 25kHz Bandwidth Necessary bandwidthEmission Designator M=3 kHz 16K0F3E D=5 kHz Bn= 6 + 10 x 1 = 16 kHz F3E represents a FM voice transmission 2. Fast Frequency Shift K…

Text truncated - open the document above for the full version.
