CASTBBH5ABase Station Transceiver

TB7100 base station Installation and Operation Manual MBB-00001-02 Issue 2 December 2005 2TB7100 Installation and Operation Manual © Tait Electronics Limited December 2005 Tait Contact Information Tait Radio Communications Corporate Head Office Tait Electronics Ltd P.O. Box 1645 Christchurch New Zealand For the address and telephone number of regional offices, refer to the TaitWorld website: We b s i t e :http://www.taitworld.com Technical Support For assistance with specific technical issues, contact Technical Support: E-mail:[email protected] We b s i t e :http://support.taitworld.com To our European customers: Tait Electronics Limited is an environmentally responsible company which supports waste minimization and material recovery. The European Union’s Waste Electrical and Electronic Equipment Directive requires that this product be disposed of separately from the general waste stream when its service life is over. Please be environmentally responsible and dispose through the original supplier, your local municipal waste “separate collection” service, or contact Tait Electronics Limited. TB7100 Installation and Operation Manual3 © Tait Electronics Limited May 2005 Contents Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Scope of Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Enquiries and Comments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Updates of Manual and Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Associated Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Publication Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 1.1 Frequency Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 1.2 RF Output Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 1.3 Power Supply Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 1.4 Mechanical Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 1.5 Product Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 2 Mechanical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 2.1 Tray. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 2.2 UI Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 2.3 Receiver Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 2.4 Transmitter Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 2.5 SI Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 2.6 AC Power Supply Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 3 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 3.1 Receiver Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 3.1.1 RF Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 3.1.2 Digital Baseband Processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 3.1.3 Audio Processing and Signalling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 3.2 Transmitter Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 3.2.1 Audio Processing and Signalling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 3.2.2 Frequency Synthesizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 3.2.3 RF Power Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 3.3 User Interface Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 3.4 System Interface Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 3.4.1 Internal Power Distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 3.4.2 Serial Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 3.4.3 General Purpose IO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 3.4.4 Receiver Audio Processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 3.4.5 Tone On Idle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 3.4.6 Transmitter Audio Processing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 4TB7100 Installation and Operation Manual © Tait Electronics Limited May 2005 3.4.7 Opto Isolated Keying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 3.4.8 Relay Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 3.4.9 Fan Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 3.4.10 RSSI . . . . . . . . . . .…

Text truncated - open the document above for the full version.

TB7100 base station Installation Guide MBB-00003-03 Issue 3 March 2006 2TB7100 Installation Guide © Tait Electronics Limited March 2006 Contact Information Tait Radio Communications Corporate Head Office Tait Electronics Limited P.O. Box 1645 Christchurch New Zealand For the address and telephone number of regional offices, refer to the TaitWorld website: Website:http://www.taitworld.com Technical Support For assistance with specific technical issues, contact Technical Support: E-mail:[email protected] Website:http://support.taitworld.com Copyright and Trademarks All information contained in this manual is the property of Tait Electronics Limited. All rights reserved. This manual may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-readable form, without prior written permission from Tait Electronics Limited. The word TAIT and the TAIT logo are trademarks of Tait Electronics Limited. All trade names referenced are the service mark, trademark or registered trademark of the respective manufacturers. Disclaimer There are no warranties extended or granted by this manual. Tait Electronics Limited accepts no responsibility for damage arising from use of the information contained in the manual or of the equipment and software it describes. It is the responsibility of the user to ensure that use of such information, equipment and software complies with the laws, rules and regulations of the applicable jurisdictions. Enquiries and Comments If you have any enquiries regarding this manual, or any comments, suggestions and notifications of errors, please contact Technical Support. Updates of Manual and Equipment In the interests of improving the performance, reliability or servicing of the equipment, Tait Electronics Limited reserves the right to update the equipment or this manual or both without prior notice. Intellectual Property Rights This product may be protected by one or more patents of Tait Electronics Limited together with their international equivalents, pending patent applications and registered trade marks: NZ338097, NZ508054, NZ508340, NZ508806, NZ508807, NZ509242, NZ509640, NZ509959, NZ510496, NZ511155, NZ511421, NZ516280/519742, NZ519118, NZ519344, NZ520650/537902, NZ521450, NZ524509, NZ524537, NZ524630, NZ530819, NZ534475, NZ534692, NZ535471, NZ536945, NZ537434, NZ534369, NZ522236, NZ524378, AU 2003281447, AU2002235062, AU 2004216984, CA2439018, EU03784706.8, EU02701829.0, EU04714053.8, GB23865476, GB2386010, GB0516094.0, GB0516092.4, US09/847322, US60/ 613748, US60/539617, US10/520827, US10/468740, US5,745,840, US10/520827. To Our European Customers Tait Electronics Limited is an environmentally responsible company which supports waste minimization and material recovery. The European Union’s Waste Electrical and Electronic Equipment Directive requires that this product be disposed of separately from the general waste stream when its service life is over. Please be environmentally responsible and dispose through the original supplier, your local municipal waste “separate collection” service, or contact Tait Electronics Limited. TB7100 Installation Guide3 © Tait Electronics Limited March 2006 Contents 1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1.1 Personal Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1.2 Equipment Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1.3 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 1.4 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1.5 Grounding and Lightning Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1.6 Recommended Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 1.7 Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 1.8 Installing the Base Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 2 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 2.1 External Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 2.2 Internal Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Associated Documentation
MBB-00001-xxTB7100 Installation and Operation Manual
MBB-00002-xxTB7100 Specifications Manual
MBB-00006-xxTB7100 Installation Guide (French)
MBB-00007-xxTB7100 Installation Guide (Spanish)
MBB-00008-xxTB7100 Installation Guide (Chinese)
MBB-00005-xxTB7100 Service Manual
MBA-00013-xxTBA0STU/TBA0STP Calibration and Test Unit Operation Manual The characters xx represent the issue number of the documentation. All available documentation is provided on the Product CD supplied with the base station. Updates may also be published on the Tait support website. Consult your nearest Tait Dealer or Customer Service Organisation for more information Tuning and Configuration If your base station has not been tuned to your requirements at the factory, you will need to tune the base station before operating it. To do this you will need to use the Calibration Application software included on the Product CD, plus the TBA0STU calibration test unit which includes the TB7100 adapter. (Customers using the TBA0ST1 calibration and test unit should use the TBB0STU-TBB adapter.) The base station has been programmed with a default software configuration and default passwords at the factory. You will need to use the Program Application software to configure your base station to suit the requirements of your radio system. Refer to the Calibr…

Text truncated - open the document above for the full version.

TB7100 base station TB8100 base station TB9100 base station TBA0STU / TBA0STP Calibration and Test Unit Operation Manual MBA-00013-01 Issue 1 September 2005 2TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005 Tait Contact Information Tait Radio Communications Corporate Head Office Tait Electronics Ltd P.O. Box 1645 Christchurch New Zealand For the address and telephone number of regional offices, refer to the TaitWorld website: We b s i t e :http://www.taitworld.com Technical Support For assistance with specific technical issues, contact Technical Support: E-mail:[email protected] We b s i t e :http://support.taitworld.com To our European customers: Tait Electronics Limited is an environmentally responsible company which supports waste minimization and material recovery. The European Union’s Waste Electrical and Electronic Equipment Directive requires that this product be disposed of separately from the general waste stream when its service life is over. Please be environmentally responsible and dispose through the original supplier, your local municipal waste “separate collec- tion” service, or contact Tait Electronics Limited. TBA0STU/TBA0STP CTU Operation Manual3 © Tait Electronics Limited September 2005 Contents Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Scope of Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Enquiries and Comments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Updates of Manual and Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Associated Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Publication Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2 Modification History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3 Using the CTU with a TB7100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 4 Using the CTU with a TB8100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 5 Using the CTU with a TB9100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Appendix A - CTU Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Appendix B - CTU Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 4TBA0STU/TBA0STP CTU Operation Manual © Tait Electronics Limited September 2005 Preface Scope of Manual This manual provides information on using the TBA0STU/TBA0STP base station Calibration and Test Unit (CTU) with a Tait base station. It describes the input and output connectors and controls available on the CTU, and includes a description of the accessories supplied with the CTU. A block diagram is also provided. Enquiries and Comments If you have any enquiries regarding this manual, or any comments, suggestions and notifications of errors, please contact Technical Support (refer to “Tait Contact Information” on page 2). Updates of Manual and Equipment In the interests of improving the performance, reliability or servicing of the equipment, Tait Electronics Ltd reserves the right to update the equipment or this manual or both without prior notice. Copyright All information contained in this manual is the property of Tait Electronics Ltd. All rights are reserved. This manual may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-readable form, without prior written permission from Tait Electronics Ltd. All trade names referenced are the service mark, trademark or registered trademark of the respective manufacturers. Disclaimer There are no warranties extended or granted by this manual. Tait Electronics Ltd accepts no responsibility for damage arising from use of the information contained in the manual or of the equipment and software it describes. It is the responsibility of the user to ensure that use of such information, equipment and software complies with the laws, rules and regulations of the applicable jurisdictions. TBA0STU/TBA0STP CTU Operation Manual5 © Tait Electronics Limited September 2005 Document Conventions Within this manual, four types of alerts are given to the reader: Warning, Caution, Important and Note. The following paragraphs illustrate each type of alert and its associated symbol. Warning!!This alert is used when there is a potential risk of death or serious injury. CautionThis alert is used when there is a risk of minor or moderate injury to people. ImportantThis alert is used to war n about the r isk of equipment dam- age or malfunction. NoteThis alert is used to highlight information that is required to ensure procedures are performed correctly. Associated Documentation TB7100 Calibration Application online Help. TB7100 Programming Application online Help. TB7100 Installation and Operation Manual. TB7100 Specifications Manual. TB8100 Calibration Kit User’s Manual and online Help. TB8100 Service Kit and Alarm Center User’s Manuals and online Help. TB8100 Installation and Operation Manual. TB8100 Specifications Manual. TB8100 Service Manual. TB9100 Calibration Software User’s Manual and online Help. TB9100 Customer Service Software User’s Manual and online Help. TB9100 Installation …

Text truncated - open the document above for the full version.

05/06/07 FCC ID: [CASTBBH5A] Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, (Tait Electronics Limited), hereby request confidentiality for the [Block diagrams, Schematics, Parts Lists, Tune up, Operational Description and RF Module Description] presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. [Steve Crompton] [Tait Electronics Limited]

Elite Quote EEE-Q26330TCB Tait Electronics Ltd 535 Wairakei Road, PO Box 1645 Christchurch, New Zealand Telephone: +64 +3 358 1026 Fax: +64 +3 358 3903 Email: [email protected] 1 st June 2007 Mr. D. Crowder Elite Electronic Engineering Inc 1516 Centre Circle Downers Grove Illinois 60515-1082 United States of America Dear Daniel, Subject: TCB Services on a 25W ( 400-470 MHz ) Base Station Transceiver – FCC ID: CASTBBH5A Enclosed are the hard copy documents required to initiate the process, copies have been posted to you. • CSF-20-01 Certification Agreement • CSF-20-10 Anti Drug Abuse Certification • Confidentiality Statement Our finance staff will fax a Purchase Order Number for this job, and your invoice will be paid by telegraphic transfer. I will upload the files that will be required by the FCC, to you. Will you please 1. Add the following Grant Note to the Grant of Authorisation • Grant Note: BC ‘The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed’ 2. Mark the Grant with Rule Parts 22 and 90 Yours sincerely, Des Fox Compliance Co-Ordinator

TELTEST Laboratories Tait Electronics Limited Report Number 2630 TELTEST Laboratories – A Division of Tait Electronics Limited Telephone: 64 3 358 3399, Fax: 64 3 358 0432 PO Box 1645, 558 Wairakei Road, Christchurch, New Zealand Page 1 of 33 Laboratory Test Report For the TBBH5A Base Station Transceiver Tested In accordance with FCC 47 CFR Parts 22 and 90 Report Revision: 2 Issue Date: 29-May-2007 FCC ID: CASTBBH5A PREPARED BY: Marcus Ludwig ___________________ Test Technician CHECKED & APPROVED BY: S A Crompton ___________________ Laboratory Manager All tests reported herein have been performed in accordance with the laboratory's scope of accreditation This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. TELTEST Laboratories Tait Electronics Limited Report Number 2630 FCC ID: CASTBBH5A Page 2 of 33 Report Revision: 2 Issue Date: 29/May/07 TABLE OF CONTENTS REVISION HISTORY ........................................................................................................................... 3 INTRODUCTION .................................................................................................................................. 3 REPORT PREPARED FOR ................................................................................................................. 3 STATEMENT OF COMPLIANCE...................................................................................................... 4 DESCRIPTION OF SAMPLE .............................................................................................................. 4 TEST CONDITIONS ............................................................................................................................. 4 MODULATION TYPES AND EMISSION DESIGNATORS ........................................................... 5 TEST RESULTS..................................................................................................................................... 6 TRANSMITTER OUTPUT POWER (CONDUCTED) ....................................................................... 6 TRANSMITTER AUDIO FREQUENCY RESPONSE - PRE-EMPHASIS ........................................ 7 TRANSMITTER MODULATION LIMITING ................................................................................... 9 SIDEBAND SPECTRUM .................................................................................................................. 11 SPURIOUS EMISSIONS (CONDUCTED) ....................................................................................... 17 SPURIOUS EMISSIONS (RADIATED) ........................................................................................... 20 TRANSMITTER FREQUENCY STABILITY (TEMPERATURE).................................................. 23 TRANSMITTER FREQUENCY STABILITY (VOLTAGE) ............................................................ 25 TRANSIENT FREQUENCY BEHAVIOR ........................................................................................ 26 TEST EQUIPMENT USED................................................................................................................. 31 ANNEX A.............................................................................................................................................. 32 TEST SETUP DETAILS.................................................................................................................... 32 TELTEST Laboratories Tait Electronics Limited Report Number 2630 FCC ID: CASTBBH5A Page 3 of 33 Report Revision: 2 Issue Date: 29/May/07 REVISION HISTORY Date Revision Comments 21-May-2007 1 Initial test report 29-May-2007 2 2400 bps FFSK was added to the report INTRODUCTION Type approval testing of the TBBH5A 25 Watt base station transceiver as addition to the Tait product range of the USA market in accordance with: FCC CFR47 Part 22 and 90 The 25 W version of type TBBH5A equipment is to be assigned the FCC ID: CASTBBH5A REPORT PREPARED FOR Tait Electronics Ltd PO Box 1645 558 Wairakei Rd Christchurch New Zealand TELTEST Laboratories Tait Electronics Limited Report Number 2630 FCC ID: CASTBBH5A Page 4 of 33 Report Revision: 2 Issue Date: 29/May/07 STATEMENT OF COMPLIANCE The TBBH5A Base Station transceiver as tested in this report was found to conform to the following standards: FCC CFR 47 Parts 22 & 90 DESCRIPTION OF SAMPLE Equipment: Base Station Transceiver. 400MHz to 470MHz Type: TBBH5A Details: Type Code TBBH5A Product Code TBBH5H5-A10-00 Serial Number 18035298 TX Module S/N 19242649 RX Module S/N 19231049 TX Module RX Module Hardware ID TMAB13-H5T1_0102 TMAB13-H5R1_0102 Radio Application QMA1F_std_02.13.00.10 QMA1F_std_02.13.00.10 Boot Code QMA1B_std_1.03.00.0005 QMA1B_std_1.03.00.0005 FPGA Image QMA1G_std_1.07.02.0001 QMA1G_std_1.07.02.0001 TEST CONDITIONS All testing was performed at the following conditions. Ambient Temperature 15 o C to 30 o C Relative Humidity 20% to 75% Standard Test Voltage 120 V ac TELTEST Laboratories Tait Electronics Limited Report Number 2630 FCC ID: CASTBBH5A Page 5 of 33 Report Revision: 2 Issue Date: 29/May/07 MODULATION TYPES AND EMISSION DESIGNATORS Modulation type: F3E Analogue FM F2D FFSK Data (1200 bps, 2400 bps) F1D THSD (12000 bps, 19200 bps) Channel spacing: 12.5 kHz, 25 kHz Emission designators: Analogue FM 11K0F3E, 16K0F3E FFSK Data 1200bps 6k60F2D, 9k60F2D FFSK Data 2400bps 7k80F2D, 10k8F2D THSD 7K70F1D, 12K7F1D TELTEST Laboratories Tait Electronics Limited Report Number 2630 FCC ID: CASTBBH5A Page 6 of 33 Report Revision: 2 Issue Date: 29/May/07 TEST RESULTS TRANSMITTER OUTPUT POWER (CONDUCTED) SPECIFICATION: FCC 47 CFR 2.1046 GUIDE: TIA/EIA-603C 2.2.1 MEASUREMENT PROCEDURE: 1. Refer Annex A for Equipment set up. 2. The coaxial attenuator has an impedance of 50 Ohms. 3. The unmodulated output power was measured with an RF Power sensor connected to the modulation analyser. MEASUREMENT RESULTS: Manufacturer’s Rated Output Po…

Text truncated - open the document above for the full version.
