CASTEL0033Base Station Transmitter

M850-00T856/857 General InformationC1.1 Copyright TEL31/09/98 1T856/857 General Information This section provides a brief description of the T856 transmitter and T857 exciter, along with detailed specifications and a list of types available. The following topics are covered in this section. SectionTitlePage 1.1Introduction1.7 1.2 1.2.1 1.2.2 1.2.3 1.2.4 1.2.4.1 1.2.4.2 1.2.4.3 1.2.5 1.2.6 1.2.6.1 1.2.6.2 1.2.6.3 Specifications Introduction General RF Section Audio Processor Inputs Modulation Characteristics CTCSS Microcontroller Test Standards European Telecommunication Standard DTI CEPT Recommendation T/R-24-01 Telecommunications Industry Association 1.8 1.8 1.8 1.9 1.10 1.10 1.11 1.11 1.11 1.12 1.12 1.12 1.12 1.3Product Codes1.13 1.4T856 Standard Product Range1.14 1.5T857 Standard Product Range1.15 FigureTitlePage 1.1T856 Main Circuit Block Identification1.4 1.2T856 Front Panel Controls1.4 1.3T857 Main Circuit Block Identification1.6 1.4T857 Front Panel Controls1.6 C1.2T856/857 General InformationM850-00 31/09/98Copyright TEL M850-00T856/857 General InformationC1.3 Copyright TEL31/09/98 replace A4 pages C1.3/C1.4 with A3 pages C1.3/C1.4 C1.4T856/857 General InformationM850-00 31/09/98Copyright TEL replace A4 pages C1.3/C1.4 with A3 pages C1.3/C1.4 M850-00T856/857 General InformationC1.5 Copyright TEL31/09/98 replace A4 pages C1.5/C1.6 with A3 pages C1.5/C1.6 C1.6T856/857 General InformationM850-00 31/09/98Copyright TEL replace A4 pages C1.5/C1.6 with A3 pages C1.5/C1.6 M850-00T856/857 General InformationC1.7 Copyright TEL31/09/98 1.1Introduction The T856 is a synthesised, microprocessor controlled FM base station transmitter designed for single or multichannel operation in the 400 to 520MHz frequency range 1 with a standard power output of 25W. The RF section of the transmitter comprises a fre- quency synthesiser which provides 100mW of frequency modulated RF drive to a two stage, wide band output driver followed by a 25W power amplifier. A thermal shut- down feature is provided in the T856 in case operating temperatures exceed acceptable levels. The T857 is a synthesised, microprocessor controlled FM base station exciter designed for single or multichannel operation in the 400 to 520MHz frequency range 1 . With a standard power output of only 1W, the exciter is designed for use with the T858 50W or T859 100W power amplifiers. The RF section of the exciter comprises a frequency syn- thesiser which provides 100mW of frequency modulated RF drive to a two stage, wide band output amplifier. A wide selection of audio characteristics may be obtained from the audio processor. Optional circuit blocks are an audio compressor and a pre-emphasis stage. They can be bypassed or linked to one or both audio inputs, and then back into the remaining audio circuitry in almost any combination. All audio processor options are link selectable. The synthesiser frequency is programmed via the serial communications port. Eight channel select lines are accessible via an optional D-range connector (D-range 2 - T800-03-0000) at the rear of the set. All components except those of the VCO are mounted on a single PCB. This is secured to a die-cast chassis which is divided into compartments to individually shield each sec- tion of circuitry. Access to both sides of the main circuit board is obtained by removing each of the chassis lids. There is provision within the chassis to mount small option PCBs. The front panel controls include line sensitivity, microphone socket and carrier switch. This switch turns on the carrier (unmodulated) as an aid to servicing. The T856 and T857 are both 60mm wide and each occupies a single space in a Tait rack frame, which has the ability to accommodate up to seven standard modules. 1. Although capable of operating over the 400-520MHz frequency range, the T856 and T857 have an 8MHz switching range (see Section 1.2.3 and Section 3.1). C1.8T856/857 General InformationM850-00 31/01/99Copyright TEL 1.2Specifications 1.2.1Introduction The performance figures given are minimum figures, unless otherwise indicated, for equipment tuned with the maximum switching range and operating at standard room temperature (+22°C to +28°C) and standard test voltage (13.8V DC). Where applicable, the test methods used to obtain the following performance figures are those described in the EIA and ETS specifications. However, there are several parame- ters for which performance according to the CEPT specification is given. Refer to Sec- tion 1.2.6 for details of test standards. Details of test methods and the conditions which apply for Type Approval testing in all countries can be obtained from Tait Electronics Ltd. The terms "wide bandwidth", "mid bandwidth" and "narrow bandwidth" used in this and following sections are defined in the following table. 1.2.2General Number Of Channels.. 128 (standard) 1 Supply Voltage: Operating Voltage .. 10.8 to 16V DC Standard Test Voltage .. 13.8V DC Polarity .. negative earth only Polarity Protection .. diode Supply Current: Transmit- T856.. 5.5A (typical) - T857.. 750mA Standby - T856.. 165mA (typical) - T857.. 150mA (typical) Operating Temperature Range .. -20°C to +60°C Channel Spacing Modulation 100% Deviation Receiver IF Bandwidth Wide Bandwidth25kHz±5.0kHz15.0kHz Mid Bandwidth20kHz±4.0kHz12.0kHz Narrow Bandwidth12.5kHz±2.5kHz7.5kHz 1. Additional channels may be factory programmed. Contact your nearest Tait Dealer or Customer Service Organisation. M850-00T856/857 General InformationC1.9 Copyright TEL31/09/98 Dimensions: Height .. 183mm Width .. 60mm Length .. 320mm Weight .. 2.1kg Time-Out Timer (optional) .. 0 to 5 minutes adjustable in 10 second steps Tail Timer .. 0 to 5 seconds adjustable in 100ms steps Transmit Key Time.. <30ms Transmit Lockout Timer.. 0 to 1 minute adjustable in 10 second steps 1.2.3RF Section Frequency Range .. 400-520MHz (refer to Section 1.4 and Section 1.5) Modulation Type .. FM Frequency Increment .. 5 or 6.25kHz Switching Range .. 8MHz (i.…

Text truncated - open the document above for the full version.

TELTEST Laboratories Tait Electronics Ltd PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone:(64) (3) 3583399 Fax:(64) (3) 3580432 21 Jun. 99 To whom it may concern T85X-XX-XXXX This equipment meets the requirements of the FCC Rules, Part 90.203(e) and (g), as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment’s external operation controls. Regards Rob Weeks Compliance Laboratory Technician

TELTEST Laboratories Tait Electronics Ltd PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone:(64) (3) 3583399 Fax:(64) (3) 3580432 27 Jan 2000 To whom it may concern T857-1X-XXXX The following information is in the Service Manual provided as attachment 857_9a4.pdf, and can be found on page c1.15 (T856/857 General Information) T857 Standard Product Range. Caution:T857-1X-XXXX Product Types The 406 to 406.1MHz frequency range is reserved worldwide for use by Distress Beacons. Do not program exciters to operate in this frequency range. Future releases of the PGM800Win Programming Software will prevent the Frequency Band 406 to 406.1MHZ from being programmed into the radios. Rob Weeks Compliance Laboratory Technician

IPN 220-01398-04 M850-00 T857 PCB Information C6.3.37 Copyright TEL 21/06/99 T857 Mechanical Assembly 220-01398-04 KeyThe upper number is the component identification number which appears in the “Legend” column of the Mechanical & Miscellaneous Parts on the facing page.The lower number indicates how many of this component are used in this location or function.

 IPN 220-01398-04C6.3.38 T857 PCB Information M850-00 21/06/99 Copyright TEL IPN 220-01398-04 M850-00 T857 PCB Information C6.3.43 Copyright TEL 21/06/99 T857 PCB Layout - Top Side 220-01398-04 A L BD CE J N KM H G F P 12345678 %D205 L300 + C201 C205 C317 %D210 +13V8 9 10 11 + 39 1213 14 12 15 + TP603 COMPRESSION SW230 RV210 #R330 IC740 IC740 E 1 IC260 SK504 IC210 RV220 SK205 220-01398-04 POCI +4V1 1 GND GND IC240 LPF-OUT 1 TX-LED BLK P231 S/LED A B C D EF GH IJ K LM N C204 GND R315 L303 B C C237 IC820 L920 P233 =R705 R334 + T210 P215 D230 IC650 =IC700 RV210 IC720 + + SK501SK502SK503 + #C295 P245 C841 + 7 BUFF-IN + 1 LK302 IC230 IC260 + + L750 28 D111 SW230 + 29 P170 IC250 T610 =SK710 RED + 6 SK205 + #R331 L309 RV805 P290 IC630 IC640 IC730 + IC750 IC610 + 1 #L313 + P810 #R332 + C207 IC210 TP604 C920 + C550 C233 IC300 2 T857EX P291 LEVEL P217 P150 TP602 SK810 SK505 C930 SK810 RED P160 C239 + TP601 TP607 C910 40 + + SK513 SK522 E C838 P825 P835 1 P820 P830 P840 + 857- %C713 +9V P230 + T210 + CTCSS BLK +4V1 %RV300 Q270 1 %C707 C765 + 857-10857-13857-15 857-20857-23857-25 PRODUCT TYPE PRODUCT TYPE 857-857- P208 P204 P225 P219 IC710 C774 C708 805 SK410 SK310 TP305 C300A Q304 L312 + P240 P239 C202 P235 P257 L910 9 P263 %R200 %R203 P251 10 C242 P249 SK200 1 + P210 + C263 C287 IC220 C265 15 SK805 D111A Q315 B C625 PL100 SMD HOLE &C269 %C294 %C295 #C315 #C316 #C321 #C322 #C323 #C326 #C327 #C335 #C345 %C707 #L307 #L313 #L315 &R264 &R265&R266 %R298 #R307 #R330 #R331 #R332 %C713 %C733 %D205 %D210 %R150 %R200 %R203 %R550 %R553 %R715 %R726 %RV300 =IC700 =R705 =SK710 C201 C202 C204 C205 C207 C209 C210 C211 C213 C215 C217 C219 C221 C223 C225 C227 C229 C230 C232 C233 C235 C237 C239 C241 C242 C243 C245 C247 C249 C251 C253 C255 C257 C259 C260 C261 C263 C265 C267 &C271 C273 C275 C277 C279 C281 C283 C285 C287 &C289 C291 C293 C300A C300B C301C302C303 C304 C305 C306 C307 C308 C309 C310 C311 C312 C313 C314 C317 C318 C319 C320 C324 C325 C328 C329 C330 C331 C332 C333 C334 C336 C337 C340 C341 C342 C350 C351 C354 C360 C503 C505 C510 C513 C514 C515 C516 C535 C536 C537 C545 C546 C550 C600 C601 C605 C610A C610B C611A C611B C615C616 C623 C625 C626 C628 C630 C631A C634 C636 C638 C640 C655 C660 C665 C670 C673 C677 C681 C684 C687 C690 C693 C700 C703 C706 C708 C709 C710 C711 C712 C714 C719 C720 C722 C724 C725 C726 C727 C729 C735 C736 C740A C740B C741A C741B C742A C742B C743 C745 C750 C757C759 C761 C762 C764 C765 C767 C769 C770 C772 C774 C776 C782 C784 C786 C788 C790 C792 C810 C812 C813 C822 C823C824 C826 C827 C828 C830 C838 C841 C844 C910 C920C930 D111 D111A D220 D230 D240 D250 D260 D270 D301 D302 D303 D510 D610 D620 D630 D635 D635A D640 D645 D710 D720 D730 D730A D740 D740A D810 D810A IC210 IC220 IC230 IC240 IC250 IC260 IC300 IC610 IC630 IC640 IC650 IC710IC720IC730 IC740 IC750 IC820 IC830 L300 L302 L303 L305 L306 L307 L308 L309 L310 L312 L314 L350 L535 L600 L615 L750 L910L920 LK302 P100 P150P160 P170 P204 P208 P210 P215P217 P219P225 P230 P231 P233 P235 P237 P239P240 P243P244 P245 P247P248 P249P251 P255 P257 P259P261 P263 P267 P269 P271 P273 P275 P290 P291 P805 P810 P820 P825 P830 P835 P840 PL100 PL205PL210 PL215 PL220 Q210 Q220 Q230 Q240 Q250 Q260 Q270 Q301 Q302 Q304 Q306 Q307 Q308 Q309 Q310 Q311 Q315 Q505 Q510 Q520 Q530 Q540 Q550 Q610 Q620 Q630 Q660 Q670 Q710 Q720 Q730 Q740 Q750 Q760 Q770 Q775 Q780 Q785 Q790 Q795 Q810 Q820 Q830 Q840 Q850 Q860 R160 R201 R202 R204 R205 R206R207 R208 R209 R210 R211 R212 R213 R214 R215 R216 R217 R218 R219 R220 R221 R223 R224 R225R226 R227 R228 R229 R230 R231 R232 R233 R235 R237R238 R239 R241 R242 R244 R245 R247 R248 R249 R251 R253R254 R255 R256 R257 R258 R259 R260 R262 R263 R267 R268 R269 R270 R271 R272 R273 R274 R275 R277 R278 R279R280 R282 R283 R284 R285 R286 R287 R288 R289 &R290R291 R292 R293 R294 R295 R296 R297 R299 R300 R301 R302 R303 R304 R305 #R306 R308 R309 R310R311 R312 R313R314 R315 R322 R323 R324 R325 R326 R327 R328 R329 R333 R334 R335 R336 R337 R338 R339 R340 R341 R342 R343 R344R345 R346 R347 R348 R349 R350 R355 R356 R357 R358 R359 R501 R502 R503 R504R505R510 R514 R515 R517 R518 R519 R520 R525 R530 R535 R540 R545 R555 R560 R609 R613 R615 R617 R619R621 R625 R629 R633 R637R638 R640 R641R645 R649 R653 R655 R656 R657 R661 R665R669 R673 R677 R681 R685 R689 R693 R696 R701 R702 R703 R704 R706 R708 R710 R711 R712 R713 R714 R717R718 R719 R720 R721 R722 R723 R725 R727 R728 R734 R735 R736 R742 R743 R744 R746 R747 R748 R749 R750 R752 R753 R754 R756 R757 R758 R759 R760 R762 R763 R765 R766 R767 R769 R771 R772 R774 R775 R777 R780R782 R784 R785R786 R787 R790 R791 R801 R802 R808 R809 R810 R811 R812 R813 R815 R816 R818 R819 R821 R822 R824R825 R826R827R828 R829 R830R831R832R833R835R836 R837R840R841R842R843 R845 R847 R848 R849 R850 R853 R854 R855 R859 R861 R863 R865 R867 R871 R872 R873R874 R875 R876 R877 R879 RV210 RV220 RV805 SK200 SK205 SK310 SK410 SK501SK502SK503SK504SK505 SK513 SK522 SK531SK532SK533SK534SK535 SK805 SK810 SL810 SW230 T210 T610 T857 T85710T85713T85715 T85720T85723T85725 T857XT857_ THOLE TOPFIDA TOPFIDB TP206 TP305 TP601 TP602 TP603 TP604 TP607 TP710 TP715 TSLOT The darker shading shows the outline of the chassis. IC810 %R150 (10 Ω ) is fitted only when the T857 is used in a Series I rack frame (refer to Part I for full details). L314 is fitted only when cyclic keying is required. IPN 220-01398-04C6.3.44 T857 PCB Information M850-00 21/06/99 Copyright TEL T857 PCB Layout - Bottom Side 220-01398-04 Q305 EC DB K A P L M N JHGF 12345678 BHOLE BOTFIDA BOTFIDB BSLOT LINK1 LINK2 Q305 SL201SL202SL203SL204 SL501 The darker shading shows the footprint of the bottom cover. IPN 220-01398-04 M850-00 T857 PCB Information C6.3.45 Copyri…

Text truncated - open the document above for the full version.

FCC ID: CASTEL0033 TELTEST REPORT 1516 T859-10-0501 BASE STATION S/N 245861 Page 1 of 42 REPORT NUMBER 1516Jan 2000 RADIO PERFORMANCE MEASUREMENTS On the T859-10-0501 Base Station Transmitter FCC ID: CASTEL0033 SN o 245861 in accordance with FCC 47 CFR Parts 22 and 90 PREPARED BY:Rob Weeks_____________________ Test Technician CHECKED & APPROVED BY:S.A. Crompton_____________________ Laboratory Manager TELTEST Laboratories Tait Electronics Limited PO Box 1645 558 Wairakei Road Christchurch 5 New Zealand Phone: +64 3 358 3399 Fax: +64 3 358 0432 FCC ID: CASTEL0033 TELTEST REPORT 1516 T859-10-0501 BASE STATION S/N 245861 Page 2 of 42 TABLE OF CONTENTS TESTPAGE TRANSMITTER OUTPUT POWER (CONDUCTED)3 AUDIO FREQUENCY FILTER4 TRANSMITTER AUDIO FREQUENCY RESPONSE6 MODULATION LIMITING8 MODULATION LIMITING (STEADY STATE)11 MODULATION LIMITING (INSTANTANEOUS)13 OCCUPIED BANDWIDTH15 SPURIOUS EMISSIONS (CONDUCTED)18 SPURIOUS EMISSIONS (RADIATED)23 TRANSMITTER FREQUENCY STABILITY (TEMPERATURE)28 TRANSMITTER FREQUENCY STABILITY (VOLTAGE)30 TRANSIENT FREQUENCY BEHAVIOUR31 LIST OF TEST EQUIPMENT40 FCC ID: CASTEL0033 TELTEST REPORT 1516 T859-10-0501 BASE STATION S/N 245861 Page 3 of 42 NAME OF TEST:TRANSMITTER OUTPUT POWER (CONDUCTED) TEST CONDITIONS:Ambient temperature 19 o C Relative humidity65 % Standard Voltage120VAC SPECIFICATION:FCC 47 CFR 2.1046 GUIDE:TIA/EIA-603 2.2.1 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was set up as shown on the following diagram. 2. The coaxial attenuator used has an impedance of 50Ω. 3. The unmodulated output power was measured by means of an RF Power meter. MEASUREMENT RESULTS: Manufacturers rated output power:Continuously variable 20W to 100W 421.1MHz100W nominal20W nominal Power (W)107.621.53 Variation from nom (%)+7.60+7.65 Measurement uncertainty (dB) +0.63 -0.68 LIMIT CLAUSE:FCC 47 CFR 90.205 Radio Type: Base Station Frequency Band: 400MHz - 440MHz (n)The output power shall not exceed by more than 20% the manufacturers rated output power for the particular transmitter. TEST SETUP:See page 40 for test equipment information. EUT AC CABLE POWER SENSOR ATTENLOAD POWER METER 15 16 86 73 60 FCC ID: CASTEL0033 TELTEST REPORT 1516 T859-10-0501 BASE STATION S/N 245861 Page 4 of 42 NAME OF TEST:AUDIO FREQUENCY FILTER RESPONSE TEST CONDITIONS:Ambient temperature 21 o C Relative humidity70 % Standard Voltage120VAC SPECIFICATION:FCC 47 CFR 2.1047 (a) GUIDE:TIA/EIA-603 2.2.15 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was set up as shown on the following diagram. 2. The EUT was set up in such a way that the audio input and audio output were connected directly to the audio low pass filter circuitry. 3. A tone of 1000 Hz was set as a reference. 4. The AF applied to the filter was varied, with the level held constant. The filter response in dB was plotted. MEASUREMENT RESULTS: See the plot on following page. LIMIT CLAUSE:FCC 47 CFR 90.211 (a) “Transmitters utilizing analog emissions that are equipped with an audio low-pass filter must meet the emission limitations specified in Part 90.210.” TEST SETUP USED:See page 40 for test equipment information. LOAD SCOPE AF GEN AUDIO ANAL 22 70 EUT AC 87 87 FCC ID: CASTEL0033 TELTEST REPORT 1516 T859-10-0501 BASE STATION S/N 245861 Page 5 of 42 NAME OF TEST:AUDIO FREQUENCY FILTER RESPONSE SPECIFICATION:FCC 47 CFR 2.1047 (a) -60.00 -50.00 -40.00 -30.00 -20.00 -10.00 0.00 10.00 100100010000100000 Freq Hz Response dB ResponseLimit CASTEL 0033 24-Jan-00 LOW PASS FILTER RESPONSE FCC ID: CASTEL0033 TELTEST REPORT 1516 T859-10-0501 BASE STATION S/N 245861 Page 6 of 42 NAME OF TEST:TRANSMITTER AUDIO FREQUENCY RESPONSE PRE-EMPHASIS TEST CONDITIONS:Ambient temperature 19.5 o C Relative humidity70 % Standard Voltage120VAC SPECIFICATION:FCC 47 CFR 2.1047 (a) GUIDE:TIA/EIA-603 2.2.6 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was set up as shown on the following diagram. 2. An audio input tone of 1000Hz was applied, the level set to obtain 20% max deviation. This was used as the 0dB reference point. 3. With the input level held constant, the AF frequency was varied. 4. The response in dB relative to 1000Hz was measured. MEASUREMENT RESULTS: See the plots on following page for both 12.5KHz and 25KHz channel separation. LIMIT CLAUSE:TIA/EIA-603 4.2.6 TEST SETUP:See page 40 for test equipment information. AF GEN EUTCABLEATTEN MOD ANAL 13 11 8338 AC FCC ID: CASTEL0033 TELTEST REPORT 1516 T859-10-0501 BASE STATION S/N 245861 Page 7 of 42 NAME OF TEST:TRANSMITTER AUDIO FREQUENCY RESPONSE PRE-EMPHASIS SPECIFICATION:FCC 47 CFR 2.1047 (a) TRANSMITTER PRE-EMPHASIS -35 -30 -25 -20 -15 -10 -5 0 5 10 15 100100010000 Freq Hz Response dB AF Response dBupper limitlower limit CASTEL0033 17-Jan-00 12.5KHz Channel Spacing TX Freq 421.1MHz TRANSMITTER PRE-EMPHASIS -35 -30 -25 -20 -15 -10 -5 0 5 10 15 100100010000 Freq Hz Response dB AF Response dBupper limitlower limit CASTEL0033 17-Jan-00 25KHz Channel Spacing TX Freq 421.1 MHz FCC ID: CASTEL0033 TELTEST REPORT 1516 T859-10-0501 BASE STATION S/N 245861 Page 8 of 42 NAME OF TEST:TRANSMITTER MODULATION LIMITING TEST CONDITIONS:Ambient temperature 19.5 o C Relative humidity70 % Standard Voltage120VAC SPECIFICATION:FCC 47 CFR 2.1047 (b) GUIDE:TIA/EIA-603 2.2.3 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was set up as shown on the following diagram. 2. The modulation response was measured at three audio frequencies, varying the input level. 3. Measurements were made for both positive and negative deviation. MEASUREMENT RESULTS: See the plots on following pages for both 12.5KHz and 25KHz channel spacing. LIMIT CLAUSE:FCC 47 CFR 90.211(a) TEST SETUP:See page 40 for test equipment information. AF GEN EUTCABLEATTEN MOD ANAL 13 11 8338 AC FCC ID: CASTEL0033 TELTEST REPORT 1516 T859-10-0501 BASE STATION S/N 245861 Page 9 of 42 NAME OF TEST:TRANSMITTER MODULATION LIMITING SPECIFICATION:FCC 47 CFR 2.1047 (b) MODULATION LIMITING (Positive Deviation) 0 1 2 3 -90-80-70-60-50-40-30-20-10 0…
