CASTEL0046Base Station Transmitter

TELTEST Laboratories Tait Electronics Ltd PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone:(64) (3) 3583399 Fax:(64) (3) 3580432 September 2000 To whom it may concern T836-26-0000 This equipment meets the requirements of the FCC Rules, Part 90.203(e) and (g), as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment’s external operation controls. Regards Garry Pringle Compliance Laboratory Technician

TELTEST Laboratories Tait Electronics Ltd PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone:(64) (3) 3583399 Fax:(64) (3) 3580432 26 September 2000 To whom it may concern T836-26-0000 CONFIDENTIALITY REQUEST Reference rule sections 0.457 (d) (ii) and pursuant to rule section 0.459 (a) confidentiality is requested as follows: Specific Information: Schematics The schematics contain trade secret information which is not made routinely available to the public or to our competitors. Disclosure of this information could result in an unfair advantage to our competitors. It should be treated as confidential for the duration of effectiveness of the Grant Of Authorisation. Regards Garry Pringle Compliance Laboratory Technician

M830-001 Copyright TEL23/07/99 T830 Series II Base Station Equipment 136-174MHz Service Manual Issue 201 August 1999 M830-00-201 2M830-00 23/07/99Copyright TEL Head Office New Zealand Tait Electronics Ltd 558 Wairakei Road P.O. Box 1645 Christchurch New Zealand Phone: 64 3 358-3399 Fax: 64 3 358-3636 Radio Systems Division 535 Wairakei Road P.O. Box 1645 Christchurch New Zealand Phone: 64 3 358-3399 Fax: 64 3 358-2825 Australia Tait Electronics (Aust) Pty Ltd 186 Granite Street Geebung Queensland 4034 P. O . B o x 6 7 9 Virginia Queensland 4014 Australia Phone: 61 7 3865-7799 Toll Free: 1800 077-112 Fax: 61 7 3865-7990 Beijing Tait Mobile Radio (HK) Ltd Beijing Representative Office Room 812, Tower A Beijing Bright China Chang An Building No. 7 Jianguomennei Dai Jei Dongcheng District Beijing China 100005 Canada Tait Mobile Radio Inc. Unit 5, 158 Anderson Avenue Markham Ontario L6E1A9 Canada Phone: 1 905 472-1100 Toll Free: 1 800 890-8248 Fax: 1 905 472-5300 France Ta i t F r a n c e S a r l 2 Avenue de la Cristallerie 92 316 Sèvres, Cedex France Phone: 33 1 41 14-05-50 Fax: 33 1 41 14-05-55 Germany Tait Mobilfunk GmbH Willstätterstraße 50 D-90449 Nürnberg 60 Germany Phone: 49 911 96 746-0 Fax: 49 911 96 746-79 Hong Kong Tait Mobile Radio (HK) Ltd Unit 2216, North Tower Concordia Plaza 1, Science Museum Road Tsim Sha Tsui East Kowloon Phone: 852 2369-3040 Fax: 852 2369-3009 New Zealand Tait Communications Ltd Unit 4, 75 Blenheim Road P. O . B o x 1 1 8 5 Christchurch Phone: 64 3 348-3301 Fax: 64 3 343-0558 Singapore Tait Electronics (Far East) Pte Ltd 4 Leng Kee Road SIS Building #05-11A Singapore 159088 Phone: 65 471-2688 Fax: 65 479-7778 Ta i w a n Tait Mobile (Taiwan) Ltd 1104, No. 142 Chung Hsiao E. Rd Sec. 4 Ta i p e i Ta i w a n Phone: 886 2 2731-1290 Fax: 886 2 2711-6351 Thailand Tait Mobile Radio Ltd 14/1 Suwan Tower Third Floor Soi Saladaeng 1 North Sathorn Road Bangrak Bangkok 10500 Thailand Phone: 662 267-6290 Fax: 662 267-6293 United Kingdom Tait Europe Ltd Ermine Business Park Ermine Road Huntingdon Cambridgeshire PE18 6YA United Kingdom Phone: 44 1480-52255 Fax: 44 1480-411996 USA Tait Electronics (USA) Inc. 9434 Old Katy Road Suite 110 Houston Texas 77055 USA Phone: 1 713 984-8684 Toll Free: 1 800 222-1255 Fax: 1 713 468-6944 Internet http://www.taitworld.com T800 T800 M830-003 Copyright TEL23/07/99 About This Manual ScopeThis manual contains general, technical and servicing informa- tion on T830 Series II 25W, 50W and 100W base stations which comprise the following equipment: FormatWe have published this manual in a ring binder so that "revision packages" containing additional information pertaining to new issues of PCBs can be added as required. Revision PackagesRevision packages will normally be published to coincide with the release of information on a new PCB, and may also contain additions or corrections pertaining to other parts of the manual. You may order as many packages as you require from your local Tait Dealer or Customer Service Organisation. Revision pack- ages are supplied ready-punched for inclusion in your manual. Revision ControlEach page in this manual has a date of issue. This is to comply with various Quality Standards, but will also serve to identify which pages have been updated and when. Each page and its publication date is listed in the "List of Effective Pages", and a new list containing any new/revised pages and their publica- tion dates will be sent with each revision package. Any portion of text that has been changed is marked by a verti- cal line (as shown at left) in the outer margin of the page or col- umn. Where the removal of an entire paragraph means there is no text left to mark, an arrow (as shown at left) will appear in the outer margin. The number beside the arrow will indicate how many paragraphs have been deleted. Changes to diagrams that cannot be marked by these methods will be explained in an Amendments Box added to the diagram. The manual issue and revision status are indicated by the last three digits of the manual product code. These digits start at 200 and will increment through 201, 202, 203, etc., as revision pack- ages are published, e.g: 25W base stationT835 receiver T836 25W transmitter 50W base stationT835 receiver T837 exciter T838 50W power amplifier 100W base stationT835 receiver T837 exciter T839 100W power amplifier 2 2 0 3 issue statusrevision status 4M830-00 23/07/99Copyright TEL Thus, issue 203 indicates the third revision to issue 2 and means that three packages should have been added to the manual. The issue digit will only change if there is a major product revision, or if the number of revision packages to be included means that the manual becomes difficult to use, at which point a new issue manual will be published in a new ring binder. PCB InformationPCB information is provided for all current issue PCBs, as well as all previous issue PCBs manufactured in production quanti- ties, and is grouped according to PCB. Thus, you will find the parts list, grid reference index (if necessary), PCB layouts and circuit diagram(s) for each individual PCB grouped together. ErrorsIf you find an error in this manual, or have a suggestion on how it might be improved, please do not hesitate to contact Customer Support, Radio Systems Division, Tait Electronics Ltd, Christch- urch, New Zealand (full contact details are on page 2). Updating Equipment And Manuals In the interests of improving performance, reliability or servicing, Tait Electronics Ltd reserve the right to update their equipment and/or manuals without prior notice. Copyright All information contained in this manual is the property of Tait Electronics Ltd. All rights are reserved. This manual may not, in whole or part, be copied, photocopied, reproduced, translated stored or reduced to any electronic medium or machine readable form without prior written permission from Tait Electronics Ltd. Ordering Tait Service Manuals You can order additional copies of this s…

Text truncated - open the document above for the full version.

FCC ID: CASTEL0046 TELTEST REPORT: 1558 T836-26-0000 BASE STATIO N S/N: 731656 Page 1 of 43 REPORT NUMBER 1558SEPTEMBER 2000 RADIO PERFORMANCE MEASUREMENTS On the T836-26-0000 Base Station Transmitter FCC ID: CASTEL0046 SN: 731656 In accordance with FCC 47 CFR Parts 22 and 90 PREPARED BY:Garry Pringle ___________________ Test Technician CHECKED & APPROVED BY:SA Crompton ___________________ Laboratory Manager TELTEST LABORATORIES Tait Electronics Ltd PO Box 1645 558 Wairakei Road Christchurch 8005 New Zealand Phone:+64-3-3583399 Fax:+64-3-3580432 FCC ID: CASTEL0046 TELTEST REPORT: 1558 T836-26-0000 BASE STATIO N S/N: 731656 Page 2 of 43 TABLE OF CONTENTS TESTPAGE TRANSMITTER OUTPUT POWER (CONDUCTED) 3 AUDIO FREQUENCY FILTER 4 TRANSMITTER AUDIO FREQUENCY RESPONSE 5 MODULATION LIMITING 7 MODULATION LIMITING (STEADY STATE) 10 MODULATION LIMITING (INSTANTANEOUS) 12 OCCUPIED BANDWIDTH 14 SPURIOUS EMISSIONS (CONDUCTED) 19 SPURIOUS EMISSIONS (RADIATED) 24 TRANSMITTER FREQUENCY STABILITY ( TEMPERATURE) 29 TRANSMITTER FREQUENCY STABILITY (VOLTAGE) 31 TRANSIENT FREQUENCY BEHAVIOUR 32 LIST OF TEST EQUIPMENT 41 FCC ID: CASTEL0046 TELTEST REPORT: 1558 T836-26-0000 BASE STATIO N S/N: 731656 Page 3 of 43 NAME OF TEST:TRANSMITTER O UTPUT POWER (CO NDUCTED) TEST CO NDITIONS:Ambient Temperat ure17 o C Relative Humidity45% Standard Voltage120V AC SPECIFICATION:FCC 47 CFR 2.1046 GUIDE:TIA/EIA-603 2.2.1 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was set up as shown on the following diagram. 2. The coaxial attenuator has an impedance of 50 Ohms. 3. The unmodulated output power was measured with an RF Power meter. MEASUREMENT RESULTS: Manufacturer’s Rated Output Power:Continuously Variable 5 W to 25 W 161.0025 MHz25 W nominal5 W nominal POWER (W)24.744.83 Variation from Nominal (%)-1.04- 3.4 Measurement Uncertainty (dB) +0.63 -0.68 LIMIT CLAUSE:FCC 47 CFR 90.205 Radio Type:Base Station Frequency Band:150MHz ~ 174MHz (n) The output power shall not exceed by more than 20% the manufacturer’s rated output power for the particular transmitter. TEST SETUP:See page 41 for Test Equipment information. EUT AC CABLE POWER SENSOR ATTENLOAD POWER METER 15 70 16 8662, 66 FCC ID: CASTEL0046 TELTEST REPORT: 1558 T836-26-0000 BASE STATIO N S/N: 731656 Page 4 of 43 NAME OF TEST:AUDIO FREQ UENCY FILTER RESPO NSE TEST CO NDITIONS:Ambient Temperat ure o C Relative Humidity% Standard Voltage120V AC SPECIFICATION:FCC 47 CFR 2.1047 GUIDE:TIA/EIA-603 2.2.15 MEASUREMENT PROCEDURE: This test was not carried out as the EUT meets the emission limits specified in §90.210. MEASUREMENT RESULTS: See Occupied Bandwidth tests on page 14. LIMIT CLAUSE:FCC 47 CFR 90.211 (a) (a) Transmitters utilizing analog emissions that are equipped with an audio low-pass filter must meet the emission limitations specified in §90.210.... TEST SETUP:See page 14 – Occupied Bandwidth FCC ID: CASTEL0046 TELTEST REPORT: 1558 T836-26-0000 BASE STATIO N S/N: 731656 Page 5 of 43 NAME OF TEST:TRANSMITTER AUDIO FREQ UENCY RESPO NSE PRE-EMPHASIS TEST CO NDITIONS:Ambient Temperat ure17 o C Relative Humidity45% Standard Voltage120V AC SPECIFICATION:FCC 47 CFR 2.1047 (a) GUIDE:TIA/EIA-603 2.2.6 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was set up as shown on the following diagram. 2. An audio input tone of 1000Hz was applied with the level set to obtain 20% of maximum deviation. This was used as the 0dB reference point. 3. The AF was varied while the audio level was held constant. 4. The response in dB relative to 1000Hz was measured. MEASUREMENT RESULTS:See the plot on the following page. LIMIT CLAUSE:TIA/EIA-603 2.2.6 TEST SETUP:See page 41 for Test Equipment information. AF GEN EUTCABLEATTEN MOD ANAL 13 11 8338 AC FCC ID: CASTEL0046 TELTEST REPORT: 1558 T836-26-0000 BASE STATIO N S/N: 731656 Page 6 of 43 NAME OF TEST:TRANSMITTER AUDIO FREQ UENCY RESPO NSE PRE-EMPHASIS SPECIFICATION:FCC CFR 2.1047 (a) Tx FREQUENCY:161.0025 MHz TRANSMITTER PRE-EMPHASIS -35 -30 -25 -20 -15 -10 -5 0 5 10 15 100100010000 Freq Hz Response dB AF Response dBupper limitlower limit CASTEL0046 12-Sep-00 12.5KHz Channel Spacing TX Freq 161.0025MHz TRANSMITTER PRE-EMPHASIS -35 -30 -25 -20 -15 -10 -5 0 5 10 15 100100010000 Freq Hz Response dB AF Response dBupper limitlower limit CASTEL0046 13-S ep-00 25K Hz Channel S pacing TX Freq 161.0025 MHz FCC ID: CASTEL0046 TELTEST REPORT: 1558 T836-26-0000 BASE STATIO N S/N: 731656 Page 7 of 43 NAME OF TEST:TRANSMITTER MODULATION LIMITING TEST CO NDITIONS:Ambient Temperat ure20 o C Relative Humidity50% Standard Voltage120V AC SPECIFICATION:FCC 47 CFR 2.1047 (b) GUIDE:TIA/EIA-603 2.2.3 MEASUREMENT PROCEDURE: 1. The EUT was set up as shown on the following diagram. 2. The modulation response was measured at three audio frequencies while varying the input level. 3. Measurements were made for both Positive and Negative Deviation. MEASUREMENT RESULTS: See the plot on the following pages for 12.5 kHz and 25.0 kHz channel spacing.. LIMIT CLAUSE:FCC 47 CFR 90.211 (a) TEST SETUP:See page 41 for Test Equipment information. AF GEN EUTCABLEATTEN MOD ANAL 13 11 8338 AC FCC ID: CASTEL0046 TELTEST REPORT: 1558 T836-26-0000 BASE STATIO N S/N: 731656 Page 8 of 43 NAME OF TEST:TRANSMITTER MODULATION LIMITING SPECIFICATION:FCC CFR 2.1047 (b) Tx FREQUENCY:161.0025 MHz MODULATION LIMITING (Positive Deviation) 0 1 2 3 -90-80-70-60-50-40-30-20-10010 Input Level dBm Deviation KHz 300 Hz1000 Hz2000 HzLimit CASTEL0046 14-S ep-00 12.5KHz Channel Spacing Tx Freq 161.0025 MHz MODULATION LIMITING (Negative Deviation) 0 1 2 3 -90-80-70-60-50-40-30-20-10010 Input Level dBm Deviation KHz 300 Hz1000 Hz2000 HzLimit CASTEL0046 14-Sep-00 12.5kHz Channel Spacing Tx Freq 161.0025 MHz FCC ID: CASTEL0046 TELTEST REPORT: 1558 T836-26-0000 BASE STATIO N S/N: 731656 Page 9 of 43 NAME OF TEST:TRANSMITTER MODULATION LIMITING SPECIFICATION:FCC CFR 2.1047 (b) Tx FREQUENCY:161.0025 MHz MODULATION LIMITING (Positive Deviation) 0 1 2 3 4 5 6 -90-80-70-60-50-40-30-20-10010 Input Level …
