CASTEL0047One way paging transmitters T836-26-1010 & T836-26

M830-00 T836/837 General Information C1.3 Copyright TEL 30/04/98 The photograph in Figure 1.1 on the next page will help you to identify the maincircuit blocks in the T836.There is a similar photograph in Figure 4.4 which shows the main tuning and adjustment controls.Extending both these fold-outs willallow you to refer to both photographswhile using the manual.The photograph in Figure 1.2 on the next page shows the T836 front panel con-trols. C1.4 T836/837 General Information M830-00 30/04/98 Copyright TEL Figure 1.1 T836 Main Circuit Block Identification Figure 1.2 T836 Front Panel Controls 1 234 5 6 78 A B C 9 10 Key: 1 2 3 4 5 6 7 low pass filter PA exciter drive amplifier audio processor VCO regulators synthesiser 8 9 10 A B C microcontroller and CTCSS duct for cabling to extra D-range (if fitted) D-range RF output D-range connector (“D-range 1”) incl. audio in & DC in (refer to Section 2.2 in Part F) microcontroller On LEDThe On LED is lit when theT836 is transmitting. Carrier SwitchKeys the transmitter (whiledisabling the 600 Ω line and microphone audio). Supply LEDThe Supply LED is lit whenDC power is supplied to thetransmitter. Line SensitivitySets the gain of the 600 Ω line input of the audio processor. Microphone SocketFor connecting a T800-80 micro-phone to allow local control ofthe transmitter. The 600 Ω line is disabled when the PTT button ispressed. M830-00 T836/837 General Information C1.5 Copyright TEL 30/04/98 The photograph in Figure 1.3 on the next page will help you to identify the maincircuit blocks in the T837.There is a similar photograph in Figure 4.5 which shows the main tuning and adjustment controls.Extending both these fold-outs willallow you to refer to both photographswhile using the manual.The photograph in Figure 1.4 on the next page shows the T837 front panel con-trols. C1.6 T836/837 General Information M830-00 30/04/98 Copyright TEL Figure 1.3 T837 Main Circuit Block Identification Figure 1.4 T837 Front Panel Controls 1 23 4 5 6 8 9 A B C 7 Key: 1 2 3 4 5 6 7 low pass filter exciter drive amplifier audio processor VCO regulators synthesiser microcontroller and CTCSS 8 9 A B C duct for cabling to extra D-range (if fitted) D-range RF output D-range connector (“D-range 1”) incl. audio in & DC in (refer to Section 2.2 in Part F) microcontroller On LEDThe On LED is lit when theT837 is transmitting. Carrier SwitchKeys the exciter (whiledisabling the 600 Ω line and microphone audio). Supply LEDThe Supply LED is lit whenDC power is supplied to theexciter. Line SensitivitySets the gain of the 600 Ω line input of the audio processor. Microphone SocketFor connecting a T800-80 micro-phone to allow local control ofthe exciter. The 600 Ω line is dis- abled when the PTT button ispressed. M830-00 T836/837 Functional Testing C4.9 Copyright TEL 30/04/98 Figure 4.4 T836 Main Tuning & Adjustment Controls R460CV451CV1PL4-1RV330 high temperature RV320 power adjust RV210 line sensitivity SW230 carrier IC700 TCXO L490 power adjust RV310 temperature adjust RV220 compression level RV805 CTCSS level adjust PL205 PL220 PL215 PL210 SK805 The photograph printed at rightwill help you to identify the maincontrols used in tuning and adjust-ing the T836.There is a similar photograph inFigure 1.1 which shows the main circuit blocks.Extending both these fold-outs willallow you to refer to both photo-graphs while using the manual.

M830-00 T836/837 Installation F2.1 Copyright TEL 23/07/99 2 T836/837 Installation 2.1 Rack Mounting The T836 transmitter and T837 exciter are designed for use in a standard 483mm rackframe using a Tait T800 Series II guide. The guide is securely mounted to the rack framewith front and rear retaining screws, and the T836/837 is secured into the guide withtwo front panel mounting screws. Figure 2.1 shows a standard, double module guide which can also be fitted with an optional backplane PCB to locate and mate the rearD-range connector(s). For more information on available guide kits, refer to the T800Ancillary Equipment Service Manual or your nearest Tait Dealer or Customer ServiceOrganisation. A rear mounted N-type connector is used for RF output on the T836/837, while all DC,audio and control connections are via the rear mounted D-range connector, D-range 1(PL100). An additional rear D-range connector (T800-03-0000) can be fitted whenremote multichannel operation, or additional control or low frequency lines arerequired (refer to Figure 2.2 ). 2.2 Rack Wiring The D-range input and output connections are shown in Figure 2.3 and Figure 2.4 . Ensure that the cables are not subjected to any stresses due to tight bends or incorrectlengths.Make sure the RF coax cable to the N-type connector is free from sharp bends or twists.If access to the rear of the rack frame is restricted, the cable should be long enough toallow the chassis to be fully withdrawn from the guide. Figure 2.3 T836/837 D-Range 1 Wiring - Rear View Figure 2.4 T836/837 D-Range 2 Wiring - Rear View (standard T800-03-0000 kit) Note: Figure 2.4 above shows the standard pin allocations for the T800-03-0000 auxiliary D-range kit. A T800-03 auxiliary D-range kit is also available forspecial applications requiring custom internal wiring. Front PanelMounting Holes Rack Mounting Holes Rack Mounting Holes Rack Mounting Holes Slots For D-RangeConnectors Rack Mounting Holes Aperture For RFConnectors Optional Backplane PCBMounts On Rear Of Guide N-Type Connector D-Range Plug(D-Range 1) Space For OptionalD-Range Plug(D-Range 2) Front Panel Mounting Hole Figure 2.2 T836/837 Chassis Connectors Figure 2.1 T800-41-0002 Double Guide Kit

1 23 45 6 7 8 9 10 11 12 1314 15 External CTCSS input:1kHz deviation @150Hz (500mV rms) To key transmitter:high impedance<0.7V = key High isolationkeying option:6 to 50V DC To key PA, opencollector Can be configured asAudio 1 by internallink resistors if required Short together fornormal operation Sensitivity: -30dBm External/auxiliaryaudio processing Power supply, -ve earth 10.8 to 16V DC Line I/P1CTCSSSerial ComAudio 2Tx EnableLine I/P4Line I/P3Line I/P2 Opto Key + Opto Key - +13.8V Gnd Tx Key Can be configured as Audio 1 by internal link resistors if required.Refer to Part I. Open drain type;capable of sinking2.25mA via 2k2 Ω ; V max. = 5V ds 1 23 45 6 7 8 9 10 11 12 1314 15 CH_SLCT 0 CH_SLCT 1 CH_SLCT 2CH_SLCT 3CH_SLCT 4CH_SLCT 5CH_SLCT 6 CH_SLCT 7 GND TX RELAY DRV CTCSS DISABLE SERIAL COM AUX-OUT 0AUX-OUT 1AUX-OUT 2 F2.2 T836/837 Installation M830-00 23/07/99 Copyright TEL 2.3 Power Supply If a power supply other than an appropriate Tait model is used, ensure that it is capableof providing enough current to drive the T800 system and is also free from excessiveripple or noise.The system should be protected by the use of appropriately rated fuses in the powersupply.Note: It is particularly important when the prime power source is a battery thatfuses be employed in all supply lines. 2.4 Reverse Polarity Protection A crowbar diode is fitted to all T836 transmitters and T837 exciters for protectionagainst connection to a power supply of incorrect polarity. It also provides overvoltageprotection from voltage transients caused by lightning strikes.Note: A fuse must be fitted in the power supply line for the diode to provide effec-tive protection.

M830-00CI Copyright TEL30/04/98 Part CT836 Transmitter & T837 Exciter This part of the manual is divided into six sections, as listed below. There is a detailed table of contents at the start of each section. SectionTitle 1General Information 2Circuit Operation 3Initial Tuning & Adjustment 4Functional Testing 5Fault Finding 6PCB Information CIIM830-00 30/04/98Copyright TEL M830-00T836/837 General InformationC1.1 Copyright TEL30/04/98 1T836/837 General Information This section provides a brief description of the T836 transmitter and T837 exciter, along with detailed specifications and a list of types available. The following topics are covered in this section. SectionTitlePage 1.1Introduction1.7 1.2 1.2.1 1.2.2 1.2.3 1.2.4 1.2.4.1 1.2.4.2 1.2.4.3 1.2.5 1.2.6 Specifications Introduction General RF Section Audio Processor Inputs Modulation Characteristics CTCSS Microcontroller Test Standards 1.8 1.8 1.8 1.9 1.10 1.10 1.10 1.11 1.12 1.12 1.3Product Codes1.13 1.4T836 Standard Product Range1.14 1.5T837 Standard Product Range1.15 FigureTitlePage 1.1T836 Main Circuit Block Identification1.4 1.2T836 Front Panel Controls1.4 1.3T837 Main Circuit Block Identification1.6 1.4T837 Front Panel Controls1.6 C1.2T836/837 General InformationM830-00 30/04/98Copyright TEL M830-00T836/837 General InformationC1.3 Copyright TEL30/04/98 replace A4 pages C1.3/C1.4 with A3 pages C1.3/C1.4 C1.4T836/837 General InformationM830-00 30/04/98Copyright TEL replace A4 pages C1.3/C1.4 with A3 pages C1.3/C1.4 M830-00T836/837 General InformationC1.5 Copyright TEL30/04/98 replace A4 pages C1.5/C1.6 with A3 pages C1.5/C1.6 C1.6T836/837 General InformationM830-00 30/04/98Copyright TEL replace A4 pages C1.5/C1.6 with A3 pages C1.5/C1.6 M830-00T836/837 General InformationC1.7 Copyright TEL23/07/99 1.1Introduction The T836 is a synthesised, microprocessor controlled FM base station transmitter designed for single or multichannel operation in the 136 to 174MHz frequency range 1 with a standard power output of 25W. The RF section of the transmitter comprises a fre- quency synthesiser which provides 170mW of frequency modulated RF drive to a two stage, wide band output driver followed by a 25W power amplifier. A thermal shut- down feature is provided in the T836 in case operating temperatures exceed acceptable levels. The T837 is a synthesised, microprocessor controlled FM base station exciter designed for single or multichannel operation in the 136 to 174MHz frequency range 1 . With a standard power output of only 800mW, the exciter is designed for use with the T838 50W or T839 100W power amplifiers. The RF section of the exciter comprises a fre- quency synthesiser which provides 170mW of frequency modulated RF drive to a two stage, wide band output amplifier. A wide selection of audio characteristics may be obtained from the audio processor. Optional circuit blocks are an audio compressor and a pre-emphasis stage. They can be bypassed or linked to one or both audio inputs, and then back into the remaining audio circuitry in almost any combination. All audio processor options are link selectable. The synthesiser frequency is programmed via the serial communications port. Eight channel select lines are accessible via an optional D-range connector (D-range 2 - T800-03-0000) at the rear of the set. All components except those of the VCO are mounted on a single PCB. This is secured to a die-cast chassis which is divided into compartments to individually shield each sec- tion of circuitry. Access to both sides of the main circuit board is obtained by removing each of the chassis lids. There is provision within the chassis to mount small option PCBs. The front panel controls include line sensitivity, microphone socket and carrier switch. This switch turns on the carrier (unmodulated) as an aid to servicing. The T836 and T837 are both 60mm wide and each occupies a single space in a Tait rack frame, which has the ability to accommodate up to seven standard modules. 1. Although capable of operating over the 136-174MHz frequency range, the T836 and T837 have an 8MHz switching range (see Section 1.2.3 and Section 3.1). C1.8T836/837 General InformationM830-00 23/07/99Copyright TEL 1.2Specifications 1.2.1Introduction The performance figures given are minimum figures, unless otherwise indicated, for equipment tuned with the maximum switching range and operating at standard room temperature (+22°C to +28°C) and standard test voltage (13.8V DC). Where applicable, the test methods used to obtain the following performance figures are those described in the EIA and ETS specifications. However, there are several parame- ters for which performance according to the CEPT specification is given. Refer to Sec- tion 1.2.6 for details of test standards. Details of test methods and the conditions which apply for Type Approval testing in all countries can be obtained from Tait Electronics Ltd. The terms "wide bandwidth", "mid bandwidth" and "narrow bandwidth" used in this and following sections are defined in the following table. 1.2.2General Number Of Channels.. 128 (standard) 1 Supply Voltage: Operating Voltage .. 10.8 to 16V DC Standard Test Voltage .. 13.8V DC Polarity .. negative earth only Polarity Protection .. crowbar diode Line Keying Supply (if required) .. -50V DC Supply Current: Transmit- T836.. 4.5A (typical) - T837.. 600mA Standby .. 150mA (typical) Operating Temperature Range .. -30°C to +60°C Channel Spacing Modulation 100% Deviation Receiver IF Bandwidth Wide Bandwidth25kHz±5.0kHz15.0kHz Mid Bandwidth20kHz±4.0kHz12.0kHz Narrow Bandwidth12.5kHz±2.5kHz7.5kHz 1. Additional channels may be factory programmed. Contact your nearest Tait Dealer or Customer Service Organisation. M830-00T836/837 General InformationC1.9 Copyright TEL23/07/99 Dimensions: Height .. 183mm Width .. 60mm Length .. 320mm Weight .. 2.1kg Time-Out Timer (optional) .. 0 to 5 minutes 1 adjustable in 10 sec- ond steps Tail Timer .. 0 to 5 seconds adjustable in 100ms 2 steps Transmit…

Text truncated - open the document above for the full version.

-----Original Message----- From: Frank Coperich <[email protected]> To: [email protected] <[email protected]> Date: Wednesday, August 09, 2000 11:07 AM Subject: Re: VHF & UHF Transmitter Question Yes, you may do this. The Grant of Certification will show the normal frequency stability for the internal reference on the specifications line entry. A comment on the bottom of the Grant will indicate that a high stability option is available. The basic transmitter (FCC ID) will be officially recognized as having the basic (internal reference) stability capability. >>> "Joanne Backes" <[email protected]> 08/08/00 04:14PM >>> Dear Frank: We have a series of VHF and UHF Transmitters. There are two versions of each transmitter. Version 1 uses an internal frequency reference, and Version 2 uses a high stability external reference. Can we family list both versions under the same FCC ID? Both versions are identical, except for the frequency reference. Thank you in advance for your prompt reply. Regards, Joanne Backes KTL Ottawa

1Paging Exciter/Transmitter Description 1 Letter stating the differences between T836-26- 1010 with family listing of T836-26-1012 1.1 T836-26-1010 The T836-26-1010 is Tait transmitter which has been modified by adding a T800-32-0000 DFSK modulator board. The transmitter, without the modulator board, is described as: • Narrowband with a wide-band audio filter • 148 – 174 MHz operating bandwidth • 2.5ppm stability from –30 ° C -- +60 ° C The T800-32-0000 contains an internal oscillator. 1.2 T836-26-1012 The T836-26-1010 is Tait transmitter which has been modified by adding a T800-32-0100 DFSK modulator board. The transmitter, without the modulator board, is described as: • Narrowband with a wide-band audio filter • 148 – 174 MHz operating bandwidth • 2.5ppm stability from –30 ° C -- +60 ° C The T800-32-0100 DFSK modulator board uses an external reference via a connector on the back of the exciter.

⇓ 35.00mm ⇓ ⇐ 0885 FCCID: CASTEL0047 CANADA: xxxxxxxxxx 46.00mm T836-26-1010 Rev 1 706471 Ta it Ele c tro nic s Limite d Made in New Zealand ⇐ Tait Electronics Ltd DRAWNCHKDAPVDDATETait Ele ctronics Ltd Dime ns io ns in mm unle s s otherwise stated. Scale: NTS LMG 1 ORIGINAL 12/09 ISSAMENDMENTDATE Title: Label for T836-26-1010 DRAWING No 0012/LMG

⇓ 35.00mm ⇓ ⇐ 0885 FCCID: CASTEL0047 CANADA: xxxxxxxxxx 46.00mm T836-26-1012 Rev 1 707549 Ta it Ele c tro nic s Limite d Made in New Zealand ⇐ Tait Electronics Ltd DRAWNCHKDAPVDDATETait Ele ctronics Ltd Dime ns io ns in mm unle s s otherwise stated. Scale: NTS LMG 1 ORIGINAL 12/09 ISSAMENDMENTDATE Title: Label for T836-26-1012 DRAWING No 0013/LMG

FCCID: CASTEL0048 CANADA: xxxxxxxxxx 0885 T856-26-1010 Rev 1 706492 Tait Electronics Limited Made in New Zealand FCCID: CASTEL0047 CANADA: xxxxxxxxxx 0885 T836-26-1010 Rev 1 706471 Tait Electronics Limited Made in New Zealand

T8X6/7 -X6-121X S erial Number Tait Electronics LimitedMade in New Zealand 4.6cm 3.5cm 1.4cm

M830-00T836 PCB InformationC6.2.1 Copyright TEL30/04/98 6.2T836 Transmitter PCB This section contains the following information. IPNSectionPage 220-011395-02 Parts List Mechanical & Miscellaneous Parts Mechanical Assembly Grid Reference Index PCB Layout - Top Side PCB Layout - Bottom Side Test Points & Options Connections - Top & Bottom Side Transmitter Overview Diagram Audio Processor Circuit Diagram Exciter Circuit Diagram PA Circuit Diagram VCO Section Circuit Diagram Regulators Circuit Diagram Synthesiser Circuit Diagram Microcontroller Circuit Diagram Harmonic Filter Circuit Diagram 6.2.3 6.2.8 6.2.9 6.2.11 6.2.15 6.2.16 6.2.17 6.2.18 6.2.19 6.2.20 6.2.21 6.2.22 6.2.23 6.2.24 6.2.25 6.2.26 C6.2.2T836 PCB InformationM830-00 30/04/98Copyright TEL IPN 220-01395-02 M830-00T836 PCB Information C6.2.3 Copyright TEL23/07/99 T836 Parts List (IPN 220-01395-02) How To Use This Parts List The components listed in this parts list are divided into two main types: those with a circuit reference (e.g. C2, D1, R121, etc.) and those without (miscellaneous and mechanical). Those with a circuit reference are grouped in alphabetical order and then in numerical order within each group. Each component entry comprises three or four columns: the circuit reference, variant (if applicable), IPN and description. A number in the variant col- umn indicates that this is a variant component which is fitted only to the product type listed. Static sensitive devices are indicated by an (S) at the start of the description column. The miscellaneous and mechanical section lists the variant and common parts in IPN order. Where possible, a number in the legend column indicates their position in the mechanical assembly drawing. The Parts List Amendments box below lists component changes that took place after the parts list and diagrams in this section were compiled. These changes (e.g. value changes, added/deleted components, etc.) are listed by circuit reference in alphanumeric order and supersede the information given in the parts list or diagrams. Components without circuit references are listed in IPN order. Parts List Amendments &C269T836-16-0000/836-26-0000: changed from 1p5 (IPN 015-21150-01) to 4p7 (IPN 015-21470-01) for FCC Type Approval requirements (710655). C289T836-16-0000/836-26-0000: changed from 47n (IPN 015-25470-08) to 68n (IPN 015-25680-08) for FCC Type Approval requirements (710655). C314Deleted to improve low frequency stability (710137). C316, C347Changed from 22n (015-25220-08) to 47n (015-25470-08) to improve cyclic keying & standby current (710059). #C448136-156MHz (-10, -13 & -15): changed from 39p (015-02390-02) to 33p (015-02330-02) to improve low band per- formance. C910A, C950A2p2 capacitors (015-01220-06) added on top of C910 & C950 to improve the low pass filter at 174MHz (710155). D111Changed from MR750 (IPN 001-00011-60) to MR2520L (IPN 001-00012-90) to provide overvoltage transient sup- pression (750087/88/89/90/91/92). IC710Changed from 74HCV04 (IPN 002-74910-04) to 74HC04 (IPN 002-74900-04) to increase the gain of the TCXO buffer (710312). R313Changed from 27k (036-15270-00) to 18k (036-15180-00) to improve cyclic keying & standby current (710059). R320, R321Changed from 47k (036-15470-00) to 33k (036-15330-00) to improve cyclic keying & standby current (710059). Changed from 33k (036-15330-00) to 56k (036-15560-00) for ACP IETS 300-113 compliance (710158). R355Changed from 82k (036-15820-00) to 47k (036-15470-00) to improve cyclic keying & standby current (710059). R356Changed from 47k (036-15470-00) to 220k (036-16220-00) to improve cyclic keying & standby current (710059). R357Changed from 47k (036-15470-00) to 22k (036-15220-00) to improve cyclic keying & standby current (710059). Changed from 22k (036-15220-00) to 47k (036-15470-00) for ACP IETS 300-113 compliance (710158). R713Changed from 22Ω (IPN 036-12220-00) to 0Ω (IPN 036-10000-00) to improve hum & noise performance (710837/ 839/840/841). RV220Changed to IPN 042-05470-07 (47k preset) because IPN 042-05470-06 no longer available (710793/96/97/98). 303-11169-03T800 chassis: replaced by 303-11169-04 312-01052-01T800 top lid: replaced by 312-01052-02 312-01053-01T800 bottom lid: replaced by 312-01053-02 349-00020-36The two M3x8 Torx screws which secure the module into the rack frame have been replaced by M3x8 Pozidriv screws (IPN 349-00020-55) (750101/2/3/5/6). New chassis and lid tooling introduced, incorporating mechanical improvements and better RF shielding (750027, 750028 & 750029). Note that the new lids should be used only with the new chassis. IPN 220-01395-02 C6.2.4 T836 PCB InformationM830-00 30/04/98Copyright TEL RefVarIPNDescriptionRefVarIPNDescription C201020-07470-92CAP BI-P RA 4M7 50V 6X11 5 LS C202020-07470-92CAP BI-P RA 4M7 50V 6X11 5 LS C204020-07470-92CAP BI-P RA 4M7 50V 6X11 5 LS C205020-07470-92CAP BI-P RA 4M7 50V 6X11 5 LS C207014-07470-00CAP TANT CHIP 4U7 3.5 X 2.8MM C209015-25470-08CAP CER 0805 47N 10% X7R 50V C210015-06100-08CAP CER 1206 100N 10% X7R 50V C211015-06100-08CAP CER 1206 100N 10% X7R 50V C213025-08100-02CAP TANT BEAD 10M 10% 16V C215014-08220-01(L)CAP TANT 22UF10V276MSER C217015-24220-08CAP CER 0805 2N2 10% X7R 50V C219015-24100-08CAP CER 0805 1N 10% X7R 50V C221014-08220-01(L)CAP TANT 22UF10V276MSER C223015-06100-08CAP CER 1206 100N 10% X7R 50V C225015-06100-08CAP CER 1206 100N 10% X7R 50V C227015-06100-08CAP CER 1206 100N 10% X7R 50V C229015-23150-01CAP CER 0805 150P 5% NPO 50V C230015-06100-08CAP CER 1206 100N 10% X7R 50V C232015-23150-01CAP CER 0805 150P 5% NPO 50V C233020-08470-02CAP ELE RA 47M 16V 6X11MM C235015-24100-08CAP CER 0805 1N 10% X7R 50V C237020-07100-02CAP ELE RA 1M 50V 5X11MM C239020-07470-92CAP BI-P RA 4M7 50V 6X11 5 LS C241015-06100-08CAP CER 1206 100N 10% X7R 50V C242025-08100-02CAP TANT BEAD 10M 10% 16V C243015-24100-08CAP CER 0805 1N 10% X7R 50V C245015-23150-01CAP CER 0805 150P 5% NPO 50V C247015-23150-01CAP CER 0805 150P 5% NPO 50V C249015-24100-08CAP CER 0805 1N 10% …

Text truncated - open the document above for the full version.

C4.10 T836/837 Functional Testing M830-00 30/04/98 Copyright TEL M830-00 T836/837 Functional Testing C4.11 Copyright TEL 30/04/98 Figure 4.5 T837 Main Tuning & Adjustment Controls CV1PL4-1 RV210 line sensitivity SW230 carrier IC700 TCXO RV220 compression level RV805 CTCSS level adjust PL205 PL220 PL215 PL210 SK805 The photograph printed at rightwill help you to identify the maincontrols used in tuning and adjust-ing the T837.There is a similar photograph inFigure 1.3 which shows the main circuit blocks.Extending both these fold-outs willallow you to refer to both photo-graphs while using the manual. C4.12 T836/837 Functional Testing M830-00 30/04/98 Copyright TEL IPN 220-01395-02 M830-00 T836 PCB Information C6.2.9 Copyright TEL 30/04/98 T836 Mechanical Assembly 220-01395-02 KeyThe upper number is the component identification number which appears in the “Legend” column of the Mechanical & Miscellaneous Parts on the facing page.The lower number indicates how many of this component are used in this location or function.

 IPN 220-01395-02C6.2.10 T836 PCB Information M830-00 30/04/98 Copyright TEL IPN 220-01395-02 M830-00 T836 PCB Information C6.2.15 Copyright TEL 30/04/98 T836 PCB Layout - Top Side 220-01395-02 A L BD CE J N KM H G F PQ 123456789 &C269 %C294 %C295 %C707 &R264 &R265&R266 %R298 %C713 %C733 %R150 %R715 %R726 =R705 =SK710 C201 C202 C204 C205 C207 C209 C210 C211 C213 C215 C217 C219 C221 C223 C225 C227 C229 C230 C232 C233 C235 C237 C239 C241 C242 C243 C245 C247 C249 C251 C253 C255 C257 C259 C260 C261 C263 C265 C267 C271 C273 C275 C277 C279 C281 C283 C285 C287 C289 C291 C293 C302 C308 C310 C312 C313 C314 C316 C317 C318 C320 C330A C330B C347 C348 C373 C376 C385 C427 C430 C495 C503 C505 C510 C513 C535 C550 C605 C610A C610B C611A C611B C623 C625 C626 C628 C630 C631A C634 C636 C638 C640 C655 C660 C665 C670 C673 C677 C681 C684 C687 C690 C693 C700 C703 C705 C706 C708 C709 C710 C712 C720 C722 C724 C725 C726 C727 C729 C735 C736 C740A C740B C741A C741B C742A C742B C743 C745 C757 C759 C761 C762 C764 C765 C767 C769 C770 C772 C774 C776 C782 C784 C786 C788 C790 C792 C810 C812 C813 C822 C823C824 C826 C827 C828 C830 C838 C841 C844 CV451 D220 D230 D240 D250 D260 D270 D610 D620 D630 D640 D710 D720 D810 IC210 IC220 IC230 IC240 IC250 IC260 IC330 IC610 IC630 IC640 IC650 IC710IC720 IC730 IC740 IC750 IC820 IC830 L335 L340 L345 L350 L360 L365 L375 L385 L445 L450 L455 L465 L470 L480 L750 P100 P150P160 P170 P204 P208 P210P211 P212 P215P217 P219P225 P230 P231 P233 P235 P237 P239 P240 P243P244 P245 P247P248 P249P251 P255 P257 P259P261 P263 P265 P267 P269 P271 P273 P275 P750 P805 P810 P820 P825 P830P835 P840 PL205PL210PL220 Q210 Q220 Q230 Q240 Q250 Q260 Q270 Q305 Q310 Q315 Q355 Q360 Q365 Q370 Q510 Q520 Q530 Q540 Q550 Q610 Q620 Q630 Q660 Q670 Q710 Q720 Q730 Q740 Q750 Q760 Q770 Q775 Q780 Q785 Q790 Q795 Q810 Q820 Q830 Q840 Q850 Q860 R160 R201 R202 R204 R205 R206R207 R208 R209 R210 R212 R213 R214 R215 R216 R217 R218 R219 R221 R223 R224 R225R226 R227 R229 R230 R231 R232 R233 R235 R237R238 R239 R241 R242 R244 R245 R247 R248 R249 R251 R253R254 R255 R256 R257 R258 R259 R260 R262 R263 R267 R268 R269 R270 R271 R272 R273 R274 R275 R277 R278 R279 R280 R282 R283 R284 R285 R286 R287 R288 R289 R290R291 R292 R293 R294 R295 R296 R297 R299 R301R302R303 R304 R307 R308R309 R310 R313R314 R315 R316 R317 R318 R321 R322 R323R324 R325 R326 R327R328 R330A R355R356 R357 R358 R359 R360R362 R378R380 R382 R388 R390 R392 R394 R396 R410 R425 R430 R460 R502R505R510 R515 R520 R525 R530 R535 R540 R545 R550 R555R560 R609 R613 R615 R617 R625 R633 R637 R641 R645 R649 R653 R657 R661 R665 R669R673 R677 R681R685 R689R693 R696 R701 R702 R703 R706 R708R710 R711 R712 R713 R717R718 R719 R720 R721 R722 R723 R725 R727 R728 R742 R743 R744 R746 R747 R748 R749 R750 R752 R753 R754 R756 R757 R758 R759 R760 R762R763 R765 R766 R767 R769 R771 R772 R774 R775 R777 R784 R785 R786 R787 R790 R791 R792 R801 R802 R808 R809 R810 R811 R812 R813 R815 R816 R818 R819 R821 R822 R824R825 R826R827R828 R829 R830R831R832R833R835R836 R837R840R841R842R843 R845 R846R847 R848 R849 R850 R853 R854 R855 R859 R861 R863 R865 R867 R871 R872 R873R874 R875 R876 R877 R879 RV220 RV310 RV330 RV805 SK310 SK420 SL810 T610 T836- T83610T83613T83615 T83620T83623T83625 T836_ TOPFIDA TOPFIDB TOPHOLE TOPSLOT TP310 SW230 RV210 SK205 T210 PL215 TP206 SK502SK503SK504SK501SK505 SK513 SK522 SK535 SK534SK533SK532SK531 R621R619 R629 TP601 D635 TP607 TP604 TP603 TP602 L910 L940 L920L930 D111 PL100 SK810 SK805 =IC700 C750 TP715 D740 D730 TP710 SL320 TP305 TP308 L370 L355 L380 L495 TP313 TP314 TP402 D330 TP401 L400 L415 L440 L490 L420 R415 L425 L410 R405 TP410 TP409 L475 L485 D410 D420 T836 TRANSMITTER 123456789 A L BD CE J N KM H G F PQ &C269 %C294 %C295 %C707 &R264 &R265&R266 %R298 %C713 %C733 %R150 %R715 %R726 =R705 =SK710 C201 C202 C204 C205 C207 C209 C210 C211 C213 C215 C217 C219 C221 C223 C225 C227 C229 C230 C232 C233 C235 C237 C239 C241 C242 C243 C245 C247 C249 C251 C253 C255 C257 C259 C260 C261 C263 C265 C267 C271 C273 C275 C277 C279 C281 C283 C285 C287 C289 C291 C293 C302 C308 C310 C312 C313 C314 C316 C317 C318 C320 C330A C330B C347 C348 C373 C376 C385 C427 C430 C495 C503 C505 C510 C513 C535 C550 C605 C610A C610B C611A C611B C623 C625 C626 C628 C630 C631A C634 C636 C638 C640 C655 C660 C665 C670 C673 C677 C681 C684 C687 C690 C693 C700 C703 C705 C706 C708 C709 C710 C712 C720 C722 C724 C725 C726 C727 C729 C735 C736 C740A C740B C741A C741B C742A C742B C743 C745 C757 C759 C761 C762 C764 C765 C767 C769 C770 C772 C774 C776 C782 C784 C786 C788 C790 C792 C810 C812 C813 C822 C823C824 C826 C827 C828 C830 C838 C841 C844 CV451 D220 D230 D240 D250 D260 D270 D610 D620 D630 D640 D710 D720 D810 IC210 IC220 IC230 IC240 IC250 IC260 IC330 IC610 IC630 IC640 IC650 IC710IC720 IC730 IC740 IC750 IC820 IC830 L335 L340 L345 L350 L360 L365 L375 L385 L445 L450 L455 L465 L470 L480 L750 P100 P150P160 P170 P204 P208 P210P211 P212 P215P217 P219P225 P230 P231 P233 P235 P237 P239P240 P243P244 P245 P247P248 P249P251 P255 P257 P259P26…

Text truncated - open the document above for the full version.

Master: ktlFCCPart22-90.doc Date: August 9, 2000 KTL Test Report:0R02733 Applicant:Tait Electronics Ltd. 558 Wairakei Road Burnside Christchurch, New Zealand Equipment Under Test:VHF Paging Transmitter (E.U.T.)T836-26-1010 Standard T836-26-1012 Externally Referenced FCC ID:CASTEL0047 In Accordance With:FCC Part 22 FCC Part 90 Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: G. Westwell, Technologist Date: Total Number of Pages:24 KTL Ottawa FCC PART 22 FCC PART 90 PROJECT NO.: 0R02733 EQUIPMENT: VHF Paging Transmitter, T836-26-1010 Standard And T836-26-1012 Externally Referenced FCC ID: CASTEL0047 Page 2 of 19 Table of Contents Section 1. Summary of Test Results.......................................................................................... 3 Section 2. General Equipment Specification ........................................................................... 5 Section 3. RF Power Output .....................................................................................................6 Section 4. Occupied Bandwidth................................................................................................ 7 Section 5. Spurious Emissions at Antenna Terminals........................................................... 11 Section 6. Field Strength of Spurious Emissions................................................................... 12 Section 7. Frequency Stability................................................................................................ 13 Section 8. Transient Frequency Behaviour ........................................................................... 14 Section 9. Test Equipment List ..........................................................…

Text truncated - open the document above for the full version.
