Part 1 explains how the TM8250 radio with the graphical display operates.
Part 2 outlines the installation procedure for all TM8200 radios. If you need further assistance or your radio does not operate as you expect, contact your radio provider. Important safety information This user’s guide also contains important safety and compli- ance information about using and installing TM8200 radios. Refer to page 11 for user safety and compliance instructions and page 42 for installation safety instructions. Safety warnings used in this guide Within this guide, the following conventions are used to alert you to important safety information: Warning:There is a potential risk of death or serious injury. Caution:There is the risk of minor or moderate injury to people. Caution:“Caution” is used without the safety alert symbol when there is a risk of equipment damage or malfunction. Feedback about this guide If you have any enquiries regarding this guide, or any comments, suggestions and notifications of errors, please contact Technical Support at [email protected]. 4About this guide Changes to this guide In the interests of improving the performance, reliability or servicing of the equipment, Tait Electronics Ltd reserves the right to update both the equipment or this user’s guide, with- out prior notice. Website: For contact details and technical assistance, go to http://www.taitworld.com/, and http://support.taitworld.com/. Copyright information All information contained in this guide is the property of Tait Electronics Ltd. All rights are reserved. These guides may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-readable form, without prior written permission from Tait Electronics Ltd. All trade names referenced are the service mark, trademark, or registered trademark of the respective manufacturers. Disclaimer There are no warranties extended or granted by this guide. Tait Electronics Ltd accepts no responsibility for damage aris- ing from use of the information contained in the guide or of the equipment and software it describes. It is the responsibil- ity of the user to ensure that use of such information, equip- ment and software complies with the laws, rules and regulations of the applicable jurisdictions. Your radio’s settings Use the following table to list your radio’s programmed settings. Frequently used channels and groups Function key settings quick access menus: IDDescriptionIDDescription scroll keys on/off key volumecontrol microphonesocket press-to talk key(PTT) red display speaker green amber microphone radio status LEDs function keys1 to 4 left selection key right selection key Main menu Navigating your radio’s menus Main menu: conventional modeNote: Only features programmed for your radio will be available. Radio operation9 Part 1: Radio operation About this guide .......................................................................... 3 Important safety information ....................................................................... 3 Safety warnings used in this guide ..........................…

Text truncated - open the document above for the full version.

FCC ID: [CASTMAB1D] Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, (Tait Electronics Ltd.), hereby request confidentiality for the [Block diagrams, Schematics, Parts Lists, Tune up and Operational Description] presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. [Steve Crompton] [Tait Electronics Ltd.]

TELTEST Laboratories Tait Electronics Limited Report Number 2076 FCC ID: CASTMAB1D Page 1 of 42 REPORT NUMBER 2076August 2004 RADIO PERFORMANCE MEASUREMENTS On the TMAB24-B101 Mobile Transceiver FCC ID: CASTMAB1D SN: 19017507 In accordance with FCC 47 CFR Parts 22 and 90 PREPARED BY:Marcus Ludwig___________________ Test Technician CHECKED & APPROVED BY:Hamish Newton___________________ Senior Technician TELTEST Laboratories Tait Electronics Limited PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone : (64) (3) 3583399 Fax: (64) (3) 3580432 TELTEST Laboratories Tait Electronics Limited Report Number 2076 FCC ID: CASTMAB1D Page 2 of 42 REPORT ON : Type Approval Testing of the TMAB24-B101 (Serial No 19017507) in accordance with: FCC CFR 47 Parts 22 & 90 FCC ID: CASTMAB1D PREPARED FOR : Tait Electronics Ltd PO Box 1645 558 Wairakei Rd Christchurch New Zealand DISTRIBUTION : TELTest LaboratoryMr S CromptonCopy No 1 Tait Electronics LtdMr. Des Fox Copy No 2 Tait Electronics LtdMr. Dereck FiddesCopy No 3 APPROVED : Hamish Newton Senior Technician Date : All tests reported herein have been performed in accordance with the laboratory's scope of accreditation This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. Copy No: TELTEST Laboratories Tait Electronics Limited Report Number 2076 FCC ID: CASTMAB1D Page 3 of 42 TABLE OF CONTENTS DECLARATION OF CONFORMITY................................................................................................. 4 TEST CONDITIONS ............................................................................................................................. 5 NECESSARY BANDWIDTH AND EMISSION DESIGNATORS ................................................... 5 TEST RESULTS..................................................................................................................................... 7 TRANSMITTER OUTPUT POWER (CONDUCTED) ...................................................................... 7 TRANSMITTER AUDIO FREQUENCY RESPONSE - PRE-EMPHASIS ....................................... 8 TRANSMITTER MODULATION LIMITING ................................................................................. 10 OCCUPIED BANDWIDTH ..............................................................................................................13 SPURIOUS EMISSIONS (CONDUCTED)....................................................................................... 26 SPURIOUS EMISSIONS (RADIATED)........................................................................................... 29 TRANSMITTER FREQUENCY STABILITY (TEMPERATURE) ................................................. 32 TRANSMITTER FREQUENCY STABILITY (VOLTAGE) ........................................................... 34 TRANSIENT FREQUENCY BEHAVIOR ....................................................................................... 35 TEST EQUIPMENT USED................................................................................................................. 40 APPENDIX A ....................................................................................................................................... 41 TEST SETUP DETAILS.................................................................................................................... 41 TELTEST Laboratories Tait Electronics Limited Report Number 2076 FCC ID: CASTMAB1D Page 4 of 42 DECLARATION OF CONFORMITY We, TELTEST LABORATORIES of 558 Wairakei Road, Christchurch New Zealand, declare under our sole responsibility that the product: Equipment:Mobile Transceiver Type:TMAB1D Product code:TMAB24-B101 Serial Numbers:19007584 Quantity:1 To which this declaration relates is in conformity with the following standards: FCC CFR 47 Parts 22 & 90 Signature:__________________________ S. A. Crompton Compliance Laboratory Manager. Date:__________ TELTEST Laboratories Tait Electronics Limited Report Number 2076 FCC ID: CASTMAB1D Page 5 of 42 Test Conditions All testing was performed at the following conditions. Ambient Temperature15 o C to 35 o C Relative Humidity20% to 75% Standard Test Voltage13.8Vdc Necessary Bandwidth and Emission Designators SPECIFICATION:FCC 47 CFR 2.202 The Necessary Bandwidth is the minimum value of the occupied bandwidth sufficient to ensure the transmission of information at the rate and with the quality required for the system employed. This is calculated using the following formula. Bn = 2M + 2DKWhere: Bn = Necessary Bandwidth M = Maximum modulation frequency For Data transmission M = B/2 Where: B = Modulation rate in Baud D = Peak deviation K = Constant For Analogue transmission this is 1 For Data transmission this is typically 1.2 1. Analogue Voice 12.5kHz Bandwidth Necessary bandwidthEmission Designator M = 3kHz11k0F3E D = 2.5kHz F3E represents a FM voice transmission Bn = 6 + 5 x 1 =11kHz 2. Analogue Voice 25kHz Bandwidth Necessary bandwidthEmission Designator M = 3kHz16k0F3E D = 5kHz F3E represents a FM voice transmission Bn = 6 + 10 x 1 =16kHz 3. Fast Frequency Shift Keying (FFSK) 12.5kHz Bandwidth Necessary bandwidthEmission Designator M = 0.6 (Baud rate = 1200)4k80F2D D = 1.5kHz (60% of peak deviation) F2D represents a FM data transmission with the use of a modulating sub carrier Bn = 1.2 + 3 x 1.2 =4.8kHz TELTEST Laboratories Tait Electronics Limited Report Number 2076 FCC ID: CASTMAB1D Page 6 of 42 4. Fast Frequency Shift Keying (FFSK) 25kHz Bandwidth Necessary bandwidthEmission Designator M = 0.6 (Baud rate = 1200)8k40F2D D = 3kHz (60% of peak deviation) F2D represents a FM data transmission with the use of a modulating sub carrier Bn = 1.2 + 6 x 1.2 =8.4kHz 5. Tait High Speed Date (THSD) THSD uses a 4 level gaussian frequency shift keying (CP-4GFSK) modulation scheme. It can be used when transferring data between two radios. Data is transmitted at a rate of 12000bps for narrow band channels, and 19200bps for wide-band channels.…

Text truncated - open the document above for the full version.

FCC ID: CASTMAB1DPage 1 of 9 REPORT NUMBER 2076MPEFCC ID: CASTMAB1D TELTEST Laboratories Tait Electronics Limited PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone : (64) (3) 3583399 Fax: (64) (3) 3580432 TEST: FCC 47 CFR 1.1310 Maximum Permissible Exposure ENVIRONMENTAL ASSESSMENT On the TMAB24-B101 Mobile Transceiver S/N: 19017507 In accordance with ANSI/IEEE Std C95.1, 1999 OET Bulletin 65 97-01 and Supplement C (Edition 01-01) DATE:August 2004 PREPARED BY:M. Ludwig__________________ Test Technician CHECKED & APPROVED BY:Hamish Newton __________________ Senior Technician This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. FCC ID: CASTMAB1DPage 2 of 9 TABLE OF CONTENTS Page SUMMARY OF RESULTS ................................................................................................................... 3 OPERATING CONDITIONS AND EXPOSURE CONDITIONS .................................................... 3 LIMITS ................................................................................................................................................... 3 RECOMMENDED ANTENNAS .......................................................................................................... 3 MEASUREMENT GUIDANCE ...........................................................................................................4 TEST RESULTS, TRANSMITTER POWER ..................................................................................... 5 TEST RESULTS, MPE.......................................................................................................................... 5 TEST EQUIPMENT LIST .................................................................................................................... 7 INFORMATION TO BE PLACED IN MANUAL.............................................................................. 8 APPENDIX 1 TEST POSITIONS DIAGRAM.................................................................................... 9 FCC ID: CASTMAB1DPage 3 of 9 Summary of Results: Antenna GainAntenna PositionMeasurement PositionResult 2.15 dBi RoofExternal: Side COMPLIES 5.15 dBi RoofExternal: Side COMPLIES 2.15 dBi RoofInternal: Front Seat COMPLIES 2.15 dBi RoofInternal: Back Seat COMPLIES 5.15 dBi RoofInternal: Front Seat COMPLIES 5.15 dBi RoofInternal: Back Seat COMPLIES See Appendix A for details of the measurement positions. Operating and Exposure conditions: Operating Conditions:Mobile transmitter using vehicle mounted antennas only Exposure conditions:Occupational/Controlled Exposure (operator). General Population/Uncontrolled (passengers and bystanders) Safe Distance: Recommended Minimum lateral safe distance from the antenna:90 cm Limit: Occupational/Controlled Exposure: 30 - 300 MHz: 1.0 mW/cm 2 General population/Uncontrolled Exposure: 30 - 300 MHz: 0.2 mW/cm 2 Recommended Antennas: Antenna Type:Monopole (λ/4 antenna) Antenna Gain:2.15 dBi Antenna Type:Monopole (5λ/8 antenna) Antenna Gain:5.15 dBi FCC ID: CASTMAB1DPage 4 of 9 Measurement Guidance: 2) Mobile PTT – Parts 80, 90 a) §2.1033(c)(3) requires device operating and installation instructions to be submitted during equipment certification; instructions should include the minimum separation distance and other constraints required for the device and its antenna(s) to meet MPE limits b) Per definition of a mobile device a minimum separation distance of 20 cm is required i) Antenna installation conditions should maintain the estimated minimum MPE separation distance ii) A separation distance based on MPE evaluation (measurement or computer modeling) that is smaller than the estimated MPE distance may be used if it is applicable for the antenna installation conditions c) Basic RF exposure instructions are requested for devices that meet general population exposure requirements, as part of the §2.1033(c)(3) required operating instructions; RF exposure training instructions and labeling info are requested for devices that satisfy occupational exposure requirements Federal Communications Commission OET Laboratory Division March 18, 2004 FCC ID: CASTMAB1DPage 5 of 9 Test Results: NAME OF TEST:TRANSMITTER OUTPUT POWER (CONDUCTED) TEST CONDITIONS:Ambient Temperature23 o C Relative Humidity33 % SPECIFICATION:FCC 47 CFR 2.1046 GUIDE:TIA/EIA-603 2.2.1 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was connected to an RF Power meter using a coaxial attenuator with an impedance of 50 Ohms. 2. The unmodulated output power was measured. MEASUREMENT RESULTS: Transmit Frequency:157.65MHz Manufacturer’s Rated Output Power50Watts Supply Voltage, motor idling, transmitting.13.65Volts Measured Output Power49.6Watts Measurement Uncertainty (dB) ± 0.5 dB Maximum Transmit Power is set in the factory to 52 watts +2 / -1 watt. This setting is not adjustable by the user. The MPE results are scaled to simulate results from a 54 watt carrier with a 50% duty cycle. NAME OF TEST:ENVIRONMENTAL ASSESSMENT SPECIFICATION:FCC 47 CFR 1.1310 Measurement Method: Field strength measurements were performed with the antenna centrally mounted on the roof of a representative vehicle (Honda Accord 2001 LXI four door sedan, dimensions 185.5 long, 71.5 wide and 57.1 inches high ). See Appendix A for details. External Field strength readings were recorded at a position 20 cms from the car body, to represent the closest position for a bystander. Measurements were taken at 20 cm intervals vertically over a height of 2 metres. Internal field strength readings were recorded in the front and back seat locations in the areas where the highest field strength is found. Measurements were made in an area 40cm wide representing the head and upper and lower torso. Spatial averaging is carried out to determine the MPE result (IEEE C95.1 3.29). FCC ID: CASTMAB1DPage 6 of 9 Roof mounted antenna: 1.Position: 90 degrees to side of car, 20 cms from the body, on a line intersecting the roof an…
