CASTMAB1ZExternal Radio Frequency Power Amplifier

TM9100 mobiles 110 Watt Mobile Installation Guide 27 October 2005 2Contact informationTM9100 Mobiles: 110 W Mobile Installation Guide © Tait Electronics Limited October 2005 Contact information Tait Radio Communications Corporate Head Office Tait Electronics Ltd P.O. Box 1645 Christchurch New Zealand For the address and telephone number of regional offices, refer to the TaitWorld website: We b s i t e :http://www.taitworld.com Technical Support For assistance with specific technical issues, contact Technical Support: E-mail:[email protected] We b s i t e :http://support.taitworld.com To our European customers: Tait Electronics Limited is an environmentally responsible company which supports waste minimization and material recovery. The European Union’s Waste Electrical and Electronic Equipment Directive requires that this product be disposed of separately from the general waste stream when its service life is over. Please be environmentally responsible and dispose through the original supplier, your local municipal waste “separate collec- tion” service, or contact Tait Electronics Limited. TM9100 Mobiles: 110 W Mobile Installation Guide3 © Tait Electronics Limited October 2005 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Scope of Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Enquiries and Comments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Updates of Manual and Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Associated Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2 Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 RF Exposure Hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Safe Radio Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Correct Fuse Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Interference with Vehicular Electronics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Preparation when Drilling Holes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Vehicles Powered by Liquefied Petroleum Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Radio Installation in Gas or Fuel tankers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Negative Earth Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3 Preparing the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.1 Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.2 Installation Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.3 Checking the Equipment for Completeness . . . . . . . . . . . . . . . . . . . . . . . 10 3.4 Programming Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 4 Installing the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 4.1 Selecting the Mounting Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 4.2 Installing the Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 4.3 Connecting the Power Cable to the Power Source . . . . . . . . . . . . . . . . . . 14 4.4 Installing the Remote Control Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 4.5 Installing the Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 4.6 Connecting to the Ignition Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 4.7 Connecting a Remote Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 4.8 Connecting to an Emergency Switch and/or External Alert Devices . . . . . 18 4.9 Mounting the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 4.10 Checking the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Tait General Software Licence Agreement . . . . . . . . . . . . . . . . . . . . . . . . 23 4PrefaceTM9100 Mobiles: 110 W Mobile Installation Guide © Tait Electronics Limited October 2005 Preface Scope of Manual This manual describes how to install a Tait TM9155R mobile, including microphone, antenna, emergency switch, and external alert device. The installation of accessories is described in the installation instructions provided with the equipment, and the relevant section in the service manual. Enquiries and Comments If you have any enquiries regarding this manual, or any comments, suggestions or notifications of errors, please contact Technical Support, Tait Electronics Ltd, Christchurch, New Zealand (refer to “Contact information” on page 2). Updates of Manual and Equipment In the interests of improving the performance, reliability, or servicing of the equipment, Tait Electronics Ltd reserves the right to update the equipment or this manual or both without prior notice. Copyright All information contained in this manual is the property of Tait Electronics Ltd. All rights are reserved. This manual may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to an…

Text truncated - open the document above for the full version.

13/11/05 FCC ID: [CASTMAB1Z] Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, (Tait Electronics Limited), hereby request confidentiality for the [Block diagrams, Schematics, Parts Lists, and Operational Description] presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. [Steve Crompton] [Tait Electronics Limited]

TELTEST Laboratories Tait Electronics Limited Report Number 2290-A TELTEST Laboratories – A Division of Tait Electronics LimitedTelephone: 64 3 358 3399, Fax: 64 3 358 0432 PO Box 1645, 558 Wairakei Road, Christchurch, New Zealand Page 1 of 10 Environmental Assessment For the TMAA42-B100 External RF Power Amplifier In accordance with FCC 47 CFR 1.1310 Report Revision:1 Issue Date:18-Oct-2005 FCC ID:CASTMAB1Z PREPARED BY:Hamish Newton___________________ Test Technician CHECKED & APPROVED BY:Steve Crompton___________________ Laboratory Manager All tests reported herein have been performed in accordance with the laboratory's scope of accreditation This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. TELTEST Laboratories Tait Electronics Limited Report Number 2290-A Page 2 of 10Report Revision: 1 Issue Date: 18-Oct-2005 TABLE OF CONTENTS REVISION HISTORY ........................................................................................................................... 3 INTRODUCTION .................................................................................................................................. 4 REPORT PREPARED FOR ................................................................................................................. 4 DESCRIPTION OF SAMPLE .............................................................................................................. 4 STATEMENT OF COMPLIANCE...................................................................................................... 4 TEST CONDITIONS ............................................................................................................................. 4 OPERATING AND EXPOSURE CONDITIONS ............................................................................... 5 RECOMMENDED ANTENNAS .......................................................................................................... 5 TEST RESULTS..................................................................................................................................... 6 INFORMATION TO BE PLACED IN USER/INSTALLATION MANUAL................................... 8 TEST EQUIPMENT USED................................................................................................................... 9 MEASUREMENT PROCEDURE ........................................................................................................ 9 TELTEST Laboratories Tait Electronics Limited Report Number 2290-A Page 3 of 10Report Revision: 1 Issue Date: 18-Oct-2005 REVISION HISTORY DateRevisionComments 18-Oct-20051Initial test report TELTEST Laboratories Tait Electronics Limited Report Number 2290-A Page 4 of 10Report Revision: 1 Issue Date: 18-Oct-2005 INTRODUCTION Maximum permissible exposure assessment on the TMAA42-B100 external radio frequency power amplifier in accordance with: FCC CFR 1.1310 REPORT PREPARED FOR Tait Electronics Ltd PO Box 1645 558 Wairakei Rd Christchurch New Zealand DESCRIPTION OF SAMPLE FCC ID:CASTMAB1Z Type:TMAB1Z Product code:TMAA42-B100 Serial Numbers:13133324 Quantity:1 The TMAB1Z is an External Radio Frequency Power Amplifier designed to operate in the 136MHz to 174MHz band. It has a fixed output power of 110W, and output impedance of 50 ohms. It has been tested with the TMAB32-B100 (serial number 19057434) mobile, which has the output power fixed at 1 watt. The mobile performs all modulation, and the TMAB1Z is only used to increase the output power of the mobile. STATEMENT OF COMPLIANCE The TMAA42-B100 external radio frequency power amplifier was found to conform to the following standards: FCC 47 CFR 1.1310 TEST CONDITIONS All testing was performed at the following conditions. Ambient Temperature15 o C to 30 o C Relative Humidity20% to 75% Standard Test Voltage13.8Vdc TELTEST Laboratories Tait Electronics Limited Report Number 2290-A Page 5 of 10Report Revision: 1 Issue Date: 18-Oct-2005 OPERATING AND EXPOSURE CONDITIONS Operating Conditions:Mobile transmitter using vehicle mounted antennas only Exposure conditions:Occupational/Controlled Exposure (operator). Limit: 30 - 300 MHz: 1.0 mW/cm 2 General Population/Uncontrolled (passengers and bystanders) Limit: 30 - 300 MHz: 0.2 mW/cm 2 Safe Distance Recommended Minimum lateral safe distance from the antenna:110 cm RECOMMENDED ANTENNAS Antenna Type:Monopole (λ/4 antenna) Antenna Gain:2.15 dBi Antenna Type:Monopole (5λ/8 antenna) Antenna Gain:5.15 dBi TELTEST Laboratories Tait Electronics Limited Report Number 2290-A Page 6 of 10Report Revision: 1 Issue Date: 18-Oct-2005 TEST RESULTS Evaluation of the MPE requirement for the TMAA42-B100 110W external RF power amplifier is based on measurements that were made on the 50W mobile transceiver 1 , which covers the same frequency band. The increase in power represents a gain of. dB42.3 50 110 log10 =       = or a numeric gain of 2.2 Therefore to represent the results for 110W, the measured results for the 50W mobile have been multiplied by 2.2. Test Distance metres λ/4 antenna5λ/8 antenna UnitsPower Density, mW/cm 2 Probe Height metres 50W Mobile measured Results 110W Mobile Calculated Results FCC Duty Cycle Applied 50W Mobile measured Results 110W Mobile Calculated Results FCC Duty Cycle Applied 0.2 0.0180.040 0.020 0.0090.020 0.010 0.4 0.0340.075 0.037 0.0170.037 0.019 0.6 0.0150.033 0.017 0.0110.024 0.012 0.8 0.0320.070 0.035 0.0070.015 0.008 1.0 0.1130.249 0.124 0.0140.031 0.015 1.2 0.1710.376 0.188 0.0490.108 0.054 1.4 0.3030.667 0.333 0.0980.216 0.108 1.6 0.3330.733 0.366 0.1430.315 0.157 1.8 0.3500.770 0.385 0.1960.431 0.216 2.0 0.3400.748 0.374 0.2810.618 0.309 Average 0.1880.091 1. The MPE report for the 50W mobile can be found at Annex A. TELTEST Laboratories Tait Electronics Limited Report Number 2290-A Page 7 of 10Report Revision: 1 Issue Date: 18-Oct-2005 Test Results MPE Inside Vehicle: Roof mounted Antenna λ/4 antenna5λ/8 antenna Power Den…

Text truncated - open the document above for the full version.

TELTEST Laboratories Tait Electronics Limited Report Number 2290 TELTEST Laboratories – A Division of Tait Electronics LimitedTelephone: 64 3 358 3399, Fax: 64 3 358 0432 PO Box 1645, 558 Wairakei Road, Christchurch, New Zealand Page 1 of 19 Laboratory Test Report For the TMAA42-B100 External Radio Frequency Power Amplifier Tested In accordance with FCC 47 CFR Parts 22 and 90 Report Revision:2 Issue Date:03-Nov-2005 FCC ID:CASTMAB1Z PREPARED BY:Garry Pringle___________________ Test Technician CHECKED & APPROVED BY:Hamish Newton___________________ Senior Technician All tests reported herein have been performed in accordance with the laboratory's scope of accreditation This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. TELTEST Laboratories Tait Electronics Limited Report Number 2290 Page 2 of 19Report Revision: 2 Issue Date: 03-Nov-2005 TABLE OF CONTENTS REVISION HISTORY ................................................................................................................3 INTRODUCTION ....................................................................................................................... 4 REPORT PREPARED FOR ...................................................................................................... 4 DESCRIPTION OF SAMPLE .................................................................................................... 4 STATEMENT OF COMPLIANCE ............................................................................................. 4 TEST CONDITIONS .................................................................................................................. 4 NECESSARY BANDWIDTH AND EMISSION DESIGNATORS .............................................. 5 TEST RESULTS........................................................................................................................ 5 TRANSMITTER OUTPUT POWER (CONDUCTED) ............................................................ 5 ANALOGUE VOICE.......................................................................................................................7 FFSK................................................................................................................................................8 DIGITAL – Voice/Data....................................................................................................................9 SPURIOUS EMISSIONS (CONDUCTED)........................................................................... 10 SPURIOUS EMISSIONS (RADIATED) ............................................................................... 12 TRANSIENT FREQUENCY BEHAVIOR ............................................................................. 14 TEST EQUIPMENT USED ...................................................................................................... 17 ANNEX A................................................................................................................................. 18 TEST SETUP DETAILS ....................................................................................................... 18 TELTEST Laboratories Tait Electronics Limited Report Number 2290 Page 3 of 19Report Revision: 2 Issue Date: 03-Nov-2005 REVISION HISTORY DateRevisionComments 19-Sep-20051Initial test report 03-Oct-20052Re-tested conducted emissions after improvements in LPF TELTEST Laboratories Tait Electronics Limited Report Number 2290 Page 4 of 19Report Revision: 2 Issue Date: 03-Nov-2005 INTRODUCTION Type Approval Testing of the TMAA42-B100 (Serial No 13133324) in accordance with: FCC CFR 47 Parts 22 & 90 REPORT PREPARED FOR Tait Electronics Ltd PO Box 1645 558 Wairakei Rd Christchurch New Zealand DESCRIPTION OF SAMPLE FCC ID:CASTMAB1Z Type:TMAB1Z Product code:TMAA42-B100 Serial Numbers:13133324 Quantity:1 The TMAB1Z is an External Radio Frequency Power Amplifier designed to operate in the 136MHz to 174MHz band. It has a fixed output power of 110W, and output impedance of 50 ohms. It has been tested with the TMAB32-B100 (serial number 19057434) mobile, which has the output power fixed at 1 watt. The mobile performs all modulation, and the TMAB1Z is only used to increase the output power of the mobile. STATEMENT OF COMPLIANCE The TMAA42-B100 External Radio Frequency Power Amplifier as tested in this report was found to conform to the following standards: FCC CFR 47 Parts 22 & 90 TEST CONDITIONS All testing was performed at the following conditions. Ambient Temperature15 o C Æ 30 o C Relative Humidity20% Æ 75% Standard Test Voltage13.8Vdc TELTEST Laboratories Tait Electronics Limited Report Number 2290 Page 5 of 19Report Revision: 2 Issue Date: 03-Nov-2005 NECESSARY BANDWIDTH AND EMISSION DESIGNATORS The TMAA42-B100 ERFPA does not provide any modulation. It is intended to be used with the following types of emissions as defined in 90.207 F3E – FM, Analogue Voice F1E – FM, Digital Voice F1D – FM, Digital Data, no subcarrier F2D – FM, Digital Data, modulated subcarrier F7E – FM, Two or more channels containing quantized or digital voice information F7D – FM, Two or more channels containing quantized or digital information TEST RESULTS TRANSMITTER OUTPUT POWER (CONDUCTED) SPECIFICATION:FCC 47 CFR 2.1046 GUIDE:TIA/EIA-603C 2.2.1 MEASUREMENT PROCEDURE: 1. Refer Annex A for Equipment set up. 2. The coaxial attenuator has an impedance of 50 Ohms. 3. The unmodulated output power was measured with an RF Power meter. MEASUREMENT RESULTS: Manufacturer’s Rated Output Power:110 Watts 162.1 MHz110 W nominalW nominal POWER (W) 107.0 Variation from Nominal (%) -2.7 Measurement Uncertainty (dB) +0.63 -0.68 LIMIT CLAUSE:FCC 47 CFR 90.205 (r) Radio Type:Mobile Transceiver Frequency Band:150 MHz Æ 174 MHz The output power shall not exceed by more than 20% the manufacturer’s rated output power for the particular transmitter. TELTEST Laboratories Tait Electronics Limited Report Number 2290 Page 6 of 19Rep…

Text truncated - open the document above for the full version.
