CASTMAC0CMobile Transceiver

TA I T : T H ERIG H T FIT 3 Directive 1999/5/EC Declaration of Conformity daDansk Undertegnede Tait Electronics Limited erklærer herved, at følgende udstyr TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Se endvidere: http://eudocs.taitworld.com/ deDeutsch Hiermit erklärt Tait Electronics Limited die Übereinstimmung der Geräte TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C mit den grundlegenden Anforderungen und den anderen relevanten Festlegungen der Richtlinie 1999/5/EG. Siehe auch: http://eudocs.taitworld.com/ elΕλληνικός Με την παρουσα Tait Electronics Limited δηλωνει οτι TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C συμμορφωνεται προσ τισ ουσιωδεισ απαιτησεισ και τισ λοιπεσ σχετικεσ διαταξεισ τησ οδηγιασ1999/5/ΕΚ. βλέπε και: http://eudocs.taitworld.com/ enEnglish Tait Electronics Limited declares that this TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C complies with the essential require- ments and other relevant provisions of Directive 1999/5/EC. See also: http://eudocs.taitworld.com/ esEspañol Por medio de la presente Tait Electronics Limi- ted declara que el TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Vease también: http://eudocs.taitworld.com/ fiSuomi Tait Electronics Limited vakuuttaa täten että TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukai- nen. Katso: http://eudocs.taitworld.com/ frFrançais Par la présente, Tait Electronics Limited déclare que les appareils TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C sont confor- mes aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Voir aussi: http://eudocs.taitworld.com/ itItaliano Con la presente Tait Electronics Limited dichiara che questo TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Vedi anche: http://eudocs.taitworld.com/ nlNederlands Hierbij verklaart Tait Electronics Limited dat het toestel TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/ EG. Zie ook: http://eudocs.taitworld.com/ ptPortuguês Tait Electronics Limited declara que este TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C está conforme com os requisitos essenciais e outras provisões da Directiva 1999/5/CE. Veja também: http://eudocs.taitworld.com/ svSvensk Härmed intygar Tait Electronics Limited att denna TMAA4C, TMAB1C, TMAH5C, TMAH6C & TMAC0C står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direk- tiv 1999/5/EG. Se även: http://eudocs.taitworld.com/ 4 Copyright and trademarks All information contained in this document is the property of Tait Electronics Limited. All rights reserved. This document may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-readable form, without prior written permission from Tait Electronics Limited. The word TAIT and the TAIT logo are trademarks of Tait Electronics Limited. All trade names referenced are the service mark, trademark or registered trademark of the respective manufacturers. Disclaimer There are no warranties extended or granted by this document. Tait Electronics Limited accepts no responsibility for damage arising from use of the information contained in the document or of the equipment and software it describes. It is the responsibility of the user to ensure that use of such information, equipment and software complies with the laws, rules and regulations of the applicable jurisdictions. Enquiries and comments If you have any enquiries regarding this document, or any comments, suggestions and notifications of errors, please contact Technical Support. Updates of manual and equipment In the interests of improving the performance, reliability or servicing of the equipment, Tait Electronics Limited reserves the right to update the equipment or this document or both without prior notice. 5 Intellectual property rights This product may be protected by one or more patents or designs of Tait Electronics Limited together with their international equivalents, pending patent or design applications, and registered trade marks: NZ 409837, NZ 409838, NZ 508806, NZ 508807, NZ 509242, NZ 509640, NZ 509959, NZ 510496, NZ 511155, NZ 511421, NZ 516280/NZ 519742, NZ 520650/NZ 537902, NZ 521450, NZ 522236, NZ 524369, NZ 524378, NZ 524509, NZ 524537, NZ 524630, NZ 530819, NZ 534475, NZ 534692, NZ 535471, NZ 537434, NZ 546295, NZ 547713, NZ 569985, AU 2003281447, AU 2004216984, AU 2005207405, AU 2005267973, AU 11677/2008, AU 13745/2008, CA 2554213, CA 2574670, CN 200830113832.x, CN 200830113833.4, EU 1,532,866, EU 1,599,792, EU 05704655.9, EU 000915475-0001, EU 000915475-0002, GB 23865476, GB 2386010, GB 2413249, GB 2413445, US 11/232716, US 10/597339, US 10/520827, US 5,745,840, US 7,411,461, US 10/546696, US 10/546,697, US 10/520827, US 10/547964, US 10/523952, US 11/572700, US 29/306491, US 61/085036. Environmental responsibilities Tait Electronics Limited is an environmentally responsible company which supports waste minimization, material recovery and restrictions in the use of hazardous materials. The European Union’s Waste Electrical and Electronic Equipment (WEEE) Directive requires that this product be disposed of separately from the general waste stream when its service life is over. For more information about how to dispose of your unwanted Tait product, visit the Tait Electronics WEEE website at www.taitworld.com/weee. 6 Please be environmentally responsible and dispose through the original supplier, or contact Tait Electronics Limited. Tait Electronics Limited also complies with the Restriction of the Use of Certa…

Text truncated - open the document above for the full version.

TM8100 TM8200 TM9100 TP8100 TP9100 Safety and Compliance Information Tait Software License Agreement Informations sur la conformité et consignes de sécurité Contrat de licence logiciel de Tait Sicherheitshinweise und Informationen zur Einhaltung von Richtlinien und gesetzlichen Vorschriften Tait Softwarelizenzvertrag Informação sobre segurança e regras que devem ser observados Acordo de licença de software da Tait Información sobre medidas de seguridad y conformidad Contrato de licencia de software de Tait 产品安全与符合性信息 大吉软件许可协议 MTA-00011-04 07/2010 © Tait Electronics Limited 2 Directive 1999/5/EC Declaration of Conformity Dansk: Undertegnede Tait Electronics Limited erklærer herved, at følgende udstyr TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Se endvidere: http://eudocs.taitradio.com/ Deutsch: Hiermit erklärt Tait Electronics Limited die Übereinstimmung der Geräte TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A mit den grundlegenden Anforderungen und den anderen relevanten Festlegungen der Richtlinie 1999/5/EG. Siehe auch: http://eudocs.taitradio.com/ Ελληνικός: Με την παρουσα Tait Electronics Limited δηλωνει οτι TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A συμμορφωνεται προσ τισ ουσιωδεισ απαιτησεισ και τισ λοιπεσ σχετικεσ διαταξεισ τησ οδηγιασ 1999/5/ΕΚ. βλέπε και: http://eudocs.taitradio.com/ English: Tait Electronics Limited declares that this TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. See also: http://eudocs.taitradio.com/ Español: Por medio de la presente Tait Electronics Limited declara que el TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Vea también: http://eudocs.taitradio.com/ Suomi: Tait Electronics Limited vakuuttaa täten että TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Katso: http://eudocs.taitradio.com/ Français: Par la présente, Tait Electronics Limited déclare que les appareils TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A sont conformes aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Voir aussi: http://eudocs.taitradio.com/ Italiano: Con la presente Tait Electronics Limited dichiara che questo TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Vedi anche: http://eudocs.taitradio.com/ Nederlands: Hierbij verklaart Tait Electronics Limited dat het toestel TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/ EG. Zie ook: http://eudocs.taitradio.com/ Português: Tait Electronics Limited declara que este TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A está conforme com os requisitos essenciais e outras provisões da Directiva 1999/5/CE. Veja também: http://eudocs.taitradio.com/ Svensk: Härmed intygar Tait Electronics Limited att denna TMAA4A, TMAA4C, TMAB1A, TMAB1C, TMAB1E, TMAC0A, TMAC0C, TMAH5A,TMAH5C, TMAH5E, TMAH6A, TMAH6C, TMAH6E, TPAB1A, TPAH5A, TPAH6A, TPCB1A, TPCC0A, TPCH5A & TPCH6A står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. Se även: http://eudocs.taitradio.com/ 3 English Contact information Tait Radio Communications Corporate Head Office Tait Electronics Limited P.O. Box 1645 Christchurch New Zealand For the address and telephone number of regional offices, refer to our website: www.taitradio.com About this document Before using the radio, please read the important safety and compliance information below. Before using an intrinsically safe (IS) radio, see also “Intrinsically Safe Radios (TP8100/TP9100 only)” on page 9. For information about the way your radio operates, see the user’s guide or contact your radio provider. Copyright and trademarks All information contained in this document is the property of Tait Electronics Limited. All rights reserved. This document may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-readable form, without prior written permission from Tait Electronics Limited. The word TAIT and the TAIT logo are trademarks of Tait Electronics Limited. All trade names referenced are the service mark, trademark or registered trademark of the respective manufacturers. Intellectual property rights This product may be protected by one or more patents or designs of Tait Electronics Limited together with their international equivalents, pen…

Text truncated - open the document above for the full version.

11/11/10 FCC ID: CASTMAC0C Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, (Tait Electronics Limited), hereby request confidentiality for the Block diagrams, Schematics, Parts Lists, Tune up and Operational Description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. Steve Crompton Tait Electronics Limited

Justification Letter – Extended Frequency Range FCC ID: CASTMAC0C To meet the requirements of Federal Communications Commission (F.C.C.) publication, KDB634817 - Frequency Range Listings for Certification Grants, Tait Electronics Limited submits the following attestation. This Mobile Transceiver has: 1. The design capability to operate in the frequency band 174-225 MHz. 2. Complies with 47CFR Part 90.203(e) in that the equipment operator cannot directly program transmit frequencies using the normally accessible external controls. Programming this equipment is the responsibility of Tait Electronics Limited approved Service Agents In addition to the following rule parts applied for: 80 90 90T This device may be utilised in systems operated by Federal and Public Safety agencies, as indicated in the table beneath. The Grant Note ‘EF’ should be appended to the Grant of Authorisation, indicating this operation is required. B1 Freq. Range (MHz) Part 80 Part 90K Part 90T 216-220 F/NF F/NF 220-222 F/NF NF=Non Federal, F=Federal Des Fox Compliance Cordinator Tait Electronics Limited Christchurch 11th November 2010

FCC ID:CASTMAC0C RF Exposure Calculations Safe Distance Calculations 1 : Eq 1: S = PG / (4 π R 2 ) Where: S = power density in mW per cm 2 P = net power input to the antenna in mW G= linear gain of antenna R = distance from the antenna in cm f = transmitter frequency in MHz Re-arrange to solve for R: Eq 2: R = (PG/ (4 π S)) -2 Limits: From CFR 47 1.1310, for controlled environment S = 1 mW per cm 2 At 216 MHz and 222 MHz S = 1 mW per cm 2 Net input power to antenna: Manufacturer’s rated power is 25 Watts. FCC CFR Pt 90.205 (s) requires an additional 20% allowance: (25/100) x 120 = 30 Watts FCC CFR 47 pt 2.1091 PTT duty cycle power averaging, PTT duty cycle of 50% 2 : Pnet = 15 watts. Antenna types: The recommended antennas are a quarter wave whip with a gain of 0dBd, a 5/8 whip with a gain of 3dBd, or a co-linear whip with 5dBd gain: Antenna Gain, dBd 0 35 Antenna Gain, Linear 1.64 3.275.19 MPE calculations for these antennas for minimum safe distance are given for the bottom and top of the allocated frequency bands: 216 and 222 MHz: 222MHz and 216 MHz Antenna Type 0dBd3dBd5dBd P mW 15000.0015000.0015000.00 Linear Gain G 1.643.275.19 4πS 4.074.074.07 R=√(PG/4πS) 44.2562.579 Results: Minimum safe Distance centimetres, Controlled limit: Antenna Gain, dBd 035 216 MHz and 222 MHz 44.2562.579 References: 1. FCC OET Bulletin 65 Edition 97-01, Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields, p. 19. 2. Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies. 447498 D01 Mobile Portable RF Exposure v04, FCC Knowledge Database. END

TELTEST Laboratories Tait Electronics Limited Report Number 3222 TELTEST Laboratories – A Division of Tait Electronics Limited Telephone: 64 3 358 3399, Fax: 64 3 358 0432 PO Box 1645, 558 Wairakei Road, Christchurch, New Zealand Page 1 of 71 Laboratory Test Report RADIO PERFORMANCE MEASUREMENTS for the TMAC0C Mobile Transceiver Tested In accordance with FCC 47 CFR Parts 80, 90K and 90T Report Revision: 1 Issue Date: 8-November-2010 FCC ID: CASTMAC0C PREPARED BY: Garry Pringle ___________________ Test Technician CHECKED & APPROVED BY: Steve Crompton ___________________ Laboratory Manager All tests reported herein have been performed in accordance with the laboratory's scope of accreditation This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. TELTEST Laboratories Tait Electronics Limited Report Number 3222 FCC ID: CASTMAC0C Page 2 of 71 Report Revision: 1 Issue Date: 8-November-2010 TABLE OF CONTENTS REVISION HISTORY ................................................................................................................3 INTRODUCTION ....................................................................................................................... 4 REPORT PREPARED FOR ...................................................................................................... 4 DESCRIPTION OF SAMPLE .................................................................................................... 4 STATEMENT OF COMPLIANCE ............................................................................................. 4 TEST CONDITIONS .................................................................................................................. 4 MODULATION TYPES AND EMISSION DESIGNATORS ...................................................... 5 TEST RESULTS........................................................................................................................ 6 TRANSMITTER OUTPUT POWER (CONDUCTED) ............................................................. 6 TRANSMITTER AUDIO FREQUENCY RESPONSE - PRE-EMPHASIS............................... 7 TRANSMITTER MODULATION LIMITING .......................................................................... 11 OCCUPIED BANDWIDTH ................................................................................................... 17 ANALOG VOICE.............................................................................................................. 18 FFSK – 1200 bps............................................................................................................. 28 FFSK – 2400 bps............................................................................................................. 38 THSD................................................................................................................................48 SPURIOUS EMISSIONS (CONDUCTED) ........................................................................... 58 SPURIOUS EMISSIONS (RADIATED) ................................................................................ 61 TRANSMITTER FREQUENCY STABILITY (TEMPERATURE) .......................................... 64 TRANSMITTER FREQUENCY STABILITY (VOLTAGE)..................................................... 68 TEST EQUIPMENT USED................................................................................................... 69 ANNEX A................................................................................................................................. 70 TEST SETUP DETAILS ....................................................................................................... 70 TELTEST Laboratories Tait Electronics Limited Report Number 3222 FCC ID: CASTMAC0C Page 3 of 71 Report Revision: 1 Issue Date: 8-November-2010 REVISION HISTORY Date Revision Comments 8-November-2010 1 Initial test report TELTEST Laboratories Tait Electronics Limited Report Number 3222 FCC ID: CASTMAC0C Page 4 of 71 Report Revision: 1 Issue Date: 8-November-2010 INTRODUCTION Type Approval Testing of the TMAB22-C001A Serial No 19578172 174 MHz Æ 225 MHz in accordance with: FCC CFR 47 Parts 80, 90K & 90T REPORT PREPARED FOR Tait Electronics Ltd PO Box 1645 558 Wairakei Rd Christchurch New Zealand DESCRIPTION OF SAMPLE Manufacturer Tait Electronics Limited Equipment: Mobile Transceiver Type: TMAC0C Product code: TMAB22-C001A Serial Numbers: 19578172 Quantity: 1 Hardware & Software Control Head Type Code and Version Hardware ID TMAC40-0000_0004 Boot Code QCA2B_std_2.01.00.0002 Radio Application QCA2F_std_6.01.00.0051 FPGA Image QCA2G_std_2.01.00.0001 Torso Hardware ID TMAB22-C000_0201 Boot Code QMA2B_std_2.01.00.0002 DSP QMA2A_std_6.01.00.0051 Radio Application QMA2F_std_6.01.00.0051 FPGA Image QMA2G_s01_2.01.00.0001 STATEMENT OF COMPLIANCE The TMAB22-C001A Mobile transceiver as tested in this report was found to conform to the following standards: FCC CFR 47 Parts 80, 90K (216 Æ 220MHz), & 90T (220 Æ 222MHz) TEST CONDITIONS All testing was performed at the following conditions. Ambient Temperature 15 o C Æ 30 o C Relative Humidity 20% Æ 75% Standard Test Voltage 13.8 V DC TELTEST Laboratories Tait Electronics Limited Report Number 3222 FCC ID: CASTMAC0C Page 5 of 71 Report Revision: 1 Issue Date: 8-November-2010 MODULATION TYPES AND EMISSION DESIGNATORS Modulation Types: F3E Analog FM F2D FFSK Data ( 1200 bps, 2400 bps) F1D THSD (12000 bps, 19200 bps) Channel Spacings: 12.5 kHz, 25.0 kHz Emission Designators: Analog FM 11k0F3E, 16k0F3E FFSK Data 1200 bps 6k60F2D, 9k60F2D FFSK Data 2400 bps 7k80F2D, 10k8F2D THSD Data 12000 bps 7k70F1D, ~ 19200 bps ~ 12k7F1D TELTEST Laboratories Tait Electronics Limited Report Number 3222 FCC ID: CASTMAC0C Page 6 of 71 Report Revision: 1 Issue Date: 8-November-2010 TEST RESULTS TRANSMITTER OUTPUT POWER (CONDUCTED) SPECIFICATION: FCC 47 CFR 2.1046 GUIDE: TIA/EIA-603C 2.2.1 MEASUREMENT PROCEDURE: 1. Refer Annex …

Text truncated - open the document above for the full version.
