CASTMAH5DMobile Transceiver

MMA-00003-02 Issue 2 © Tait Electronics Ltd September 2004. All rights reserved. Directive 1999/5/EC Declaration Directive 1999/5/EC Declaration of Conformity daDansk Undertegnede Tait Electronics Ltd erklærer herved, at følgende udstyr TMAB1C, TMAD1C & TMAH5C overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Se endvidere: http://eudocs.taitworld.com/ deDeutsch Hiermit erklärt Tait Electronics Ltd die Übere- instimmung des Gerätes TMAB1C, TMAD1C & TMAH5C mit den grundlegenden Anforderungen und den anderen relevanten Festlegungen der Richtlinie 1999/5/EG. Siehe auch: http://eudocs.taitworld.com/ elΕλληνικός Με την παρουσα Tait Electronics Ltd δηλωνει οτι TMAB1C, TMAD1C & TMAH5C συμμορφωνεται προσ τισ ουσιωδεισ απαιτησεισ και τισ λοιπεσ σχετικεσ διαταξεισ τησ οδηγιασ1999/5/ΕΚ. βλέπε και: http://eudocs.taitworld.com/ enEnglish Tait Electronics Ltd declares that this TMAB1C, TMAD1C & TMAH5C complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. See also: http://eudocs.taitworld.com/ esEspañol Por medio de la presente Tait Electronics Ltd declara que el TMAB1C, TMAD1C & TMAH5C cumple con los requisitos esen- ciales y cualesquiera otras disposiciones apli- cables o exigibles de la Directiva 1999/5/CE. Vea también: http://eudocs.taitworld.com/ fiSuomi Tait Electronics Ltd vakuuttaa täten että TMAB1C, TMAD1C & TMAH5C tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Katso: http://eudocs.taitworld.com/ frFrançais Par la présente, Tait Electronics Ltd déclare que l'appareil TMAB1C, TMAD1C & TMAH5C est conforme aux exigences essentielles et aux autres dispositions perti- nentes de la directive 1999/5/CE. Voir aussi: http://eudocs.taitworld.com/ itItaliano Con la presente Tait Electronics Ltd dichiara che questo TMAB1C, TMAD1C & TMAH5C è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Vedi anche: http://eudocs.taitworld.com/ nlNederlands Hierbij verklaart Tait Electronics Ltd dat het toestel TMAB1C, TMAD1C & TMAH5C in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/ EG. Zie ook: http://eudocs.taitworld.com/ ptPortuguês Tait Electronics Ltd declara que este TMAB1C, TMAD1C & TMAH5C está conforme com os requisitos essenciais e outras provisões da Directiva 1999/5/CE. Veja também: http://eudocs.taitworld.com/ svSvensk Härmed intygar Tait Electronics Ltd att denna TMAB1C, TMAD1C & TMAH5C står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. Se även: http://eudocs.taitworld.com/ 2 About this guide3 About this guide This user’s guide provides information about TM8200 radios and is divided into two parts.
Part 1 explains how the TM8250 radio with the graphical display operates.
Part 2 outlines the installation procedure for all TM8200 radios. If you need further assistance or your radio does not operate as you expect, contact your radio provider. Important safety information This user’s guide also contains important safety and compli- ance information about using and installing TM8200 radios. Refer to page 11 for user safety and compliance instructions and page 42 for installation safety instructions. Safety warnings used in this guide Within this guide, the following conventions are used to alert you to important safety information: Warning:There is a potential risk of death or serious injury. Caution:There is the risk of minor or moderate injury to people. Caution:“Caution” is used without the safety alert symbol when there is a risk of equipment damage or malfunction. Feedback about this guide If you have any enquiries regarding this guide, or any comments, suggestions and notifications of errors, please contact Technical Support at [email protected]. 4About this guide Changes to this guide In the interests of improving the performance, reliability or servicing of the equipment, Tait Electronics Ltd reserves the right to update both the equipment or this user’s guide, with- out prior notice. Website: For contact details and technical assistance, go to http://www.taitworld.com/, and http://support.taitworld.com/. Copyright information All information contained in this guide is the property of Tait Electronics Ltd. All rights are reserved. These guides may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-readable form, without prior written permission from Tait Electronics Ltd. All trade names referenced are the service mark, trademark, or registered trademark of the respective manufacturers. Disclaimer There are no warranties extended or granted by this guide. Tait Electronics Ltd accepts no responsibility for damage aris- ing from use of the information contained in the guide or of the equipment and software it describes. It is the responsibil- ity of the user to ensure that use of such information, equip- ment and software complies with the laws, rules and regulations of the applicable jurisdictions. Your radio’s settings Use the following table to list your radio’s programmed settings. Frequently used channels and groups Function key settings quick access menus: IDDescriptionIDDescription scroll keys on/off key volumecontrol microphonesocket press-to talk key(PTT) red display speaker green amber microphone radio status LEDs function keys1 to 4 left selection key right selection key Main menu Navigating your radio’s menus Main menu: conventional modeNote: Only features programmed for your radio will be available. Radio operation9 Part 1: Radio operation About this guide .......................................................................... 3 Important safety information ....................................................................... 3 Safety warnings used in this guide ..........................…

Text truncated - open the document above for the full version.

TELTEST Laboratories Tait Electronics Ltd PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone:(64) (3) 3583399 Fax:(64) (3) 3580432 29 September 2004 To whom it may concern TMAH5D The following ‘Note’ is part of the Service Manual and can be found on Page 39, Part 3 Disassembly and Assembly of Radio : Introduction ...Note: The frequency ranges 156.8 MHz ± 375 kHz, 243 MHz ± 5 kHz, and 406.0 to 406.1 MHz are reserved worldwide for use by distress beacons. Do not program transmitters to operate in any of these frequency bands. Your’s faithfully, Des Fox Compliance Co-ordinator Mobile Radio Service ManualDisassembly and Re-assembly of Radio39 October 2003 © Tait Electronics Limited 3Disassembly and Re-assembly of Radio IntroductionThis section covers the disassembly and re-assembly procedures entailed in level-1 repairs of the radio. These procedures are: ■detachment of control head ■disassembly of control head ■disassembly of radio body ■re-assembly of radio body ■re-assembly and attachment of control head The procedures are detailed in Subsection 3.1 to Subsection 3.5 respectively. A brief outline of the overall level-1 repair procedure itself is given below. ImportantObserve anti-static precautions when servicing the radio in order to avoid damage caused by static discharges. NoteThe frequency ranges 156.8 MHz ± 375 kHz, 243 MHz ± 5 kHz, and 406.0 to 406.1 MHz are reserved worldwide for use by distress beacons. Do not program transmitters to operate in any of these frequency bands. Outline of level-1 repair procedure For level-1 repairs first determine whether the control head or radio body is faulty. Do so by exchanging the control head for a spare control head. (Detach the control head as described in Subsection 3.1.) If the fault is rectified, the original control head is faulty; if not, the radio body is faulty. In the case of a faulty two-digit control head, also exchange the control-head loom for a spare loom. If the fault is rectified, the original loom is faulty; if not, the control head itself is faulty. After thus isolating the fault, repair a faulty control head and a faulty radio body as indicated in the following two paragraphs respectively. Control head is faultyIf the control head is faulty, first inspect the control head for obvious damage as described in Subsection 3.1. Replace any damaged part or assembly; this might require removing the control-head board as described in Subsection 3.2. If there is no obvious damage, replace the control-head board. In either case, re-assemble the radio as described in Subsection 3.5, and subject the radio to a final test.

FCC ID: [CASTMAH5D] Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, (Tait Electronics Limited), hereby request confidentiality for the [Block diagrams, Schematics, Parts Lists, Tune up and Operational Description] presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. [Steve Crompton] [Tait Electronics Limited]

TELTEST Laboratories Tait Electronics Limited Report Number 2091 FCC ID: CASTMAH5D Page 1 of 41 REPORT NUMBER 2091SEPTEMBER 2004 RADIO PERFORMANCE MEASUREMENTS On the TMAB24-H501 Mobile Transceiver FCC ID: CASTMAH5D SN: 19019124 In accordance with FCC 47 CFR Parts 22 and 90 PREPARED BY:Garry Pringle___________________ Test Technician CHECKED & APPROVED BY:Hamish Newton___________________ Senior Technician TELTEST Laboratories Tait Electronics Limited PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone : (64) (3) 3583399 Fax: (64) (3) 3580432 TELTEST Laboratories Tait Electronics Limited Report Number 2091 FCC ID: CASTMAH5D Page 2 of 41 REPORT ON : Type Approval Testing of the TMAB24-H501 (Serial No 19019124) in accordance with: FCC CFR 47 Parts 22 & 90 FCC ID: CASTMAH5D PREPARED FOR : Tait Electronics Ltd PO Box 1645 558 Wairakei Rd Christchurch New Zealand DISTRIBUTION : TELTest LaboratoryMr S CromptonCopy No 1 Tait Electronics LtdMr. Des Fox Copy No 2 Tait Electronics LtdMr. Dereck FiddesCopy No 3 APPROVED : Hamish Newton Senior Technician Date : All tests reported herein have been performed in accordance with the laboratory's scope of accreditation This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. Copy No: TELTEST Laboratories Tait Electronics Limited Report Number 2091 FCC ID: CASTMAH5D Page 3 of 41 TABLE OF CONTENTS DECLARATION OF CONFORMITY................................................................................................. 4 TEST CONDITIONS ............................................................................................................................. 5 NECESSARY BANDWIDTH AND EMISSION DESIGNATORS ................................................... 5 TEST RESULTS..................................................................................................................................... 7 TRANSMITTER OUTPUT POWER (CONDUCTED) ...................................................................... 7 TRANSMITTER AUDIO FREQUENCY RESPONSE - PRE-EMPHASIS ....................................... 8 TRANSMITTER MODULATION LIMITING ................................................................................. 10 OCCUPIED BANDWIDTH ..............................................................................................................12 SPURIOUS EMISSIONS (CONDUCTED)....................................................................................... 25 SPURIOUS EMISSIONS (RADIATED)........................................................................................... 28 TRANSMITTER FREQUENCY STABILITY (TEMPERATURE) ................................................. 31 TRANSIENT FREQUENCY BEHAVIOR ....................................................................................... 34 TEST EQUIPMENT USED................................................................................................................. 39 APPENDIX A ....................................................................................................................................... 40 TEST SETUP DETAILS.................................................................................................................... 40 TELTEST Laboratories Tait Electronics Limited Report Number 2091 FCC ID: CASTMAH5D Page 4 of 41 DECLARATION OF CONFORMITY We, TELTEST LABORATORIES of 558 Wairakei Road, Christchurch New Zealand, declare under our sole responsibility that the product: Equipment:Mobile Transceiver Type:TMAH5D Product code:TMAB24-H501 Serial Numbers:19019124 Quantity:1 To which this declaration relates is in conformity with the following standards: FCC CFR 47 Parts 22 & 90 Signature:__________________________ S. A. Crompton Compliance Laboratory Manager. Date:__________ TELTEST Laboratories Tait Electronics Limited Report Number 2091 FCC ID: CASTMAH5D Page 5 of 41 Test Conditions All testing was performed at the following conditions. Ambient Temperature15 o C to 30 o C Relative Humidity20% to 75% Standard Test Voltage13.8Vdc Necessary Bandwidth and Emission Designators SPECIFICATION:FCC 47 CFR 2.202 The Necessary Bandwidth is the minimum value of the occupied bandwidth sufficient to ensure the transmission of information at the rate and with the quality required for the system employed. This is calculated using the following formula. Bn = 2M + 2DKWhere: Bn = Necessary Bandwidth M = Maximum modulation frequency For Data transmission M = B/2 Where: B = Modulation rate in Baud D = Peak deviation K = Constant For Analogue transmission this is 1 For Data transmission this is typically 1.2 1. Analogue Voice 12.5kHz Bandwidth Necessary bandwidthEmission Designator M = 3kHz11k0F3E D = 2.5kHz F3E represents a FM voice transmission Bn = 6 + 5 x 1 =11kHz 2. Analogue Voice 25kHz Bandwidth Necessary bandwidthEmission Designator M = 3kHz16k0F3E D = 5kHz F3E represents a FM voice transmission Bn = 6 + 10 x 1 =16kHz 3. Fast Frequency Shift Keying (FFSK) 12.5kHz Bandwidth Necessary bandwidthEmission Designator M = 0.6 (Baud rate = 1200)4k80F2D D = 1.5kHz (60% of peak deviation) F2D represents a FM data transmission with the use of a modulating sub carrier Bn = 1.2 + 3 x 1.2 =4.8kHz TELTEST Laboratories Tait Electronics Limited Report Number 2091 FCC ID: CASTMAH5D Page 6 of 41 4. Fast Frequency Shift Keying (FFSK) 25kHz Bandwidth Necessary bandwidthEmission Designator M = 0.6 (Baud rate = 1200)8k40F2D D = 3kHz (60% of peak deviation) F2D represents a FM data transmission with the use of a modulating sub carrier Bn = 1.2 + 6 x 1.2 =8.4kHz 5. Tait High Speed Date (THSD) THSD uses a 4 level gaussian frequency shift keying (CP-4GFSK) modulation scheme. It can be used when transferring data between two radios. Data is transmitted at a rate of 12000bps for narrow band channels, and 19200bps for wide-band channels. Due to the difficulties in determining the value of k, the necessary bandwidth has been measured usin…

Text truncated - open the document above for the full version.

FCC ID: CASTMAH5DPage 1 of 10 REPORT NUMBER 2091MPEFCC ID: CASTMAH5D TELTEST Laboratories Tait Electronics Limited PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone : (64) (3) 3583399 Fax: (64) (3) 3580432 TEST: FCC 47 CFR 1.1310 Maximum Permissible Exposure ENVIRONMENTAL ASSESSMENT On the TMAB24-H501 Mobile Transceiver S/N: 19019124 In accordance with ANSI/IEEE Std C95.1, 1999 OET Bulletin 65 97-01 and Supplement C (Edition 01-01) DATE:August 2004 PREPARED BY:Hamish Newton__________________ Test Technician CHECKED & APPROVED BY:SA Crompton __________________ Laboratory Manager This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. FCC ID: CASTMAH5DPage 2 of 10 TABLE OF CONTENTS Page SUMMARY OF RESULTS ................................................................................................................... 3 OPERATING CONDITIONS AND EXPOSURE CONDITIONS .................................................... 4 LIMITS ................................................................................................................................................... 4 RECOMMENDED ANTENNAS .......................................................................................................... 4 MEASUREMENT GUIDANCE ...........................................................................................................4 TEST RESULTS, TRANSMITTER POWER ..................................................................................... 5 TEST RESULTS, MPE.......................................................................................................................... 6 TEST EQUIPMENT LIST .................................................................................................................... 7 INFORMATION TO BE PLACED IN MANUAL.............................................................................. 8 APPENDIX 1 TEST POSITIONS DIAGRAM.................................................................................... 9 FCC ID: CASTMAH5DPage 3 of 10 Summary of Results: Antenna GainAntenna PositionMeasurement PositionResult 2.15 dBi RoofExternal: Side COMPLIES 5.65 dBi RoofExternal: Side COMPLIES 5.65 dBi TrunkExternal: Rear Side COMPLIES 5.65 dBi TrunkExternal: Rear Corner COMPLIES 5.65 dBi TrunkExternal: Centre rear COMPLIES 2.15 dBi RoofInternal: Front Seat COMPLIES 2.15 dBi RoofInternal: Back Seat COMPLIES 5.65 dBi RoofInternal: Front Seat COMPLIES 5.65 dBi RoofInternal: Back Seat COMPLIES 5.65 dBi TrunkInternal: Front Seat COMPLIES 5.65 dBi TrunkInternal: Back Seat COMPLIES See Appendix A for details of the measurement positions. FCC ID: CASTMAH5DPage 4 of 10 Operating and Exposure conditions: Operating Conditions:Mobile transmitter using vehicle mounted antennas only Exposure conditions:Occupational/Controlled Exposure (operator). General Population/Uncontrolled (passengers and bystanders) Safe Distance: Recommended Minimum lateral safe distance from the antenna:90 cm Limit: Occupational/Controlled Exposure: 30 - 300 MHz: 1.0 mW/cm 2 300 – 1500 MHzf/300 for test frequency of 463.725MHz = 1.55 mW/cm 2 General population/Uncontrolled Exposure: 30 - 300 MHz: 0.2 mW/cm 2 300 – 1500 MHzf/1500 for test frequency of 463.725MHz = 0.31 mW/cm 2 Recommended Antennas: Antenna Type:Monopole (λ/4 antenna) Antenna Gain:2.15 dBi Antenna Type:Monopole (Collinear antenna) Antenex AB4503C Antenna Gain:5.65 dBi Measurement Guidance: 2) Mobile PTT – Parts 80, 90 a) §2.1033(c)(3) requires device operating and installation instructions to be submitted during equipment certification; instructions should include the minimum separation distance and other constraints required for the device and its antenna(s) to meet MPE limits b) Per definition of a mobile device a minimum separation distance of 20 cm is required FCC ID: CASTMAH5DPage 5 of 10 i) Antenna installation conditions should maintain the estimated minimum MPE separation distance ii) A separation distance based on MPE evaluation (measurement or computer modeling) that is smaller than the estimated MPE distance may be used if it is applicable for the antenna installation conditions c) Basic RF exposure instructions are requested for devices that meet general population exposure requirements, as part of the §2.1033(c)(3) required operating instructions; RF exposure training instructions and labeling info are requested for devices that satisfy occupational exposure requirements Federal Communications Commission OET Laboratory Division March 18, 2004 Test Results: NAME OF TEST:TRANSMITTER OUTPUT POWER (CONDUCTED) TEST CONDITIONS:Ambient Temperature22 o C Relative Humidity35 % SPECIFICATION:FCC 47 CFR 2.1046 GUIDE:TIA/EIA-603 2.2.1 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was connected to an RF Power meter using a coaxial attenuator with an impedance of 50 Ohms. 2. The unmodulated output power was measured. MEASUREMENT RESULTS: Transmit Frequency:463.725MHz Manufacturer’s Rated Output Power40Watts Supply Voltage, motor idling, transmitting.13.64Volts Measured Output Power41.86Watts Measurement Uncertainty (dB) ± 0.5 dB Maximum Transmit Power is set in the factory to 41.6 watts +2 / -1 watt. This setting is not adjustable by the user. The MPE results are scaled to simulate results from a 43.6 watt carrier with a 50% duty cycle. FCC ID: CASTMAH5DPage 6 of 10 NAME OF TEST:ENVIRONMENTAL ASSESSMENT SPECIFICATION:FCC 47 CFR 1.1310 Measurement Method: Field strength measurements were performed for two antenna positions on a representative vehicle (Honda Accord 2001 LXI four door sedan, dimensions 185.5 long, 71.5 wide and 57.1 inches high ). See Appendix A for details. External Field strength readings were recorded at four positions 20 cms from the car body, to represent the closest position for a bystander. Measurements were taken at 20 cm intervals vertically over a height of 2 metres. Internal field strength readings were recorded in the …
