© Tait Electronics Ltd May 2003About this Guide1 About this Guide This user’s guide provides information about both TM8105 and TM8115 mobile radios and is divided into two parts. Part A explains how the TM8115 radio operates. The TM8105 radio has a control head without user con- trols, so no TM8105 operating information is needed. Part B outlines the installation procedure for both TM8105 and TM8115 radios, and gives the interface specifications for the TM8105 remote connector. Important Safety Information This user’s guide also contains important safety informa- tion about using and installing TM8105 and TM8115 radios. Refer to page 6 for user safety instructions and page 18 for installation safety instructions. Updating this Guide In the interests of improving the performance, reliability or servicing of the equipment, Tait Electronics Ltd reserves the right to update both the equipment or this user’s guide, without prior notice. 2About this Guide Your Radio’s Settings Use the following table to list your radio’s programmed settings. Channel List Function Key Settings IDDescriptionIDDescription Radio Operation5 Part 1: Radio Operation About this Guide ...........................................................................1 Important Safety Information ....................................................................... 1 Updating this Guide .................................................................................... 1 Safety Warnings ...........................................................................6 Warning: Safe Operation ....................................................................... 6 Warning: High Temperatures ................................................................. 6 Warning: FCC RF Exposure Limits ..........................................................6 Caution: Radio Protection ...................................................................... 7 Getting Started .............................................................................8 Radio Controls ............................................................................................ 8 Radio Indicators ........................................................................................ 10 LED Indicators ..................................................................................... 10 Audible Indicators ............................................................................... 10 Basic Operation ...........................................................................11 Turning the Radio On and Off .................................................................... 11 Adjusting the Volume ................................................................................ 11 Selecting a Channel .................................................................................. 11 Making a Call ........................................................................................... 11 Transmit Timer .................................................................................... 12 Receiving a Call ........................................................................................ 12 What You Hear on a Channel .................................................................... 12 Signalling Mute ................................................................................... 12 Squelch ............................................................................................... 13 Monitor .................................................................................................... 13 Activating Monitor .............................................................................. 13 Activating Squelch Override ................................................................. 13 Scanning ................................................................................................... 14 Activating Scanning ............................................................................ 14 Nuisance Delete .................................................................................. 14 Priority Scanning ................................................................................. 14 Troubleshooting .........................................................................15 Removing the Radio from the Vehicle ........................................................ 15 Notes ............................................................................................16 6Safety Warnings Safety Warnings Warning: Safe Operation Switch the radio off at petrol filling stations or near flammable liquids or gases. Switch the radio off in the vicinity of explo- sive devices and blasting zones. Using a handheld microphone or a radio while driving a vehicle may violate the laws and legislation that apply in your country or state. Please check the vehicle regulations in your area. Warning: High Temperatures The bottom surface of the radio and the heatsink fins can become hot during prolonged operation. Do not touch these parts of the radio. Warning: FCC RF Exposure Limits This product generates RF (radio frequency) energy during transmissions. This device must be restricted to work-related use in an occupational/controlled expo- sure environment. The radio operator must have control of the exposure conditions and duration of all persons exposed to the antenna of this transmitter to satisfy FCC RF exposure compliance. This device is not approved for general population use. This device must only be used with authorized acces- sories and antennas. The operator must ensure that the minimum safe dis- tance of 0.9 m (35 inches) between persons and the antenna is maintained during transmissions. Safety Warnings7 This minimum safe distance is based on the assump- tion that there is a duty cycle of 50% transmit mode to stand-by or receive modes. The radio is in transmit mode when the PTT (press-to-talk) key on the micro- phone is pressed and th…
Text truncated - open the document above for the full version.
FCC ID: [CASTMAH6A] Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, (Tait Electronics Limited), hereby request confidentiality for the [Block diagram, Schematic and Product description] presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. [Steve Crompton] [Tait Electronics Limited]
Pos Item Description Len Qt y Units Effective Exp StdCost W/H Circuit References 10 008-00031-01 LCD Fm1 W/Border TMA 0 1 ea 10-Jul-03 TELMR2 LCD1 20 209-00011-00 Strip Fm1 LCD Elastomeric Conn 0 2 ea 10-Jul-03 TELMR2 30 219-02882-00 Loom Control Head TMA 0 1 ea 10-Jul-03 TELMR2 40 240-00021-41 Hdr Pin 18w 2Row 2.54mm Str 0 1 ea 10-Jul-03 TELMR2 50 252-00011-00 Spkr 45mm 4w 160hm Foster 0 1 ea 10-Jul-03 TELMR2 60 262-00003-00 Lightpipe Key Indicator-S TMA 0 2 ea 10-Jul-03 TELMR2 70 262-00004-00 Lightpipe Key Indicator-L TMA 0 2 ea 10-Jul-03 TELMR2 80 307-01024-00 Grille Spkr Cloth TMA 0 1 ea 10-Jul-03 TELMR2 90 311-01054-00 Knob Vol Ctrl w D-Spring TMA 0 1 ea 10-Jul-03 TELMR2 100 311-03114-01 K/Pad FM1 TMA 0 1 ea 10-Jul-03 TELMR2 110 312-01095-00 Lens Fm1 TMA Tait El 0 1 ea 10-Jul-03 TELMR2 140 346-10030-08 Scrw P/T Wn1412 Kc30x08 Zbc 0 3 ea 10-Jul-03 TELMR2 150 365-01639-00 Lbl Blank 25x9mm Z-Ultimate 0 1 ea 10-Jul-03 TELMR2 160 365-01717-01 Lbl Tait EL TM8115 TMA 0 1 ea 10-Jul-03 TELMR2 170 XMAC20 2 Dig Ctrl Hd Pca 0 1 ea 10-Jul-03 TELMR2 210 316-06786-01 Pnl Frt Fm1 TMA 0 1 ea 11-Aug-03 TELMR2 220 319-30073-01 Spcr Frame Fm1 TMA 0 1 ea 11-Aug-03 TELMR2 180 399-00010-86 Bag Static Shlding 127x203mm 0 1 ea 10-Jul-03 TELMR2 190 410-01183-01 Pkg Box 70X210X70 TMA 0 1 ea 10-Jul-03 TELMR2 200 410-01186-01 Pkg Ins Ctrl Hd TMA 0 1 ea 10-Jul-03 TELMR2 230 365-00011-38 Lbl Static Warning Yel 0 1 ea 19-Aug-03 TELMR2 BOM for TMAC20-0T revision 003 65 - Carcassin g 80 - Final Assembl y /Pac k
Pos Item Description Len Qt y Units Effective Exp StdCost W/H Circuit References 10 001-10002-02 Diode SMD BB202 VCAP SOD523 0 1 ea 19-Jun-03 TELMS6 D2 30 002-10054-02 IC SMD TMS320VC5402 144TQFP 0 1 ea 19-Jun-03 TELMS6 IC2 40 002-10093-66 IC 93C66 4k Serial Eeprom Tsop 0 1 ea 26-Aug-03 TELMS6 IC6 50 002-10793-18 IC TPS79318 1V8 LD0 200mA Reg 0 1 ea 19-Jun-03 TELMS6 IC10 60 002-12880-00 IC 28W800 Bot Flash 90ns Tsop 0 1 ea 19-Jun-03 TELMS6 IC5 70 002-74910-41 IC SMD 74V1G04 Inverter SC70 0 1 ea 19-Jun-03 TELMS6 IC4 80 014-08100-30 Cap Tant SMD 100u 10v Loesr D 0 2 ea 19-Jun-03 TELMS6 C48, C49 120 018-13150-00 Cap 0603 150p 50v NPO +-5% 0 2 ea 19-Jun-03 TELMS6 C51, C52 130 018-16100-00 Cap 0603 100n 16vx7r+- 10% 0 32 ea 27-Aug-03 TELMS6 C10, C12, C17, C23, C24, C25, C26, C27, C28, C29, C31, C32, C33, C34, C35, C36, C37, C38, C39, C4, C43, C44, C45, C46, C50, C57, C58, C59, C60, C61, C7, C9 150 038-13470-00 Res 0603 470e 1/16w +- 5% 0 2 ea 19-Jun-03 TELMS6 R23, R3 160 038-14150-00 Res 0603 1k5 1/16w +-5% 0 2 ea 19-Jun-03 TELMS6 R10, R7 180 038-15470-10 Res 0603 47k 1/16w+-1% 0 3 ea 19-Jun-03 TELMS6 R14, R26, R27 200 038-17100-00 Res 0603 1m 1/16w +-5% 0 1 ea 19-Jun-03 TELMS6 R9 210 159-77560-35 Ind SMD 0603 5.6uh 10% Smi F 0 1 ea 19-Jun-03 TELMS6 L1 420 038-10000-00 Res 0603 Zero 0hm 1/16w +-5% 0 1 ea 25-Jun-03 TELMS6 R16 430 038-12100-00 Res 0603 10e 1/16w +-5% 0 1 ea 25-Jun-03 TELMS6 R17 460 018-11180-10 Cap 0603 1p8 50v NPO+- 0.1p 0 1 ea 7-Jul-03 TELMS6 C55 470 018-12180-10 Cap 0603 18p 50v NPO +- 1% 0 2 ea 7-Jul-03 TELMS6 C53, C54 480 018-12100-10 Cap 0603 10p 50v NPO+- 0.1 0 1 ea 26-Aug-03 TELMS6 C68 BOM for XMABP10 revision 00 5 35 - SMD To p Side 490 038-15100-10 Res 0603 10k 1/16w +-1% 0 1 ea 27-Aug-03 TELMS6 R4 500 038-16100-10 Res 0603 100k 1/16w +- 1% 0 1 ea 26-Aug-03 TELMS6 R12 510 220-01698-03 Pcb Dgtl Mcm TMA 0 1 ea 26-Aug-03 TELMS6 PCB 230 001-10054-02 Diode SMD BAT54AW SOT-323 0 1 ea 19-Jun-03 TELMS6 D1 250 002-10741-39 IC 74LCX139 2X2T04 DCdr Tosp16 0 1 ea 19-Jun-03 TELMS6 IC3 260 002-11020-15 IC Sram 32KX16 15ns Async Tsop 0 1 ea 19-Jun-03 TELMS6 IC9 270 002-20100-60 IC SMD EP1C6T144C8 Pld 144TQFP 0 1 ea 19-Jun-03 TELMS6 IC1 280 014-08100-30 Cap Tant SMD 100u 10v Loesr D 0 2 ea 19-Jun-03 TELMS6 C21, C8 310 018-15100-00 Cap 0603 10n 50v X7r +- 10% 0 1 ea 19-Jun-03 TELMS6 C56 320 018-16100-00 Cap 0603 100n 16vx7r+- 10% 0 17 ea 27-Aug-03 TELMS6 C1, C11, C13, C14, C15, C16, C18, C19, C2, C20, C3, C30, C40, C41, C42, C5, C6 340 038-13470-00 Res 0603 470e 1/16w +- 5% 0 1 ea 19-Jun-03 TELMS6 R22 350 038-14330-00 Res 0603 3k3 1/16w +-5% 0 1 ea 19-Jun-03 TELMS6 R11 370 038-15470-10 Res 0603 47k 1/16w+-1% 0 1 ea 19-Jun-03 TELMS6 R32 390 274-10023-00 Xtal 12.288MHz Hc- 49/Sm+-30ppm 0 1 ea 19-Jun-03 TELMS6 XL1 440 018-12470-10 Cap 0603 47p 50v NPO+- 0.1 0 4 ea 25-Jun-03 TELMS6 C69, C70, C71, C72 450 038-12220-00 Res 0603 22e 1/16w +-5% 0 1 ea 25-Jun-03 TELMS6 R1 520 002-10725-15 IC SMD TPS72515 1V5 LDO 1A Reg 0 1 ea 26-Aug-03 TELMS6 IC11 530 038-15100-10 Res 0603 10k 1/16w +-1% 0 2 ea 27-Aug-03 TELMS6 R2, R5 540 038-16100-10 Res 0603 100k 1/16w +- 1% 0 2 ea 26-Aug-03 TELMS6 R13, R25 36 - SMD Bottom Side
Pos Item Description Len Qt y Units Effective Exp StdCost W/H Circuit References 10 252-00010-41 Mic Capsule Electret 2.7*6mm 0 1 ea 2-Sep-03 TELMR1 20 365-00011-38 Lbl Static Warning Yel 0 1 ea 2-Sep-03 TELMR1 30 369-01031-00 Rbbr Mic Upper A3M2751 T3K 0 1 ea 2-Sep-03 TELMR1 40 399-00010-53 Bag Plstc 150*250mm 0 1 ea 2-Sep-03 TELMR1 50 399-00010-86 Bag Static Shlding 127x203mm 0 1 ea 2-Sep-03 TELMR1 60 410-01162-00 Pkg Hdr Card Blank 0 1 ea 2-Sep-03 TELMR1 70 XMAA02-06 Pba Concealed & Dyn Mic 0 1 ea 2-Sep-03 TELMR1 80 240-10003-00 Hdr SMD 6w 2x3 Lo-Prof 2mm 0 1 ea 9-Sep-03 TELMR1 P3 90 240-10004-00 Hdr SMD 8w 2x4 Lo-Prof 2mm 0 1 ea 9-Sep-03 TELMR1 P2 BOM for TMAA02-06 revision 002 80 - Final Assembl y /Pac k
Pos Item Description Len Qt y Units Effective Exp StdCost W/H Circuit References 10 XMAB12-H600 450-530M PCA 0 1 ea 10-Jul-03 TELMR2 20 XMABM00 Rad Body Mech Std 0 1 ea 10-Jul-03 TELMR2 30 410-01184-01 Pkg Box Radio 210X210X70 TMA 0 1 ea 10-Jul-03 TELMR2 40 410-01185-01 Pkg Ins Radio Body TMA 0 1 ea 10-Jul-03 TELMR2 50 428-00002-01 S/W Licence Agreement Eng 0 1 ea 10-Jul-03 TELMR2 70 MM8100-00-03-804 U/Gde TM8105/8115 Eng/Fre/SAsp 0 1 ea 21-Aug-03 TELMR2 BOM for TMAB12-H600 revision 002 65 - Carcassin g 80 - Final Assembl y /Pac k Pos Item Description Len Qt y Units Effective Exp StdCost W/H Circuit References 10 000-10036-00 Xstr SMD BFR360F NPN Lo Noise 0 2 ea 7-Jul-03 TELMS6 Q401, Q404 20 000-10055-15 Xstr PD55015S 15w 12.5v SO10RF 0 2 ea 7-Jul-03 TELMS6 Q309, Q310 30 000-10084-71 Xstr BC847BW NPN SOT323 0 5 ea 7-Jul-03 TELMS6 Q308, Q502, Q512, Q601, Q702 40 000-10084-72 Xstr BC847BS NPN Dual SOT363 0 3 ea 7-Jul-03 TELMS6 Q200, Q507, Q508 50 000-10084-73 Xstr BC847BPNNPN/PNP SOT363 0 1 ea 7-Jul-03 TELMS6 Q701 60 000-10085-70 Xstr BC856 PNP Dual SOT363 0 2 ea 7-Jul-03 TELMS6 Q400, Q506 70 000-10085-71 Xstr SMD BC857BW PNP SOT323 0 5 ea 7-Jul-03 TELMS6 Q201, Q500, Q600, Q700, Q708 90 000-10748-90 Xstr SGA7489 Casc Gain Block 0 1 ea 7-Jul-03 TELMS6 Q303 100 000-10941-00 Xstr SMD PBR941 NPN SOT23 0 2 ea 7-Jul-03 TELMS6 Q504, Q510 110 000-10951-00 Xstr SMD PBR951 NPN SOT23 0 1 ea 7-Jul-03 TELMS6 Q300 120 001-10012-50 Diode SMD MA4P1250 Pin3x2mm 0 2 ea 7-Jul-03 TELMS6 D307, D310 130 001-10015-00 Diode SMD BAT15-099R Sch 0 1 ea 7-Jul-03 TELMS6 D405 140 001-10057-02 Diode SMD BBY57-02v Vcap Sc-79 0 3 ea 7-Jul-03 TELMS6 D401, D402, D403 150 001-10070-01 Diode BAV70W Dual Ss SOT323 0 2 ea 7-Jul-03 TELMS6 D703, D710 160 001-10070-07 Diode BAS70-07w Dualsch SOT343 0 2 ea 7-Jul-03 TELMS6 D304, D305 170 001-10084-33 Diode SMD BZX84C3V3 Zen SOT23 0 1 ea 7-Jul-03 TELMS6 D704 180 001-10084-62 Diode SMD BZX84C6V2 Zen SOT23 0 1 ea 7-Jul-03 TELMS6 D721 BOM for XMAB12-H600 revision 01 2 35 - SMD To p Side 190 001-10099-01 Diode BAV99w Dual Ss 0 11 ea 7-Jul-03 TELMS6 D301, D400, D503, D700, D701, D702, D709, D719, D720, D722, D726 200 002-10009-00 IC LF90CPT V/LO DROP OUT 9VREG 0 1 ea 7-Jul-03 TELMS6 IC601 210 002-10045-50 IC SMD AK455OVT Codec Tssop-16 0 1 ea 7-Jul-03 TELMS6 IC205 220 002-10065-21 IC AD6521ACA Dual Codec 0 1 ea 7-Jul-03 TELMS6 IC204 230 002-10072-20 IC LMV722 2X0PAMP L/Noise Msop 0 1 ea 7-Jul-03 TELMS6 IC502 240 002-10151-90 IC SMD TDA1519C 2x11w Aud Pwr 0 1 ea 7-Jul-03 TELMS6 IC202 250 002-10266-70 IC SMD RF2667 Quad Demod Q-Sop 0 1 ea 7-Jul-03 TELMS6 IC400 270 002-14111-00 IC SMD ADF4111BRU PLL Tssop20 0 1 ea 7-Jul-03 TELMS6 IC503 280 002-16236-70 IC M62367GP 8bit 8ch D - A Ssop 0 1 ea 7-Jul-03 TELMS6 IC203 290 002-20103-24 IC BA10324 4x Op Amp Ssop-14 0 2 ea 7-Jul-03 TELMS6 IC301, IC303 300 002-74910-41 IC SMD 74V1G04 Inverter SC70 0 1 ea 7-Jul-03 TELMS6 IC500 310 002-74916-60 IC SMD 74HC1G66 Bilat Sw Sc70 0 1 ea 7-Jul-03 TELMS6 IC501 320 013-16100-05 Cap SMD PPS 100n 16v 5% 1210 0 1 ea 7-Jul-03 TELMS6 C565 330 013-16150-65 Cap Smd PPS 150n 50v 5% 4036 0 1 ea 7-Jul-03 TELMS6 C548 340 014-07470-05 Cap Tant SMD 4u7 16v 10% A 0 3 ea 7-Jul-03 TELMS6 C504, C579, C585 360 015-02680-07 Cap Cer 1111 68p 5% 500v C17cf 0 2 ea 7-Jul-03 TELMS6 C331, C334 370 015-07220-08 Cap Cer 1206 2u2 16v X7r 0 1 ea 7-Jul-03 TELMS6 C207 380 015-07470-08 Cap 1206 4u7 - 20%+80% Y5v 16v 0 1 ea 7-Jul-03 TELMS6 C531 390 015-21100-05 Cap Cer 0805 1p0 +- 0.1pf 200v 0 3 ea 7-Jul-03 TELMS6 C385, C386, C387 400 015-21120-05 Cap Cer 0805 1p2 +0.1pf 2 0 2 ea 7-Jul-03 TELMS6 C364, C366 410 015-21150-05 Cap Cer 0805 1p5 +0.1pf 200v 0 1 ea 7-Jul-03 TELMS6 C369 420 015-21180-05 Cap Cer 0805 1p8 +-0.1 200v 0 6 ea 7-Jul-03 TELMS6 C372, C373, C375, C379, C380, C381 430 015-21220-05 Cap Cer 0805 2p2 +- 0.1pf 200v 0 4 ea 7-Jul-03 TELMS6 C374, C376, C382, C383 440 015-21270-05 Cap Cer 0805 2p7 +0.1pf 200v 0 2 ea 7-Jul-03 TELMS6 C399Q, C399R 450 015-21330-05 Cap Cer 0805 3p3+- 0.1pf 200v 0 2 ea 7-Jul-03 TELMS6 C399O, C399P 460 015-21680-05 Cap Cer 0805 6p8+- 0.1pf 200v 0 2 ea 7-Jul-03 TELMS6 C354, C362 470 015-21820-05 Cap Cer 0805 8p2+- 0.1pf 200v 0 8 ea 7-Jul-03 TELMS6 C353, C355, C361, C363, C398C, C398D, C398E, C398F 480 015-22100-05 Cap Cer 0805 10p +0.1pf 200v 0 2 ea 7-Jul-03 TELMS6 C398A, C398B 490 015-22120-05 Cap 0805 12p 1% NPO 200v 0 4 ea 7-Jul-03 TELMS6 C396E, C396F, C397E, C397F 510 015-22220-05 Cap 0805 22p 1% 200v 0 3 ea 15-Jul-03 TELMS6 C321, C396B, C397B 520 015-22270-05 Cap Cer 0805 27p+- 0.1pf 200v 0 1 ea 15-Jul-03 TELMS6 C320 530 015-22330-05 Cap Cer 0805 33p+- 0.1pf 200v 0 2 ea 15-Jul-03 TELMS6 C328, C329 540 015-22680-05 Cap 0805 68p 1% 200v Grm40 0 1 ea 30-Jul-03 TELMS6 C395A 560 015-23150-01 Cap Cer 0805 150p 5% NPO 50v 0 2 ea 25-Aug-03 TELMS6 C318, C333 570 015-23150-05 Cap 0805 150p 1% 200v Grm40 0 7 ea 15-Jul-03 TELMS6 C317, C326, C327, C348, C349, C350, C389 590 015-26100-08 Cap Cer 0805 100n 10% X7r 50v 0 8 ea 7-Jul-03 TELMS6 C103, C228, C325, C330, C605, C606, C715, C733 600 015-27100-10 Cap Cer 0805 1m+80- 20% Y5v 16v 0 1 ea 7-Jul-03 TELMS6 C224 610 016-09100-07 Cap Elec SMD 100u 35v Loesr 0 1 ea 7-Jul-03 TELMS6 C604 630 018-11100-10 Cap 0603 1p0 50v NPO+ - 0.1p 0 3 ea 7-Jul-03 TELMS6 C462, C467, C578 640 018-11120-10 Cap 0603 1p2 50v NPO+ - 0.1p 0 5 ea 30-Jul-03 TELMS6 C304, C406, C432, C437, C560 660 018-11220-10 Cap 0603 2p2 50v NPO+ - 0.1p 0 1 ea 7-Jul-03 TELMS6 C433 670 018-11270-10 Cap 0603 2p7 50v NPO+ - 0.1p 0 1 ea 7-Jul-03 TELMS6 C469 680 018-11390-10 Cap 0603 3p9 50v NPO+ - 0.1p 0 3 ea 7-Jul-03 TELMS6 C367, C420, C441 690 018-11470-10 Cap 0603 4p7 50v NPO+ - 0.1p 0 2 ea 7-Jul-03 TELMS6 C400, C405 700 018-11600-10 Cap 0603 6p0 50v NPO+ - 0.1p 0 1 ea 7-Jul-03 TELMS6 C371 720 018-11820-10 Cap 0603 8p2 50v NPO+ - 0.1p 0 2 ea 15-Jul-03 TELMS6 C309, C451 730 018-12100-10 Cap 0603 10p 50v NPO+ - 0.1 0 4 ea 15-Jul-03 TELMS6 C408, C442, C443, C518 740 018-12120-10 Cap 0603 12p 50v NPO +-1% 0 1 ea 7-Jul…
Text truncated - open the document above for the full version.
TM8000 Programming Application User’s Manual 2ND DRAFT1 Part A: Getting started ......................................................................................9 Reading and programming your radio ....................................................... 11 Reading a radio .................................................................................... 11 Opening a database file ......................................................................... 11 Creating a new database file .................................................................. 11 Saving a database file ............................................................................. 12 Programming a radio ............................................................................ 12 Using the programming application ........................................................... 13 Navigating between forms .................................................................... 13 Changing access levels .......................................................................... 13 Changing the application language ........................................................ 13 Changing application start-up options ................................................... 14 Shortcut keys ........................................................................................ 14 Changing data ............................................................................................ 15 Text box .............................................................................................. 15 Drop-down box ................................................................................... 15 Check box ............................................................................................ 16 Grids .................................................................................................... 16 Transferring data ........................................................................................ 17 Creating templates ................................................................................ 17 Copying data to grids ............................................................................ 17 Copying rows within a grid .................................................................. 18 Copying individual fields ...................................................................... 18 Menu commands ....................................................................................... 20 File menu ............................................................................................. 20 Edit menu ............................................................................................ 21 Radio menu ......................................................................................... 22 Network menu ..................................................................................... 23 Tools menu .......................................................................................... 23 Help menu ........................................................................................... 24 Part B: Getting and using help .......................................................................25 Using What's This? Help ........................................................................... 27 Accessing information in the help file ......................................................... 28 Getting help on the Internet ...................................................................... 29 Part C: Programming conventional features .................................................31 Basic radio settings ..................................................................................... 33 About audible indicators ....................................................................... 33 Enabling all audible indicators .......................................................... 33 Setting the volume of audible indicators .......................................... 34 Permanently disabling individual audible indicators .......................... 34 Configuring the LCD backlight ............................................................ 34 Setting low power conditions ............................................................... 35 Setting how the radio starts ................................................................... 35 About PTT Inhibit ............................................................................... 36 Setting what happens when the PTT is keyed ....................................... 36 Setting an external alert ......................................................................... 37 Transmit, receive and monitor ................................................................... 39 About mutes ......................................................................................... 39 Restricting the transmit time and setting a lockout ................................ 39 Setting when the radio can transmit (Transmit Inhibit) .......................... 40 Bypassing repeaters (repeater talkaround) .............................................. 40 22ND DRAFT © Tait Electronics Ltd 2003 About monitor ..................................................................................... 40 Using monitor with subaudible signalling ............................................. 40 Using monitor with a closed selective system ....................................... 41 Setting how monitor is opened ............................................................ 41 Opening and closing monitor via a keypress .................................... 42 Opening and closing monitor via the hookswitch ........................... 42 Opening monitor via a press of the PTT ......................................... 42 Opening monitor when sending a selective call ............................... 42 Opening monitor when receiving a selective call ............................. 43 Setting how …
Text truncated - open the document above for the full version.
FCC ID: CASTMAH6APage 1 of 6 SUPPLEMENTARY REPORT NUMBER 1917MPEFCC ID: CASTMAH6A TEST: FCC 47 CFR 1.1310 Maximum Permissible Exposure ENVIRONMENTAL ASSESSMENT On the TMAB12-H600 Mobile Transceiver S/N: 19001381 In accordance with ANSI/IEEE Std C95.1, 1999 OET Bulletin 65 97-01 DATE:SEPTEMBER 2003 PREPARED BY:M. Ludwig___________________ Test Technician CHECKED & APPROVED BY:SA Crompton___________________ Laboratory Manager TELTEST Laboratories Tait Electronics Limited PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone : (64) (3) 3583399 Fax: (64) (3) 3580432 FCC ID: CASTMAH6APage 2 of 6 TABLE OF CONTENTS PAGE Contents: 2 Operating Conditions and Exposure conditions, Minimum Safe Distance calculations. 3 Test results, Transmitter Power. 4 Test results, MPE, Average power calculations. 5 Information to be placed in Manual 6 FCC ID: CASTMAH6APage 3 of 6 Operating and Exposure conditions: Operating Conditions:Mobile transmitter using vehicle mounted antennas only Exposure conditions:Occupational/Controlled Exposure. Minimum Safe Distance calculations: R = ( P G / 4 π S ) 1/2 Where S = power density in mW per cm 2 P = net power input to the antenna in mW R = distance from the antenna in cm G = linear gain of antenna relative to an isotropic radiator Antenna Type:Monopole (λ/4 whip) Antenna Gain:2.15 dBi Transmitter Power:25 Watts Limit:300 – 1500 MHz: f/300 mW/cm 2 For f = 463.725 MHz, s = 1.546 Power gain product:25000 x 1.64 = 41000 mW Minimum safe distance:(41000 / 4π x 1.546) 1/2 = 46 cm Antenna Type:Monopole (5λ/8 whip) Antenna Gain:5.15 dBi Transmitter Power:25 Watts Limit:300 – 1500 MHz: f/300 mW/cm 2 For f = 463.725 MHz, s = 1.546 Power gain product:25000 x 3.27 = 81750 mW Minimum safe distance:(81750 / 4π x 1.546) 1/2 = 65 cm FCC ID: CASTMAH6APage 4 of 6 Test Results: NAME OF TEST:TRANSMITTER OUTPUT POWER (CONDUCTED) TEST CONDITIONS:Ambient Temperature22 o C Relative Humidity47 % Standard Voltage13.8V DC SPECIFICATION:FCC 47 CFR 2.1046 GUIDE:TIA/EIA-603 2.2.1 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was connected to an RF Power meter using a coaxial attenuator with an impedance of 50 Ohms. 2. The unmodulated output power was measured. MEASUREMENT RESULTS: Frequency: 463.725 MHzManufacturer’s Rated Output Power: 25 W nominal POWER (W)25 Measurement Uncertainty (dB) +0.63, -0.68 NAME OF TEST:ENVIRONMENTAL ASSESSMENT TEST CONDITIONS:Ambient Temperature22 o C Relative Humidity47% Standard Voltage13.8V DC SPECIFICATION:FCC 47 CFR 1.1310 GUIDE:ANSI/IEEE Std C95.1, 1999, OET Bulletin 65 97-01 Test Method: The antenna is mounted on a metallic ground-plane which is placed on a non metallic turntable 1.35 m high and clear of nearby objects. Peak power density readings are taken at 0.2m vertical increments using a calibrated isotropic probe at the calculated safe distance from the antenna. The measurement equipment is operated remotely using fibre optics to reduce field perturbations. FCC ID: CASTMAH6APage 5 of 6 Test Distance metres 0.58 m (distance for λ/4 whip)0.81 m (distance for 5λ/8 whip) Power Density, mW/cm 2 Power Density, mW/cm 2 Probe Height metres Result for 25W TX power.Result for 25W TX power. 0.2 0.0670.057 0.4 0.0250.048 0.6 0.0700.084 0.8 0.0700.124 1.0 0.1610.080 1.2 0.3400.164 1.4 0.4580.076 1.6 0.6300.205 1.8 0.4230.398 2.0 0.1960.499 Calculations of average power (sum of results/number of results): Test Distance, m 0.58 m (distance for λ/4 whip) 0.81 m (distance for 5λ/8 whip) Body partAverage Power Density, mW/cm 2 Average Power Density, mW/cm 2 Whole Body Probe Height 0.2 to 2.0m 0.2440.173 Upper Body Probe Height 1.0 to 2.0m 0.3150.203 Lower Body Probe Height 0.2 to 0.8m 0.0580.078 Limit, Occupational/Controlled Exposure: 300 – 1500 MHz: f/300 mW/cm 2 For f = 463.725 MHz, s = 1.546 Test Equipment Used: Power Meter:Rohde and Schwarz NRVS s/n 841954/005 Isotropic ProbeHoladay HI-422 s/n 95661 Antenna MastTait TurntableTait FCC ID: CASTMAH6APage 6 of 6 Information to be placed in User/Installation manual: Warning: Warning: RF Exposure Hazard To comply with FCC RF exposure limits, this product must be installed using an externally mounted antenna with either a 2.15dBi or 5.15dBi gain. This antenna must not be mounted at a location such that any person or persons can come closer than 0.9m (35 inches) to the antenna. Safety Training Information: Warning: FCC RF Exposure Limits This product generates RF (radio frequency) energy during transmissions. This device must be restricted to work-related use in an occupational/controlled exposure environment. The radio operator must have control of the exposure conditions and duration of all persons exposed to the antenna of this transmitter to satisfy FCC RF exposure compliance. • This device is not approved for general population use. • This device must only be used with authorized accessories and antennas. The operator must ensure that the minimum safe distance of 0.9m (35 inches) between persons and the antenna is maintained during transmissions. This minimum safe distance is based on the assumption that there is a duty cycle of 50% transmit mode to stand-by or receive modes. The radio is in transmit mode when the PTT (press-to- talk) key on the microphone is pressed and the control head red LED (light emitting diode) glows. Please refer to the following website for more information on what RF energy is and how to control your exposure to assure compliance with established RF exposure limits. Website: http://www.fcc.gov/oet/rfsafety/rf-faqs.html END
FCC ID: CASTMAH6A TELTEST REPORT: 1917 TMAB12-H600 S/N: 19001365 Page 1 of 47 REPORT NUMBER 1917SEPTEMBER 2003 RADIO PERFORMANCE MEASUREMENTS On the TMAB12-H600 Mobile Transceiver FCC ID: CASTMAH6A SN: 19001365 In accordance with FCC 47 CFR Parts 22 and 90 PREPARED BY:Garry Pringle ___________________ Test Technician CHECKED & APPROVED BY:SA Crompton___________________ Laboratory …
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 6 | 22,9 | 450 MHz - 530 MHz | 25 W | 19K6F1D | 1.5 ppm |

Base Station Transceiver
Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Base Station Transceiver
Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Mobile Transceiver
Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Portable Transceiver
Equipment Class
TNF - Licensed Non-Broadcast Transmitter Held to Face
Portable Transceiver
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
