CASTMAK5BMobile Transceiver





  MMA-00002-03 Issue 3 © Tait Electronics Ltd January 2006. All rights reserved.1 Directive 1999/5/EC Declaration of Conformity daDansk Undertegnede Tait Electronics Limited erklærer herved, at følgende udstyr TMAB1A & TMAH5A overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Se endvidere: http://eudocs.taitworld.com/ deDeutsch Hiermit erklärt Tait Electronics Limited die Übereinstimmung der Geräte TMAB1A & TMAH5A mit den grundlegenden Anforderungen und den anderen relevanten Festlegungen der Richtlinie 1999/5/EG. Siehe auch: http://eudocs.taitworld.com/ elΕλληνικός Με την παρουσα Tait Electronics Limited δηλωνει οτι TMAB1A & TMAH5A συμμορφωνεται προσ τισ ουσιωδεισ απαιτησεισ και τισ λοιπεσ σχετικεσ διαταξεισ τησ οδηγιασ1999/5/ΕΚ. βλέπε και: http://eudocs.taitworld.com/ enEnglish Tait Electronics Limited declares that this TMAB1A & TMAH5A complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. See also: http://eudocs.taitworld.com/ esEspañol Por medio de la presente Tait Electronics Limited declara que el TMAB1A & TMAH5A cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Vea también: http://eudocs.taitworld.com/ fiSuomi Tait Electronics Limited vakuuttaa täten että TMAB1A & TMAH5A tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Katso: http://eudocs.taitworld.com/ frFrançais Par la présente, Tait Electronics Limited déclare que l'appareil TMAB1A & TMAH5A est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Voir aussi: http://eudocs.taitworld.com/ itItaliano Con la presente Tait Electronics Limited dichiara che questo TMAB1A & TMAH5A è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Vedi anche: http://eudocs.taitworld.com/ nlNederlands Hierbij verklaart Tait Electronics Limited dat het toestel TMAB1A & TMAH5A in overeen- stemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/ EG. Zie ook: http://eudocs.taitworld.com/ ptPortuguês Tait Electronics Limited declara que este TMAB1A & TMAH5A está conforme com os requisitos essenciais e outras provisões da Directiva 1999/5/CE. Veja também: http://eudocs.taitworld.com/ svSvensk Härmed intygar Tait Electronics Limited att denna TMAB1A & TMAH5A står I överens- stämmelse med de väsentliga egenskapsk- rav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. Se även: http://eudocs.taitworld.com/ 2 To our European customers: Tait Electronics Limited is an environmentally responsible company which supports waste minimization and material recovery. The European Union’s Waste Electrical and Electronic Equipment Directive requires that this product be disposed of separately from the general waste stream when its service life is over. Please be environmentally responsible and dispose through the original supplier, your local municipal waste “separate collection” service, or contact Tait Electronics Limited. A l’attention de nos clients européens: Tait Electronics Limited est une société respectueuse de l’environnement qui apporte son soutien à la minimisation des déchets et à la récupération des matériaux. Selon la Directive de l’Union européenne relative à l’élimination des déchets d’équipements électriques et électroniques, ce produit doit être éliminé séparément et ne doit pas être jeté avec les ordures ménagères à la fin de sa durée de vie. Veuillez respecter l’environnement et éliminez ce produit par l’intermédiaire du fournisseur initial, de votre service municipal de collecte séparée des déchets, ou contactez Tait Electronics Limited. Para nuestros clientes europeos: Tait Electronics Limited es una empresa que se preocupa por el medio ambiente y apoya el reciclaje y la mínima eliminación de residuos. La Directiva de Eliminación de residuos de aparatos eléctricos y electrónicos de la Unión Europea obliga a que se tire este producto al final de su vida útil por separado del resto de los residuos. Rogamos que se responsabilice por el medio ambiente y, cuando llegue el momento de tirar el producto, se ponga en contacto con el distribuidor original, el servicio de recolección de residuos especiales local de su ayuntamiento, o con Tait Electronics Limited. 欧洲客户： Tait电子有限公司对环境保护极为负责，公司支持把废品降低到最小程度 并支持材料回收。根据欧盟废旧电气和电子设备指导(European Union’s Waste Electrical and Electronic Equipment Directive)条例要求：当 本产品服务寿命结束时，应该与一般废品分开，单独进行处置。为了对环 境保护负责，请通过你的产品提供商、当地废品“单独回收”服务机构处 置废弃产品，或联系Tait电子有限公司获得支持。 English © Tait Electronics Limited January 2006. All rights reserved. TM8100 User’s Guide English 4 Safety and compliance warnings Safety and compliance warnings Warning: FCC RF exposure limits This product generates RF (radio frequency) energy during transmissions. This device must be restricted to work-related use in an occupational/controlled exposure environment. The radio operator must have control of the exposure condi- tions and duration of all persons exposed to the antenna of this transmitter to satisfy FCC RF exposure compliance. This device is not approved for general population use. ■This device must only be used with authorized accessories and antennas. ■The operator must ensure that the minimum safe distance of 0.9 m (35 inches) between persons and the antenna is maintained during transmissions. ■This minimum safe distance is based on the assumption that there is a duty cycle of 50% transmit mode to stand- by or receive modes. The radio is in transmit mode when the PTT (press-to-talk) key on the microphone is pressed and the control head red LED (light emitting diode) glows. Please refer to the following website for more information on what RF energy is and how to control your exposure to ensure compliance with established …

Text truncated - open the document above for the full version.

EEE-Q25663TCB 15/02/2007 FCC ID: CASTMAK5B Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, (Tait Electronics Limited), hereby request confidentiality for the Block diagrams, Schematics, Parts lists, Tune up and Operational Description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. Steve Crompton, Laboratory Manager, Tait Electronics Ltd.

FCC ID: CASTMAK5BPage 1 of 11 REPORT NUMBER 2507 FCC ID: CASTMAK5B TELTEST Laboratories Tait Electronics Limited PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone : (64) (3) 3583399 Fax: (64) (3) 3580432 TEST: FCC 47 CFR 1.1310 Maximum Permissible Exposure ENVIRONMENTAL ASSESSMENT On the TMAB14-K500 Mobile Transceiver S/N: 19176196 In accordance with ANSI/IEEE Std C95.1, 1999 OET Bulletin 65 97-01 and Supplement C (Edition 01-01) DATE:8 February 2006 PREPARED BY:Robin Kidson __________________ Test Technician CHECKED & APPROVED BY:SA Crompton __________________ Laboratory Manager This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. FCC ID: CASTMAK5BPage 2 of 11 TABLE OF CONTENTS Page SUMMARY OF RESULTS ................................................................................................................... 3 OPERATING CONDITIONS AND EXPOSURE CONDITIONS .................................................... 4 LIMITS ................................................................................................................................................... 4 RECOMMENDED ANTENNAS .......................................................................................................... 4 MEASUREMENT GUIDANCE ...........................................................................................................5 TEST RESULTS, TRANSMITTER POWER ..................................................................................... 5 TEST RESULTS, MPE.................................................................................................................. 6 TEST EQUIPMENT LIST .................................................................................................................... 9 INFORMATION TO BE PLACED IN MANUAL............................................................................ 10 APPENDIX 1 TEST POSITIONS DIAGRAM.................................................................. 11 FCC ID: CASTMAK5BPage 3 of 11 Summary of Results: 762.0125 MHz: Antenna GainAntenna PositionMeasurement PositionResult 2.15 dBi RoofExternal: Side COMPLIES 2.15 dBi TrunkExternal: Rear Side COMPLIES 2.15 dBi TrunkExternal: Rear Corner COMPLIES 2.15 dBi TrunkExternal: Centre rear COMPLIES 5.65 dBi RoofExternal: Side COMPLIES 5.65 dBi TrunkExternal: Rear Side COMPLIES 5.65 dBi TrunkExternal: Rear Corner COMPLIES 5.65 dBi TrunkExternal: Centre rear COMPLIES 2.15 dBi RoofInternal: Front Seat COMPLIES 2.15 dBi RoofInternal: Back Seat COMPLIES 2.15 dBi TrunkInternal: Front Seat COMPLIES 2.15 dBi TrunkInternal: Back Seat COMPLIES 5.65 dBi RoofInternal: Front Seat COMPLIES 5.65 dBi RoofInternal: Back Seat COMPLIES 5.65 dBi TrunkInternal: Front Seat COMPLIES 5.65 dBi TrunkInternal: Back Seat COMPLIES 806.0125 MHz: Antenna GainAntenna PositionMeasurement PositionResult 2.15 dBi RoofExternal: Side COMPLIES 2.15 dBi TrunkExternal: Rear Side COMPLIES 2.15 dBi TrunkExternal: Rear Corner COMPLIES 2.15 dBi TrunkExternal: Centre rear COMPLIES 5.65 dBi RoofExternal: Side COMPLIES 5.65 dBi TrunkExternal: Rear Side COMPLIES 5.65 dBi TrunkExternal: Rear Corner COMPLIES 5.65 dBi TrunkExternal: Centre rear COMPLIES 2.15 dBi RoofInternal: Front Seat COMPLIES 2.15 dBi RoofInternal: Back Seat COMPLIES 2.15 dBi TrunkInternal: Front Seat COMPLIES 2.15 dBi TrunkInternal: Back Seat COMPLIES 5.65 dBi RoofInternal: Front Seat COMPLIES 5.65 dBi RoofInternal: Back Seat COMPLIES 5.65 dBi TrunkInternal: Front Seat COMPLIES 5.65 dBi TrunkInternal: Back Seat COMPLIES See Appendix A for details of the measurement positions. FCC ID: CASTMAK5BPage 4 of 11 Operating and Exposure conditions: Operating Conditions:Mobile transmitter using vehicle mounted antennas only Exposure conditions:Occupational/Controlled Exposure (operator). General Population/Uncontrolled (passengers and bystanders) Safe Distance: Recommended Minimum lateral safe distance from the antenna:90 cm Limit: Occupational/Controlled Exposure: 30 - 300 MHz: 1.0 mW/cm 2 300 – 1500 MHzf/300 mW/cm 2 for test frequency of 762.0125MHz = 2.54 mW/cm 2 for test frequency of 806.0125MHz = 2.69 mW/cm 2 General population/Uncontrolled Exposure: 30 - 300 MHz: 0.2 mW/cm 2 300 – 1500 MHzf/1500 mW/cm 2 for test frequency of 762.0125MHz = 0.508 mW/cm 2 for test frequency of 806.0125MHz = 0.537 mW/cm 2 Recommended Antennas: Antenna Type:Monopole (λ/4 antenna) Antenna Gain:2.15 dBi Antenna Type:Monopole (Collinear antenna) Antenna Gain:5.65 dBi FCC ID: CASTMAK5BPage 5 of 11 Measurement Guidance: 2) Mobile PTT – Parts 80, 90 a) §2.1033(c)(3) requires device operating and installation instructions to be submitted during equipment certification; instructions should include the minimum separation distance and other constraints required for the device and its antenna(s) to meet MPE limits b) Per definition of a mobile device a minimum separation distance of 20 cm is required i) Antenna installation conditions should maintain the estimated minimum MPE separation distance ii) A separation distance based on MPE evaluation (measurement or computer modeling) that is smaller than the estimated MPE distance may be used if it is applicable for the antenna installation conditions c) Basic RF exposure instructions are requested for devices that meet general population exposure requirements, as part of the §2.1033(c)(3) required operating instructions; RF exposure training instructions and labeling info are requested for devices that satisfy occupational exposure requirements Federal Communications Commission OET Laboratory Division March 18, 2004 Test Results: NAME OF TEST:TRANSMITTER OUTPUT POWER (CONDUCTED) TEST CONDITIONS:Ambient Temperature22 o C Relative Humidity35 % SPECIFICATION:FCC 47 CFR 2.1046 GUIDE:TIA/EIA-603 2.2.1 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was connected to an RF Power meter using a coaxial attenuator with an impedance of 50 Ohms. 2. The unmodulated output po…

Text truncated - open the document above for the full version.

TELTEST Laboratories Tait Electronics Limited Report Number 2539 TELTEST Laboratories – A Division of Tait Electronics LimitedTelephone: 64 3 358 3399, Fax: 64 3 358 0432 PO Box 1645, 558 Wairakei Road, Christchurch, New Zealand Page 1 of 35 Laboratory Test Report For the TMAB14-K500 Mobile Transceiver Tested In accordance with FCC 47 CFR Parts 22 and 90S Report Revision:1 Issue Date:08-Feb-2007 FCC ID:CASTMAK5B PREPARED BY:Robin Kidson___________________ Test Technician CHECKED & APPROVED BY:Steve Crompton___________________ Laboratory Manager All tests reported herein have been performed in accordance with the laboratory's scope of accreditation This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. TELTEST Laboratories Tait Electronics Limited Report Number 2539 FCC ID: CASTMAK5B Page 2 of 35Report Revision: 1 Issue Date: 08-Feb-2007 TABLE OF CONTENTS REVISION HISTORY ........................................................................................................................... 2 INTRODUCTION .................................................................................................................................. 3 REPORT PREPARED FOR ................................................................................................................. 3 DESCRIPTION OF SAMPLE .............................................................................................................. 3 STATEMENT OF COMPLIANCE...................................................................................................... 3 TEST CONDITIONS ............................................................................................................................. 3 NECESSARY BANDWIDTH AND EMISSION DESIGNATORS ................................................... 4 TEST RESULTS..................................................................................................................................... 5 TRANSMITTER OUTPUT POWER (CONDUCTED) ...................................................................... 5 TRANSMITTER AUDIO FREQUENCY RESPONSE - PRE-EMPHASIS ....................................... 6 TRANSMITTER MODULATION LIMITING ................................................................................... 8 OCCUPIED BANDWIDTH ..............................................................................................................10 ANALOGUE VOICE.....................................................................................................................11 FFSK..............................................................................................................................................13 FFSK..............................................................................................................................................14 SPURIOUS EMISSIONS (CONDUCTED)....................................................................................... 21 SPURIOUS EMISSIONS (RADIATED)........................................................................................... 25 TRANSMITTER FREQUENCY STABILITY (TEMPERATURE) ................................................. 30 TRANSMITTER FREQUENCY STABILITY (VOLTAGE) ........................................................... 31 TEST EQUIPMENT USED................................................................................................................. 33 ANNEX A.............................................................................................................................................. 34 TEST SETUP DETAILS................................................................................................................ 34 REVISION HISTORY DateRevisionComments 08-Feb-20071Initial test report TELTEST Laboratories Tait Electronics Limited Report Number 2539 FCC ID: CASTMAK5B Page 3 of 35Report Revision: 1 Issue Date: 08-Feb-2007 INTRODUCTION Type Approval Testing of the TMAB14-K500 (Serial No 19226261) in accordance with: FCC CFR 47 Parts 22 & 90S REPORT PREPARED FOR Tait Electronics Ltd PO Box 1645 558 Wairakei Rd Christchurch New Zealand DESCRIPTION OF SAMPLE Equipment:Mobile Transceiver Type:TMAK5B Product code:TMAB14-K500 Serial Numbers:19226261 Quantity:1 STATEMENT OF COMPLIANCE The TMAB14-K500 mobile transceiver as tested in this report was found to conform to the following standards: FCC CFR 47 Parts 22 & 90S TEST CONDITIONS All testing was performed at the following conditions. Ambient Temperature 15 o CÆ 30 o C Relative Humidity 20%Æ 75% Standard Test Voltage 13.8 Vdc TELTEST Laboratories Tait Electronics Limited Report Number 2539 FCC ID: CASTMAK5B Page 4 of 35Report Revision: 1 Issue Date: 08-Feb-2007 NECESSARY BANDWIDTH AND EMISSION DESIGNATORS SPECIFICATION:FCC 47 CFR 2.202 The Necessary Bandwidth is the minimum value of the occupied bandwidth sufficient to ensure the transmission of information at the rate and with the quality required for the system employed. This is calculated using the following formula. Bn = 2M + 2DKWhere: Bn = Necessary Bandwidth M = Maximum modulation frequency For Data transmission M = B/2 Where: B = Modulation rate in Baud D = Peak deviation K = Constant For Analogue transmission this is 1 For Data transmission this is typically 1.2 1. Analogue Voice 12.5kHz Bandwidth Necessary bandwidthEmission Designator M=3 kHz 11K0F3E D= 2.5 kHz Bn= 6 + 5 x 1 = 11kHz F3E represents a FM voice transmission 25kHz Bandwidth Necessary bandwidthEmission Designator M=3 kHz 16K0F3E D=5 kHz Bn= 6 + 10 x 1 = 16 kHz F3E represents a FM voice transmission 2. Fast Frequency Shift Keying (FFSK) 12.5kHz Bandwidth Necessary bandwidthEmission Designator M= 1.8 kHz 6K60F2D D= 1.5 kHz Bn= 3.6 + 3 x 1 = 6.6 kHz F2D represents a FM data transmission with the use of a modulating sub carrier 25kHz Bandwidth Necessary bandwidthEmission Designator M= 1.8 kHz 9K60F2D D=3 kHz Bn= 3.6 + 6 x 1 = 9.6 kHz F2D repre…

Text truncated - open the document above for the full version.
