CASTMAK5DMobile Transmitter

1 TM8200 mobiles Safety and Compliance Information Informations sur la conformité et consignes de sécurité Información sobre medidas de seguridad y conformidad del producto 产品安全与符合性信息 MMA-00052-01 Issue 01 June 2006 2© Tait Electronics Limited 2006 Directive 1999/5/EC Declaration of Conformity daDansk Undertegnede Tait Electronics Limited erklærer herved, at følgende udstyr TMAA4C, TMAB1C, TMAH5C & TMAC0C overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Se endvidere: http://eudocs.taitworld.com/ deDeutsch Hiermit erklärt Tait Electronics Limited die Übereinstimmung der Geräte TMAA4C, TMAB1C, TMAH5C & TMAC0C mit den grundlegenden Anforderungen und den anderen relevanten Festlegungen der Richtlinie 1999/5/EG. Siehe auch: http://eudocs.taitworld.com/ elΕλληνικός Με την παρουσα Tait Electronics Limited δηλωνει οτι TMAA4C, TMAB1C, TMAH5C & TMAC0C συμμορφωνεται προσ τισ ουσιωδεισ απαιτησεισ και τισ λοιπεσ σχετικεσ διαταξεισ τησ οδηγιασ1999/5/ΕΚ. βλέπε και: http://eudocs.taitworld.com/ enEnglish Tait Electronics Limited declares that this TMAA4C, TMAB1C, TMAH5C & TMAC0C complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. See also: http://eudocs.taitworld.com/ esEspañol Por medio de la presente Tait Electronics Limited declara que el TMAA4C, TMAB1C, TMAH5C & TMAC0C cumple con los requisi- tos esenciales y cualesquiera otras disposi- ciones aplicables o exigibles de la Directiva 1999/5/CE. Vea también: http://eudocs.taitworld.com/ fiSuomi Tait Electronics Limited vakuuttaa täten että TMAA4C, TMAB1C, TMAH5C & TMAC0C tyyppinen laite on direktiivin 1999/5/EY oleel- listen vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Katso: http://eudocs.taitworld.com/ frFrançais Par la présente, Tait Electronics Limited déclare que l'appareil TMAA4C, TMAB1C, TMAH5C & TMAC0C est conforme aux exigences essentielles et aux autres disposi- tions pertinentes de la directive 1999/5/CE. Voir aussi: http://eudocs.taitworld.com/ itItaliano Con la presente Tait Electronics Limited dichi- ara che questo TMAA4C, TMAB1C, TMAH5C & TMAC0C è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Vedi anche: http://eudocs.taitworld.com/ nlNederlands Hierbij verklaart Tait Electronics Limited dat het toestel TMAA4C, TMAB1C, TMAH5C & TMAC0C in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/ EG. Zie ook: http://eudocs.taitworld.com/ ptPortuguês Tait Electronics Limited declara que este TMAA4C, TMAB1C, TMAH5C & TMAC0C está conforme com os requisitos essenciais e outras provisões da Directiva 1999/5/CE. Veja também: http://eudocs.taitworld.com/ svSvensk Härmed intygar Tait Electronics Limited att denna TMAA4C, TMAB1C, TMAH5C & TMAC0C står I överensstämmelse med de väsentliga egenskapskrav och övriga rele- vanta bestämmelser som framgår av direktiv 1999/5/EG. Se även: http://eudocs.taitworld.com/ Product safety and compliance information3 English Copyright and trademarks All information contained in this manual is the property of Tait Electronics Limited. All rights reserved. This manual may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-readable form, without prior written permission from Tait Electronics Limited. The word TAIT and the TAIT logo are trademarks of Tait Electronics Limited. All trade names referenced are the service mark, trademark or registered trademark of the respective manufacturers. Intellectual property rights This product may be protected by one or more patents of Tait Electronics Limited together with their international equivalents, pending patent applications and registered trade marks: NZ338097, NZ508054, NZ508340, NZ508806, NZ508807, NZ509242, NZ509640, NZ509959, NZ510496, NZ511155, NZ511421, NZ516280/519742, NZ519118, NZ519344, NZ520650/537902, NZ521450, NZ524509, NZ524537, NZ524630, NZ530819, NZ534475, NZ534692, NZ535471, NZ536945, NZ537434, NZ534369, NZ522236, NZ524378, AU2003281447, AU2002235062, AU2004216984, CA2439018, EU 03784706.8, EU02701829.0, EU04714053.8, GB23865476, GB 2386010, GB0516094.0, GB0516092.4, US09/847322, US60/613748, US60/539617, US10/520827, US10/468740, US5,745,840, US10/520827. To our European customers Tait Electronics Limited is an environmentally responsible company which supports waste minimization and material recovery. The European Union’s Waste Electrical and Electronic Equipment Directive requires that this product be disposed of separately from the general waste stream when its service life is over. Please be environmentally responsible and dispose through the original supplier, your local municipal waste “separate collection” service, or contact Tait Electronics Limited. 4Product safety and compliance information English About this booklet This booklet contains important safety and compliance information. For information about the way your radio operates, contact your radio provider. Before using your radio, please read the following important safety and compliance information. Radio frequency exposure information For your own safety and to ensure you comply with the Federal Communication Commission’s (FCC) radio frequency (RF) exposure guidelines, please read the following information before using this radio. Using this radio You should use this radio only for work-related purposes (it is not authorized for any other use) and if you are fully aware of, and can exercise control over, your exposure to RF energy. To prevent exceeding FCC RF exposure limits, you must control the amount and duration of RF that you and other people are exposed to. It is also important that you: !Do not remove the RF Exposure label from the radio. Product safety and compliance information5 English !Ensure this RF exposure information accompa- nies the radio when it is transferred to other users. !Do not use the radio if yo…

Text truncated - open the document above for the full version.





  MMA-00003-05 Issue 5 © Tait Electronics Limited June 2006. All rights reserved.1 Directive 1999/5/EC Declaration of Conformity daDansk Undertegnede Tait Electronics Limited erklærer herved, at følgende udstyr TMAA4C, TMAB1C, TMAH5C & TMAC0C overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Se endvidere: http://eudocs.taitworld.com/ deDeutsch Hiermit erklärt Tait Electronics Limited die Übereinstimmung der Geräte TMAA4C, TMAB1C, TMAH5C & TMAC0C mit den grundlegenden Anforderungen und den anderen relevanten Festlegungen der Richtlinie 1999/5/EG. Siehe auch: http://eudocs.taitworld.com/ elΕλληνικός Με την παρουσα Tait Electronics Limited δηλωνει οτι TMAA4C, TMAB1C, TMAH5C & TMAC0C συμμορφωνεται προσ τισ ουσιωδεισ απαιτησεισ και τισ λοιπεσ σχετικεσ διαταξεισ τησ οδηγιασ1999/5/ΕΚ. βλέπε και: http://eudocs.taitworld.com/ enEnglish Tait Electronics Limited declares that this TMAA4C, TMAB1C, TMAH5C & TMAC0C complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. See also: http://eudocs.taitworld.com/ esEspaÒol Por medio de la presente Tait Electronics Limited declara que el TMAA4C, TMAB1C, TMAH5C & TMAC0C cumple con los requisi- tos esenciales y cualesquiera otras disposi- ciones aplicables o exigibles de la Directiva 1999/5/CE. Vea también: http://eudocs.taitworld.com/ fiSuomi Tait Electronics Limited vakuuttaa täten että TMAA4C, TMAB1C, TMAH5C & TMAC0C tyyppinen laite on direktiivin 1999/5/EY oleel- listen vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Katso: http://eudocs.taitworld.com/ frFranÁais Par la présente, Tait Electronics Limited déclare que l'appareil TMAA4C, TMAB1C, TMAH5C & TMAC0C est conforme aux exigences essentielles et aux autres disposi- tions pertinentes de la directive 1999/5/CE. Voir aussi: http://eudocs.taitworld.com/ itItaliano Con la presente Tait Electronics Limited dichi- ara che questo TMAA4C, TMAB1C, TMAH5C & TMAC0C è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Vedi anche: http://eudocs.taitworld.com/ nlNederlands Hierbij verklaart Tait Electronics Limited dat het toestel TMAA4C, TMAB1C, TMAH5C & TMAC0C in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/ EG. Zie ook: http://eudocs.taitworld.com/ ptPortuguÍs Tait Electronics Limited declara que este TMAA4C, TMAB1C, TMAH5C & TMAC0C está conforme com os requisitos essenciais e outras provisões da Directiva 1999/5/CE. Veja também: http://eudocs.taitworld.com/ svSvensk Härmed intygar Tait Electronics Limited att denna TMAA4C, TMAB1C, TMAH5C & TMAC0C står I överensstämmelse med de väsentliga egenskapskrav och övriga rele- vanta bestämmelser som framgår av direktiv 1999/5/EG. Se även: http://eudocs.taitworld.com/ 2Safety and compliance warnings Safety and compliance warnings To our European customers: Tait Electronics Limited is an environmen- tally responsible company which supports waste minimization and material recovery. The European Union’s Waste Electrical and Electronic Equipment Directive requires that this product be disposed of separately from the general waste stream when its service life is over. Please be environmen- tally responsible and dispose through the original supplier, your local municipal waste “separate collec- tion” service, or contact Tait Electronics Limited. Radio frequency exposure information For your own safety and to ensure you comply with the Federal Communication Commission’s (FCC) radio frequency (RF) exposure guidelines, please read the following information before using this radio. Using this radio You should use this radio only for work-related purposes (it is not authorized for any other use) and if you are fully aware of, and can exercise control over, your exposure to RF energy. To prevent exceeding FCC RF exposure limits, you must control the amount and duration of RF that you and other people are exposed to. It is also important that you: ■Do not remove the RF exposure label from the radio. ■Ensure this RF exposure information accompanies the radio when it is transferred to other users. ■Do not use the radio if you do not adhere to the guide- lines on controlling your exposure to RF. Safety and compliance warnings3 Controlling your exposure to RF energy This radio emits RF energy or radio waves primarily when calls are made. RF is a form of electromagnetic energy (as is sunlight), and there are recommended levels of maximum RF exposure. To control your exposure to RF and comply with the maxi- mum exposure limits for occupational/controlled environ- ments, follow these guidelines: ■Do not talk (transmit) on the radio more than the rated transmit duty cycle. This is important because the radio radiates more energy when it is transmitting than when it is receiving. ■While you are transmitting (talking or sending data) on the radio, you must ensure that there is always a distance of 0.9 m (35 inches) between people and the antenna. This is the minimum safe distance. ■Use the radio only with Tait-approved antennas and attachments, and make only authorized modifications to the antenna otherwise you could damage the radio and violate FCC regulations. Website: For more information on what RF energy is and how to control your exposure to it, go to http://www.fcc.gov/oet/rfsafety/rf-faqs.html. Compliance with RF energy exposure standards This two-way radio complies with these RF energy exposure standards and guidelines: ■United States Federal Communications Commission, Code of Federal Regulations; 47 CFR 1.1307, 1.1310 and 2.1091 ■American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 4Safety and compliance warnings ■Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition. This radio complies with the IEEE (FCC) and ICNIRP exposure limits for occupational/controlled R…

Text truncated - open the document above for the full version.

EEE-Q25767ATCB 8/03/2007 FCC ID: CASTMAK5D Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, (Tait Electronics Limited), hereby request confidentiality for the Block diagrams, Schematics, Parts lists, Tune up and Operational Description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. Steve Crompton, Laboratory Manager, Tait Electronics Ltd.

FCC ID: CASTMAK5D Page 1 of 11 REPORT NUMBER 2564 FCC ID: CASTMAK5D TELTEST Laboratories Tait Electronics Limited PO Box 1645 558 Wairakei Road Christchurch New Zealand Phone : (64) (3) 3583399 Fax: (64) (3) 3580432 TEST: FCC 47 CFR 1.1310 Maximum Permissible Exposure ENVIRONMENTAL ASSESSMENT On the TMAB24-K500 Mobile Transceiver S/N: 19226272 In accordance with ANSI/IEEE Std C95.1, 1999 OET Bulletin 65 97-01 and Supplement C (Edition 01-01) DATE: 8 March 2007 PREPARED BY: Robin Kidson __________________ Test Technician CHECKED & APPROVED BY: SA Crompton __________________ Laboratory Manager This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. FCC ID: CASTMAK5D Page 2 of 11 TABLE OF CONTENTS Page SUMMARY OF RESULTS ................................................................................................................... 3 OPERATING CONDITIONS AND EXPOSURE CONDITIONS .................................................... 4 LIMITS ................................................................................................................................................... 4 RECOMMENDED ANTENNAS .......................................................................................................... 4 MEASUREMENT GUIDANCE ...........................................................................................................5 TEST RESULTS, TRANSMITTER POWER ..................................................................................... 5 TEST RESULTS, MPE .................................................................................................................. 6 TEST EQUIPMENT LIST .................................................................................................................... 9 INFORMATION TO BE PLACED IN MANUAL............................................................................ 10 APPENDIX 1 TEST POSITIONS DIAGRAM.................................................................. 11 FCC ID: CASTMAK5D Page 3 of 11 Summary of Results: 762.0125 MHz: Antenna Gain Antenna Position Measurement Position Result 2.15 dBi Roof External: Side COMPLIES 2.15 dBi Trunk External: Rear Side COMPLIES 2.15 dBi Trunk External: Rear Corner COMPLIES 2.15 dBi Trunk External: Centre rear COMPLIES 5.65 dBi Roof External: Side COMPLIES 5.65 dBi Trunk External: Rear Side COMPLIES 5.65 dBi Trunk External: Rear Corner COMPLIES 5.65 dBi Trunk External: Centre rear COMPLIES 2.15 dBi Roof Internal: Front Seat COMPLIES 2.15 dBi Roof Internal: Back Seat COMPLIES 2.15 dBi Trunk Internal: Front Seat COMPLIES 2.15 dBi Trunk Internal: Back Seat COMPLIES 5.65 dBi Roof Internal: Front Seat COMPLIES 5.65 dBi Roof Internal: Back Seat COMPLIES 5.65 dBi Trunk Internal: Front Seat COMPLIES 5.65 dBi Trunk Internal: Back Seat COMPLIES 806.0125 MHz: Antenna Gain Antenna Position Measurement Position Result 2.15 dBi Roof External: Side COMPLIES 2.15 dBi Trunk External: Rear Side COMPLIES 2.15 dBi Trunk External: Rear Corner COMPLIES 2.15 dBi Trunk External: Centre rear COMPLIES 5.65 dBi Roof External: Side COMPLIES 5.65 dBi Trunk External: Rear Side COMPLIES 5.65 dBi Trunk External: Rear Corner COMPLIES 5.65 dBi Trunk External: Centre rear COMPLIES 2.15 dBi Roof Internal: Front Seat COMPLIES 2.15 dBi Roof Internal: Back Seat COMPLIES 2.15 dBi Trunk Internal: Front Seat COMPLIES 2.15 dBi Trunk Internal: Back Seat COMPLIES 5.65 dBi Roof Internal: Front Seat COMPLIES 5.65 dBi Roof Internal: Back Seat COMPLIES 5.65 dBi Trunk Internal: Front Seat COMPLIES 5.65 dBi Trunk Internal: Back Seat COMPLIES See Appendix A for details of the measurement positions. FCC ID: CASTMAK5D Page 4 of 11 Operating and Exposure conditions: Operating Conditions: Mobile transmitter using vehicle mounted antennas only Exposure conditions: Occupational/Controlled Exposure (operator). General Population/Uncontrolled (passengers and bystanders) Safe Distance: Recommended Minimum lateral safe distance from the antenna: 90 cm Limit: Occupational/Controlled Exposure: 30 - 300 MHz: 1.0 mW/cm 2 300 – 1500 MHz f/300 mW/cm 2 for test frequency of 762.0125MHz = 2.54 mW/cm 2 for test frequency of 806.0125MHz = 2.69 mW/cm 2 General population/Uncontrolled Exposure: 30 - 300 MHz: 0.2 mW/cm 2 300 – 1500 MHz f/1500 mW/cm 2 for test frequency of 762.0125MHz = 0.508 mW/cm 2 for test frequency of 806.0125MHz = 0.537 mW/cm 2 Recommended Antennas: Antenna Type: Monopole (λ/4 antenna) Antenna Gain: 2.15 dBi Antenna Type: Monopole (Collinear antenna) Antenna Gain: 5.65 dBi FCC ID: CASTMAK5D Page 5 of 11 Measurement Guidance: 2) Mobile PTT – Parts 80, 90 a) §2.1033(c)(3) requires device operating and installation instructions to be submitted during equipment certification; instructions should include the minimum separation distance and other constraints required for the device and its antenna(s) to meet MPE limits b) Per definition of a mobile device a minimum separation distance of 20 cm is required i) Antenna installation conditions should maintain the estimated minimum MPE separation distance ii) A separation distance based on MPE evaluation (measurement or computer modeling) that is smaller than the estimated MPE distance may be used if it is applicable for the antenna installation conditions c) Basic RF exposure instructions are requested for devices that meet general population exposure requirements, as part of the §2.1033(c)(3) required operating instructions; RF exposure training instructions and labeling info are requested for devices that satisfy occupational exposure requirements Federal Communications Commission OET Laboratory Division March 18, 2004 Test Results: NAME OF TEST: TRANSMITTER OUTPUT POWER (CONDUCTED) TEST CONDITIONS: Ambient Temperature 22 o C Relative Humidity 35 % SPECIFICATION: FCC 47 CFR 2.1046 GUIDE: TIA/EIA-603 2.2.1 MEASUREMENT PROCEDURE: 1. The Equipment Under Test (EUT) was connected to an RF Power meter using a coaxial attenuator…

Text truncated - open the document above for the full version.

TELTEST Laboratories Tait Electronics Limited Report Number 2548 TELTEST Laboratories – A Division of Tait Electronics Limited Telephone: 64 3 358 3399, Fax: 64 3 358 0432 PO Box 1645, 558 Wairakei Road, Christchurch, New Zealand Page 1 of 38 Laboratory Test Report For the TMAB24-K500 Mobile Transceiver Tested in accordance with FCC 47 CFR Parts 22 and 90S Report Revision: 1 Issue Date: 06-Mar-2007 FCC ID: CASTMAK5D PREPARED BY: Robin Kidson ___________________ Test Technician CHECKED & APPROVED BY: Steve Crompton ___________________ Laboratory Manager All tests reported herein have been performed in accordance with the laboratory's scope of accreditation This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. TELTEST Laboratories Tait Electronics Limited Report Number 2548 FCC ID: CASTMAK5D Page 2 of 38 Report Revision: 1 Issue Date: 06-Mar-2007 TABLE OF CONTENTS REVISION HISTORY ........................................................................................................................... 3 INTRODUCTION .................................................................................................................................. 4 REPORT PREPARED FOR ................................................................................................................. 4 DESCRIPTION OF SAMPLE .............................................................................................................. 4 STATEMENT OF COMPLIANCE ...................................................................................................... 4 TEST CONDITIONS ............................................................................................................................. 4 NECESSARY BANDWIDTH AND EMISSION DESIGNATORS ................................................... 5 TEST RESULTS..................................................................................................................................... 6 TRANSMITTER OUTPUT POWER (CONDUCTED) ....................................................................... 6 TRANSMITTER AUDIO FREQUENCY RESPONSE - PRE-EMPHASIS ........................................ 7 TRANSMITTER MODULATION LIMITING ................................................................................... 9 OCCUPIED BANDWIDTH............................................................................................................... 11 SPURIOUS EMISSIONS (CONDUCTED) ....................................................................................... 24 SPURIOUS EMISSIONS (RADIATED) ........................................................................................... 29 TRANSMITTER FREQUENCY STABILITY (TEMPERATURE).................................................. 34 TRANSMITTER FREQUENCY STABILITY (VOLTAGE) ............................................................ 35 TEST EQUIPMENT USED................................................................................................................. 36 ANNEX A.............................................................................................................................................. 37 TEST SETUP DETAILS................................................................................................................ 37 TELTEST Laboratories Tait Electronics Limited Report Number 2548 FCC ID: CASTMAK5D Page 3 of 38 Report Revision: 1 Issue Date: 06-Mar-2007 REVISION HISTORY Date Revision Comments 06-Mar-2007 1 Initial test report TELTEST Laboratories Tait Electronics Limited Report Number 2548 FCC ID: CASTMAK5D Page 4 of 38 Report Revision: 1 Issue Date: 06-Mar-2007 INTRODUCTION Type Approval Testing of the TMAB24-K500 (Serial No 19226272) in accordance with: FCC CFR 47 Parts 22 & 90S REPORT PREPARED FOR Tait Electronics Ltd PO Box 1645 558 Wairakei Rd Christchurch New Zealand DESCRIPTION OF SAMPLE Equipment: Mobile Transceiver Type: TMAK5D Product code: TMAB24-K500 Serial Numbers: 19226272 Quantity: 1 STATEMENT OF COMPLIANCE The TMAB24-K500 mobile transceiver as tested in this report was found to conform to the following standards: FCC CFR 47 Parts 22 & 90S TEST CONDITIONS All testing was performed at the following conditions. Ambient Temperature 15 o C Æ 30 o C Relative Humidity 20% Æ 75% Standard Test Voltage 13.8 Vdc TELTEST Laboratories Tait Electronics Limited Report Number 2548 FCC ID: CASTMAK5D Page 5 of 38 Report Revision: 1 Issue Date: 06-Mar-2007 NECESSARY BANDWIDTH AND EMISSION DESIGNATORS SPECIFICATION: FCC 47 CFR 2.202 The Necessary Bandwidth is the minimum value of the occupied bandwidth sufficient to ensure the transmission of information at the rate and with the quality required for the system employed.This is calculated using the following formula: Bn = 2M + 2DK Where: Bn = Necessary Bandwidth M = Maximum modulation frequency For Data transmission M = B/2 Where: B = Modulation rate in Baud D = Peak deviation K = Constant For Analogue transmission this is 1 For Data transmission this is typically 1.2 1. Analogue Voice 12.5kHz Bandwidth Necessary bandwidth Emission Designator M = 3 kHz 11K0F3E D = 2.5 kHz Bn = 6 + 5 x 1 = 11kHz F3E represents a FM voice transmission 25kHz Bandwidth Necessary bandwidth Emission Designator M = 3 kHz 16K0F3E D = 5 kHz Bn = 6 + 10 x 1 = 16 kHz F3E represents a FM voice transmission 2. Fast Frequency Shift Keying (FFSK) 12.5kHz Bandwidth Necessary bandwidth Emission Designator M = 1.8 kHz 6K60F2D D = 1.5 kHz Bn = 3.6 + 3 x 1 = 6.6 kHz F2D represents a FM data transmission with the use of a modulating sub carrier 25kHz Bandwidth Necessary bandwidth Emission Designator M = 1.8 kHz 9K60F2D D = 3 kHz Bn = 3.6 + 6 x 1 = 9.6 kHz F2D represents a FM data transmission with the use of a modulating sub carrier 3. Tait High Speed Data (THSD) THSD uses a 4 level gaussian frequency shift keying (CP-4GFSK) modulation scheme. Data is transmitted at a rate of 12000bps for narrow band ch…

Text truncated - open the document above for the full version.
