CASTMBL3BMobile Transceiver

TM9300 DMR Mobile Radios User’s Guide MMB-00001-05 · Issue 5 · March 2015 Contents 3 Contents For your safety........................................................ 8 Menu maps............................................................ 17 1About this guide .................................................. 19 Safety warnings used in this guide ................................. 19 Related documentation................................................... 20 2Getting started ..................................................... 21 About your DMR digital radio.......................................... 22 About the radio controls.................................................. 23 Understanding the radio display ..................................... 26 Understanding the radio indicators ................................. 28 Using function keys to access frequently used features. 30 Navigating the radio’s menus ......................................... 31 Using the alphanumeric keys to search a list ................. 33 3Basic operation .................................................... 34 Turning the radio on and off........................................... 35 Adjusting the speaker volume ........................................ 36 Locking and unlocking the keypad ................................. 37 Changing the radio’s operating mode............................. 38 4Operating in conventional mode ........................ 39 Selecting a zone ............................................................. 40 Selecting a channel ........................................................ 41 Selecting a group............................................................ 42 Understanding talkgroups............................................... 43 Checking that a channel is clear..................................... 44 Making a call................................................................... 45 Making an individual call................................................. 46 Making a call using the address book ............................ 46 Making a local call .......................................................... 47 Connecting to a telephone network ................................ 48 Making an emergency call .............................................. 50 Sending a status message ............................................. 51 Transmitting at low power............................................... 51 Ending active calls .......................................................... 52 Activating the repeater before a call ............................... 53 Communicating directly with other radios....................... 54 Receiving a call .............................................................. 55 Receiving a text message .............................................. 55 Hearing faint and noisy signals....................................... 56 Using the radio in different repeater areas ..................... 58 4 Contents Scanning a group of channels........................................ 59 5Operating in trunked mode .................................66 Checking that your network is available ......................... 67 Changing your network .................................................. 67 Making a preset call ....................................................... 68 About trunked zones and workgroups............................ 70 About emergency operation ........................................... 73 Dialing a PABX number.................................................. 75 Dialing a PSTN number.................................................. 75 Receiving a call .............................................................. 76 Re-establishing a call ..................................................... 77 Checking the queue ....................................................... 78 About status messages .................................................. 80 About trunked text messages......................................... 82 Placing the radio in do-not-disturb mode........................ 85 Calls to conventional channels or conventional groups . 86 6Dialing calls in trunked mode .............................87 MPT 1343 dialing ........................................................... 88 Nokia ANN fleet calls...................................................... 90 Accessing common trunking functions ........................... 92 7GPS location services ..........................................94 About GPS location information ..................................... 95 About GPS status information ........................................ 95 Viewing GPS information ............................................... 96 8Loneworker monitoring .......................................97 Activating loneworker monitoring ................................... 97 Responding to a loneworker alarm................................. 98 9Encryption .............................................................99 About encryption .......................................................... 100 Encrypting calls ............................................................ 100 Making an encrypted call.............................................. 101 Receiving an encrypted call ......................................... 101 Removing encryption keys from the radio .................... 102 10 Customizing radio settings ...............................103 Changing the volume of all audible indicators.............. 104 Changing the volume of keypress tones ...................... 104 Changing to quiet operation ......................................... 105 Changing to silent operation......................................... 105 Changing the external alert option ............................... 106 Turning on backlighting ................................................ 106 Adjusting the display contrast....................................... 108 Contents 5 11 Troubleshooting .......................…

Text truncated - open the document above for the full version.

TM9400 P25 Mobile Radios User’s Guide MMB-00003-04 · Issue 4 · September 2014 Contents 3 Contents For your safety........................................................ 9 Menu maps............................................................ 18 1About this guide .................................................. 20 Safety warnings used in this guide ................................. 20 Related documentation................................................... 21 2Getting started ..................................................... 22 About P25 digital radios.................................................. 23 Lack of static noise ..................................................... 23 Coverage .................................................................... 23 P25 phase 2 operation ............................................... 23 About the radio controls.................................................. 24 About the keypad microphone.................................... 25 About the hand-held control head .............................. 26 Understanding the radio display ..................................... 27 Radio display icons .................................................... 27 Understanding the radio indicators ................................. 28 Status indicators ......................................................... 28 Audible tones.............................................................. 29 Using function keys to access frequently used features. 30 Viewing the function key settings ............................... 30 Navigating the radio’s menus ......................................... 31 Using the Main menu ................................................. 31 Accessing frequently used menus.............................. 31 3Basic operation .................................................... 33 Turning the radio on and off........................................... 34 Security lock on power-up feature .............................. 34 Adjusting the speaker volume ........................................ 35 Locking and unlocking the keypad ................................. 35 Selecting a zone ............................................................. 36 Selecting a channel ........................................................ 37 Limiting call time ............................................................. 38 Checking recent calls ..................................................... 38 4Operating in conventional mode ........................ 40 Making calls.................................................................... 41 Making an individual call............................................. 41 Understanding talkgroups .......................................... 42 Making an emergency call.......................................... 43 Receiving calls................................................................ 44 4 Contents Identifying a caller (talking party ID) ........................... 44 Receiving a two-tone call ........................................... 45 Communicating directly with other radios....................... 46 Checking that the channel is clear ................................. 47 Turning monitor on and off ......................................... 47 Using the radio in different repeater areas ..................... 48 Selecting a voting group............................................. 48 Suspending a channel from a voting group................ 49 Hearing faint and noisy signals ...................................... 50 Turning squelch override on and off........................... 50 5Operating in P25 trunking mode .........................51 About P25 trunking......................................................... 52 Checking that the system is available ............................ 52 Making a talkgroup call................................................... 54 Receiving a talkgroup call .............................................. 56 Making an individual call ................................................ 56 Receiving an individual call ............................................ 57 Emergency calls ............................................................. 57 Making a phone call ....................................................... 58 Unconnected calls .......................................................... 59 Failsoft mode operation.................................................. 60 Radio-based failsoft ................................................... 60 Infrastructure failsoft................................................... 60 Dynamic regrouping ....................................................... 61 6Scanning ...............................................................62 About scanning............................................................... 63 Activating standard scanning ......................................... 65 Activating background scanning..................................... 65 Changing the background scan group assigned to the function key ...................................................... 66 Activating in-zone scanning............................................ 66 Activating talkgroup scanning......................................... 67 Making a call while scanning.......................................... 68 Suspending a channel from a scan group...................... 68 Editing a scan group....................................................... 69 Selecting a group to edit ............................................ 69 Viewing group membership........................................ 70 Adding a channel to a group ...................................... 71 Deleting a channel from a group ................................ 72 Changing a group’s transmit channel......................... 72 Changing a group’s first or second priority channel ... 73 7P25 services ..........................................................74 Messages .........................................…

Text truncated - open the document above for the full version.

Tait Limited Phone: +64 3 358 0403 PO Box 1645, 558 Wairakei Road Fax: +64 3 358 9299 Burnside, Christchurch 8053 www.taitradio.com New Zealand 20 June 2015 Daniel E Crowder Elite Electronic Engineering Inc. 1516 Centre Circle, Downers Grove Illinois 60515 United States of America Dear Dan, Subject: Part 90.203 (j) (5) Certification Statement – FCC ID: CASTMBL3B Tait Limited certifies that it’s digital mobile transceiver FCC ID: CASTMBL3B, meets a spectrum efficiency standard of one voice channel per 6.25 kHz of channel bandwidth. Additionally, Tait Limited certifies the equipment is capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. Yours sincerely, Brian Emmett Standards and Compliance Engineer

Tait Limited Phone: +64 3 357 0283 PO Box 1645, 558 Wairakei Road Fax: +64 3 358 9299 Burnside, Christchurch 8053 www.taitradio.com New Zealand 20th June 2015 Request for Confidentiality FCC ID: CASTMBL3B In accordance with 47 C.F.R. Section 0.457 and 0.459, Tait Limited, hereby requests confidentiality for , Schematics, Parts List, Tune-up Procedure, and Operational Description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. David Jackson Test Laboratory Services Manager Tait Limited

Tait Limited Phone: +64 3 358 1026 PO Box 1645, 558 Wairakei Road Fax: +64 3 358 9299 Burnside, Christchurch 8053 www.taitradio.com New Zealand Justification Letter – Extended Frequency Range FCC ID: CASTMAL3B To meet the requirements of Federal Communications Commission (F.C.C.) publication, KDB634817 - Frequency Range Listings for Certification Grants, Tait Limited submits the following attestation. This Mobile Transceiver has: 1. The design capability to operate in the frequency band 896-940 MHz. 2.Complies with 47CFR Part 90.203(e) in that the equipment operator cannot directly program transmit frequencies using the normally accessible external controls. Programming this equipment is the responsibility of Tait Limited approved Service Agents In addition to the following rule part applied for: 90 This device may be utilised in systems operated by Federal and Public Safety agencies, as indicated in the table beneath. The Grant Note ‘EF’ should be appended to the Grant of Authorisation, indicating this operation is required. Freq. Range (MHz) Part 90 896-901 F/NF 902-928 NF 928-929 F/NF 929-930 F/NF 935-940 F/NF NF=Non Federal, F=Federal Des Fox Co mpliance Cordinator Tait Limited Christchurch 30 th June 2015

Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 1 of 8 Tait Limited External Photographs Exhibit (June 2015) Product: Mobile transceiver Type code: TMBL3B FCC ID: CASTMBL3B IC: 737A-TMBL3B Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 2 of 8 Photograph 01: Radio front view Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 3 of 8 Photograph 02: Radio top view Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 4 of 8 Photograph 03: Radio bottom view Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 5 of 8 Photograph 04: Front panel Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 6 of 8 Photograph 05: Left-hand side Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 7 of 8 Photograph 06: Right-hand side Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 8 of 8 Photograph 07: Rear

Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 1 of 10 Tait Limited Internal Photographs Exhibit (June 2015) Product: Mobile transceiver Type code: TMBL3B FCC ID: CASTMBL3B IC: 737A-TMBL3B Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 2 of 10 Photograph 01: Radio - Main PCB top with shields Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 3 of 10 Photograph 02: Radio - Main PCB top without shields Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 4 of 10 Photograph 03: Radio - Main PCB bottom with shields Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 5 of 10 Photograph 04: Radio - Main PCB bottom without shields Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 6 of 10 Photograph 05: Control Head - internal Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 7 of 10 Photograph 06: Control Head – Internal with main PCB removed Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 8 of 10 Photograph 07: Control Head - main PCB top with shields Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 9 of 10 Photograph 08: Control Head – Main PCB top without shields Tait Limited 535 Wairakei Road, Christchurch 8053 PO Box 1645 CHCH New Zealand +64 3 358 3399, www.taitradio.com Page 10 of 10 Photograph 09: Control Head – Main PCB bottom

TELTEST Laboratories Tait Limited Report Number 3662 FCC ID: CASTMBL3B Report Revision: 1 IC:737A-TMBL3B Page 1 of 11 LABORATORY TEST REPORT TEST: FCC 47 CFR 1.1310 Maximum Permissible Exposure (MPE) MPE ASSESSMENT For the 30 Watt Mobile Transceiver Type TMBL3B FCC ID: CASTMBL3B IC: 737A-TMBL3B In accordance with ANSI/IEEE Std C95.1 KDB 447498 v05 DATE: 30 June 2015 PREPARED BY: L. M. White Test Technician CHECKED & APPROVED BY: M. C. James Laboratory Technical Manager This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager. TELTEST Laboratories – A Division of Tait Limited Telephone: 64 3 358 3399, PO Box 1645, 558 Wairakei Road, Christchurch, New Zealand Fax: 64 3 359 4632 TELTEST Laboratories Tait Limited Report Number 3662 FCC ID: CASTMBL3B Report Revision: 1 IC:737A-TMBL3B Page 2 of 11 Contents CONTENTS ..................................................................................................... 2 REVISION HISTORY ....................................................................................... 2 DESCRIPTION OF SAMPLE: .......................................................................... 3 SUMMARY OF RESULTS: .............................................................................. 3 OPERATING AND EXPOSURE CONDITIONS: .............................................. 3 LIMITS: ............................................................................................................ 4 RECOMMENDED ANTENNAS: ....................................................................... 4 MEASUREMENT GUIDANCE: ........................................................................ 4 TEST RESULTS: ............................................................................................. 5 TEST EQUIPMENT USED: ............................................................................. 7 INFORMATION TO BE PLACED IN USER/INSTALLATION MANUAL: .......... 8 APPENDIX 1 .................................................................................................. 10 Revision History Date Revisio Comments 30 June 2015 1 Initial test report TELTEST Laboratories Tait Limited Report Number 3662 FCC ID: CASTMBL3B Report Revision: 1 IC:737A-TMBL3B Page 3 of 11 Description of Sample: Manufacturer Tait Limited Equipment: Mobile Transceiver Type: TMBL3B Product Code: T02-00012-YPAA Serial Number(s): 20288278 Frequency Range: 896-901 / 935-940 MHz Quantity: 1 Summary of Results: Limit: 47 CFR 1.1310 RSS-102 issue 5 Antenna Gain Antenna Position Measurement Position Result-USA Result-Canada 2.15 dBi Roof A External: Side COMPLIES COMPLIES 8 dBi Roof A External: Side COMPLIES COMPLIES 2.15 dBi Trunk C External: Rear COMPLIES COMPLIES 8 dBi Trunk C External: Rear COMPLIES COMPLIES 2.15 dBi Trunk B External: 45 degrees COMPLIES COMPLIES 8 dBi Trunk B External: 45 degrees COMPLIES COMPLIES 2.15 dBi Roof Internal: Front Seat COMPLIES COMPLIES 8 dBi Roof Internal: Front Seat COMPLIES COMPLIES 2.15 dBi Roof Internal: Back Seat COMPLIES COMPLIES 8 dBi Roof Internal: Back Seat COMPLIES COMPLIES See Appendix A for details of the measurement positions. Operating and Exposure Conditions: Operating Conditions: Mobile transmitter using vehicle mounted antennas only. Exposure conditions: Occupational/Controlled Exposure (operator). General Population/Uncontrolled (passengers and bystanders) Safe Distance: Recommended minimum lateral safe distance from the antenna: 90 cm TELTEST Laboratories Tait Limited Report Number 3662 FCC ID: CASTMBL3B Report Revision: 1 IC:737A-TMBL3B Page 4 of 11 Limits: 47 CFR 1.1310 896MHz 916.5MHz (Test Frequency) 940MHz Occupational/Controlled Exposure: f/300 mW/cm 2 3.0mW/cm 2 3.1mW/cm 2 3.1mW/cm 2 General population/Uncontrolled Exposure: f/1500 mW/cm 2 0.6mW/cm 2 0.6mW/cm 2 0.6mW/cm 2 RSS-102 issue 5 896MHz 916.5MHz (Test Frequency) 940MHz Occupational/Controlled Exposure: 0.6455f 0.5 W/m 2 19W/m 2 1.9mW/cm 2 20W/m 2 2.0mW/cm 2 20W/m 2 2.0mW/cm 2 General population/Uncontrolled Exposure: 0.0.619f 0.6834 W/cm 2 3W/m 2 0.3mW/cm 2 3W/m 2 0.3mW/cm 2 3W/m 2 0.3mW/cm 2 Recommended Antennas: Antenna Type Antenna Gain Monopole (λ/4 antenna) 2.15 dBi Monopole (Co-linear antenna) 8 dBi Measurement Guidance: Federal Communications Commission OET Laboratory Division KDB 447498 v05. Per definition of a mobile device a minimum separation distance of 20 cm is required. The minimum separation distances required to install an antenna on a vehicle must be larger than those tested for compliance and must be disclosed separately to antenna installers and radio operators to ensure compliance. A separation distance based on MPE evaluation (measurement or computer modelling) that is smaller than the estimated MPE distance may be used if it is applicable for the antenna installation conditions. A mid-sized sedan was used for the testing so that the results can be applied to a larger vehicle resulting in conservative exposure conditions. The roof antenna position tested is closer to bystanders than if it were mounted centrally (as recommended in the installation instructions) in order to ensure that even on small vehicle the separation distance is more conservative than the tested distance. TELTEST Laboratories Tait Limited Report Number 3662 FCC ID: CASTMBL3B Report Revision: 1 IC:737A-TMBL3B Page 5 of 11 Test Results: NAME OF TEST: TRANSMITTER OUTPUT POWER (CONDUCTED) SPECIFICATION: FCC 47 CFR 2.1046 GUIDE: TIA/EIA-603D 2.2.1 TRANSMITTER POWER MEASUREMENT: 1. The Equipment Under Test (EUT) was connected to an RF power meter using a coaxial attenuator with an impedance of 50 Ohms. 2. The unmodulated output power was measured. MEASUREMENT RESULTS: Transmit Frequency: 916.5 MHz Supply Voltage: 13.8 Volts Measured Output Power: 2.43 Watts Measurement Uncertainty (dB): ± 0.5 dB The MPE results are scaled to simulate results from a 30 watt transmitter. A margin of 20% is added to the rated power output of 30 watts giving 36 watts …

Text truncated - open the document above for the full version.

TELTEST Laboratories Tait Ltd Report Number 3655 FCC ID: CASTMBL3B Page 1 of 62 Report Revision: 1 IC : 737A-TMBL3B Issue Date: 30 June 2015 LABORATORY TEST REPORT RADIO PERFORMANCE MEASUREMENTS for the TMBL3B Mobile Transceiver Tested in accordance with: FCC 47 CFR Part 90 RSS-119 Issue 12 RSS-Gen Issue 4 Report Revision: 1 Issue Date: 30 June 2015 PREPARED BY: L. M. White _______________ Test Technician CHECKED & APPROVED BY: M. C. James _______________ Laboratory Technical Manager OATS FCC LISTING REGISTRATION: 837095 OATS IC LISTING REGISTRATION: SITE# 737A-1 All tests reported herein have been performed in accordance with the laboratory's scope of accreditation. This document must not be reproduced except in full, without the written permission of the Compliance Laboratory Manager TELTEST Laboratories (A Division of Tait Communications) Telephone: 64 3 358 3399 PO Box 1645, 558 Wairakei Road, Christchurch, New Zealand. FAX: 64 3 359 4632 TELTEST Laboratories Tait Ltd Report Number 3655 FCC ID: CASTMBL3B Page 2 of 62 Report Revision: 1 IC : 737A-TMBL3B Issue Date: 30 June 2015 TABLE OF CONTENTS REVISION .................................................................................................................. 2 INTRODUCTION ........................................................................................................ 3 STATEMENT OF COMPLIANCE ............................................................................... 4 MODULATION TYPES, NECESSARY BANDWIDTH & EMISSION DESIGNATORS 5 TEST RESULTS ......................................................................................................... 7 TRANSMITTER OUTPUT POWER (CONDUCTED) .............................................. 7 TRANSMITTER AUDIO FREQUENCY RESPONSE - PRE-EMPHASIS ................ 8 TRANSMITTER MODULATION LIMITING ........................................................... 11 TRANSMITTER OCCUPIED BANDWIDTH AND SPECTRUM MASKS ............... 15 TRANSMITTER SPURIOUS EMISSIONS (CONDUCTED) .................................. 40 TRANSMITTER SPURIOUS EMISSIONS (RADIATED) ....................................... 50 TRANSMITTER FREQUENCY STABILITY - TEMPERATURE ............................ 54 TRANSMITTER FREQUENCY STABILITY - VOLTAGE ...................................... 58 RECEIVER SPURIOUS EMISSIONS (CONDUCTED) ......................................... 59 TEST EQUIPMENT LIST.......................................................................................... 60 ANNEX A – TEST SETUP DETAILS ........................................................................ 62 REVISION Date Revision Comments 30 June 2015 1 Initial test report TELTEST Laboratories Tait Ltd Report Number 3655 FCC ID: CASTMBL3B Page 3 of 62 Report Revision: 1 IC : 737A-TMBL3B Issue Date: 30 June 2015 INTRODUCTION This report demonstrates that the TMBL3B 30 W mobile transceiver complies with FCC 47 Part 90, and RSS-119 Issue 12 & RSS-Gen Issue 4. This radio supports analog, digital FFSK, P25 phase-1, P25 phase-2, and Digital Mobile Radio modulations. REPORT PREPARED FOR Tait Communications PO Box 1645 558 Wairakei Road Christchurch New Zealand DESCRIPTION OF SAMPLE Manufacturer Tait Limited Equipment: Mobile Transceiver Type: TMBL3B Product Code: T02-00012-YPAA Serial Number(s): 20288278 Quantity: 1 HARDWARE & SOFTWARE Type Analog and DMR P25 Phase I & II Hardware ID TMBB14-L300_0006 TMBB14-L300_0006 Boot Code QMB1B_S00_3.01.03.0001 QMB1B_S00_3.01.03.0001 DSP QMB1A_E00_2.01.00.0018 QMB1A_A02_2.01.00.0025 Radio Application QMB1F_E00_2.01.00.0018 QMB1F_A00_2.01.00.0025 FPGA Image QMB1G_S00_1.07.00.0002 QMB1G_S00_1.07.00.0002 TEST CONDITIONS All testing was performed between 16 Æ 26 June 2015, and under the following conditions: Ambient temperature: 15 o C Æ 30 o C Relative Humidity: 20% Æ 75% Standard Test Voltage 13.8 V DC Modulation Channel Spacing Speech Channels Symbol Rate (symbols/sec) Data Rate (bps) Analogue FM 12.5 kHz 1 - - FFSK Fast Frequency Shift Keying 12.5 kHz - 1200 1200 12.5 kHz - 2400 2400 Digital Mobile Radio (DMR) 4 Level FSK (2 slot TDMA) (ETSI TS102 361-1) 12.5 kHz 2 4800 9600 APCO P25 Phase 1 C4FM (TIA 102) 12.5 kHz 1 4800 9600 APCO P25 Phase 2 H-CPM (2 slot TDMA) (TIA 102) 12.5 kHz 2 6000 12000 TELTEST Laboratories Tait Ltd Report Number 3655 FCC ID: CASTMBL3B Page 4 of 62 Report Revision: 1 IC : 737A-TMBL3B Issue Date: 30 June 2015 STATEMENT OF COMPLIANCE We, TELTEST LABORATORIES of 558 Wairakei Road, Christchurch, New Zealand, declare under our sole responsibility that the product: Equipment: Mobile Transceiver Type: TMBL3B Product Code: T02-00012-YPAA Serial Number(s): 20288278 Quantity: 1 to which this declaration relates, is in conformity with the following standards: FCC 47 CFR Part 90 RSS-119 Issue 12 & RSS-Gen Issue 4 Signature: ___________________ M. C. James Laboratory Technical Manager Date: ___________________ TELTEST Laboratories Tait Ltd Report Number 3655 FCC ID: CASTMBL3B Page 5 of 62 Report Revision: 1 IC : 737A-TMBL3B Issue Date: 30 June 2015 MODULATION TYPES, NECESSARY BANDWIDTH & EMISSION DESIGNATORS MODULATION TYPES: F3E Analogue Frequency Modulation (FM) F2D FFSK 1200 bps and 2400 bps FXW DMR Digital Voice 9600 bps FXD DMR Digital Data 9600 bps F1E, F7E P25 phase 1 Digital Voice 9600 bps F1D, F7D P25 phase 1 Digital Data 9600 bps F1W P25 phase 2 Digital Voice / Data 12000 bps CHANNEL SPACINGS: 12.5 kHz EMISSION DESIGNATORS: 12.5 kHz Analog FM 11K0F3E FFSK Data 1200 bps 6K60F2D FFSK Data 2400 bps 7K80F2D Digital Voice DMR 7K60FXW Digital Data DMR 7K60FXD Digital Voice P25 phase 1 8K10F1E Digital Data P25 phase 1 8K10F1D Digital Voice P25 phase 2 8K10F1W Digital Data P25 phase 2 8K10F1W CALCULATIONS Equation: Bn = 2M + 2Dk (M is highest modulating frequency; D is peak allowable deviation; k is a constant of 1 for FM) Analog Voice 12.5 kHz Bandwidth Necessary bandwidth Emission Designator M = 3.0 kHz 11K0F3E D = 2.5 kHz F3E rep…

Text truncated - open the document above for the full version.
