CFS-2C2BHTRANRemote control

Manual of Remote Control Parameter ⚫ Frequency：315MHZ； ⚫ Work Voltage：7～12V ⚫ Work current：14ma±1ma ⚫ Quiescent current：0uA ⚫ Code：rolling code HCS301； ⚫ Work distance ：80m in the open area with Receiver ； Learning code(Match the remote with receiver ): When the receiver connects with power, the LED of the receiver light on. Then you press the learn button on the receiver, receiver LED starts to flash. Press the remote control button within the 30s, and the receiver LED flashes faster and light on, it’s mean matching the receiver and remote successfully. Note: When you press the remote control, the LED of the remote control will light on. If you keep pressing, the LED keeps light. O FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. -English: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. -French: Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1)l'appareil ne doit pas produire de brouillage, et (2)l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

Ademco Inc. Model Difference Product Name: Remote control Model Number: 0E-2C2BHTRAN, 0E-4C4BHTRAN FCC Identifier: CFS-2C2BHTRAN All the models are the same circuit and RF module, except the model names and Number of appearance keys. Regards Sincerely Client’s signature Client’s name / title : Christian Fouth / Sr. Wireless Certification Engineer Contact information / address: 2 Corporate Center Drive Suite 100 Melville, NY 11747

Ademco Inc. 1/1 Letter of Authorization Company: Ademco Inc. Address: 2 Corporate Center Drive Suite 100 Melville, NY 11747 Product Name: Remote control Model Number: 0E-2C2BHTRAN, 0E-4C4BHTRAN FCC Identifier: CFS-2C2BHTRAN We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Christian Fouth Date: 2022-11-15 Title: Sr. Wireless Certification Engineer Signature of applicant:

Ademco Inc. 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022-11-15 Subject: Request for Confidentiality FCC ID: CFS-2C2BHTRAN To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Christian Fouth Title: Sr. Wireless Certification Engineer

Size:16*10mm M/N: 0E-2C2BHTRAN FCC ID: CFS-2C2BHTRAN IC: 573F-2C2BHTRAN M/N: 0E-4C4BHTRAN FCC ID: CFS-2C2BHTRAN IC: 573F-2C2BHTRAN Label location

ANT
