CFS8DL6CTAWireless door/window contact

SiXCTA Wireless Door/Window Contact | Contact de porte / fenêtre sans fil | Contacto inalámbrico de puerta / ventana Quick Installation Guide This wireless door / window contact is intended for use with controls that support SiX™ series devices. Guide d'installation rapide Ce contact de porte / fenêtre sans fil est conçu pour être utilisé avec les panneaux de commande qui supportent les dispositifs de la série SIX MC . Guía Rápida de Instalación Este contacto inalámbrico para puerta/ventana, ha sido diseñado para usarse con los controles compatibles con los dispositivos de la serie SiX™. A Terminal Block B Reed Switch C Magnet D Tamper E LED Magnet Gap: Make gap is 0.75"; Break gap is 1.30". NOTE: Wiring limit is 3ft. A Bornier B Contact à lame C Aimant D Antisabotage E DEL Écart de l'aimant : Écart à l'état fermé : 0,75 po; Écart à l'état ouvert : 1,3 po NOTE : La longueur maximale du câblage est de 3 pi. A Bloque de terminals B Interruptor de lengüeta C Imán D Manipulación E LED Espacio del imán: El espacio de conexión es 0,75"; El espacio de desconexión es 1,30". NOTA: El límite de cableado es 3 pies. Enroll To enroll the device, use the programming app. When prompted, activate the device by pulling the battery tab (use the tamper switch if the battery tab is removed). After enrolling and before mounting permanently, conduct a Walk test (see the controller’s instructions) to verify adequate signal strength. Adjust the device location and orientation as necessary. NOTE: Once enrolled, the device cannot be used with another system until it is removed from the current controller. See the controller’s instructions. Enrôlement Utilisez l'application de programmation pour enregistrer un dispositif. Lorsque l’identifiant vous est demandé, activez le dispositif en tirant sur la languette de la pile (utilisez l’interrupteur antisabotage si la languette de la pile est retirée). Après avoir enrôlé l'unité et avant de la mettre en place de façon permanente, effectuez des tests Tout ou rien (voir les instructions du panneau de commande) pour vérifier que la puissance du signal est adéquate. Au besoin, modifiez l'emplacement ou l'orientation du dispositif. NOTE : Une fois enrôlé, le dispositif ne peut pas être utilisé avec un autre système avant d'avoir été supprimé du panneau actuel. Reportez-vous aux instructions du panneau. Enrolar Para inscribir el dispositivo, use la aplicación de programación. Cuando se le solicite la identificación, active el dispositivo tirando de la lengüeta de la batería (use el interruptor de seguridad si se ha quitado la lengüeta de la batería). Una vez enrolado y previo a su montaje permanente, realice pruebas de Walk (vea las instrucciones del controlador) para verificar la intensidad adecuada de la señal. Ajuste la ubicación y orientación del dispositivo según sea necesario. NOTA: Una vez enrolado, el dispositivo no se puede usar con otro sistema hasta que sea removido del controlador actual. Ver las instrucciones del controlador. BATTERY CAUTION: Risk of fire, explosion and burns. Do not recharge, disassemble, heat above 212° F (100° C) or incinerate. Dispose of used batteries properly. Keep away from children. Attention de batterie: Risque d'incendie, d'explosion et de brûlures. Ne rechargez pas, démonter, chauffer au-dessus de 212° F (100°C), ou incinérer. Débarrassez-vous des batteries utilisées de façon appropriée. Gardez à partir des enfants. Precauciones con respecto a las baterías: Riesgo de FUEGO, explosión y quemaduras. No recargar, desarmar, calentar por encima de 100°C (212°F), o incinerar. Descarte Apropiadamente las baterías usadas. Manténgalas fuera del alcance de los niños. FEDERAL COMMUNICATIONS COMMISSION (FCC) & INDUSTRY CANADA (IC) STATEMENTS The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User's Manual. Unauthorized changes or modifications could void the user's authority to operate the equipment. CLASS B DIGITAL DEVICE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, as defined by FCC Rules Part 15.105. The Class B Digital Device statement can be viewed at: https://customer.resideo.com/en-US/support/residential/codes-and-standards/FCC15105/Pages/default.aspx FCC / IC STATEMENT This device complies with Part 15 of the FCC Rules, and Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Cet appareil est conforme à la partie 15 des règles de la FCC et exempt de licence RSS d’Industrie Canada. Son fonctionnement est soumis aux conditions suivantes: (1) Cet appareil ne doit pas causer d’interférences nuisibles. (2) Cet appareil doit accepter toute interférence reçue y compris les interférences causant une réception indésirable. RF EXPOSURE Warning – The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 7.8 in (20 cm) from all persons and must not be co-located or operated in conjunction with any other transmitter except in accordance with FCC and ISED multi-transmitter product procedures. Mise en Garde Exposition aux Fréquences Radio: La/les antenne(s) utilisée(s) pour cet émetteur doit/doivent être installée(s) à une distance de séparation d'au moins 20 cm (7,8 pouces) de toute personne et ne pas être située(s) ni fonctionner parallèlement à tout autre transmetteur ou antenne, excepté en conformité avec les procédures de produit multi transmetteur FCC et ISED. DECLARACIÓN IFETEL La operación de este equipo está sujeta a las siguientes dos condiciones 1. Es posible que este equipo o dispositivo no cause interferencia perjudicial y 2. Este equipo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada. Responsible Party / Issuer …

Text truncated - open the document above for the full version.

CFS8DL6CTA CFR 47 §2.911 (d)(5) Attestation Date: 02-15-2023 FCC ID: CFS8DL6CTA To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA 1. Ademco Inc. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Ademco Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Name: Christian Fouth Job Title: Global Leader Wireless Testing Company Name: Ademco Inc.

CFS8DL6CTA CFR 47 §2.911 (d)(7) Agent Designation Attestation Date: 02-15-2023 FCC ID: CFS8DL6CTA FCC FRN: 0004071130 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Ademco Inc. (“the applicant”) as required by section 2.911(d)(7), will also serve as the agent for service of process for the above referenced FCC ID. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. Christian Fouth Ademco Inc. 2 Corporate Center Dr, Melville, NY 11747 [email protected] Sincerely yours, Christian Fouth Ademco Inc. 2 Corporate Center Dr, Melville, NY 11747 [email protected]

Date: 1/23/2023 UL LLC 12 Laboratory Dr. Research Triangle Park, NC 27709 USA To whom it may concern: I, the undersigned, hereby authorize UL LLC to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL LLC as our representative, we still recognize that we are responsible to: a) fulfill the requirements for the scope of certification requested, including implementing any appropriate changes requested by UL Verification Services Telecommunications Certification Body (TCB) and / or the FCC; b) supply any and all information needed for the evaluation of the products for which certification is sought; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) not use our product certification in such a manner as to bring the TCB or FCC into disrepute and to not make any statement regarding product certification which the TCB or FCC may consider misleading or unauthorized; e) discontinue use of all advertising matter that contains any reference thereto and complies with any and all actions required by the FCC upon suspension or cancellation of certification; f) use certification only to indicate that products are certified in conformity with specified standards; g) endeavor to ensure that no certificate or report or any part thereof is used in a misleading manner, and any copies of the grants/certificates shall be reproduced in their entirety; h) comply with the requirements of the TCB and FCC, including the use of marks and label information prescribed for the scope of certification, when making reference to product certification in communication media such as documents, brochure or advertisements; i) comply with the requirements for certification, supply any information needed for evaluation of products to be certified and, where applicable, make provision for the participation of observers; j) ensure that products marketed under the scope of the requested certification continue to comply with the certification requirements; k) provide a sample of a production unit for testing within 30 days of the request should this product be selected as part of either the TCB’s or the FCC’s market surveillance requirements; l) keep a record of all complaints relating to product’s compliance with requirements of relevant standard; make records available to UL or FCC when requested; take appropriate action with respect to such complaints and any deficiencies found in the product that affect compliance with requirements for certification; document the actions taken with respect to complaints and/or deficiencies; m) inform the TCB immediately of any changes that may affect its ability to comply with the certification requirements. This authorization is valid until further written notice from the applicant. Sincerely Yours, Christian Fouth Global Leader Wireless Testing Ademco Inc.

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality CFS8DL6CTA To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. •Schematic Diagram •RF Block Diagram •Operational Description •BOM Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Christian Fouth Global Leader Wireless Testing Ademco Inc. 01 /23/2023

External Photos CFS8DLRF6CTA / 573F-RF6CTA 1 SI XCTA/PROSIXCT EXTERNAL PHOTOS Figure 1 TOP VIEW Figure 2 BOTTOM VIEW External Photos CFS8DLRF6CTA / 573F-RF6CTA 2 Figure 3 REAR VIEW Figure 4 FRONT VIEW External Photos CFS8DLRF6CTA / 573F-RF6CTA 3 Figure 5 SIDE VIEW LEFT Figure 6 SIDE VIEW RIGHT

CFS8DL6CTA/573F-6CTA Label Location Figure 1 Device back cover The FCC/ISED IDs and the FCC compliance statement are molded into the device's back cover. FCC/ISED IDs FCC ID: CFS8DL6CTA IC: 573F-6CTA RF6CTA


      !"## $ %&' !%()*+ !

Internal Photos CFS8DLRF6CTA / 573F-RF6CTA 1 SI XCTA/PROSIXCT INTERNAL PHOTOS Figure 1 TOP VIEW Figure 2 PCB TOP VIEW Internal Photos CFS8DLRF6CTA / 573F-RF6CTA 2 Figure 3 PCB with Antennas ANT1 ANT2 Internal Photos CFS8DLRF6CTA / 573F-RF6CTA 3 Figure 4 PCB BACK Figure 5 Case Interior top cover Internal Photos CFS8DLRF6CTA / 573F-RF6CTA 4 Figure 6 Case Interior bottom cover

FCC Part 1 Subpart I FCC Part 2 Subpart J RF EXPOSURE REPORT FOR Temperature Sensor MODEL NUMBER: RF6CTA FCC ID: CFS8DL6CTA IC: 573F-6CTA REPORT NUMBER: R14558575-E2 ISSUE DATE: 2022-12-01 Prepared for: Ademco Inc. 2 Corporate Center Dr. Melville, NY 11747, U.S.A. Prepared by: UL LLC 12 LABORATORY DR. RESEARCH TRIANGLE PARK, NC 27709 USA TEL: (919) 549-1400 REPORT NO: R14558575-E2 DATE: 2022-12-01 FCC ID: CFS8DL6CTA IC: 573F-6CTA Page 2 of 10 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. REVISION HISTORY Rev. Issue Date Revisions Revised By V1 2022-12-01 Initial Issue Charles Moody REPORT NO: R14558575-E2 DATE: 2022-12-01 FCC ID: CFS8DL6CTA IC: 573F-6CTA Page 3 of 10 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. TABLE OF CONTENTS REVISION HISTORY ..................................................................................................................2 1. ATTESTATION OF TEST RESULTS ..................................................................................4 2. TEST METHODOLOGY ......................................................................................................5 3. REFERENCES ....................................................................................................................5 4. FACILITIES AND ACCREDITATION ..................................................................................5 5. DECISION RULES AND MEASUREMENT UNCERTAINTY ...............................................6 5.1. METROLOGICAL TRACEABILITY ...............................................................................6 5.2. DECISION RULES ........................................................................................................6 5.3. MEASUREMENT UNCERTAINTY ................................................................................6 6. MAXIMUM PERMISSIBLE EXPOSURE (LIMITS AND EQUATIONS) ................................7 6.1. FCC RULES .................................................................................................................7 6.2. EQUATIONS .................................................................................................................8 7. RF EXPOSURE RESULTS ................................................................................................10 END OF REPORT ....................................................................................................................10 REPORT NO: R14558575-E2 DATE: 2022-12-01 FCC ID: CFS8DL6CTA IC: 573F-6CTA Page 4 of 10 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: Ademco Inc. 2 Corporate Center Dr. Melville, NY 11747, U.S.A. EUT DESCRIPTION: Temperature Sensor MODEL: RF6 SERIAL NUMBER: Non-Serialized SAMPLE RECEIVED DATE: 2022-10-28 DATE TESTED: 2022-10-28 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 1 SUBPART I & PART 2 SUBPART J Complies UL LLC. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. All samples tested were in good operating condition throughout the entire test program. Measurement Uncertainties are published for informational purposes only and were not taken into account unless noted otherwise. This document may not be altered or revised in any way unless done so by UL LLC. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL LLC. will constitute fraud and shall nullify the document. Approved & Released For UL LLC By: Prepared By: Michael Antola Charles Moody Staff Engineer Electrical Engineer Consumer, Medical, and IT Segment Consumer, Medical, and IT Segment UL LLC UL LLC REPORT NO: R14558575-E2 DATE: 2022-12-01 FCC ID: CFS8DL6CTA IC: 573F-6CTA Page 5 of 10 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 2. TEST METHODOLOGY All calculations were made in accordance with FCC Parts 1.1310, 2.1091, 2.1093, KDB 447498 D01 v06, KDB 447498 D03 V01, IEEE Std C95.1-2005, IEEE Std C95.3-2002. 3. REFERENCES Output power, Duty cycle and Antenna gain data is excerpted from product documentation provided by the applicant. 4. FACILITIES AND ACCREDITATION UL LLC is accredited by A2LA, Certificate Number 0751.06, for all testing performed within the scope of this report. Testing was performed at the locations noted below. Address ISED CABID ISED Company Number FCC Registration ☒ Building 2800 Suite Perimeter Park Dr. Suite B Morrisville, NC 27560, U.S.A US0067 27265 825374 REPORT NO: R14558575-E2 DATE: 2022-12-01 FCC ID: CFS8DL6CTA IC: 573F-6CTA Page 6 of 10 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 5. DECISION RULES AND MEASUREMENT UNCERTAINTY 5.1. METROLOGICAL TRACEABILITY The measuring equipment utilized to perform the tests documented in this report has been calibrated in accordance with the manufacturer's recommendations, and is traceable to recognized national standards. 5.2. DECISION RULES For all tests where the applicable U LAB <…
