CGDHH2RFIDHand held UHF RFID Reader for in-store retail applications

The !D Hand 2 is a RFID handheld reader in a revolutionary design. The handheld reader was designed with users in mind; with only one button to activate and operate, you offer your staff a unique and user-friendly application. The !D Hand 2 is lightweight, and known for its performance with outstanding RFID reading and writing capabilities. specifications • Lightweight and superior ergonomics • Optimal reading performance • Single button user interface • Vibration motor and beeper • 2D imaging barcode scanner • Can be charged wirelessly in a docking station • Compatible with iPod, iPhone and iPad*, and other Bluetooth-enabled devices • Designed in collaboration with major retailers for optimum ease of use • Open API available for integration by system integrators and/or retailers !D Hand 2 RFID Technology www.nedap-retail.com Parallelweg 2d NL-7141 DC Groenlo the Netherlands t+31 (0) 544 471555 f +31 (0) 544 465814 [email protected] ordering information DescriptionArticle number ASSY HH2 RFID R1 WHITE 9215441 ASSY HH2 RFID R2 WHITE9565035 PS ASSY HH2 WHITE | 29-05-2015 options • Bumper to protect the !D Hand in rough environments • Docking station to charge the !D Hand 2 wireless technical specifications • Air interface protocol EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C • Supported regionRegion 1 • Radiated powerEurope (ETSI EN 302 208): 2W erp • Antenna typeCross-dipole • Maximum tag throughput 200 labels per second • Reading distance1.5m - 3.0m / 4.92ft - 9.84ft (depending on label and orientation) • Barcode reader2D imaging (CMOS) barcode scanner • ConnectivityBluetooth, USB, Wireless charging (Qi) • Battery lifeStandby, when connected over Bluetooth: 36 hours. When reading: 4 hours. Not connected, standby: 1 month • Dimensions318 x 112 x 38mm 1.04ft x 4.41”ft x 1.5” • Weight264 gr / 0.58 lbs • Mains100 - 240V • Operating temp.0 .. 45ºC, 0 .. 113ºF package includes • !D Hand 2 • Micro USB charger 76 38 318 112 0 3 76 38 318 112 0 3 Region 1: Europe (ETSI EN 302 208), Armenia, Azerbaijan, Hong Kong, India, Jordan, Oman, Russia, Saudi Arabia, South Africa, Tunisia, United Arab Emirates and Vietnam Region 2: United States (FCC Part 15.247), Australia, Brazil, Argentina, Canada, Chile, Colombia, Costa Rica, Dominican Republic, Israel, Mexico, New Zealand, Panama, Peru, Taiwan, Uruguay and Venezuela

N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. Groenlo, 27 August 2015 Return address: PO Box 6, 7140 AA Groenlo, The Netherlands American Certification Body Certification Department 6731 Whittier Avenue, Suite C110 McLean, Virginia 22101 USA Subject: Cover letter FCC filing CGDHH2RFID To whom it may concern, We, N.V. Nederlandsche Apparatenfabriek "Nedap", hereby would like to apply for FCC certification of the following device: FCC ID : CGDHH2RFID FRN : 0007696149 Brand : Nedap Model : ASSY HH2 RFID Type of Service : New Application Description : Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz The following PDF files (exhibits) are electronically submitted: 1. Cover letter (this document) 2. Request for confidentiality 3. Application form 4. Antenna information 5. Bill of material (2 provided 5a, 5b) 6. Circuit diagram (2 provided 6a, 6b) 7. Block diagram 8. Interior photograph report 9. Exterior photograph report 10. Label location incl. label 11. Theory of Operation 12. Test report in conformity (2 provided 12a and 12b) 13. Test setup photographs 14. Install Manual 15. Brochure 16. RF Exposure statement 17. Grant Blue Tooth module WT12A FCC ID: QOQWT12 18. RF Exposure statement WT12A Best regards, N.V. Nederlandsche Apparatenfabriek “Nedap“ Reinold Hubers Compliance Engineer

N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. Request for Confidentiality Date: 27 August 2015 Subject: Confidentiality Request for: CGDHH2RFID and 1444A-HH2RFID Pursuant to FCC 47 CRF 0.457(d)(2)(i) and 0.459 and IC RSP-100, Section 6.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term X Permanent Block Diagrams Short Term X Permanent Operation Description/Theory of Operation Short Term Permanent* 1 Short Term X Permanent Schematics Short Term X Permanent Parts List & Placement/BOM Short Term Permanent* 3 N.V. Nederlandsche Apparatenfabriek Nedap has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Reinold Hubers Compliance Engineer 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section V regarding EXCEPTIONAL CIRCUMSTANCES. As of the October 2014 version of this document, TCB’s can not authorize these requests. The applicant should petition the FCC by submitting an inquiry as directed. A copy of this inquiry and the FCC’s response must be provided with the application.

Page 1 of 6 Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz Brand Nedap Model: ASSY HH2 RFID Exterior Photographs Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 2 of 6 Description of item Description of EUT : Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz Manufacture : N.V. Nederlandsche Apparatenfabriek “Nedap” Brand : Nedap Model : ASSY HH2 RFID FCC ID : CGDHH2RFID IC : 1444A-HH2RFID Type of service : New Application Applicant information Applicant's representative : Mr. Reinold Hubers Company : N.V. Nederlandsche Apparatenfabriek “Nedap” Address : Parallelweg 2 Postal code : 7141 DC City : Groenlo Country : Netherlands Telephone number : +31 (0) 544 471111 Telefax number : +31 (0) 544 463475 Email : [email protected] 10 August 2015 Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 3 of 6 Table of contents 1 TOTAL OVERVIEW OF THE ASSY HH2 RFID ...................................................................................................................... 4 2 TOP SIDE ............................................................................................................................................................................... 4 3 BOTTOM SIDE ....................................................................................................................................................................... 5 4 SIDE VIEW ............................................................................................................................................................................. 5 5 LABELING OF THE POWER SUPPLY .................................................................................................................................... 6 Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 4 of 6 1 Total overview of the ASSY HH2 RFID 2 Top side Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 5 of 6 3 Bottom side 4 Side view Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 6 of 6 5 Labeling of the Power supply

Page 1 of 5 Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz Brand Nedap Model: ASSY HH2 RFID Label Loaction Label photographs Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 2 of 5 Description of item Description of EUT : Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz Manufacture : N.V. Nederlandsche Apparatenfabriek “Nedap” Brand : Nedap Model : ASSY HH2 RFID FCC ID : CGDHH2RFID IC : 1444A-HH2RFID Type of service : New Application Applicant information Applicant's representative : Mr. Reinold Hubers Company : N.V. Nederlandsche Apparatenfabriek “Nedap” Address : Parallelweg 2 Postal code : 7141 DC City : Groenlo Country : Netherlands Telephone number : +31 (0) 544 471111 Telefax number : +31 (0) 544 463475 Email : [email protected] 03 September 2015 Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 3 of 5 Table of contents 1 LOCATION OF LABEL ........................................................................................................................................................... 4 2 LABEL ..................................................................................................................................................................................... 5 Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 4 of 5 1 Location of label Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 5 of 5 2 Label

Page 1 of 12 Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz Brand Nedap Model: ASSY HH2 RFID Interior Photographs Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 2 of 12 Description of item Description of EUT : Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz Manufacture : N.V. Nederlandsche Apparatenfabriek “Nedap” Brand : Nedap Model : ASSY HH2 RFID FCC ID : CGDHH2RFID IC : 1444A-HH2RFID Type of service : New Application Applicant information Applicant's representative : Mr. Reinold Hubers Company : N.V. Nederlandsche Apparatenfabriek “Nedap” Address : Parallelweg 2 Postal code : 7141 DC City : Groenlo Country : Netherlands Telephone number : +31 (0) 544 471111 Telefax number : +31 (0) 544 463475 Email : [email protected] 10 August 2015 Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 3 of 12 Table of contents 1 EXTERNAL PHOTOGRAPH OF THE ASSY HH2 RFID ......................................................................................................... 4 2 INTERNAL PHOTOGRAPH COVER REMOVED ................................................................................................................... 4 2.1 TOP COVER REMOVED ..................................................................................................................................................... 4 2.2 OVERVIEW INTERNAL ...................................................................................................................................................... 5 2.3 CONTROLLER BOARD REMOVED ...................................................................................................................................... 5 3 UHF TRANSCEIVER BOARD ................................................................................................................................................. 6 3.1 SHIELDING COVERS REMOVED FRONT ............................................................................................................................. 6 3.1.1 Detail 1 .................................................................................................................................................................. 7 3.1.2 Detail 2 .................................................................................................................................................................. 7 3.2 TRANSCEIVER BOARD BACK ............................................................................................................................................ 8 3.3 TRANSCEIVER BOARD UHF ANTENNA FRONT ................................................................................................................. 9 3.3.1 Detail 3 .................................................................................................................................................................. 9 3.4 TRANSCEIVER BOARD UHF ANTENNA BACK ................................................................................................................. 10 3.4.1 Detail 4 ................................................................................................................................................................ 10 4 CONTROLLER BOARD ........................................................................................................................................................ 11 4.1 CONTROLLER BOARD FRONT ......................................................................................................................................... 11 4.2 CONTROLLER BOARD BACK ........................................................................................................................................... 11 4.2.1 Detail 5 ................................................................................................................................................................ 12 Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 4 of 12 1 External photograph of the ASSY HH2 RFID 2 Internal photograph cover removed 2.1 Top cover removed Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 5 of 12 2.2 Overview internal 2.3 Controller board removed Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 6 of 12 3 UHF Transceiver board 3.1 Shielding covers removed front Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID New Application Page 7 of 12 3.1.1 Detail 1 3.1.2 Detail 2 Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: Type of Application: Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz N.V. Nederlandse Apparatenfabriek “N…

Text truncated - open the document above for the full version.

N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. Groenlo, 20 November 2015 Declaration on radiation safety standard conformance Return address: PO Box 6, 7140 AA Groenlo, The Netherlands American Certification Body Certification Department 6731 Whittier Avenue, Suite C110 McLean, Virginia 22101 USA To whom it may concern We, N.V. Nederlandsche Apparatenfabriek “Nedap”, declare that the following product: Description : Hand held UHF RFID Reader for in-store retail applications operating on 902-928 MHz FCC ID : CGDHH2RFID Manufacturer : N.V. Nederlandsche Apparatenfabriek “Nedap” Brand : Nedap Model : ASSY HH2 RFID has a maximum conducted peak power of 26.05 dBm equals 403 mW. With an antenna gain of +1 dBi (1.26 x) this results in 508 mW peak in the frequency range of 902 – 928 MHz. meaning the power density at 8.5 cm distance for near fields can be calculated as follows : S = Ppeak/4* * R 2 (power density) Ppeak = 508 mW S = Ppeak / 4* * R 2 = 508 / 4**(8.5 cm) 2 = 0.560 mW/cm 2 The limit is 1 mW/cm 2 This means that according to OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01), the equipment fulfills the requirements on power density for general population/uncontrolled exposure and therefore fulfills the requirements of 47 CFR Part 15.247 (b)(5). For the SAR exclusion threshold calculations (10g, extremity-SAR), see the next page of this document. N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. SAR exclusion threshold calculations (10g, extremity-SAR) KDB 447498 D01 General RF Exposure Guidance v05r02, section 4.3.1 1) provides the following equation (10g SAR test exclusion threshold) for test separation distances of less than 50 mm (step 1): (푚푎푥푖푚푢푚 푝표푤푒푟 표푓 푐ℎ푎푛푛푒푙 푖푛푐푙푢푑푖푛푔 푡푢푛푒−푢푝 푡표푙푒푟푎푛푐푒 (푚푊)) (푚푖푛푖푚푢푚 푡푒푠푡 푠푒푝푎푟푎푡푖표푛 푑푖푠푡푎푛푐푒 ( 푚푚 ) ) ×√푓 ( 퐺퐻푧 ) ≤7.5 • f (GHz) is the RF channel transmit frequency in GHz; • Power and distance are rounded to the nearest mW and mm before calculation; • The result is rounded to one decimal place for comparison; • 7.5 is referred to as the numeric threshold. Since the test separation distance is >= 50 mm, KDB 447498 D01 General RF Exposure Guidance v05r02, section 4.3.1 2), must be taken into account. Section 4.3.1 2) a) contains the following equation for calculating the SAR exclusion threshold at test separation distance >= 50 mm (for frequencies between 100 MHz and 1500 MHz): ( ( 푃표푤푒푟 푎푙푙표푤푒푑 푎푡 푛푢푚푒푟푖푐 푡ℎ푟푒푠ℎ표푙푑 푓표푟 50 푚푚 푖푛 푠푡푒푝 1 ( 푚푊 ) ) + ( ( 푡푒푠푡 푠푒푝푎푟푎푡푖표푛 푑푖푠푡푎푛푐푒 − 50 푚푚 ) × ( 푓(푀퐻푧)/150 ) ) ) 푚푊 Power allowed at numeric threshold for 50 mm in step 1 (mW): 푚푎푥푖푚푢푚 푝표푤푒푟 표푓 푐ℎ푎푛푛푒푙 푖푛푐푙푢푑푖푛푔 푡푢푛푒−푢푝 푡표푙푒푟푎푛푐푒 ( 푚푊 ) = ( 7.5 √ 푓 ( 퐺퐻푧 ) ) ×(푚푖푛푖푚푢푚 푡푒푠푡 푠푒푝푎푟푎푡푖표푛 푑푖푠푡푎푛푐푒 ( 푚푚 ) ) 푚푎푥푖푚푢푚 푝표푤푒푟 표푓 푐ℎ푎푛푛푒푙 푖푛푐푙푢푑푖푛푔 푡푢푛푒−푢푝 푡표푙푒푟푎푛푐푒 ( 푚푊 ) =( 7.5 √ 0.928 )×50 푚푎푥푖푚푢푚 푝표푤푒푟 표푓 푐ℎ푎푛푛푒푙 푖푛푐푙푢푑푖푛푔 푡푢푛푒−푢푝 푡표푙푒푟푎푛푐푒 ( 푚푊 ) =389.2 푚푊 Power allowed at a test separation distance of 85 mm (for frequencies between 100 MHz and 1500 MHz, mW): (389.2+ ( ( 85 − 50 ) × ( 928/150 ) ) ) 푚푊 (389.2+ ( 35× ( 928/150 ) ) ) 푚푊 ( 389.2+ ( 35×6.19 ) ) 푚푊 ( 389.2+216.5 ) 푚푊 605.7 푚푊 The maximum peak output power (EIRP) in the frequency range of 902 – 928 MHz is 508 mW and less than the calculated threshold of 605.7 mW. N.V. Nederlandsche Apparatenfabriek “Nedap” Reinold Hubers Compliance Engineer

Testing and certification of electronic and electric appliances, systems, installations and telecommunication systems TÜV Rheinland Nederland B.V. Eiberkamp 10 9351 VT Leek Telephone: +31 88 8887888 Telefax: +31 594 504804 E-mail: [email protected] Web: www.tuv.com Project number: 15072203.fcc01 Page 1 of 44 TEST REPORT CONCERNING THE COMPLIANCE OF A SPREAD SPECTRUM TRANSMITTER, BRAND Nedap, MODEL ASSY HH2 RFID WITH 47 CFR PART 15 (10-1-14 Edition), RSS-Gen (Issue 4, November 2014) and RSS-247 (Issue 1, May 2015). 15050105.fcc01_Rev03 October 14, 2015 FCC listed Industry Canada R&TTE, LVD, EMC Notified Body : : : 90828 2932G-2 1856 Test specification(s): Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: FCC Part 15, RSS-Gen, RSS-247 Spread Spectrum Transmitter N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID Project number : 15072203.fcc01 Page 2 of 44 MEASUREMENT/TECHNICAL REPORT N.V. Nederlandsche Apparatenfabriek “Nedap” Model: ASSY HH2 RFID FCC ID: CGDHH2RFID IC: 1444A-HH2RFID This report concerns: Original grant/certification Class 1 permissive change Verification Equipment type: Spread Spectrum Transmitter (DSS) Report prepared by: Name : Richard van der Meer Company name : TÜV Rheinland Nederland B.V. Address : Eiberkamp 10 Postal code/city : 9351VT Leek Mailing address : P.O. Box 37 Postal code/city : 9350 AA Leek Country : The Netherlands Telephone number : + 31 594 505 005 Telefax number : + 31 594 504 804 E-mail : [email protected] The data taken for this test and report herein was done in accordance with 47 CFR Part 15 (10-1-14 Edition) and the measurement procedures of ANSI C63.10-2013. TÜV Rheinland Nederland B.V. at Leek, The Netherlands, certifies that the data is accurate and contains a true representation of the emission profile of the Equipment Under Test (EUT) on the date of the test as noted in the test report. I have reviewed the test report and find it to be an accurate description of the test(s) performed and the EUT so tested. Date: October 14, 2015 Signature: P. de Beer Technical Manager TÜV Rheinland Nederland B.V. Test specification(s): Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: FCC Part 15, RSS-Gen, RSS-247 Spread Spectrum Transmitter N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID Project number : 15072203.fcc01 Page 3 of 44 Test Summary The device under test does:  fulfill the general approval requirements as identified in this test report o not fulfill the general approval requirements as identified in this test report The EUT was tested in accordance with the specifications given in the table below. Test Standard Description Pass / Fail 47 CFR Part 15 (10-1-14 Edition) RSS-247 Issue 1, May 15 Page 15.207(a) RSS-Gen(7.2.4) AC power-line conducted emissions 40 - 43 Pass 15.209 and 15.247(d) RSS-Gen(4.9 and 7.2.5) and RSS-247 5.5 Radiated emissions 27 – 31 Pass 15.205 and 15.223 RSS-Gen(7.2.2) Radiated emissions in restricted bands 37 - 39 Pass 15.215(c) and 15.223(a) RSS-Gen(4.6.1) and RSS-Gen (4.6.2) RSS-247 5.1(3) Occupied bandwidth and Bandwidth of the emission 15 - 22 Pass 15.247(b)(1) RSS-247 5.4(1) Peak Output Power 12 - 15 Pass 15.247(a) RSS-247 5.1(3) Hopping characteristics 23 – 26 Pass 15.247(d) RSS-247 5.5 Conducted Spurious Emissions 32 - 36 Pass Table : testspecifications Test specification(s): Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: FCC Part 15, RSS-Gen, RSS-247 Spread Spectrum Transmitter N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID Project number : 15072203.fcc01 Page 4 of 44 Description of test item Test item : Spread Spectrum Transmitter (DSS) Manufacturer : N.V. Nederlandsche Apparatenfabriek “Nedap” Brand : Nedap Model : ASSY HH2 RFID Serial number : 026 (radiated tests) and 035 (conducted tests) : Applicant information Applicant's representative : Mr. J. Hulshof / Mr. R. Hubers Company : N.V. Nederlandsche Apparatenfabriek “Nedap” Address : Parallelweg 2 Postal code : 7141 DC City : Groenlo Country : The Netherlands Telephone number : +31 544 471 162 Telefax number : +31 544 463 475 Test(s) performed Location : Leek Test(s) started : June 02, 2015 Test(s) completed : September 09, 2015 Purpose of test(s) : Equipment Authorization (Original grant/certification) Test specification(s) : FCC 47 CFR Part 15, Subpart C, Section 15.247 (10-1-14 Edition) RSS-Gen (Issue 4, November 2014) an RSS-247 (Issue 1, May 2015) ANSI C63.10-2013 Test engineer(s) : R. van der Meer Report written by : R. van der Meer Report date : October 14, 2015 This report shall not be reproduced, except in full, without the written permission of TÜV Rheinland Nederland B.V. The test results relate only to the item(s) tested. Test specification(s): Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: FCC Part 15, RSS-Gen, RSS-247 Spread Spectrum Transmitter N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID Project number : 15072203.fcc01 Page 5 of 44 Table of contents 1 General information. .............................................................................................................................................. 6 1.1 Product description. ........................................................................................................................................ 6 1.1.1 Introduction. ............................................................................................................................................ 6 1.2 Related submittal(s) and/or Grant(s). ............................................................................................................. 6 1.2.1 General. .................................................................................................................................................. 6 1.3 Tested system details. ..................................................…

Text truncated - open the document above for the full version.

Testing and certification of electronic and electric appliances, systems, installations and telecommunication systems TÜV Rheinland Nederland B.V. Eiberkamp 10 9351VT Leek The Netherlands Telephone: +31 594 505005 Telefax: +31 594 504804 Internet: www.tuv.com/nl E-mail: [email protected] Project number: 15072203.p01 Page 1 of 8 PHOTOGRAPHS OF THE TESTSETUP OF A SPREAD SPECTRUM TRANSMITTER, BRAND Nedap, MODEL ASSY HH2 RFID. 15072203.p01 September 09, 2015 FCC listed Industry Canada R&TTE, LVD, EMC Notified Body : : : 90828 2932G-2 1856 Test specification(s): Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: FCC Part 15, RSS-Gen, RSS-247 Spread Spectrum Transmitter N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap ASSY HH2 RFID CGDHH2RFID 1444A-HH2RFID Project number: 15072203.p01 Page 2 of 8 Description of test item Test item : Spread Spectrum Transmitter (DSS) Manufacturer : N.V. Nederlandsche Apparatenfabriek “Nedap” Brand : Nedap Model : ASSY HH2 RFID Serial number : 026 (radiated tests) and 035 (conducted tests) : Applicant information Applicant's representative : Mr. J. Hulshof…

Text truncated - open the document above for the full version.
