CGDVP1910Inductive Card Reader

Service manual For installation, operation and service ISO DSP Reader IO . VP1910 9 - 2012 / Manual version 1.2 Manual part no. 5278503 VP1910-200PM-00 ISO DSP Reader Manual version 1.2 Version overview Manual version 1.0 / 10 - 2011 First release Manual version 1.1 / 12 - 2011 New menu options described and appendixes added. Manual version 1.2 / 9 - 2012 FCC and industry Canada text added. Max. antenna power level added for USA/Canada and Europe. Compliance statement (part15.19) This device complies with part 15 of the FCC Rules and to RSS210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Déclaration Conformité Cet appareil se conforme aux normes RSS210 exemptés de license du Industry Canada. L'opération est soumis aux deux conditions suivantes: (1) cet appareil ne doit causer aucune interférence, et (2) cet appareil doit accepter n'importe quelle interférence, y inclus interférence qui peut causer une opération non pas voulu de cet appareil. Warning (part15.21) Changes or modifications not expressly approved by party responsible for compliance could void the user’s authority to operate the equipment. This information is furnished for guidance, and with no guarantee as to its accuracy or completeness; its publication conveys no license under any patent or other right, nor does the publisher assume liability for any consequence of its use; specifications and availability of goods mentioned in it are subject to change without notice; it is not to be reproduced in any way, in whole or in part, without the written consent of the publisher. © Nedap N.V., AGRI P.O. Box 104 NL-7140 AC GROENLO The Netherlands VP1910-200PM-00 ISO DSP Reader Manual version 1.2 VP1910 DSP ISO Reader Contents 1 Introduction 1 2 Description and functioning 2 3 Safety 2 4 Installation 2 4.1 Mounting 2 4.2 Connections 3 5 Adjustments 4 5.1 Check after power up 4 5.2 Communication 4 5.3 Address 4 5.4 Antenna tuning 5 5.5 Antenna power 6 5.6 Software setup 6 6 Advanced 7 6.1 Testing inputs and outputs 7 6.2 Advanced antenna adjustment 7 6.3 Identification test options 9 7 Trouble shooting 10 8 Maintenance, cleaning and disposal 10 Appendix A: Specifications 11 Appendix B: Display and push button 13 Appendix C: Overview display menu 14 Appendix D: Overview display menu, GEA options 16 Appendix E: Overview display menu, RS485 options 17 Appendix F: LED indicator overview 18 Appendix G: VP1910 connected to a Velos VP8001 (VPU) 19 Appendix H: LAN Ethernet crossover cable 20 Appendix I: LAN Ethernet straight cable 21 Appendix J: Antenna connection 22 Appendix K: Velos cable 23 Appendix L: Two antennas < 3m distance 24 VP1910-200PM-00 ISO DSP Reader Manual version 1.2 VP1910-200PM-00 ISO DSP Reader IO Manual version 1.2 / Page 1 Preface This manual is part of the service documentation for Nedap Velos. Reference is also made to other manuals that are part of the Nedap Velos documentation. For an overview of available Nedap Velos manuals see the manual “Nedap Velos General Description”, or visit the Nedap Agri website www.nedap-agri.com. 1 Introduction The Velos VP1910 is used for identification of animals and for controlling processes. The VP1910 must be connected to a computer (controller) and can communicate by a LAN, CAN, RS485 or VC3 protocol. The connected computer must give controlling commands to the VP1910 to operate inputs, outputs and identification. The VP1910 has the following main tasks: - Identification of tags (ISO 134.2 kHz FDX/HDX) - Controlling outputs - 5 outputs are available to activate e.g. lights, valves, relays - Reading inputs - 5 inputs available for e.g. sensors, switches - Digital noise filtering (European Burg Mainflingen filter) Following antenna types can be used: - V-sense antennas with auto tuning The VP1910 must be installed in a housing suitable for farm conditions, for example in a V-box. Figure : V-box2 with a VP1910 reader VP1910-200PM-00 ISO DSP Reader IO Manual version 1.2 / Page 2 2 Description and functioning A VP1910 has 5 inputs used for reading e.g. sensors or switches. There are also 5 outputs available to activate e.g. lights, valves or relays. The VP1910 can read tags FDX/HDX 134.2 kHz. In case installing in or near Germany there is a filter available to reduce disturbance for transmitters near Burg and Mainflingen. The VP1910 must be connected to a computer and can communicate by a LAN, CAN, RS485 or VC3 protocol. The connected computer must give controlling commands to the VP1910 to operate inputs, outputs and identification. Figure : Sticker on the VP1910 with indication of the connections Operation of the VP1910 Antenna : for reading tags, normally on Inputs : read continuously with status change sent to the controller Outputs : switched on or off by commands from the controller LEDs : switched on or off by the VP1910 according to the status Error : errors are sent to the controller All inputs and outputs can be tested by the use of the push button and display. For operation of the push button and display see appendix B. 3 Safety Installation and service only by trained personnel. Always turn off the main power when working on the electrical installation. 4 Installation Installation consits of the following steps: 1. Mounting 2. Installation of all wiring (connections) 3. Power up 4. Set address (when more than one VP1910) 5. Check and set required settings 6. Antenna adjustment (green LED on) 7. Checking the connected equipment like lamps, sensors etc. 8. Configuration in the PC Follow this manual to complete the steps. 4.1 Mounting See the relevant equipment manual relating to where the VP1910 is to be installed. VP1910-200PM-00 ISO DSP Reader IO Manual version 1.2 / Page 3 4.2 Connections See the relevant equipment manual relating to where the VP1910 is to be installed. See also …

Text truncated - open the document above for the full version.

N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. Return address: PO Box 6, 7140 AA Groenlo, The Netherlands ATCB Attn.: Mrs. M. Bosley Certification Department 6731 Whittier Avenue, Suite C110 McLean, Virginia 22101 USA Groenlo, 18 October 2012 Subject: Request of Confidentiality FCC ID: CGDVP1910 Dear Mrs. Bosley, Pursuant to section 0.457(d)(2)(i) and Section 0.459 of the FCC rules we herewith request the following exhibits, related to this application for FCC ID : CGDVP1950 Brand : Nedap Models : VP1910 GEA, VP1910 BOUMATIC and VP1910 VELOS to be withheld from public inspection and to be kept confidential. The contents of these exhibits may not be disclosed to other parties than N.V. Nederlandsche Apparatenfabriek "NEDAP" and TÜV Rheinland Electronic Products & Services (EPS) B.V.: 1. Bill of materials 2. Circuit diagram 3. Block diagram 4. Theory of operation (technical description) The reason for this request for confidentiality is that the information contained in the exhibits as listed above has been classified as company confidential. Disclosure of any portion of this information to other parties would cause substantial competitive harm. Best regards, N.V. Nederlandsche Apparatenfebriek “Nedap” Jacques Hulshof Approbation Management

N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. Groenlo, 18 October 2012 Antenna information Description : 134.2 kHz Inductive RFID Card Reader FCC ID : CGDVP1910 IC : 1444A-VP1910 Manufacturer : N.V. Nederlandsche Apparatenfabriek “Nedap” Brands : GEA, Boumatic and Nedap Models : VP1910 GEA, VP1910 BOUMATIC and VP1910 VELOS Antennas : VP6150, VP6151, Walk Through Loop Antenna and Walk Over Loop Antenna 1. VP1650 Antenna Type : Inductive O-Antenna Material : Copper strip Number of turns : 1 Wire thickness : 2 mm Width : 15 mm Dimensions : 475 x 750 mm See the diagram below N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. 2. VP1651 Antenna Type : Inductive O-Antenna Material : Copper strip Number of turns : 1 Wire thickness : 2 mm Width : 15 mm Dimensions : 475 x 750 mm See the diagram below. N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. 3. External Floor Antenna Type : Inductive O-Antenna Material : Steel Number of turns : 1 Material dimension : 20 x 5 mm Dimensions : 1200 x 800 mm See the diagram below N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. 4. External Walk Through Antenna Type : Inductive O-Antenna Material : Steel Number of turns : 1 Material dimension : 25 x 6 mm Dimensions : 1948 x 988 mm Jacques Hulshof 1984 mm 988 mm

N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. Return address: PO Box 6, 7140 AA Groenlo, The Netherlands ATCB Attn.: Mrs. M. Bosley Certification Department 6731 Whittier Avenue, Suite C110 McLean, Virginia 22101 USA Groenlo, 18 October 2012 Subject: Attestation of Similarity FCC ID: CGDVP1910 Dear Mrs. Bosley, The device with Model: VP1910 VELOS as mentioned in report “12_12021504.fcc01_Testreport CGDVP1910.pdf” is a transmitter/receiver for identifying transponders attached to animals and is operating on 134.2 kHz. This Model: VP1910 VELOS is delivered by Nedap directly to its dealers and/or end users. We also deliver two other Models: VP1910 GEA and VP1910 BOUMATIC. These units are electronically as well as mechanically the same as the VP1910 VELOS only it is delivered to the company GEA and Boumatic who deliver it to their dealers and/or end users. Therefore two new Model numbers are introduced. So Nedap provides totally 3 different types with 6 different antenna systems as there are: 1. Model: VP1910 GEA. 2. Model: VP1910 BOUMATIC. 3. Model: VP1910. We, N.V. Nederlandsche Apparatenfabriek “Nedap”, declare that the Model: VP1850 VELOS as tested in above mentioned test report is the same as Models: VP1910 GEA and VP1910 BOUMATIC with FCC ID: CGDVP1910 and also that the antennas used in combination with the Models and mentioned the test report “12_12021504.fcc01_Testreport CGDVP1910.pdf” are the same. I thereby wish to request whether you can add these models to the list of approved systems. I hope you can honor our request Best regards, N.V. Nederlandsche Apparatenfabriek “Nedap” Jacques Hulshof Approbation Management

N.V. Nederlandsche Apparatenfabriek “Nedap” Parallelweg 2 NL-7141 DC Groenlo P.O. Box 6 NL-7140 AC Groenlo T +31 (0)544 471 111 F +31 (0) 544 463 475 E [email protected] www.nedap.com Traderegister 08013836 ABN-AMRO 59.16.32.330 IBAN NL83ABNA0591632330 BIC ABNANL2A VAT NL006456285B01 The General Terms & Conditions of ICT-Office apply to all our offers and agreements. These conditions can be found at our website www.nedap.com and can be provided upon request. Return address: PO Box 6, 7140 AA Groenlo, The Netherlands ATCB Attn.: Mrs. M. Bosley Certification Department 6731 Whittier Avenue, Suite C110 McLean, Virginia 22101 USA Groenlo, 07 November 2012 Subject: Declaration following the DoC procedure for models filed under FCC ID: CGDVP1910 Dear Mrs. Bosley, The Models: : VP1910 GEA, VP1910 BOUMATIC and VP1910 VELOS as filed under FCC ID: CGDVP1910 are transceivers operating on 134.2 kHz for the identification of animals. These various models contain a connection for connecting the device to a personal computer, effectively making it a personal computer peripheral. This letter is meant to declare that we, N.V. Nederlandsche Apparatenfabriek “Nedap”, do follow the Declaration of Conformity (DoC) procedure The FCC DoC marking is placed on the equipment labels. Best regards, N.V. Nederlandsche Apparatenfabriek “Nedap” Jacques Hulshof Approbation Management

Page 1 of 8 Inductive RFID Proximity Card Reader operating on 134.2 kHz Brand Nedap Model VP1910 series Exterior Photographs Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1850 series CGDVP1910 1444A-VP1910 Page 2 of 8 Description of item Description of EUT : Inductive RFID Proximity Card Reader operating on 134.2 kHz Manufacturer : N.V. Nederlandsche Apparatenfabriek “Nedap” Brand : Nedap Models : VP1910 GEA, VP9101 BOUMATIC and VP1910 VELOS FCC ID CGDVP1910 IC 1444A-VP11910 Type of Service New Application Applicant information Applicant's representative : Mr. Jacques Hulshof Company : N.V. Nederlandsche Apparatenfabriek “Nedap” Address : Parallelweg 2 Postal code : 7141 DC City : Groenlo PO-box : 6 Postal code : 7140 AA City : Groenlo Country : The Netherlands Telephone number : +31 (0) 544 471111 Telefax number : +31 (0) 544 463475 18 October 2012 Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1850 series CGDVP1910 1444A-VP1910 Page 3 of 8 Table of contents 1 OVERVIEW OF THE VP1910 WITH THE DIFFERENT ANTENNAS AND ADJUSTMENT BOXES ....................... 4 1.1 VP1910 AND WALK THROUGH LOOP ANTENNA WITH VP6154 ADJUSTMENT BOX ............................................................... 4 1.2 VP1910 AND WALK THROUGH LOOP ANTENNA WITH EWA ADJUSTMENT BOX................................................................... 4 1.3 VP1910 AND WALK OVER LOOP ANTENNA WITH VP6154 ADJUSTMENT BOX ..................................................................... 5 1.4 VP1910 AND WALK OVER LOOP ANTENNA WITH EWA ADJUSTMENT BOX ......................................................................... 5 1.5 VP1910 WITH VP6150 (LARGE) AND VP6151 (SMALL) ANTENNA ....................................................................................... 6 2 THE VP1910 ENCLOSURE .................................................................................................................................................... 6 2.1 THE FRONT – RIGHT SIDE – TOP OF THE ENCLOSURE ............................................................................................................. 6 2.2 THE BACK - SIDE – TOP OF THE ENCLOSURE .......................................................................................................................... 7 2.3 THE FRONT – LEFT SIDE – TOP OF THE ENCLOSURE ............................................................................................................... 7 2.4 THE BOTTOM OF THE ENCLOSURE ......................................................................................................................................... 8 2.5 THE FRONT OF THE ENCLOSURE ............................................................................................................................................ 8 Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1850 series CGDVP1910 1444A-VP1910 Page 4 of 8 1 Overview of the VP1910 with the different antennas and adjustment boxes 1.1 VP1910 and Walk Through Loop antenna with VP6154 adjustment box 1.2 VP1910 and Walk Through Loop antenna with EWA adjustment box Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1850 series CGDVP1910 1444A-VP1910 Page 5 of 8 1.3 VP1910 and Walk Over Loop antenna with VP6154 adjustment box 1.4 VP1910 and Walk Over Loop antenna with EWA adjustment box Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1850 series CGDVP1910 1444A-VP1910 Page 6 of 8 1.5 VP1910 with VP6150 (large) and VP6151 (small) antenna 2 The VP1910 enclosure 2.1 The front – right side – top of the enclosure Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1850 series CGDVP1910 1444A-VP1910 Page 7 of 8 2.2 The back - side – top of the enclosure 2.3 The front – left side – top of the enclosure Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1850 series CGDVP1910 1444A-VP1910 Page 8 of 8 2.4 The bottom of the enclosure 2.5 The front of the enclosure

Page 1 of 8 Inductive RFID Proximity Card Reader operating on 134.2 kHz Brand Nedap Models VP1910 series Label Location and artwork Description of EUT: Manufacturer: Brand mark: Models: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 2 of 8 Description of item Description of EUT : Inductive RFID Proximity Card Reader operating on 134.2 kHz Manufacturer : N.V. Nederlandsche Apparatenfabriek “Nedap” Brand : Nedap Model : VP1910 GEA, VP1910 BOUMATIC and VP1910 VELOS FCC ID CGDVP1910 IC 1444A-VP1910 Type of Service New Application Applicant information Applicant's representative : Mr. Jacques Hulshof Company : N.V. Nederlandsche Apparatenfabriek “Nedap” Address : Parallelweg 2 Postal code : 7141 DC City : Groenlo PO-box : 6 Postal code : 7140 AA City : Groenlo Country : The Netherlands Telephone number : +31 (0) 544 471111 Telefax number : +31 (0) 544 463475 05 November 2012 Description of EUT: Manufacturer: Brand mark: Models: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 3 of 8 Table of contents 1 LABEL LOCATION VP1910 .................................................................................................................................................. 4 2 PHOTOGRAPHS OF THE LABELING ................................................................................................................................ 4 2.1 COMPLIANCE - OR WARNING STATEMENT ON THE VP1910 SERIES ...................................................................................... 4 2.2 VP1910 GEA ....................................................................................................................................................................... 5 2.3 VP1910 BOUMATIC .......................................................................................................................................................... 5 2.4 VP1910 VELOS .................................................................................................................................................................. 6 3 LABEL ON THE SHIPPING BOX ......................................................................................................................................... 7 3.1 POSITION .............................................................................................................................................................................. 7 3.2 VP1910 GEA ....................................................................................................................................................................... 7 3.3 VP1910 BOUMATIC .......................................................................................................................................................... 8 3.4 VP1910 NEDAP .................................................................................................................................................................. 8 Description of EUT: Manufacturer: Brand mark: Models: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 4 of 8 1 Label location VP1910 2 Photographs of the labeling 2.1 Compliance - or Warning Statement on the VP1910 series Model, IC and FCC ID Compliance statement Description of EUT: Manufacturer: Brand mark: Models: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 5 of 8 2.2 VP1910 GEA 2.3 VP1910 BOUMATIC Description of EUT: Manufacturer: Brand mark: Models: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 6 of 8 2.4 VP1910 VELOS Description of EUT: Manufacturer: Brand mark: Models: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 7 of 8 3 Label on the shipping box 3.1 Position 3.2 VP1910 GEA Description of EUT: Manufacturer: Brand mark: Models: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 8 of 8 3.3 VP1910 BOUMATIC 3.4 VP1910 NEDAP

Page 1 of 6 Inductive RFID Proximity Card Reader operating on 134.2 kHz Brand Nedap Model VP1910 series Interior Photographs Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 2 of 6 Description of item Description of EUT : Inductive Proximity Card Reader operating on 134.2 kHz Manufacturer : N.V. Nederlandsche Apparatenfabriek “Nedap” Brand : Nedap Models : VP1910 GEA, VP1910 BOUMATIC and VP1910 VELOS FCC ID CGDVP19100 IC 1444A-VP1910 Type of Service New Application Applicant information Applicant's representative : Mr. Jacques Hulshof Company : N.V. Nederlandsche Apparatenfabriek “Nedap” Address : Parallelweg 2 Postal code : 7141 DC City : Groenlo PO-box : 6 Postal code : 7140 AA City : Groenlo Country : The Netherlands Telephone number : +31 (0) 544 471111 Telefax number : +31 (0) 544 463475 18 October 2012 Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 3 of 6 Table of contents 1 FRONT AND BACKSIDE OF THE VP1910 ENCLOSURE ................................................................................................ 4 2 PHOTOGRAPHS OF INTERNAL COMPONENTS ............................................................................................................ 4 2.1 POSITION OF THE PCBS RIGHT COVER REMOVED ................................................................................................................. 4 2.2 POSITION OF THE PCBS LEFT COVER REMOVED.................................................................................................................... 5 3 THE PRINTED CIRCUIT BOARDS ...................................................................................................................................... 5 4 THE TRANSMITTER RECEIVER MODULE ..................................................................................................................... 6 4.1 FRONT SIDE TOP ................................................................................................................................................................... 6 4.2 BACK SIDE ............................................................................................................................................................................ 6 Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 4 of 6 1 Front and backside of the VP1910 enclosure 2 Photographs of internal components 2.1 Position of the PCBs right cover removed Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 5 of 6 2.2 Position of the PCBs left cover removed 3 The Printed Circuit Boards Description of EUT: Manufacturer: Brand mark: Model: FCC ID IC Inductive RFID Proximity Card Reader 134.2 kHz N.V. Nederlandsche Apparatenfabriek “Nedap” Nedap VP1910 series CGDVP1910 1444A-VP1910 Page 6 of 6 4 The transmitter receiver module 4.1 Front side top 4.2 Back side

Testing and certification electronic and electric appliances, systems, installations and telecommunication systems TÜV Rheinland EPS B.V. P.O. Box 37 9350 AA Leek (NL) Eiberkamp 10 9351 VT Leek (NL) Telephone: +31 594 505005 Telefax: +31 594 504804 Internet: www.tuv-eps.com E-mail: [email protected] Project number: 12021504.fcc01 Page 1 of 26 TEST REPORT CONCERNING THE COMPLIANCE OF A CATTLE ID-READER, OPERATING ON 134.2 kHz BRAND NEDAP, MODEL VP1910 VELOS WITH 47 CFR PART 15 (10-1-09 EDITION) AND THE REQUIREMENTS OF INDUSTRY CANADA: RSS-GEN AND RSS-210 (ISSUE 8, DECEMBER 2010) 12021504.fcc01 September 12, 2012 FCC listed Industry Canada VCCI Registered R&TTE, LVD, EMC Notified Body : : : : 90828 2932G-2 R-1518, C-1598 1856 Test specification(s): Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: FCC Part 15, RSS-GEN, RSS-210 Cattle ID Reader N.V. Nederlandsche Apparatenfabriek Nedap Nedap VP1910 VELOS CGDVP1910 1444A-VP1910 Project number : 12021504.fcc01 Page 2 of 26 MEASUREMENT/TECHNICAL REPORT N.V. Nederlandsche Apparatenfabriek “Nedap” Brand: Nedap Model: VP1910 VELOS FCC ID: CGDVP1910 IC: 1444A-VP1910 This report concerns: Original grant/certification Class 2 change Verification Verification Equipment type: Cattle ID Reader Report prepared by: Name : O.H. Hoekstra Company name : TÜV Rheinland EPS B.V. Address : Eiberkamp 10 Postal code/city : 9351 VT Leek Mailing address : P.O. Box 37 Postal code/city : 9350 AA Leek Country : The Netherlands Telephone number : + 31 594 505 005 Telefax number : + 31 594 504 804 E-mail : [email protected] The data taken for this test and report herein was done in accordance with 47 CFR Part 15 (10-1-09 Edition), RSS-GEN AND RSS-210 and the measurement procedures of ANSI C63.4-2009. TÜV Rheinland EPS B.V. at Leek, The Netherlands, certifies that the data is accurate and contains a true representation of the emission profile of the Equipment Under Test (EUT) on the date of the test as noted in the test report. I have reviewed the test report and find it to be an accurate description of the test(s) performed and the EUT so tested. Date: September 12, 2012 Signature: R. van der Meer Engineer Telecom TÜV Rheinland EPS B.V. Test specification(s): Description of EUT: Manufacturer: Brand mark: Model: FCC ID: IC: FCC Part 15, RSS-GEN, RSS-210 Cattle ID Reader N.V. Nederlandsche Apparatenfabriek Nedap Nedap VP1910 VELOS CGDVP1910 1444A-VP1910 Project number : 12021504.fcc01 Page 3 of 26 Summary The device under test does:  fulfill the general approval requirements as identified in this test report o not fulfill the general approval requirements as identified in this test report Description of test item Test item (EUT) : Cattle ID Reader Manufacturer : N.V. Nederlandsche Apparatenfabriek “Nedap” Brand : Nedap Model(s) : VP1910 VELOS Serial number(s) : -- FCC ID : CGDVP1910 IC : 1444A-VP1910 Receipt date : March 30, 2012 Applicant information Applicant's representative : Mr. J. Hulshof Company : N.V. Nederlandsche Apparatenfabriek “Nedap” Address : Parallelweg 2 Postal code : 7141 DC City : Groenlo Country : The Netherlands Telephone number : +31 544 471 162 Telefax number : +31 544 466 475 Test(s) performed Location : Leek Test(s) started : March 30, 2012 Test(s) completed : August 2, 2012 Purpose of test(s) : Equipment Authorization (Original grant/certification) Test specification(s) : 47 CFR Part 15 (10-1-09 Edition) and RSS-…

Text truncated - open the document above for the full version.
