VP4102 – Reader - Quick start 05-2013 Doc.part.no. 9741518 version 1.0 1/ 5 VP4102 Reader 434/922 MHz This sheet is intended as quick start. See service manual for more detailed instructions. The VP4102 reader is a component that is used to receive data from Smart Tags. Antenna default connection is 434MHz. Japan and Korea: switch to 922MHz! Connections Compliance statement (part15.19) This device complies with part 15 of the FCC Rules and to RSS210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Déclaration Conformité Cet appareil se conforme aux normes RSS210 exemptés de license du Industry Canada. L'opération est soumis aux deux conditions suivantes: (1) cet appareil ne doit causer aucune interférence, et (2) cet appareil doit accepter n'importe quelle interférence, y inclus interférence qui peut causer une opération non pas voulu de cet appareil. Warning (part15.21) Changes or modifications not expressly approved by party responsible for compliance could void the user’s authority to operate the equipment. This in particular is applicable for the antenna which can be delivered with the VP4102 System o range blue white blue black red orange white CAN cable LAN Ethernet straight cable white brown or VP4102 CAN cable to VPU (VP8001) Antenna 922 MHz Antenna 434 MHz TIA/EIA 568A TIA/EIA 568B VP4102 – Reader - Quick start 05-2013 Doc.part.no. 9741518 version 1.0 2/ 5 DISPLAY ADDRESS Shows the actual logic V-pack address SET ADDRESS Change the logic address DISPLAY SECTION Show section (Default 0, not used for CAN) SET SECTION Change section (not used for CAN) DISPLAY VPU ADDRESS Shows actual VPU address (one by one) SET VPU ADDRESS Changes the actual VPU address (one by one) SETTINGS TO DEFAULT All address settings back to factory settings DHCP IS ON Press long until blinking to turn on DHCP DHCP IS OFF Press long until blinking to turn off DHCP DISPLAY IP ADDRESS Shows actual IP address (one by one) SET IP ADDRESS (only shown in case of DHCP OFF) 192.168.1.101 (not used for CAN) SET IP ADDRESS 192.168.1.101 (not used for CAN) SET IP ADDRESS 192.168.1.101 (not used for CAN) SET IP ADDRESS 192.168.1.101 (not used for CAN) ACCEPT NEW IP ADDRESS (not used for CAN) DISPLAY NETWORK MASK (only shown in case of DHCP OFF) Shows the network mask (0, 8, 16, 24 or 32) (0= 0.0.0.0, 8= 255.0.0.0 etc.) SET NETWORK MASK (only shown in case of DHCP OFF) Changes the network mask (16= 255.255.0.0 etc. 32 = 255.255.255.255) IP SETTINGS TO DEFAULT All IP settings back to factory settings Display Push button VP4102 – Reader - Quick start 05-2013 Doc.part.no. 9741518 version 1.0 3/ 5 Press button until blinking Press button short To leave menu: press button until display is empty L1 TEST OUTPUT 1 Signal light TEST OUTPUT 2 Signal light TEST FREQUENCY 1 Shows signal strength frequency 1 TEST FREQUENCY 2 Shows signal strength frequency 2 TEST FREQUENCY 3 Shows signal strength frequency 3 TEST FREQUENCY 4 Shows signal strength frequency 4 TEST FREQUENCY 5 Shows signal strength frequency 5 TEST FREQUENCY 6 Shows signal strength frequency 6 RESET UHF CHANNELS SETTINGS TO DEFAULT All UHF channel settings back to factory settings DISPLAY ERROR SE = safeguard error, UE = UHF error. TRESHOLD RECEPTION (CONFIGURATION MENU) Enter value to set UHF threshold e.g. ...? FREQUENCY BAND 434MHz (EU/USA) Press long until blinking to switch to 434Mhz FREQUENCY BAND 922MHz (Japan/Korea only) Press long until blinking to switch to 922Mhz DISPLAYS RSSI STRENGTH OF LAST UHF MESSAGE View last received RSSI DISPLAYS NUMBER OF DETECTED UHF DEVICES (only when UHF network is enabled) RESTORE FACTORY DEFAULTS All VP4102 settings back to factory defaults (Default IP address) VP4102 – Reader - Quick start 05-2013 Doc.part.no. 9741518 version 1.0 4/ 5 LED indicators POWER Green on Power on off No power STATUS Slow blinking Fast blinking 1 short flash 2 short flashes 3 short flashes Operating ok Downloading or error during download V-pack not coupled Firmware present but not active No firmware present Display Blinking IP fails or CAN fails V in Green on Input power applied off No power Orange Low power, less than 20V Orange blinking Wrong CAN-bus connection, Vin and Vout swapped Red Error, plus and minus swapped V out Green on Output power off No power Orange blinking Low power Red blinking Error (overload, shortcut) LAST Green on V-pack is last one on the CAN-bus off V-pack is not last one on the CAN-bus Orange blinking CAN-bus error and last V-pack on CAN-bus Red CAN-bus error Red blinking CAN-bus warning / connected wrong LINK off LAN No connection Green LAN connection(10 Mbps / 100 Mbps) ACT Green flashing Network activity off No network activity Red Network error O1 / O2 Green on Output on off Output off Red blinking Output error (overload, shortcut) UHF Green on Data receive off No data Red UHF Error Specifications VP 4102 Dimensions 143 x 120 x 68 mm LxWxH (excluding mounting rail) Weight: ± 279 gr CAN CAN-bus communication 125 kbit/s Ethernet 100mbit/s max 100m Power Input voltage 12VDC -30 VDC Power consumption 160mA – 85mA (25VDC 100 mA) (without connected I/O such as signal lamp) Protected against reverse connection power supply Software Downloadable by the CAN network or ethernet Outputs Max. 0.4 Amp by current limiter, short-circuiting and thermal protected Antennas G-CXL 70-1LW/h nedap art. 4602366 Detection distance Lactivator Realtime labels: +/- 50m dependable of antenna situation Environment Temperature: Operating: -10 – 55 °C, Storage: -25 – 70 °C Relative humidity: 10 – 93% non condensing IP class IP 30. When installed in V-box IP 65 (cover and cables installed correctly !) Always use a NEDAP power supply VP2001 or VP2002. The Nedap guarantee-regulations are only valid when is installed as indicated in this manual. Install data cable…
