CGG-AL-1623Smart Card Programmer

Underwriters Laboratories Inc.A not-for-profit organization dedicated 1655 Scott Blvdto public safety and committed to Santa Clara, CA 95050quality service for over 100 years EMC Services Department Tel: (408) 985-2400 x32397 Fax: (408)556-6071 ELECTROMAGNETIC COMPATIBILITY (EMC) REPORT EMISSIONS Interlogix Model AL-1263 FCC ID: CGG-AL-1623 December 2, 2002 Project No.: 02SC15191 Test Report No.: NC4969-120202 Company: InterlogixModel #:AL-1623 Project: 02SC15191Report #:NC4969-120202 Page 2 of 38 REPORT DIRECTORY Title Section General Information 1.0 Scope 1.1 Purpose 1.2 Test Results 1.3 Documentation Review/Approval 1.4 General Product Description 2.0 Justification of Configuration 2.1 EUT Operating Mode(s) 2.2 Environmental Conditions in Test Lab 3.0 Calibration Details of Equipment Used for Measurement 4.0 Test Facility 5.0 Accreditations and Authorizations 6.0 Emissions Test Regulations 7.0 Equipment Classifications 7.1 Field Strength Calculations 7.2 Measurement Uncertainty 7.3 Measurement Bandwidths 7.4 Conducted Voltage Emissions 7.5 Radiated Electric Field Emissions 7.6 Radiated Electric Field Fundamental Emission Measurements 7.7 Company: InterlogixModel #:AL-1623 Project: 02SC15191Report #:NC4969-120202 Page 3 of 38 1.0General Information 1.1Scope Underwriters Laboratories Inc., authorizes the above named company to reproduce this Report, provided it is reproduced in it’s entirety. The data in this Report reflects only the items tested in the configurations and mode of operations described. All data recorded and photographs represents testing under the worst case conditions permitted by the requirements applied to the product. It is the manufacturer’s responsibility to assure that additional production units are manufactured with identical electrical and mechanical components. Any modifications necessary for compliance made during testing must be implemented in all production units for compliance to be maintained. Underwriters Laboratories Inc., shall have no liability for any deductions, inferences or generalizations drawn from this report. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the United States government 1.2Purpose Testing was performed to the following regulations: Emissions Standards used: CFR 47 Part 15 Subpart B, CFR 47 Part 15 Subpart C Company: InterlogixModel #:AL-1623 Project: 02SC15191Report #:NC4969-120202 Page 4 of 38 1.3Test Results In Compliance Not in Compliance 1.4Documentation Review/Approval Tested By:Technical Review By: Bill BarryAsim Tirmizi Staff EngineerProject Engineer International EMC ServicesInternational EMC Services Department 3014ADepartment 3014A Company: InterlogixModel #:AL-1623 Project: 02SC15191Report #:NC4969-120202 Page 5 of 38 2.0General Product Description Applicant: Interlogix Manufactured By: Same as Applicant FCC ID: CGG-AL-1623 Applicant Address: 12345 SW Leveton Drive Tualitin, OR 97062 Applicant Contact: Gene Hukkanen Model/Type No.: AL-1623 Date of Issue: December 2, 2002 File No.: NC4969 Test Report No.: NC4969-120202 Project No.: 02SC15191 Product Description The product tested is a proximity card programmer. It is an intentional radiator operating at 125 kHz. Equipment Size, Mobility, and Identification Dimensions: 1-1/2 by 3 by 6 in. Mobility: Hand-held Table-top Floor-standing Serial No:01053748 Electrical Ratings Voltage [Volts] Current or Power Frequency [Hz] Phase Eut 1206.5 W60Single Note: The unit operates at 9 Vdc which is generated by a separate power supply provided with the unit. Test Voltage & Frequency Unless indicated otherwise on the individual data sheet or test results, the test voltage and frequency was as indicated below. VoltageFrequency 120 V60 Hz Clocks/Oscillators Highest internal frequency does not exceed 108 MHz. Equipment Type Prototype Pre-Production Production Company: InterlogixModel #:AL-1623 Project: 02SC15191Report #:NC4969-120202 Page 6 of 38 Model Differences Any other model(s) represented by the models tested in this investigation will be documented by the manufacturer. Device Modifications The following modifications were necessary for compliance: None EUT and Peripherals DescriptionManufacturerModel/Part #Serial Number EUT (main unit)InterlogixAL-162301053748 EUT (power supply)LEI280903003C00224 LaptopDellPPS02961 Cables Cable TypeShield Length (meters)FerriteConnector Connection Point 1 Connection Point 2 SerialYes15 mNDB-9EUTLaptop 2.1Justification of Configuration The EUT is provided in one configuration. The EUT serial port was connected to a laptop running software that was used to operate the EUT. The EUT was provided with an additional DB-9 port marked “Reader”. No cable was connected to this port as the function of this port had not been implemented by the manufacturer at the time of testing. 2.2EUT Operating Mode(s) Equipment under test was operated during the measurement under the following conditions: The EUT was placed in its standby state with a proximity card placed on top of the enclosure. The presence of the proximity card caused the unit to continuously transmit at 125 kHz. A laptop computer running custom software was used to operate the device. Company: InterlogixModel #:AL-1623 Project: 02SC15191Report #:NC4969-120202 Page 7 of 38 3.0Environmental Conditions in Test Lab Temperature:20-25 °CAtmospheric Pressure: 680-1060 mbar Relative Humidity: 30-60%20.1-31.3 in. Hga 4.0 Calibration Details of Equipment Used for Measurement Test equipment and test accessories are calibrated on regular basis. The maximum time between calibrations is one year or what is recommended by the manufacturer, whichever is less. All test equipment calibrations are traceable to the National Institute of Standards and Technology (NIST), therefore, all test data recorded in this report is traceable to NIST. Company: InterlogixModel #:AL-1623 Project: 02SC15191Report #:NC4969-120202 Page 8 of 38 5.0 Test Facility Underwriters Laboratories I…

Text truncated - open the document above for the full version.

Company: Interlogix Model #:AL-1623 Project: 02SC15191 Report #:NC4969-120202 Page 1 of 2 Conducted Emission Test Set-up Photograph Company: Interlogix Model #:AL-1623 Project: 02SC15191 Report #:NC4969-120202 Page 2 of 2 Radiated Emission and Fundamental Measurements Test Set-up Photographs
