NX1700EIB02 (Supercedes NX1700EIA02) NetworX Series  NX-1700E Proximity Card Reader Installation and Startup NX-1700E Card Reader 2 © 2002 GE Interlogix All rights reserved. Printed in the United States of America. These instructions do not purport to cover all details or variations in equipment nor to provide every possible contingency to be met during installation, operation, and maintenance. If further information is desired or if particular problems arise that are not covered sufficiently for the purchaser’s purpose, the matter should be referred to GE Interlogix, Gladewater, Texas, USA. This document contains proprietary information of GE Interlogix, USA and is furnished to its customer solely to assist that customer in the installation, testing, operations, and/or maintenance of the equipment described.This document shall not be reproduced in whole or in part nor shall its contents be disclosed to any third party without the written approval of GE Interlogix. Please refer to the current GE Interlogix product catalog for detailed warranty information. Main800-727-2339Technical Support800-727-2339 Outside the US903-845-6941Tech Support Fax903-845-8409 Main Fax903-845-6811Sales & Literature800-547-2556 Web:www.caddx.com www.ge-interlogix.com NetworX  is a trademark of the GE Interlogix companies. NX-1700E Card Reader 3 TABLE OF CONTENTS I.GENERAL DESCRIPTION....................................................................................................................................... 5 II.WIRING DESCRIPTION ...................................................................................................................................... 5 III.INSTALLATION .................................................................................................................................................... 5 IV.ENROLLING .......................................................................................................................................................... 5 V.ADDRESSING ........................................................................................................................................................ 6 VI.PROGRAMMING .................................................................................................................................................. 6 A.USING THE LED KEYPAD ..................................................................................................... 6 Entering the Program Mode ....................................................................................................... 6 Entering the Module Address ..................................................................................................... 6 Programming a Location............................................................................................................7 Exiting the Program Mode: ........................................................................................................ 7 B.USING THE LCD KEYPAD ..................................................................................................... 8 C.PROGRAMMING DATA TYPES............................................................................................. 8 VII.ADDING/DELETING USERCARDS .................................................................................................................. 8 Adding One User ........................................................................................................................ 8 Adding User w/ Auto-Increment ................................................................................................. 9 Delete One User.......................................................................................................................... 9 VIII.PROGRAMMING LOCATIONS......................................................................................................................... 9 Location 0Programming the Scan Functions ..................................................................... 9 Locations 1 - 240Serial Numbers Mapping User Cards to Users............................................... 10 Location 241Programming the X-10 Address for the Scan Functions................................. 10 Location 242Programming the Options and Reader Partition ............................................ 11 Location 243Programming the Door Prop Zone ................................................................. 11 Location 244Programming the Various Reader Timers ...................................................... 12 Location 245Resetting the Reader Address .......................................................................... 12 IX.PROGRAMMING WORKSHEETS................................................................................................................... 13 X.ORDERING INFORMATION ............................................................................................................................ 14 XI.FCC INFORMATION.......................................................................................................................................... 15 XII.SPECIFICATIONS............................................................................................................................................... 16 NX-1700E Card Reader 4 Symbol Legend Warning Indicates a procedure, practice, condition, or statement that, if not strictly observed, could result in personal injury. * This symbol indicates electrical warnings and cautions. Caution Indicates a procedure, practice, condition, or statement that, if not strictly observed, could result in damage to or destruction of equipment or property. ** This symbol indicates general warnings and cautions.
