RS2-G3 ONE BUTTON 2-WAY REMOTE START SYSTEM INSTALLATION INSTRUCTIONS CONGRATULATIONS on your choice of a “Cool Start” System with Data Por t Technology for direct connection to bypass module by Crime stopper Security Products Inc. This booklet contains the i nformation necessary for installing your remote starter system. If any ques tions arise, contact your installation dealer or Crime stopper Security Products Inc. at the Tech Support number belo w. DISCLAIMER : This installation book is designed for the installe r or individual with an existing understanding of a utomotive electrical systems, along with the ability to test and connect wires for proper operation. To ease installation, we suggest that you READ THIS MANUAL before beginning your installation. This book is provided as a GENERAL GUIDELINE and the information contained herein may differ fro m your vehicle. Crime stopper Security Products, Inc. and its’ vendors shall not be liable for any accident result ing from the use of this product. This system is d esigned to be professionally installed into a vehicle in which al l systems and associated components are in perfect working condition. TECHNICAL SUPPORT: (800) 998-6880 Monday - Friday 8:00am - 4:30pm Pacific Std. Time Web Site: www.crimestopper.com CRIMESTOPPER SECURITY PRODUCTS, INC. 1770 S. TAPO STREET, SIMI VALLEY, CA. 93063 REV 07-25-2014 This device complies with FCC Rules part 15. Opera tion is subject to the following two conditions: (1) This device m ay not cause harmful interference, and (2) This device must acce pt any interference that may be received, including interf erence that may cause undesired operation. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modification could void th e us er’s authority to use the equipment. 2 TABLE OF CONTENTS Pre-Installation Considerations.............................................. .................................................................3 Installation Cautions & Warnings......................................................... .............................................. .....3 Low Current Wiring............................................................................................... ............ ................3-8 Parking Lights............................................................................................................... .....................6 Power Door Lock Wiring......................................................................... ...................... .....................9-.10 Smart Tachless and Tach Finder Mode.............................................. .........................................................11 Tach Programming............................................................................................... ............ ........... ........12 Diesel Glow Plug Delay ........................................................................ ................................ ................13 Option Programming Table.......... .......................................................... ....................... ....................14-15 Option Descriptions.................................................................................. .............. ................... ......16-20 Antenna Diagram...... ............................................................................................................... ...........21 Wiring Diagram............................................................................................... ........... .........................22 High Current Connector Wiring.................................................................. ...........................................23 Remote Star Diagnostics........................... ..........................................................................................23 Data Port................................................................................................................. ................... ......24 PC Programming Menu................................................................................................ .......................25 Specifications................................................ ....................................................................................26 PRE-INSTALLATION CONSIDERATIONS BEFORE BEGINNING , check all vehicle manufacturer cautions and warnin gs regarding electrical service (AIR BAGS, ABS BRAKES, ENGINE / BODY COMPUTER AND BATTERY). PLAN OUT YOUR INSTALLATION and determine most suitable locations for all compo nents to be placed. These components include: the module itself, valet/progra m button, possible relays, and antenna/receiver Allow enough wire to create a service loop with strain relief, should servici ng be required. This will also allow easier access an d mounting. DAMAGE to the Cool Start unit resulting from incorrect installation or failure to follo w guidelines stated in this book will not be covered under warranty and will be subject to repair or replacement charges. USE A VOLT OHM METER to test and locate all connections. Test Lights c an damage a vehicle’s computer systems. ADDITIONAL PARTS , which are not included with this unit, may be nee ded for your particular vehicle. These items may include extra relays or Anti-Theft System Bypass modul es. 3 INSTALLATION CAUTIONS & WARNINGS DO NOT extend the Remote start ignition harness length. Mount the module so that main harness reaches all ignition switch wiring. Extending these wires coul d result in poor or improper performance. DO NOT route any wiring that may become entangled with br ake, gas pedals, steering column or any other movin g parts in the vehicle. DO NOT exceed the rated output current of any circuit on the Remote start module. Failure to observe this w arning will result in damage to the unit not covered under warranty. DO NOT remote start the vehicle in a clo…
