CJ6AT00-046DVD-ROM Drive

Dynabook Inc.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Sep 13, 2000
Application Purpose: Original Equipment
Date of Application: Aug 30, 2000
Equipment Note: DVD-ROM Drive
Company: Dynabook Inc.
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Toshiba Corporation Application No. YFA-R2248 FCC ID: CJ6AT00-046 Exhibit - H 1 of 1 SAFETY MANUAL FOR DVD-ROM DRIVE MODEL SD-M1502

Block Diagram

Toshiba Corporation Application No. YFA-R2248 FCC ID: CJ6AT00-046 Exhibit - A 1 of 1 DVD-ROM DRIVE MODEL SD-M1502 BLOCK DIAGRAM

External Photos

Toshiba Corporation Application No. YFA-R2248 FCC ID: CJ6AT00-046 Exhibit - B 1 of 3 PHOTO OF DVD-ROM DRIVE MODEL SD-M1502 Toshiba Corporation Application No. YFA-R2248 FCC ID: CJ6AT00-046 Exhibit - B 2 of 3 PHOTO OF DVD-ROM DRIVE MODEL SD-M1502 Toshiba Corporation Application No. YFA-R2248 FCC ID: CJ6AT00-046 Exhibit - B 3 of 3 PHOTO OF DVD-ROM DRIVE MODEL SD-M1502

ID Label/Location Info

Toshiba Corporation Application No. YFA-R2248 FCC ID: CJ6AT00-046 Exhibit - C 1 of 1 ID Label/Location Info: 1. FCC statements & FCC ID number are indicated on the rating label. Word; This device complies with Part 15 of the FCC Rules. Operation is Subject to the following two conditions : (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID : CJ6AT00-046 2. Location of FCC label Front 3. Sketch of rating label

Internal Photos

Toshiba Corporation Application No. YFA-R2248FCC ID: CJ6AT00-046 Exhibit - D 1 of 4 INTERNAL PHOTO OF DVD-ROM DRIVE MODEL SD-M1502 Toshiba Corporation Application No. YFA-R2248FCC ID: CJ6AT00-046 Exhibit - D 2 of 4 INTERNAL PHOTO OF DVD-ROM DRIVE MODEL SD-M1502 Toshiba Corporation Application No. YFA-R2248FCC ID: CJ6AT00-046 Exhibit - D 3 of 4 INTERNAL PHOTO OF DVD-ROM DRIVE MODEL SD-M1502 Toshiba Corporation Application No. YFA-R2248FCC ID: CJ6AT00-046 Exhibit - D 4 of 4 INTERNAL PHOTO OF DVD-ROM DRIVE MODEL SD-M1502

Parts List/Tune Up Info

Toshiba Corporation Application No. YFA-R2248 FCC ID: CJ6AT00-046 Exhibit - F 1 of 1 PARTS LIST FOR DVD-ROM DRIVE MODEL SD-M1502 1. Technical Specifications 1) Generated Frequency : Location: X201 22.58 MHz (Main PWB) X301 33.86 MHz (Main PWB) X40166.00 MHz (Main PWB) H_IC1 450 MHz (Inside of laser module) 2) Noise Suppression Components (EMI Filter, etc.) a) Location : L001 (Main PWB) Type: ZJSR5101-332 Rating: 50 V DC, 5 A, -25dB at 35 to 200 MHz Mfr. : TDK Corporation b) Location: L601, L602, L603 (Front PWB) Type: BK1608HS601 Rating: 600 ohm at 100 MHz Mfr. : Taiyo Yuden Co., Ltd.

Schematics

Toshiba Corporation Application No. YFA-R2248 FCC ID: CJ6AT00-046 Exhibit - G 1 of 2 Circuit Diagram for DVD-ROM DRIVE MODEL SD-M1502 Toshiba Corporation Application No. YFA-R2248 FCC ID: CJ6AT00-046 Exhibit - G 2 of 2
