CJ6CET0200MTHand-held Computer and Cellular Telephone

2 INTRODUCTION It is important you read this manual (USER’S GUIDE) before using your device ( Pocket PC) to ensure its proper operation. It is recommended that important data stored in your device should be saved to a memory card (sold separately) or your personal computer (data transfer with ActiveSync ® ) on a regular basis. Before returning your unit for service, be sure to back up your data and remove any confidential, proprietary or personal information. Audiovox Communications Corp. is not responsible for damage to or loss of any programs, data or removable storage media. The purpose of the Safety Instructions in this manual is to provide you with warnings and safety instructions that will assist in preventing the misuse of your device. * All of the Safety Instructions that are contained in this manual must be read carefully and must be fully understood before you attempt to use your device in order to avoid potential hazards that could cause bodily injury or property damage, or could result in damage to your device or loss of data. * Always keep this manual in a convenient place for future reference. Trademark Information • Microsoft, ActiveSync, Outlook, Pocket Outlook, Windows, Windows NT, and the Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Microsoft products are licensed to OEMs by Microsoft Licensing, Inc., a wholly owned subsidiary of Microsoft Corporation. • Sierra Wireless, the Sierra Wireless logo, red wave design and, Watcher are trademarks of Sierra Wireless, Inc. Heart of the Wireless Machine is a registered trademark of Sierra Wireless, Inc. © 2001 Sierra Wireless, inc. • Other product names mentioned in this manual are trademarks or registered trademarks of the respective companies. 3 Product Name: Model Number(s): CET0200A (PDA2032) FCC Notice “Declaration of Conformity Information” This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Warning:Only peripherals complying with the FCC class B limits may be attached to this equipment. Operation with non-compliant peripherals or peripherals not recommended by us is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the cradle connecting port. Changes or modifications made to this equipment, not expressly approved by us or parties authorized by us could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Modifications or changes to this equipment not expressly approved by Audiovox may void the user’s authority to operate the equipment. 4 Product Name: USB Cradle Model Number(s): CEX0208B (CRU2032B) FCC Notice “Declaration of Conformity Information” This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 5 SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS • There are two categories of Safety Instructions included in this manual:
Product Warnings, (i.e., what must never be done to assure avoiding those hazards that could cause bodily injury or property damage); and
User Directions (i.e., what must always be done to assure the safe use of your device). • The Safety Instructions contained in this manual have been categorized in accordance with the seriousness of the potential hazards through the use of Signal Words. Those Signal Words, and their intended meanings, are as follows: DANGER:Indicates that a failure to observe the Safety Instruction…

Text truncated - open the document above for the full version.

OM E OPERATIONS DIGITAL MEDIA NETWORK COMPANY 2-9, SUEHIRO-CHO, OME-CITY, TOKYO 198-8710, JAPAN PHONE: +81(428) 33-1170FAX: +81(428) 30-7911 Transceiver Type: CJ6CET0200MT Federal Communication Commission Equipment Approval Services P.O.Box358315 Pittsburgh, PA 15251-5315 Subject: Affidavit for PDA with Cellular Phone Function, FCC ID: CJ6CET0200MT Gentlemen: I hereby certify that the Transceiver FCC ID: CJ6CET0200MT manufactured by TOSHIBA Corporation complies with all Requirements of OST Bulletin 53 as reference in Section 22.933 of the FCC Rules and all technical/test data enclosed with this application are true and correct. Yours faithfully, Kyo Ueda Senior Manager PDA Development & Design Dept. OM E OPERATIONS DIGITAL MEDIA NETWORK COMPANY 2-9, SUEHIRO-CHO, OME-CITY, TOKYO 198-8710, JAPAN PHONE: +81(428) 33-1170FAX: +81(428) 30-7911 Transceiver Type: CJ6CET0200MT Federal Communication Commission Equipment Approval Services P.O.Box358315 Pittsburgh, PA 15251-5315 Subject: Affidavit for PDA with Cellular Phone Function, FCC ID: CJ6CET0200MT Gentlemen: I hereby certify that the Transceiver FCC ID: CJ6CET0200MT is so designed that it complies with all the requirements for ESN protection specified in Section 22.919. (a) The transmitter in service has a unique ESN. (b) The ESN host component is permanently attached to a circuit board of the modem and the integrity of the unit's operating software can not be alterable. The ESN is isolated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and programmed in the memory with other information. (c) The ESN is factory set and can not be alterable, transferable, removable or otherwise able to be manipulated. This modem is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the modem inoperative. The information concerning ESN protection is shown in Exhibit Type “Operational Description”. Yours faithfully, Kyo Ueda Senior Manager PDA Development & Design Dept. OM E OPERATIONS DIGITAL MEDIA NETWORK COMPANY 2-9, SUEHIRO-CHO, OME-CITY, TOKYO 198-8710, JAPAN PHONE: +81(428) 33-1170FAX: +81(428) 30-7911 Transceiver Type: CJ6CET0200MT Federal Communication Commission Equipment Approval Services P.O.Box358315 Pittsburgh, PA 15251-5315 Subject: Affidavit for PDA with Cellular Phone Function, FCC ID: CJ6CET0200MT Gentlemen: I hereby certify that the Transceiver FCC ID: CJ6CET0200MT manufactured by TOSHIBA Corporation complies with Section 2.1093 of the FCC Rules. Yours faithfully, Kyo Ueda Senior Manager PDA Development & Design Dept. OM E OPERATIONS DIGITAL MEDIA NETWORK COMPANY 2-9, SUEHIRO-CHO, OME-CITY, TOKYO 198-8710, JAPAN PHONE: +81(428) 33-1170FAX: +81(428) 30-7911 Transceiver Type: CJ6CET0200MT Federal Communication Commission Equipment Approval Services P.O.Box358315 Pittsburgh, PA 15251-5315 Subject: Affidavit for PDA with Cellular Phone Function, FCC ID: CJ6CET0200MT Gentlemen: I hereby certify that the Transceiver FCC ID: CJ6CET0200MT, using the automatic A/B Roaming, Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a "9-1-1" call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other carriers. Should you have any questions or comments concerning the above, please contact the undersigned. Yours faithfully, Kyo Ueda Senior Manager PDA Development & Design Dept.

OME OPERATIONS DIGITAL MEDIA NETWORK COMPANY 2-9, SUEHIRO-CHO, OME-CITY, TOKYO 198-8710, JAPAN PHONE: +81(428) 33-1170 FAX: +81(428) 30-7911 Transceiver Type: CJ6CET0200MT Federal Communication Commission Equipment Approval Services P.O.Box358315 Pittsburgh, PA 15251-5315 Subject: Request of Confidentiality, FCC ID: CJ6CET0200MT Gentlemen: In accordance with 0.459 of CFR 47, TOSHIBA Corporation hereby requests confidentiality of the Operational Description attachment, Tune-up Procedure attachment for the above-reference Certification application. These documents contain detailed system and equipment description and related information about the product, which Toshiba Corporation considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Toshiba Corporation considers this information to be of benefit to its competitors, such that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours faithfully, Kyo Ueda Senior Manager PDA Development & Design Dept.

Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE1 OF EXHIBIT Type “External Photos” Front Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE2 OF EXHIBIT Type “External Photos” Back (showing FCC ID Nameplate) Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE3 OF EXHIBIT Type “External Photos” Side View Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE4 OF EXHIBIT Type “External Photos” Top View Bottom View

Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE1 OF EXHIBIT Type “External Photos” Front Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE2 OF EXHIBIT Type “External Photos” Back (showing FCC ID Nameplate) Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE3 OF EXHIBIT Type “External Photos” Side View Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE4 OF EXHIBIT Type “External Photos” Top View Bottom View Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE5 OF EXHIBIT Type “External Photos” Front (w/ leather case and belt clip) Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE6 OF EXHIBIT Type “External Photos” Back (w/ leather case and belt clip) Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE7 OF EXHIBIT Type “External Photos” Side View (w/ leather case and belt clip) Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE8 OF EXHIBIT Type “External Photos” Top View (w/ leather case and belt clip) Bottom View (w/ leather case and belt clip) Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE9 OF EXHIBIT Type “External Photos” Belt Clip Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE10 OF EXHIBIT Type “External Photos” Leather Case

Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE1 OF EXHIBIT Type “ID Label” ID Label FCC ID Nameplate A Nameplate of this type or one similar to this will be affixed to every Transceiver. Back (showing FCC ID nameplate) A Nameplate will be located on the outside of PDA.

Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE1 OF EXHIBIT Type “ID Label” ID Label FCC ID Nameplate A Nameplate of this type or one similar to this will be affixed to every Transceiver. Back (showing FCC ID nameplate) A Nameplate will be located on the outside of PDA.

Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE1 OF EXHIBIT Type “Internal Photos” LCD front Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE2 OF EXHIBIT Type “Internal Photos” LCD back Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE3 OF EXHIBIT Type “Internal Photos” PDA front Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE4 OF EXHIBIT Type “Internal Photos” PDA back Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE5 OF EXHIBIT Type “Internal Photos” RF Module Front Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE6 OF EXHIBIT Type “Internal Photos” RF Module Back Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE7 OF EXHIBIT Type “Internal Photos” Shielding Between PDA Board and LCD panel- Side A Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE8 OF EXHIBIT Type “Internal Photos” Shielding Between PDA Board and LCD panel - Side B Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE9 OF EXHIBIT Type “Internal Photos” Front Housing Inside Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE10 OF EXHIBIT Type “Internal Photos” Back Housing Inside Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE11 OF EXHIBIT Type “Internal Photos” Inverter Module – Side A Inverter Module – Side B Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE12 OF EXHIBIT Type “Internal Photos” Assembly Photo

SB555-T Photographs for FCC submission. #1. SB555-T Logic side with shield on. #2. SB555-T Logic side with shield off. #3. SB555-T Logic side with shield and fence off. ESN stored in this component. #4. SB555-T Radio side with shield on. #5. SB555-T Radio side with shield off. #6. SB555-T Radio side with shield and fence off.

Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE1 OF EXHIBIT Type “Internal Photos” LCD front Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE2 OF EXHIBIT Type “Internal Photos” LCD back Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE3 OF EXHIBIT Type “Internal Photos” PDA front Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE4 OF EXHIBIT Type “Internal Photos” PDA back Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE5 OF EXHIBIT Type “Internal Photos” RF Module Front Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE6 OF EXHIBIT Type “Internal Photos” RF Module Back Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE7 OF EXHIBIT Type “Internal Photos” Shielding Between PDA Board and LCD panel- Side A Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE8 OF EXHIBIT Type “Internal Photos” Shielding Between PDA Board and LCD panel - Side B Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE9 OF EXHIBIT Type “Internal Photos” Front Housing Inside Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE10 OF EXHIBIT Type “Internal Photos” Back Housing Inside Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE11 OF EXHIBIT Type “Internal Photos” Inverter Module – Side A Inverter Module – Side B Applicant: TOSHIBA Corporation Transceiver Type: CJ6CET0200MT PAGE12 OF EXHIBIT Type “Internal Photos” Assembly Photo

SB555-T Revision 5.1 Photographs January 8, 2002 Logic Components Logic Components with Shield Fence Logic Side with Shield Cover RF Components RF Components with Shield Fence RF Side with Shield Cover

Peak SAR Location © 2001 PCTEST Lab TOSHIBA FCC ID: CJ6CET0200MT (Model: CET200) NVLAP Lab Code: 100431-0 Dual-Band CDMA PDA Phone (CDMA) Body SAR File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/02010808_ZOOM.VLT Start : 8-Jan-102 11:29:24 am End : 8-Jan-102 11:37:31 am Radio Type : TOSHIBA Model Number : CET200 Serial Number : 1 Frequency : 824.70 MHz Peak Trans. Pwr : 0.280 W Start Trans. Pwr: 0.280 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Flat Phantom Posn. : E Field Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 55.200 Mixture Conductivity = 0.970 Comment : TOSHIBA DUAL-BAND PDA PHONE CH 1013 Conducted 24.5 dBm TOSHIBA DUAL-BAND PDA PHONE - BODY SAR Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.423 PCTEST Amplifier Channel Settings : 0.239 0.278 0.294 Max Location : X = 3.000, Y = -3.000, Z = 0.000 (cm) Value = 17.143 Measured Values (volts) = 1.630E-002 1.190E-002 1.016E-002 9.021E-003 7.592E-003 7.400E-003 6.434E-003 5.818E-003 5.416E-003 4.898E-003 4.489E-003 3.888E-003 3.546E-003 3.338E-003 3.245E-003 2.747E-003 2.854E-003 2.738E-003 2.385E-003 2.573E-003 2.202E-003 Calc. Voltage @ Surface (Vs) = 0.0197 Voltage @ 1.00 cm (Vt) = 0.0087 Ave. Voltage (Vs+Vt)/2 = 0.0142 Ave. SAR over 1 g (mW/g) = 0.5576 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 mW/g -1012345 Z centimeters SAR Scan File : 02010808_ZOOM Start : 8-Jan-102 11:29:24 am End : 8-Jan-102 11:37:31 am TOSHIBA/CET200/1;824.70MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/55.200/0.970 File : 02010808_ZOOM Start : 8-Jan-102 11:29:24 am End : 8-Jan-102 11:37:31 am TOSHIBA/CET200/1;824.70MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/55.200/0.97 0 0.671 0.634 0.597 0.559 0.522 0.485 0.447 0.410 0.373 0.335 File : 02010808_ZOOM Start : 8-Jan-102 11:29:24 am End : 8-Jan-102 11:37:31 am TOSHIBA/CET200/1;824.70MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/55.200/0.97 0 0.671 0.634 0.597 0.559 0.522 0.485 0.447 0.410 0.373 0.335 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/02010809_ZOOM.VLT Start : 8-Jan-102 11:42:50 am End : 8-Jan-102 11:50:56 am Radio Type : TOSHIBA Model Number : CET200 Serial Number : 1 Frequency : 836.49 MHz Peak Trans. Pwr : 0.280 W Start Trans. Pwr: 0.280 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Flat Phantom Posn. : E Field Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 55.200 Mixture Conductivity = 0.970 Comment : TOSHIBA DUAL-BAND PDA PHONE CH 0383 Conducted 24.5 dBm TOSHIBA DUAL-BAND PDA PHONE - BODY SAR Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.423 PCTEST Amplifier Channel Settings : 0.239 0.278 0.294 Max Location : X = 2.500, Y = -3.000, Z = 0.000 (cm) Value = 17.007 Measured Values (volts) = 1.577E-002 1.158E-002 1.001E-002 8.700E-003 7.457E-003 6.805E-003 6.071E-003 5.175E-003 4.761E-003 4.105E-003 3.768E-003 2.954E-003 2.983E-003 2.683E-003 2.544E-003 1.849E-003 2.037E-003 1.735E-003 1.675E-003 1.538E-003 1.600E-003 Calc. Voltage @ Surface (Vs) = 0.0190 Voltage @ 1.00 cm (Vt) = 0.0085 Ave. Voltage (Vs+Vt)/2 = 0.0137 Ave. SAR over 1 g (mW/g) = 0.5370 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/02010807_ZOOM.VLT Start : 8-Jan-102 11:12:27 am End : 8-Jan-102 11:26:02 am Radio Type : TOSHIBA Model Number : CET200 Serial Number : 1 Frequency : 848.97 MHz Peak Trans. Pwr : 0.280 W Start Trans. Pwr: 0.280 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Flat Phantom Posn. : E Field Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 55.200 Mixture Conductivity = 0.970 Comment : TOSHIBA DUAL-BAND PDA PHONE CH 0777 Conducted 24.5 dBm TOSHIBA DUAL-BAND PDA PHONE - BODY SAR Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.423 PCTEST Amplifier Channel Settings : 0.239 0.278 0.294 Max Location : X = 2.500, Y = -3.000, Z = 0.000 (cm) Value = 16.827 Measured Values (volts) = 1.592E-002 1.100E-002 9.196E-003 7.906E-003 6.923E-003 6.156E-003 5.644E-003 4.945E-003 4.290E-003 3.992E-003 3.171E-003 2.976E-003 2.690E-003 2.378E-003 2.348E-003 2.308E-003 1.950E-003 1.732E-003 1.585E-003 1.779E-003 1.703E-003 Calc. Voltage @ Surface (Vs) = 0.0199 Voltage @ 1.00 cm (Vt) = 0.0077 Ave. Voltage (Vs+Vt)/2 = 0.0138 Ave. SAR over 1 g (mW/g) = 0.5408 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/02010716_ZOOM.VLT Start : 7-Jan-102 05:57:51 pm End : 7-Jan-102 06:08:12 pm Radio Type : TOSHIBA Model Number : CET200 Serial Number : 1 Frequency : 1851.25 MHz Peak Trans. Pwr : 0.280 W Start Trans. Pwr: 0.280 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Flat Phantom Posn. : E Field Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 53.300 Mixture Conductivity = 1.520 Comment : TOSHIBA DUAL-BAND PDA PHONE CH 0025 Conducted 24.5 dBm TOSHIBA DUAL-BAND PDA PHONE - BODY SAR Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.496 PCTEST Amplifier Channel Settings : 0.309 0.361 0.421 Max Location : X = 3.000, Y = -2.500, Z = 0.000 (cm) Value = 7.913 Measured Values (volts) = 7.032E-003 5.139E-003 4.375E-003 4.048E-003 3.135E-003 3.285E-003 2.947E-003 2.602E-003 2.500E-003 2.169E-003 2.758E-003 2.232E-003 2.563E-003 2.471E-003 2.173E-003 2.365E-003 2.490E-003 2.454E-003 2.790E-003 2.619E-003 2.940E-003 Calc. Voltage @ Surface (Vs) = 0.0085 Voltage @ 1.00 cm (Vt) = 0.0039 Ave. Voltage (Vs+Vt)/2 = 0.0062 Ave. SAR over 1 g (mW/g) = 0.2845 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/02010713_ZOOM.VLT Start : 7-Jan-102 04:52:40 pm End : 7-Jan-102 05:09:49 pm Radio Type : TOSHIBA Model Number : CET200 Serial Numbe…

Text truncated - open the document above for the full version.

© 2002 PCTEST Lab FCC ID: CJ6CET0200MT NVLAP Lab Code: 100431-0 TOSHIBA Dual-Band CDMA PDA (CDMA/PCS) © 2002 PCTEST Lab FCC ID: CJ6CET0200MT NVLAP Lab Code: 100431-0 TOSHIBA Dual-Band CDMA PDA (CDMA/PCS) © 2002 PCTEST Lab FCC ID: CJ6CET0200MT NVLAP Lab Code: 100431-0 TOSHIBA Dual-Band CDMA PDA (CDMA/PCS) © 2002 PCTEST Lab FCC ID: CJ6CET0200MT NVLAP Lab Code: 100431-0 TOSHIBA Dual-Band CDMA PDA (CDMA/PCS)

© 2002 PCTEST Lab FCC ID: CJ6CET0200MT NVLAP Lab Code: 100431-0 TOSHIBA Dual-Band CDMA PDA (CDMA/PCS) © 2002 PCTEST Lab FCC ID: CJ6CET0200MT NVLAP Lab Code: 100431-0 TOSHIBA Dual-Band CDMA PDA (CDMA/PCS) © 2002 PCTEST Lab FCC ID: CJ6CET0200MT NVLAP Lab Code: 100431-0 TOSHIBA Dual-Band CDMA PDA (CDMA/PCS) © 2002 PCTEST Lab FCC ID: CJ6CET0200MT NVLAP Lab Code: 100431-0 TOSHIBA Dual-Band CDMA PDA (CDMA/PCS)

© 2002 PCTEST Engineering Lab., Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) TOSHIBA CORPORATION Dates of Tests: Jan. 7-8, 2002 Technology & Quality Management Division Test Report S/N: SAR.220102717.CJ6 Digital Media Equipment & Services Co. Test Site: PCTEST Lab, Columbia, MD USA 1-1 Shibaura 1-Chome, Minaroku Attn: Jim Papadopoulos Audiovox Communications Corp. FCC ID CJ6CET0200MT APPLICANT TOSHIBA CORPORATION EUT Type: Dual-Band CDMA PDA Phone Tx Frequency: 824.70 – 848.31 MHz (CDMA) / 1851.25 – 1908.75 MHz (PCS CDMA) Rx Frequency: 869.70 – 893.31 MHz (CDMA) / 1931.25 – 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.301W ERP CDMA (24.783 dBm) 0.359W EIRP PCS CDMA (25.551 dBm) Trade Name/Model(s): TOSHIBA CET200A/B/C/D/E FCC Classification: Licensed Non-Broadcast Transmitter Worn on Body (TNT) Application Type: Certification FCC Rule Part(s): §2.1093; ET Docket 96.326 Maximum SAR: 0.5576 W/kg CDMA Body SAR; 0.2866 W/kg PCS Body SAR; 1.0102 W/kg CDMA Hand SAR; (Avg. over 10 gms); 2.4638 W/kg PCS Hand SAR (Avg. over 10 gms) This wireless portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and has been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report) I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. SAR.220102717.CJ6 Test Report S/N: SAR.220102717.CJ6 SAR Measurement Report Test Dates: JAN. 7-8, 2002 FCC Part 22/24 Certification Table of Contents 1.1 SCOPE........................................................................................................................1 2.1 INTRODUCTION........................................................................................................2 2.2 SAR Definition......................................................................................................2 3.1 SAR MEASUREMENT SET-UP.............................................................................3 4.1 ISOTROPIC E-FIELD PROBE SYSTEM...............................................................4 5.1 E-FIELD PROBE CALIBRATION PROCESS......................................................5 6.1 PHANTOM AND EQUIVALENT TISSUES...........................................................7 7.1 SYSTEM SPECIFICATIONS...................................................................................8 8.1 MEASUREMENT PROCESS..................................................................................9 9.1 BODY-WORN TEST SETUP.................................................................................10 10.1 ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS.........................................11 11.1 MEASUREMENT UNCERTAINTIES.................................................................12 12.1 SAR TEST DATA SUMMARY.............................................................................13 13.1 SAR TEST EQUIPMENT.....................................................................................17 14.1 CONCLUSION.......................................................................................................18 Test Report S/N: SAR.220102717.CJ6 SAR Measurement Report Test Dates: Jan. 7-8, 2002 FCC Part 22/24 Certification FCC ID: CJ6CET0200MT (Model: CET200A/B/C/D/E) © 2002 PCTEST TOSHIBA Dual-Band CDMA PDA Phone 1 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Applicant Name: TOSHIBA CORPORATION Address: Technology & Quality Management Division Digital Media Equipment & Services Co. 1-1 Shibaura 1-Chome, Minaroku Attention: Jim Papadopoulos Audiovox Communications Corp. EUT Type: Dual-Band CDMA PDA Phone Trade Name: TOSHIBA Model(s): CET200A/B/C/D/E FCC IDENTIFIER: CJ6CET0200MT Tx Frequency: 824.70 – 848.31 MHz (CDMA) 1851.25 – 1908.75 MHz (PCS CDMA) Rx Frequency: 869.70 – 893.31 MHz (CDMA) 1931.25 – 1988.75 MHz (PCS CDMA) Application Type: Certification FCC Classification: Licensed Non-Broadcast Transmitter Worn on Body (TNT) FCC Rule Part(s): § 2.1093, Docket 96-326 Modulation(s): CDMA Max RF. Output Power: 0.301W ERP CDMA (24.783 dBm) 0.359W EIRP PCS CDMA (25.551 dBm) Date(s) of Tests: Jan. 7-8, 2002 Place of Tests: PCTEST Engineering Lab. Columbia, MD, U.S.A. Report Serial No.: SAR.220102717.CJ6 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.220102717.CJ6 SAR Measurement Report Test Dates: Jan. 7-8, 2002 FCC Part 22/24 Certification FCC ID: CJ6CET0200MT (Model: CET200A/B/C/D/E) © 2002 PCTEST TOSHIBA Dual-Band CDMA PDA Phone 2 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety …

Text truncated - open the document above for the full version.

TOSHIBA FCC ID: CJ6CET0200MT (Model: CET200A/B/C/D/E) Dual-Band PDA Phone (CDMA) © 2002 PCTEST SAR TEST DATA SUMMARY Ambient TEMPERATURE (°C) 21.1 Relative HUMIDITY (%) 49.2 Atmospheric PRESSURE (kPa) 101.0 Measured Values: Mixture Type: Brain Liquid Temperature ( o C): 20.2 Dielectric Constant: 41.5 Conductivity (S/m): 0.90 Liquid Depth (cm): 15.0 Closest Distance (between E-Probe & Phone): 2.5 cm Measurement Results (CDMA Face SAR) FREQUENCY POWER (dBm) Phantom Antenna SAR MHz Ch. Modul…
