CJ6MSDB01Bluetooth SDIO Card

Confidential SDIO Card Type SDIO Card TypeSDIO Card Type SDIO Card Type- -- -B for Bluetooth B for BluetoothB for Bluetooth B for Bluetooth™ ™™ ™User's Manual1.0 Draft (June 24, 2002) 1 SDIO Card Type SDIO Card TypeSDIO Card Type SDIO Card Type- -- -B for Bluetooth B for BluetoothB for Bluetooth B for Bluetooth™ ™™ ™ User's Manual User's ManualUser's Manual User's Manual 1.0 1.01.0 1.0 Draft DraftDraft Draft (June 24, 2002) (June 24, 2002) (June 24, 2002) (June 24, 2002) TOSHIBA CORPORATION TOSHIBA CORPORATIONTOSHIBA CORPORATION TOSHIBA CORPORATION Confidential SDIO Card Type SDIO Card TypeSDIO Card Type SDIO Card Type- -- -B for Blueto B for BluetoB for Blueto B for Bluetooth othoth oth™ ™™ ™ User's Manual 1.0 1.01.0 1.0 Draft Draft Draft Draft (June 24, 2002) 2 Revision History Revision Date Comments 1.0 Draft 2002-06-24 Draft (*) The Bluetooth trademarks are owned by Bluetooth SIG, Inc., U.S.A Confidential SDIO Card Type SDIO Card TypeSDIO Card Type SDIO Card Type- -- -B for Blueto B for BluetoB for Blueto B for Bluetooth othoth oth™ ™™ ™ User's Manual 1.0 1.01.0 1.0 Draft Draft Draft Draft (June 24, 2002) 3 Feature Bluetooth™ SD card is an ultra small and thin card which has built-in antenna, Bluetooth™ function and SD/IO interface compliant with SDIO Card Specification. Bluetooth™ is a low-cost and low-power wireless communication standard for short range communication which uses 2.4GHz ISM band and GFSK modulation method. Bluetooth™ specification is standardized by Bluetooth SIG and it is industry-widely supported. SDIO Card Specification is a standard for small size IO devices. SDIO Card Specification is standardized by SD Association and it is also industry-widely supported. Bluetooth™ SD card can be used with any kind of devices which have SDIO card slot and software for Bluetooth SD card, i.e. PDAs, portable PCs and desktop PCs. Appearance Direction of insertion Installation When inserting this card into SD card slot, check the form of the connector and insert it surely. PDA supporting the SD/IO Card • Connect the Bluetooth™ SD Card to a PDA. This drawing is an example. As for the position where the Bluetooth™ SD card is connected, refer to the User’s Manual of PDA. Confidential SDIO Card Type SDIO Card TypeSDIO Card Type SDIO Card Type- -- -B for Blueto B for BluetoB for Blueto B for Bluetooth othoth oth™ ™™ ™ User's Manual 1.0 1.01.0 1.0 Draft Draft Draft Draft (June 24, 2002) 4 What you can do with the Bluetooth™ SD Card < Data communication between a PDA and a PC > PDA supporting the SD/IO Card PC with Bluetooth Confidential SDIO Card Type SDIO Card TypeSDIO Card Type SDIO Card Type- -- -B for Blueto B for BluetoB for Blueto B for Bluetooth othoth oth™ ™™ ™ User's Manual 1.0 1.01.0 1.0 Draft Draft Draft Draft (June 24, 2002) 5 Specifications Model name SDIO Card Type-B for Bluetooth TM Model No. SD-BT2 Bluetooth™ specification Bluetooth™ Ver.1.1 *1 Specification of electric Operating voltage : 3.1 to 3.6V Power Consumption : 100mA(MAX.) 50mA(AVG. in transmitting/receiving) RF specification In conformity with Bluetooth radio specification Transmission electric power class : Power class 3 [ maximum output : 1mW (0dBm)] Sensitivity of receiving : –70dBm Host-Card Interface SDIO Card Specification V1.0 SDIO Card Type-B Specification for Bluetooth™ Dimension 40mm-long x 24mm-wide x 2.1mm-thick A part of protrusion is 2.8mm-thick. Bluetooth™ Protocols/Profiles implemented in the Card RF, Baseband, LMP, L2CAP *2 , SDP *2 , RFCOMM *2 , GAP *2 , SPP(Serial Port Profile) *2 *1 : Bluetooth Special Interest Group, Document number 1.C.47/1.1, February 22nd, 2001 *2 : It is supported when the card is in “SDIO Card for Bluetooth Type-B” mode. Confidential SDIO Card Type SDIO Card TypeSDIO Card Type SDIO Card Type- -- -B for Blueto B for BluetoB for Blueto B for Bluetooth othoth oth™ ™™ ™ User's Manual 1.0 1.01.0 1.0 Draft Draft Draft Draft (June 24, 2002) 6 Using this products • Using this products Using this productsUsing this products Using this products ***WARNING ***WARNING***WARNING ***WARNING Do not perform disassembly, modifications or repairs. There is a danger of fires, electrical shock, damage to the unit, and injury. Do no remove the label and do not paste the other labels. Dismantling this product will invalidate the warranty and any other service plan. Do not use this unit in an area where people wearing pacemakers may be nearby (such as in a crowded train). Electrical signals may cause abnormalities in pacemaker operation. Those with a pacemaker should operate this system from a minimum distance of 22cm or more. Electrical signals may cause abnormalities in pacemaker operation. Do not use this unit near medical electronic equipment. Likewise, do not attach medical electronic equipment to this system. Electrical signals may cause abnormalities in the operation of medical electronic equipment. Do not use this unit near automatic doors, fire detection devices, or other automatic control devices. Electrical signals may affect these devices, leading to accidents caused by malfunctions. Do not use this unit in an aircraft or in a place where this unit may electromagnetically affect other devices. An electromagnetically wave may affect these devices and cause accidents by malfunctions. If this unit give any electromagnetic interference to other device during use of this unit, turn off the system that this unit is mounted. If the system is not turned off, eject this unit from the system. Electrical signals may affect these devices, leading to accidents caused by malfunctions. Do not put this unit into your mouth to avoid swallowing it. Confidential SDIO Card Type SDIO Card TypeSDIO Card Type SDIO Card Type- -- -B for Blueto B for BluetoB for Blueto B for Bluetooth othoth oth™ ™™ ™ User's Manual 1.0 1.01.0 1.0 Draft Draft Draft Draft (June 24, 2002) 7 *** CAUTION *** CAUTION*** CAUTION *** CAUTION Do not use unit in the bath, or any other area where there is a chance of submersion or…

Text truncated - open the document above for the full version.

Date: 2002/07/03 Federal Communications Commission Equipment Approval Services Subject: Request for Confidentiality FCC ID: CJ6MSDB01 Dear Sir/Madame: In according to Section 0.459 of CFR 47, we, Toshiba Corporation, requests confidentiality as below; 1. Schematics 2. Block Diagram 3. Product Description (Technical Description) 4. Parts List These items contain detailed system and equipment description and related information about the product which Toshiba Corp. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Toshiba Corp. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Sincerely, Name: Takafumi Ito Title: Group Manager Section & Company Common Technology Development Dept., Core Technology Center Toshiba Corporation, Digital Media Network Company

Photo-1: Top View Photo-2: Bottom View

Confidential SDIO Card Type-B for Bluetooth™ Label Rev.1.0 (June 12, 2002) 1 SDIO Card Type-B for Bluetooth™ Label Rev. 1.0 (June 12, 2002) Confidential SDIO Card Type-B for Bluetooth™ Label Rev.1.0 (June 12, 2002) 2 Label

Photo-3: Top Cover Removed Photo-4: PC Board, Component Side Photo-5: PC Board, Foil Side

JAPAN QUALITY ASSURANCE ORGANIZATION 21-25, KINUTA 1-CHOME, SETAGAYA-KU, TOKYO 157-8573 JAPAN PHONE (03) 3416-0111, TELEX 242-2531 JQA J FAX (03) 3416-9691 Issue Date : July 15, 2002 Page 1 of 1 Declaration of compliance Exposure of Humans to RF Fields Requirements Applicant : Toshiba Corporation Type of Equipment : SDIO Card Bluetooth TM Model No. : SD-BT2 FCC ID : CJ6MSDB01 Regulations Applied : CFR 47 FCC 15.247(b)(5) References Documents : CFR 47 FCC 1.1307(b), 1.1310, 2.1093 and OET65 Supplement C RF Exposure Calculations : The following minimum separation distance between the EUT’s antenna and the human body was calculated in accordance with FCC OET65 Appendix B Table(B) “Limit for General Population / Uncontrolled Exposure”. The maximum permissible exposure level is defined with 1mW/cm 2 . The minimum separation distance where the exposure level reaches the permitted level can be calculated as bellow: Where: R = minimum separation distance in cm P = 0.713 mW (Max. conducted output power at antenna terminal) G = 1.31(numeric gain) = 1.17 dBi(Max. antenna Gain) S = 1.0 mW/cm 2 for 2.4 GHz (Max. permissible exposure level) Then minimum separation distance is 0.273 cm. Summary: The EUT complies with the RF exposure requirement of the above regulation. Additional information: The following warning statement is placed in user manual: "This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. End user can not modify this transmitter device. Any unauthorized modification made on the device could avoid the user's authority to operate this device." Masaaki Takahashi Senior Manager JQA EMC Engineering Dept. 2 4/*RGPSπ = SGPR π 4/*=Q C O P Y

JAPAN QUALITY ASSURANCE ORGANIZATION 21-25, KINUTA 1-CHOME, SETAGAYA-KU, TOKYO 157-8573 JAPAN PHONE (03) 3416-0111, TELEX 242-2531 JQA J FAX (03) 3416-9691 JQA APPLICATION NO.: 400-20256 Issue Date : July 15, 2002 Page 1 of 59 EMI TEST REPORT JQA APPLICATION NO. : 400-20256 Model No. : SD-BT2 Type of Equipment : SDIO Card Type-B for Bluetooth TM Regulations Applied : CFR 47 FCC Rules and Regulations Part 15 FCC ID : CJ6MSDB01 Applicant : Toshiba Corporation Address : 1-1 Shibaura 1-chome, Minato-ku, Tokyo 105-8001, Japan Manufacture : Toshiba Corporation Address : 2-5-1, Kasama, Sakae-ku, Yokohama 247-8585, Japan Received date of EUT : July 1, 2002 Final Judgment : Passed Test results in this report are obtained in use of equipment that is traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and Communication Research Laboratory (CRL) of Japan. The test results only respond to the tested sample. This report should not be reproduced except in full, without the written approval of JQA EMC Engineering Dept. Testing Div. C O P Y JQA Application No. :400-20256 FCC ID : CJ6MSDB01 Model No. :SD-BT2 Issue Date :July 15, 2002 Standard :CFR 47 FCC Rules Part 15 Page 2 of 59 JAPAN QUALITY ASSURANCE ORGANIZATION TABLE OF CONTENTS Page 1 Documentation 1.1 Test Regulation 4 1.2 General Information 4 1.3 Test Condition 5 – 11 1.4 EUT Modifications / Deviation from Standard 12 1.5 Test results 13 - 14 1.6 Summary 15 1.7 Test Configuration / Operation of EUT 16 1.8 EUT Arrangement (Drawing) 17 1.9 Preliminary Test and Test-setup (Drawings) 18 – 26 1.10 EUT Arrangement (Photographs) 27 - 29 C O P Y JQA Application No. :400-20256 FCC ID : CJ6MSDB01 Model No. :SD-BT2 Issue Date :July 15, 2002 Standard :CFR 47 FCC Rules Part 15 Page 3 of 59 JAPAN QUALITY ASSURANCE ORGANIZATION 2 Test Data 2.1 Channel Separation 30 2.2 Minimum Hopping Channel 31 – 32 2.3 Occupied Bandwidth 33 – 36 2.4 Dwell Time 37 – 42 2.5 Peak Output Power (Conduction) 43 2.6 Peak Output Power (Radiation) 44 2.7 Peak Power Density (Conduction) 45 - 46 2.8 Peak Power Density (Radiation) N/A 2.9 Spurious Emissions (Conduction) 47 - 49 2.10 Spurious Emissions (Radiation) 50 - 54 2.11 AC Power Line Conducted Emissions 55 - 56 2.12 RF Exposure Compliance 56 2.13 Spurious Emissions for Receiver (Radiation) 57 2.14 AC Power Line Conducted Emissions for Receiver 58 - 59 3 Appendix Test instruments List C O P Y JQA Application No. :400-20256 FCC ID : CJ6MSDB01 Model No. :SD-BT2 Issue Date :July 15, 2002 Standard :CFR 47 FCC Rules Part 15 Page 4 of 59 JAPAN QUALITY ASSURANCE ORGANIZATION 1 DOCUMENTATION 1.1 TEST REGULATION FCC Rules and Regulations Part 15 Subpart B and Subpart C Test procedure : The tests were performed with reference to the FCC Public Notice DA 00-705, released March 30, 2000. The test set-up was made in accordance to the general provisions of ANSIC63.4-1992. 1.2 GENERAL INFORMATION 1.2.1 Test facility : 1) Test Facility located at EMC Engineering Dept. Testing Div. : - No.2 and 3 Anechoic Chambers(3 meters Site). - Shielded Enclosure. Expiration date of FCC test facility filing : May 27, 2005 2) EMC Engineering Dept. Testing Div. is recognized under the National Voluntary Laboratory accreditation Program for satisfactory compliance established in title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200189-0 (Effective through : June 30, 2003) 1.2.2 Description of the Equipment Under Test (EUT) : 1) Type of Equipment : SDIO Card Type-B for Bluetooth TM 2) Product Type : Pre-Production 3) Category : Spread Spectrum Transmitter 4) EUT Authorization : Certification 5) FCC ID : CJ6MSDB01 6) Trade Name : SDIO Card Type-B for Bluetooth TM 7) Model No. : SD-BT2 8) Operating Frequency Range : 2402 MHz - 2480 MHz 9) Highest Frequency Used in the EUT : 2480 MHz 10) RF Output Power : 1 mW(Rated) 11) Serial No. : - 12) Date of Manufacture : - 13) Power Rating : DC 3.1-3.6V (The EUT is inserted in the Host Computer) 14) EUT Grounding : None 1.2.3 Definitions for symbols used in this test report : x - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. C O P Y JQA Application No. :400-20256 FCC ID : CJ6MSDB01 Model No. :SD-BT2 Issue Date :July 15, 2002 Standard :CFR 47 FCC Rules Part 15 Page 5 of 59 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3 TEST CONDITION 1.3.1 The measurement of Channel Separation x - was performed. - was not applicable. Used test instruments : Type Number of test instruments (Refer to Appendix) Test Receiver TR07 Spectrum Analyzer N/A Cable CA11 Attenuator AU18 Antenna N/A 1.3.2 The measurement of Minimum Hopping Channel x - was performed. - was not applicable. Used test instruments : Type Number of test instruments (Refer to Appendix) Test Receiver TR07 Spectrum Analyzer N/A Cable CA11 Attenuator AU18 Antenna N/A 1.3.3 The measurement of Occupied Bandwidth x - was performed. - was not applicable. Used test instruments : Type Number of test instruments (Refer to Appendix) Test Receiver TR07 Spectrum Analyzer N/A Cable CA11 Attenuator AU18 Antenna N/A C O P Y JQA Application No. :400-20256 FCC ID : CJ6MSDB01 Model No. :SD-BT2 Issue Date :July 15, 2002 Standard :CFR 47 FCC Rules Part 15 Page 6 of 59 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3.4 The measurement of Dwell Time x - was performed. - was not applicable. Used test instruments : Type Number of test instruments (Refer to Appendix) Test Receiver TR07 Spectrum Analyzer N/A Cable CA11 Attenuator AU18 Antenna N/A 1.3.5 The measurement of Peak Output Power and Density (Conduction) x - was performed. - was not applicable. Used test instruments : Type Number of test instruments (Refer to Appendix) Test Receiver TR07 Spectrum Analyzer N/A Cable CA11 Attenuator AU18 Antenna N/A Power Meter AU03 Power Sensor AU04 Signal Generator SG03 C O P Y JQA Application No. :400-20256 FCC ID : CJ6MSDB01 Model No.…

Text truncated - open the document above for the full version.

JQA Application No. :400-20256 FCC ID : CJ6MSDB01 Model No. :SD-BT2 Issue Date :July 15, 2002 Standard :CFR 47 FCC Rules Part 15 Page 27 of 59 JAPAN QUALITY ASSURANCE ORGANIZATION 1.10 TEST ARRANGEMENT (PHOTOGRAPHS) PHOTOGRAPHS OF EUT CONFIGURATION FOR RADIATED EMISSIONS MEASUREMENT Photograph present configuration with maximum emission C O P Y JQA Application No. :400-20256 FCC ID : CJ6MSDB01 Model No. :SD-BT2 Issue Date :July 15, 2002 Standard :CFR 47 FCC Rules Part 15 Page 28 of 59 JAPAN QUALITY ASSURANCE ORGANIZATION C O P Y JQA Application No. :400-20256 FCC ID : CJ6MSDB01 Model No. :SD-BT2 Issue Date :July 15, 2002 Standard :CFR 47 FCC Rules Part 15 Page 29 of 59 JAPAN QUALITY ASSURANCE ORGANIZATION PHOTOGRAPHS OF EUT CONFIGURATION FOR AC POWER LINE CONDUCTED EMISSIONS MEASUREMENT Photograph present configuration with maximum emission - Front View – - Side View – C O P Y
