CJ6UPP20XWLNotebook Computer W/ 802.11b WLAN Mini-PCI Module

TOSHIBA 2010 Portable Personal Computer User’s Manual Copyright © 2002 by TOSHIBA Corporation. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the informa- tion contained herein. TOSHIBA 2010 Portable Personal Computer User’s Manual First edition September 2002 Disclaimer This manual has been validated and reviewed for accuracy. The instructions and descriptions it contains are accurate for the TOSHIBA 2010 Portable Personal Computer at the time of this manual’s production. However, succeeding computers and manuals are subject to change without notice. TOSHIBA assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manual. Trademarks Intel and Pentium are registered trademarks and SpeedStep is a trademark of Intel Corporation. Windows and Microsoft are registered trademarks of Microsoft Corporation. Photo CD is a trademark of Eastman Kodak. Other trademarks and registered trademarks not listed above may be used in this manual. FCC information Product Name : Portégé 2010 Model number : PP201 FCC notice "Declaration of Conformity Information" This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installa- tion. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interfer- ence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ❑Reorient or relocate the receiving antenna. ❑Increase the separation between the equipment and receiver. ❑Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ❑Consult the dealer or an experienced radio/TV technician for help. WARNING: Only peripherals complying with the FCC class B limits may be attached to this equipment. Operation with non-compliant peripher- als or peripherals not recommended by TOSHIBA is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer’s external monitor port, USB port and microphone jack. Changes or modifications made to this equipment, not expressly approved by TOSHIBA or parties authorized by TOSHIBA could void the user’s authority to operate the equipment. The modular cable that comes with the computer must be used to connect a modem. Connect the end of the modular cable with the core to the computer. FCC conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Contact Address:TOSHIBA America Information Systems, Inc. 9740 Irvine Boulevard Irvine, California 92618-1697 Telephone:(949) 583-3000 EU Declaration of Conformity TOSHIBA declares, that the product: PP201* conforms to the following Standards: Supplementary Information:“The product complies with the requirements of the Low Voltage Directive 73/23/EEC, the EMC Directive 89/336/EEC and/or the R&TTE Directive 1999/05/EEC.” This product is carrying the CE-Mark in accordance with the related European Directives. Responsible for CE-Marking is TOSHIBA Europe, Hammfelddamm 8, 41460 Neuss, Germany. VCCI Class B Information Modem warning notice Conformity Statement The equipment has been approved to [Commission Decision “CTR21”] for pan- European single terminal connection to the Public Switched Telephone Network (PSTN). However, due to differences between the individual PSTNs provided in different countries/regions the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point. In the event of problems, you should contact your equipment supplier in the first instance. Network Compatibility Statement This product is designed to work with, and is compatible with the following networks. It has been tested to and found to conform with the additional require- ments conditional in EG 201 121. GermanyATAAB AN005,AN006,AN007,AN009,AN010 and DE03,04,05,08,09,12,14,17 GreeceATAAB AN005,AN006 and GR01,02,03,04 PortugalATAAB AN001,005,006,007,011 and P03,04,08,10 SpainATAAB AN005,007,012, and ES01 SwitzerlandATAAB AN002 All other countries/regionsATAAB AN003,004 Specific switch settings or software setup are required for each network, please refer to the relevant sections of the user guide for more details. The hookflash (timed break register recall) function is subject to separate national type approvals. It has not been tested for conformity to national type regulations, and no guarantee of successful operation of that specific function on specific national networks can be given. Japan regulations Region selection If you are using the computer in Japan, technical regulations described in the Telecommunications Business Law require that you select the Japan region mode. It is illegal to use the modem in Japan with any other selection. Redial Up to two redial attempts can be made. If more than two redial attempts are made, the modem will return Black Listed. If you are experiencing problems with the Black Listed code, set the interval between redials at one minute or longer. Japan’s Telecommunications Business Law permits up to two redials on analogue telephones, b…

Text truncated - open the document above for the full version.

1 Information sheet Wireless Interoperability The CISCO Aironet® 350 Series Mini-PCI (MPI350) products are designed to be interoperable with any wireless LAN product that is based on Direct Sequence Spread Spectrum(DSSS) radio technology, and is compliant to: ■ The IEEE 802.11 Standard on Wireless LANs(Revision B), as defined and approved by the Institute of Electrical and Electronics Engineers. ■ The Wireless Fidelity(Wi-Fi) certification as defined by the Wi-Fi Alliance. Wireless LAN and your Health Wireless LAN products, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by Wireless LAN devices however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones. Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Wireless LAN is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature. In some situations or environments, the use of Wireless LAN may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include: ■ Using the Wireless LAN equipment on board of airplanes, or ■ In any other environment where the risk of interference to other devices or services is perceived or identified as harmful. If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use the Wireless LAN device prior to turning on the equipment. Regulatory Information The CISCO Aironet® 350 Series Mini-PCI (MPI350) must be installed and used in strict accordance with the manufacturer’s instructions as described in the user documentation that comes with the product. This device complies with the following radio frequency and safety standards. Canada – Industry Canada (IC) This device complies with RSS 210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference , and (2) this device must accept any interference, including interference that may cause undesired operation of this device.” L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif. The term "IC" before the equipment certification number only signifies that the Industry Canada technical specifications were met. Approval Number : 248H-DPP20XW Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC with essential test suites as per standards: 2 ■ EN 60950 Safety of Information Technology equipment ■ EN 300 328-1 and-2 Technical requirements for radio equipment ■ EN 300 489-1 and-17 General EMC requirements for radio equipment. For outdoor usage only channel 10 (2457 MHz) and 11 (2462 MHz) is allowed. For private usage outside buildings across public grounds over less than 300m no special registration with IBPT/BIPT is required. Registration to IBPT/BIPT is required for private usage outside buildings across public grounds over more than 300m. An IBPT/BIPT license is required for public usage outside building. For registration and license please contact IBPT/BIPT. Gebruik buiten gebouw alleen op kanalen 10 (2457 MHz) en 11 (2462 MHz). Voor privé-gebruik buiten gebouw over publieke groud over afstand kleiner dan 300m geen registratie bij BIPT/IBPT nodig; voor gebruik over afstand groter dan 300m is wel registratie bij BIPT/IBPT nodig. Voor publiek gebruik buiten gebouwen is licentie van BIPT/IBPT verplicht. Voor registratie of licentie kunt u contact opnemen met BIPT. België/ Belgique: L’utilisation en extérieur est autorisé sur le canal 10 (2457 MHz) et 11 (2462 MHz). Dans le cas d’une utilisation privée, à l’extérieur d’un bâtiment, au-dessus d’un espace public, aucun enregistrement n’est nécessaire pour une distance de moins de 300m. Pour une distance supérieure à 300m un enregistrement auprès de I’IBPT est requise. Pour une utilisation publique à I’extérieur de bâtiments, une licence de I’IBPT est requise. Pour les enregistrements et licences, veuillez contacter I’IBPT. License required for outdoor installations. Check with reseller for procedure to follow Deutschland: Anmeldung im Outdoor-Bereich notwendig, aber nicht genehmigungspflichtig.Bitte mit Händler die Vorgehensweise abstimmen. Restricted frequency band: only channels 10 and 11 (2457 MHz and 2462 MHz respectively) may be used in France. License required for every installation, indoor and outdoor installations. Please contact ART for procedure to follow. France: Bande de fréquence restreinte : seuls les canaux 10 à 11 (2457 et 2462 MHz respectivement) doivent être utilisés en France. Toute utilisation, qu’elle soit intérieure ou extérieure, est soumise à autorisation. Vous pouvez contacter I’Autorité de Régulation des Télécommuniations (http://www.art-telecom.fr) pour la procédure à suivre. License required for indoor use. Use with outdoor installations not allowed Italia: E’necessaria la concessione ministeriale anche per l’uso interno. Verificare con i rivenditori la procedura da seguire. L’uso per installazione in esterni non e’ permessa. License required for outdoor installations. Check with reseller for procedure to follow Nederland Licentie verplicht voor gebruik met buitenantennes. Neem contact op met verkoper voor juiste procedure USA-Federal Communications Commission(FCC) This device complies with Part 15 of FCC Rules. Operation of the devic…

Text truncated - open the document above for the full version.

DIGITAL MEDIA NETWORK COMPANY OME COMPLEX 2-9, SUEHIRO-CHO, OME, TOKYO 198-8710, JAPAN PHONE: +81(428) 34-1872 FAX: +81(428) 33-2922 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality In reference to the application under FCC ID: CJ6UPP20XWL, and pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Document titled “Schematics”, 117 pages; Document titled “Theory of operation”, 7 page; Document titled “Block Diagram”, 1 page. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Hideo Abe Digital Media Network Company

EXHIBIT C - EUT PHOTOGRAPHS Top View Bottom View

PROPOSED FCC ID LABEL AND LOCATION TOSHIBA CORPORATION DIGITAL MEDIA NETWORK COMPANY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: CJ6UPP20XWL FCC ID LABEL LOCATION

Document No.: OFA-H3630 Page 38 of 45 Toshiba Corporation, Ome Operations EUT [Front View] [Rear View] System Board [Front] [Back] Sound Board [Front] [Back] Document No.: OFA-H3630 Page 39 of 45 Toshiba Corporation, Ome Operations Sound I/F flexible board [Front] [Back] Mini-PCI IF/ Board [Front] [Back] Touch pad module [Front] [Back] Document No.: OFA-H3630 Page 40 of 45 Toshiba Corporation, Ome Operations In Touch Button [Front] [Back] LED flexible board [Front] [Back] PC card I/F flexible board [Front] [Back] Document No.: OFA-H3630 Page 41 of 45 Toshiba Corporation, Ome Operations 12.1 inch Color LCD Toshiba Corp., Type LTM12C328 [Front] [Back] FL Inverter Nagano Japan Radio, Type NJD-7099 [Front] [Back] LCD cable RTC Battery & Speaker Document No.: OFA-H3630 Page 42 of 45 Toshiba Corporation, Ome Operations CPU Fan [Front] [Back] 1.8 inch HDD (20GB) Toshiba Corp., Type HDD1364 [Front] [Back] 1.8 inch HDD (30 GB) Toshiba Corp., Type HDD1384 [Front] [Back] Document No.: OFA-H3630 Page 43 of 45 Toshiba Corporation, Ome Operations 1.8 inch HDD (40 GB) Toshiba Corp., Type HDD1524 [Front] [Back] HDD I/F flexible board [Front] [Back] Keyboard unit [Front] [Back]

1. Illustration

in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for Laptop With 802.11b WLAN Mini PCI Module Model: PP20XX-XXXXX FCC ID: CJ6UPP20XWL March 28, 2003 REPORT NO: 03U1875-2 Prepared for Toshiba Corporation Digital Media Network Company 2-9, Suehiro-cho, Ome Tokyo, 198-8710, Japan Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 REPORT NO: 03U1875-2 DATE: March 28, 2003 FCC ID: CJ6UPP20XWL COMPLIANCE CERTIFICATION SERVICES Page 2 of 2 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Dates of Tests: March 28, 2003 Report No: 03T1875-2 APPLICANT: Toshiba Corporation Digital Media Network Company 2-9, Suehiro-cho, Ome Tokyo, 198-8710, Japan MODEL: PP20XX_XXXXX FCC ID: CJ6UPP20XWL DEVICE CATEGORY: MOBILE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: Direct Sequence Spread Spectrum (DSSS) Operating mode: Maximum continuous output Tx Frequency: 2412 ~ 2462 MHz Max. O/P Power: 19.82 dBm (Conducted) Max. SAR (1g): 1.04 mW/g Application type: Certification FCC Rule part(s): § 15.247 This wireless mobile device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager REPORT NO: 03U1875-2 DATE: March 28, 2003 FCC ID: CJ6UPP20XWL COMPLIANCE CERTIFICATION SERVICES Page 3 of 3 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. EUT DESCRIPTION........................................................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC.................5 3. DOSIMETRIC ASSESSMENT SYSTEM........................................................................5 3.1. MEASUREMENT SYSTEM DIAGRAM.......................................................................................................6 3.2. SYSTEM COMPONENTS..............................................................................................................................7 4. EVALUATION PROCEDURE..........................................................................................9 5. MEASUREMENT UNCERTAINTY................................................................................12 6. EXPOSURE LIMIT.........................................................................................................13 7. MEASUREMENT RESULTS.........................................................................................14 7.1. SYSTEM VALIDATION.................................................................................................................................14 7.2. TEST LIQUID CONFIRMATION.................................................................................................................15 7.3. EUT TUNE-UP PROCEDURES..................................................................................................................15 7.4. EUT SETUP PHOTOS.................................................................................................................................16 7.5. SAR MEASUREMENT RESULTS..............................................................................................................18 8. EUT PHOTOS................................................................................................................19 9. EQUIPMENTS LIST & CALIBRATION STATUS.........................................................21 10. REFERENCES...............................................................................................................22 11. ATTACHMENTS............................................................................................................23 REPORT NO: 03U1875-2 DATE: March 28, 2003 FCC ID: CJ6UPP20XWL COMPLIANCE CERTIFICATION SERVICES Page 4 of 4 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. EUT DESCRIPTION APPLICANT: Toshiba Corporation Digital Media Network Company 2-9, Suehiro-cho, Ome Tokyo, 198-8710, Japan MODEL: PP20XX-XXXXX FCC ID: CJ6UPP20XWL DEVICE CATEGORY: MOBILE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: Direct Sequence Spread Spectrum (DSSS) Operating mode: Maximum continuous output Tx Frequency: 2412 ~ 2462 MHz Max. O/P Power: 19.82 dBm (Conducted) Max. SAR (1g): 1.04 mW/g Application type: Certification FCC Rule part(s): § 15.247 Wireless Module: Mini-PCI Type IIIA Wireless LAN Card - Manufactured by Ambit, model PA3231U-1MPC. Antenna (s): A0 / A1 - Manufactured by Hitachi, type Stick Antenna, model HTL007, gain = -3.6 dBi 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable d…

Text truncated - open the document above for the full version.

Date/Time: 03/28/03 09:50:40 Test Laboratory: Compliance Certification Services File Name: D2450V2 SN 706_13.1 mW.da4 DUT: Dipole Type & Serial Number: D2450V2 SN 706 Program: System Validation (ET3DV6 SN 1577); I/P Power 250 mW, Air temp. 25 deg C, liquid temp. 23 deg C Communication System: CW - 2450 MHz; Frequency: 2450 MHz; Duty Cycle: 1:1 Medium: Head 2450 MHz ( σ = 1.8673 mho/m, ε = 39.33, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(5.1, 5.1, 5.1); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 1 - TP:1185 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 94 V/m Peak SAR = 28.2 mW/g SAR(1 g) = 13.1 mW/g; SAR(10 g) = 5.83 mW/g Power Drift = 0.03 dB Area Scan (9x9x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -23 -20.7 -18.4 -16.1 -13.8 -11.5 -9.2 -6.9 -4.6 -2.3 0

Date/Time: 03/28/03 11:40:44 Test Laboratory: Compliance Certification Services File Name: 1L-CH_0.743 mW.da4 EUT Setup Configuration 1 - Antenna A0 SAR in dB -25.7 -23.1 -20.5 -18 -15.4 -12.8 -10.3 -7.7 -5.13 -2.57 0 Date/Time: 03/28/03 11:40:44 Test Laboratory: Compliance Certification Services File Name: 1L-CH_0.743 mW.da4 DUT: Toshiba Type & Serial Number: PP20**_**** Program: EUT Setup Configuration 1 - Antenna A0; Air temp. 25 deg C & Liquid temp. 23.4 deg C Communication System: DSSS; Frequency: 2412 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.9545 mho/m, ε = 50.44, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 1.88 V/m Peak SAR = 2.04 mW/g SAR(1 g) = 0.743 mW/g; SAR(10 g) = 0.27 mW/g Power Drift = 0.09 dB Area Scan (15x25x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -25.7 -23.1 -20.5 -18 -15.4 -12.8 -10.3 -7.7 -5.13 -2.57 0 Date/Time: 03/28/03 12:43:00 Test Laboratory: Compliance Certification Services File Name: 2M-CH_0.846 mW.da4 DUT: Toshiba Type & Serial Number: PP20**_**** Program: EUT Setup Configuration 1 - Antenna A0; Air temp. 25 deg C & Liquid temp. 23.1 deg C Communication System: DSSS; Frequency: 2437 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.9545 mho/m, ε = 50.44, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 2.17 V/m Peak SAR = 2.4 mW/g SAR(1 g) = 0.846 mW/g; SAR(10 g) = 0.3 mW/g Power Drift = 0.07 dB Area Scan (15x25x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -28.1 -25.3 -22.4 -19.6 -16.8 -14 -11.2 -8.42 -5.61 -2.81 0 Date/Time: 03/28/03 13:35:00 Test Laboratory: Compliance Certification Services File Name: 3H-CH_1.04 mW.da4 DUT: Toshiba Type & Serial Number: PP20**_**** Program: EUT Setup Configuration 1 - Antenna A0; Air temp. 25 deg C & Liquid temp. 23.1 deg C Communication System: DSSS; Frequency: 2462 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.9545 mho/m, ε = 50.44, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 3.23 V/m Peak SAR = 3.08 mW/g SAR(1 g) = 1.04 mW/g; SAR(10 g) = 0.364 mW/g Power Drift = 0.07 dB Area Scan (15x25x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -24.2 -21.8 -19.3 -16.9 -14.5 -12.1 -9.67 -7.25 -4.83 -2.42 0 Date/Time: 03/28/03 16:25:08 Test Laboratory: Compliance Certification Services File Name: 1L-CH_0.0705 mW.da4 EUT Setup Configuration 2 - Antenna A1 SAR in dB -21.9 -19.7 -17.5 -15.4 -13.2 -11 -8.77 -6.58 -4.39 -2.19 0 Date/Time: 03/28/03 16:25:08 Test Laboratory: Compliance Certification Services File Name: 1L-CH_0.0705 mW.da4 DUT: Toshiba Type & Serial Number: PP20**_**** Program: EUT Setup Configuration 2 - Antenna A1; Air temp. 25 deg C & Liquid temp. 23.3 deg C Communication System: DSSS; Frequency: 2412 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.9545 mho/m, ε = 50.44, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 2.61 V/m Peak SAR = 0.175 mW/g SAR(1 g) = 0.0705 mW/g; SAR(10 g) = 0.0288 mW/g Power Drift = 0.09 dB Area Scan (15x25x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -21.9 -19.7 -17.5 -15.4 -13.2 -11 -8.77 -6.58 -4.39 -2.19 0 Date/Time: 03/28/03 15:27:50 Test Laboratory: Compliance Certification Services File Name: 2M-CH_0.0972 mW.da4 DUT: Toshiba Type & Serial Number: PP20**_**** Program: EUT Setup Configuration 2 - Antenna A1; Air temp. 25 deg C & Liquid temp. 23.3 deg C Communication System: DSSS; Frequency: 2437 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.9545 mho/m, ε = 50.44, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm Reference Value = 3.14 V/m Peak SAR = 0.262 mW/g SAR(1 g) = 0.0972 mW/g; SAR(10 g) = 0.0393 mW/g Power Drift = -0.12 dB Area Scan (15x25x1): Measurement grid: dx=10mm, dy=10mm SAR in dB -20 -18 -16 -14 -12 -10 -8.01 -6.01 -4 -2 0 Date/Time: 03/28/03 14:31:28 Test Laboratory: Compliance Certification Services File Name: 3H-CH_0.156 mW.da4 DUT: Toshiba Type & Serial Number: PP20**_**** Program: EUT Setup Configuration 2 - Antenna A1; Air temp. 25 deg C & Liquid temp. 23.3 deg C Communication System: DSSS; Frequency: 2462 MHz; Duty Cycle: 1:1 Medium: Muscle 2450 MHz ( σ = 1.9545 mho/m, ε = 50.44, ρ = 1000 kg/m3) Phantom section: FlatSection DASY4 Configuration: - Probe: ET3DV6 - SN1577; ConvF(4.7, 4.7, 4.7); Calibrated: 2/7/2003 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn427; Calibrated: 2/4/2003 - Phantom: SAM 2 - TP:1050 - Software: DASY4, V4.0 Build 51 Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=…
