CJ6UPP350WLNotebook PC with 802.11/b WLAN. Port�g� 3500

TOSHIBA 3500 Portable Personal Computer User’s Manual Copyright © 2002 by TOSHIBA Corporation. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the informa- tion contained herein. TOSHIBA 3500 Portable Personal Computer User’s Manual First edition November 2002 Disclaimer This manual has been validated and reviewed for accuracy. The instructions and descriptions it contains are accurate for the TOSHIBA 3500 Portable Personal Computer at the time of this manual’s production. However, succeeding computers and manuals are subject to change without notice. TOSHIBA assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manual. Trademarks Intel and Pentium are registered trademarks and SpeedStep is a trademark of Intel Corporation. Windows and Microsoft are registered trademarks of Microsoft Corporation. Photo CD is a trademark of Eastman Kodak. Other trademarks and registered trademarks not listed above may be used in this manual. FCC information Product Name : Portégé 3500 Model number : PP350 FCC notice "Declaration of Conformity Information" This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installa- tion. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interfer- ence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ❑Reorient or relocate the receiving antenna. ❑Increase the separation between the equipment and receiver. ❑Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ❑Consult the dealer or an experienced radio/TV technician for help. WARNING: Only peripherals complying with the FCC class B limits may be attached to this equipment. Operation with non-compliant peripher- als or peripherals not recommended by TOSHIBA is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer’s external monitor port, USB port and microphone jack. Changes or modifications made to this equipment, not expressly approved by TOSHIBA or parties authorized by TOSHIBA could void the user’s authority to operate the equipment. The modular cable that comes with the computer must be used to connect a modem. Connect the end of the modular cable with the core to the computer. FCC conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Contact Address:TOSHIBA America Information Systems, Inc. 9740 Irvine Boulevard Irvine, California 92618-1697 Telephone:(949) 583-3000 EU Declaration of Conformity TOSHIBA declares, that the product: PP350* conforms to the following Standards: Supplementary Information:“The product complies with the requirements of the Low Voltage Directive 73/23/EEC, the EMC Directive 89/336/EEC and/or the R&TTE Directive 1999/05/EEC.” This product is carrying the CE-Mark in accordance with the related European Directives. Responsible for CE-Marking is TOSHIBA Europe, Hammfelddamm 8, 41460 Neuss, Germany. VCCI Class B Information Modem warning notice Conformity Statement The equipment has been approved to [Commission Decision “CTR21”] for pan- European single terminal connection to the Public Switched Telephone Network (PSTN). However, due to differences between the individual PSTNs provided in different countries/regions the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point. In the event of problems, you should contact your equipment supplier in the first instance. Network Compatibility Statement This product is designed to work with, and is compatible with the following networks. It has been tested to and found to conform with the additional require- ments conditional in EG 201 121. GermanyATAAB AN005,AN006,AN007,AN009,AN010 and DE03,04,05,08,09,12,14,17 GreeceATAAB AN005,AN006 and GR01,02,03,04 PortugalATAAB AN001,005,006,007,011 and P03,04,08,10 SpainATAAB AN005,007,012, and ES01 SwitzerlandATAAB AN002 All other countries/regionsATAAB AN003,004 Specific switch settings or software setup are required for each network, please refer to the relevant sections of the user guide for more details. The hookflash (timed break register recall) function is subject to separate national type approvals. It has not been tested for conformity to national type regulations, and no guarantee of successful operation of that specific function on specific national networks can be given. Japan regulations Region selection If you are using the computer in Japan, technical regulations described in the Telecommunications Business Law require that you select the Japan region mode. It is illegal to use the modem in Japan with any other selection. Redial Up to two redial attempts can be made. If more than two redial attempts are made, the modem will return Black Listed. If you are experiencing problems with the Black Listed code, set the interval between redials at one minute or longer. Japan’s Telecommunications Business Law permits up to two redials on analogue telephones, bu…

Text truncated - open the document above for the full version.

1 Information sheet Wireless Interoperability The TOSHIBA Wireless LAN Mini PCI Card products are designed to be interoperable with any wireless LAN product that is based on Direct Sequence Spread Spectrum(DSSS) radio technology, and is compliant to: ■ The IEEE 802.11 Standard on Wireless LANs(Revision B), as defined and approved by the Institute of Electrical and Electronics Engineers. ■ The Wireless Fidelity(WiFi) certification as defined by the WECA Wireless Ethernet Compatibility Alliance. CAUTION Bluetooth™ and WirelessLAN devices operate within the same radio frequency range and may interfere with one another. If you use Bluetooth™ and WirelessLAN devices simultaneously, you may ccasionally experience a less than optimal network performance or even lose your network connection. If you should experience any such problem, immediately turn off either one of your Bluetooth™ or WirelessLAN. Please contact Toshiba PC product support on web site http://www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or http://www.pc.support.global.toshiba.com in the United States for more information. Wireless LAN and your Health Wireless LAN products, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by Wireless LAN devices however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones. Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Wireless LAN is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature. In some situations or environments, the use of Wireless LAN may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include: ■ Using the Wireless LAN equipment on board of airplanes, or ■ In any other environment where the risk of interference to other devices or services is perceived or identified as harmful. If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use the Wireless LAN device prior to turning on the equipment. 2 Regulatory Information The TOSHIBA Wireless LAN Mini PCI Card must be installed and used in strict accordance with the manufacturer’s instructions as described in the user documentation that comes with the product. This device complies with the following radio frequency and safety standards. Canada – Industry Canada (IC) This device complies with RSS 210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference , and (2) this device must accept any interference, including interference that may cause undesired operation of this device.” L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif. The term "IC" before the equipment certification number only signifies that the Industry Canada technical specifications were met. IC: 248H-DPA350S Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC with essential test suites as per standards: ■ EN 60950 Safety of Information Technology equipment ■ ETS 300 328 Technical requirements for radio equipment ■ ETS 300 826 General EMC requirements for radio equipment. For outdoor usage only channel 10 (2457 MHz) and 11 (2462 MHz) is allowed. For private usage outside buildings across public grounds over less than 300m no special registration with IBPT/BIPT is required. Registration to IBPT/BIPT is required for private usage outside buildings across public grounds over more than 300m. An IBPT/BIPT license is required for public usage outside building. For registration and license please contact IBPT/BIPT. Gebruik buiten gebouw alleen op kanalen 10 (2457 MHz) en 11 (2462 MHz). Voor privé-gebruik buiten gebouw over publieke groud over afstand kleiner dan 300m geen registratie bij BIPT/IBPT nodig; voor gebruik over afstand groter dan 300m is wel registratie bij BIPT/IBPT nodig. Voor publiek gebruik buiten gebouwen is licentie van BIPT/IBPT verplicht. Voor registratie of licentie kunt u contact opnemen met BIPT. België/ Belgique: L’utilisation en extérieur est autorisé sur le canal 10 (2457 MHz) et 11 (2462 MHz). Dans le cas d’une utilisation privée, à l’extérieur d’un bâtiment, au-dessus d’un espace public, aucun enregistrement n’est nécessaire pour une distance de moins de 300m. Pour une distance supérieure à 300m un enregistrement auprès de I’IBPT est requise. Pour une utilisation publique à I’extérieur de bâtiments, une licence de I’IBPT est requise. Pour les enregistrements et licences, veuillez contacter I’IBPT. License required for outdoor installations. Check with reseller for procedure to follow Deutschland: Anmeldung im Outdoor-Bereich notwendig, aber nicht genehmigungspflichtig.Bitte mit Händler die Vorgehensweise abstimmen. Restricted frequency band: only channels 10 and 11 (2457 MHz and 2462 MHz respectively) may be used in France. License required for every installation, indoor and outdoor installations. Please contact ART for procedure to follow. France: Bande de fréquence restreinte : seuls les canaux 10 à 11 (2457 et 2462 MHz respectivement) doivent être utilisés en France. Toute utilisation, qu’elle soit intérieure ou extérieure, est soumise à autorisation. Vous pouvez contacter I’Autorité de Régulation des Télécommuniations (http://www.art-telecom.fr) …

Text truncated - open the document above for the full version.

From: Raj, Hans (Hans) [[email protected]] Sent: Friday, September 27, 2002 1:24 AM To: Nakamura, Norimasa; Raj, Hans (Hans); Hoekstra, Frans (Frans); Suzuki, Atsuhiko (Steve); Takahashi, Keiichi (Keiichi); Furuno, Yoshinori (Yoshi) Cc: TAIS Peter Leone Subject: RE: [URGENT!!] Special Tuned Agere Ruby Dear Norimasa-san, Pls find the response from our Regulatory Team; ---------------------------------------------------------------------------- ------------------------------------- on each radio grant FCC mentions the Output Power in Watts of the product. But one can measure the power in different ways, e.g.: - average power, - peak power. The value FCC uses on the grant is the peak power and that value is higher than the (average) value that relates to the value we use in specifications (= average power!). So Cetecom measured 0.085 mW (19 dBm) peak power and the measured average power on the connector should be around 15 dBm. Thus we do not have to provide cards with changed output power! The test house Toshiba uses can check the peak power value conform FCC requirements when they perform the SAR tests. ---------------------------------------------------------------------------- -------------------------------------- I hope this helps so pls contact me if you have any further questions. Kind Regards ______________________________ Hans Raj Program Manager OEM agere systems Office: 30 607 6510 Cell : 6 5577 3218 Fax : 30 609 7556 eMail : [email protected] _____________________________ -----Original Message----- From: Nakamura, Norimasa [mailto:[email protected]] Sent: Friday, September 27, 2002 4:17 AM To: Agere Raj Hans; Agere Frans Hoekstra (orinoco); Agere Steve Suzuki (orinoco); Agere Takahashi; Agere Yoshi Furuno (orinoco) Cc: Nakamura Norimasa; TAIS Peter Leone Subject: [URGENT!!] Special Tuned Agere Ruby Dear Hans san, Maybe, this is first mail for you. I am Nori Nakamura. I am in charge of HW of Wireless LAN for Toshiba Note Book PC at Ome and I am working with Kasuga san. I have ask favor for you. We have a plan to launch new PC which has Ruby Mini PCI and Bluetooth on end of Oct. '02. We are working w/ the test lab. of CCS (Compliance Certification Service) in US to obtain FCC now. Since the antenna of new PC is located near human body, it is mandatory to measure SAR as system and we intend to do C2PC (Class 2 Permissive Change) against already approved certification of Ruby (Please see attached file). As you may know, we have obtained FCC grant by using Ruby w/ CETECOM Germany on the beginning of this year. However, the output power is described as '0.085w' (about 19dBm) on FCC Grant, even if the specification of Ruby out put power is 15dBm 2dB. What we are facing the problem is Since we can not reach the 19dBm output power by using current Ruby (actual output power is 16.2dBm), we concern FCC will claim us that we do not measure SAR on max. output power condition (19dBm). Therefore, would you please provide us with the 2 sets of Ruby which has 0.085W output power for SAR measurement purpose only? If it is possible, would you please send them to the address below ? Mr. Mike C. I. Kuo Vice President Compliance Certification Service (CCS) 561F Monterey Road, Morgan Hill, CA 95037-9001 Email : [email protected] Tel : (408) 463-0885 ext. 105 Fax: (408) 463-0888 If you have any question, please let me know immediately. Best Regards, Nori Nakamura Group 5 PC Design Dept. 1 Digital Media Development Center TOSHIBA CORPORATION Tel : 428 34 2397 /Fax : 428 30 7432

in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for Touch Screen Platform With Bluetooth + IEEE 802.11b Co-Working MODEL: NIMBUS FCC ID: CJ6UPP350WL SEPTEMBER 27, 2002 REPORT NO: 02U1463-2 Prepared for Toshiba Corporation Digital Media Network Company 2-9, Suehiro-cho, Ome Tokyo, 198-8710, Japan Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 REPORT NO: 02U1463-2 DATE: September 26, 2002 FCC ID: CJ6UPP350SY COMPLIANCE CERTIFICATION SERVICES Page: 2 of 27 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Date of Tests: September 26, 2002 Report No: 02U1463-2 APPLICANT: Toshiba Corporation Digital Media Network Company 2-9, Suehiro-cho, Ome Tokyo, 198-8710, Japan MODEL: NIMBUS FCC ID: CJ6PUPP350WL DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Operating mode: Maximum continuous output Tx Frequency: Wireless LAN - Blutooth - 2412 ~ 2462 MHz 2402 ~ 2480 MHz Max. O/P Power (Conducted): Wireless LAN - Blutooth - 15.93 dBm (2462 MHz) 1.40 dBm (2480 MHz) Max. SAR (1g): 0.396 mW/g (2412 MHz) Application Type: Certification FCC Rule Part(s): §15.247 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager REPORT NO: 02U1463-2 DATE: September 26, 2002 FCC ID: CJ6UPP350WL COMPLIANCE CERTIFICATION SERVICES Page: 3 of 27 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. EUT DESCRIPTION............................................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC ...............5 3. DOSIMETRIC ASSESSMENT SYSTEM...............................................................5 3.1. MEASUREMENT SYSTEM DIAGRAM..............................................................6 3.2. SYSTEM COMPONENTS.................................................................................7 4. EVALUATION PROCEDURE..............................................................................9 5. MEASUREMENT UNCERTAINTY......................................................................12 6. EXPOSURE LIMIT ............................................................................................13 7. MEASUREMENT RESULTS..............................................................................14 7.1. SYSTEM VALIDATION.....................................................................................14 7.2. TEST LIQUID CONFIRMATION.......................................................................15 7.3. EUT TUNE-UP PROCEDURE ..........................................................................16 7.4. EUT SETUP PHOTOS.....................................................................................17 7.5. SAR MEASUREMENT RESULT.......................................................................19 7.5.1. Dualband Film Antenna.......................................................................19 7.5.2. Wideband Film Antenna......................................................................20 8. EUT PHOTOS.................................................................................................. 21 9. EQUIPMENTS LIST & CALIBRATION STATUS ..................................................25 10. REFERENCES................................................................................................. 26 11. ATTACHMENT................................................................................................. 27 REPORT NO: 02U1463-2 DATE: September 26, 2002 FCC ID: CJ6UPP350WL COMPLIANCE CERTIFICATION SERVICES Page: 4 of 27 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. EUT DESCRIPTION APPLICANT: Toshiba Corporation Digital Media Network Company 2-9, Suehiro-cho, Ome Tokyo, 198-8710, Japan MODEL: NIMBUS FCC ID: CJ6PUPP350WL DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Operating mode: Maximum continuous output Tx Frequency: Wireless LAN - Blutooth - 2412 ~ 2462 MHz 2402 ~ 2480 MHz Max. O/P Power (Conducted): Wireless LAN - Blutooth - 15.93 dBm (2462 MHz) 1.40 dBm (2480 MHz) Max. SAR (1g): 0.396 mW/g (2412 MHz) Application Type: Certification FCC Rule Part(s): §15.247 Antenna Type: Thin film omni antenna 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET Docket 93-62. REPORT NO: 02U1463-2 DATE: September 26, 2002 FCC ID: CJ6UPP350WL COMPLIANCE CERTIFICATION SERVICES Page: 5 of 27 Thi…

Text truncated - open the document above for the full version.

Toshiba, NIMBUS (Dualband Film Antenna); Frequency: 2412 MHz Frequency: 2450 MHz; Crest factor: 1.0 Medium: Muscle 2450 MHz: σ = 2.06 mho/m ε r = 51.1 ρ = 1.00 g/cm 3 SAM-1 Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1578; ConvF(4.10,4.10,4.10); SAR:Cube 5x5x7: Peak: 0.299 mW/g, SAR (1g): 0.153 mW/g, SAR (10g): 0.0759 mW/g, (Worst-case extrapolation) Penetration depth: 7.6 (7.3, 8.2) [mm]; Powerdrift: -0.06 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 0.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 21.6 SAR Tot [mW/g] 1.61E-2 4.83E-2 8.05E-2 1.13E-1 1.45E-1 09/26/02 COMPLIANCE CERTIFICATION SERVICES Toshiba, NIMBUS (Dualband Film Antenna); Frequency: 2437 MHz Frequency: 2450 MHz; Crest factor: 1.0 Medium: Muscle 2450 MHz: σ = 2.06 mho/m ε r = 51.1 ρ = 1.00 g/cm 3 SAM-1 Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1578; ConvF(4.10,4.10,4.10); SAR:Cube 5x5x7: Peak: 0.352 mW/g, SAR (1g): 0.177 mW/g, SAR (10g): 0.0873 mW/g, (Worst-case extrapolation) Penetration depth: 7.5 (7.1, 8.5) [mm]; Powerdrift: -0.01 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 0.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 21.4 SAR Tot [mW/g] 1.78E-2 5.34E-2 8.90E-2 1.25E-1 1.60E-1 09/26/02 COMPLIANCE CERTIFICATION SERVICES Toshiba, NIMBUS (Dualband Film Antenna); Frequency: 2437 MHz Frequency: 2450 MHz; Crest factor: 1.0 Medium: Muscle 2450 MHz: σ = 2.06 mho/m ε r = 51.1 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(4.10,4.10,4.10); SAR:: , , () Penetration depth: 7.3 (6.9, 8.4) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 21.4 09/26/02 COMPLIANCE CERTIFICATION SERVICES 0.0 0.1 0.2 0.3 0.4 0102030405060708090100110 SAR tot [mW/g] [mm] Toshiba, NIMBUS (Dualband Film Antenna); Frequency: 2462 MHz Frequency: 2450 MHz; Crest factor: 1.0 Medium: Muscle 2450 MHz: σ = 2.06 mho/m ε r = 51.1 ρ = 1.00 g/cm 3 SAM-1 Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1578; ConvF(4.10,4.10,4.10); SAR:Cube 5x5x7: Peak: 0.250 mW/g, SAR (1g): 0.125 mW/g, SAR (10g): 0.0620 mW/g, (Worst-case extrapolation) Penetration depth: 7.4 (6.9, 8.4) [mm]; Powerdrift: -0.06 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 0.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 21.3 SAR Tot [mW/g] 1.32E-2 3.96E-2 6.60E-2 9.24E-2 1.19E-1 09/26/02 COMPLIANCE CERTIFICATION SERVICES Toshiba, NIMBUS (Daulband Film Antenna); Frequency: 2412 MHz Frequency: 2450 MHz; Crest factor: 1.0 Medium: Muscle 2450 MHz: σ = 2.06 mho/m ε r = 51.1 ρ = 1.00 g/cm 3 SAM-1 Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1578; ConvF(4.10,4.10,4.10); SAR:Cube 5x5x7: Peak: 0.0250 mW/g, SAR (1g): 0.0128 mW/g, SAR (10g): 0.0076 mW/g, (Worst-case extrapolation) Penetration depth: 8.5 (6.5, 13.8) [mm]; Powerdrift: 0.10 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 0.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 21.2 SAR Tot [mW/g] 1.30E-3 3.90E-3 6.50E-3 9.10E-3 1.17E-2 09/26/02 COMPLIANCE CERTIFICATION SERVICES Toshiba, NIMBUS (Dualband Film Antenna); Frequency: 2437 MHz Frequency: 2450 MHz; Crest factor: 1.0 Medium: Muscle 2450 MHz: σ = 2.06 mho/m ε r = 51.1 ρ = 1.00 g/cm 3 SAM-1 Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1578; ConvF(4.10,4.10,4.10); SAR:Cube 5x5x7: Peak: 0.0310 mW/g, SAR (1g): 0.0165 mW/g, SAR (10g): 0.0090 mW/g, (Worst-case extrapolation) Penetration depth: 9.7 (8.7, 11.0) [mm]; Powerdrift: -0.08 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 0.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 21.2 SAR Tot [mW/g] 1.70E-3 5.10E-3 8.50E-3 1.19E-2 1.53E-2 09/26/02 COMPLIANCE CERTIFICATION SERVICES Toshiba, NIMBUS (Dualband Film Antenna); Frequency: 2437 MHz Frequency: 2450 MHz; Crest factor: 1.0 Medium: Muscle 2450 MHz: σ = 2.06 mho/m ε r = 51.1 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(4.10,4.10,4.10); SAR:: , , () Penetration depth: 9.5 (7.4, 13.3) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 21.2 09/26/02 COMPLIANCE CERTIFICATION SERVICES 0.000 0.010 0.020 0.030 0102030405060708090100110 SAR tot [mW/g] [mm] Toshiba, NIMBUS (Dualband Film Antenna); Frequency: 2462 MHz Frequency: 2450 MHz; Crest factor: 1.0 Medium: Muscle 2450 MHz: σ = 2.06 mho/m ε r = 51.1 ρ = 1.00 g/cm 3 SAM-1 Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1578; ConvF(4.10,4.10,4.10); SAR:Cube 5x5x7: Peak: 0.0245 mW/g, SAR (1g): 0.0123 mW/g, SAR (10g): 0.0069 mW/g, (Worst-case extrapolation) Penetration depth: 8.3 (6.9, 12.1) [mm]; Powerdrift: 0.03 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 0.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 21.3 SAR Tot [mW/g] 1.30E-3 3.90E-3 6.50E-3 9.10E-3 1.17E-2 09/26/02 COMPLIANCE CERTIFICATION SERVICES Toshiba, NIMBUS (Dualband Film Antenna); Frequency: 2412 MHz Frequency: 2450 MHz; Crest factor: 1.0 Medium: Muscle 2450 MHz: σ = 2.06 mho/m ε r = 51.1 ρ = 1.00 g/cm 3 SAM-1 Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1578; ConvF(4.10,4.10,4.10); SAR:Cube 5x5x7: Peak: 0.837 mW/g, SAR (1g): 0.396 mW/g, SAR (10g): 0.176 mW/g, (Worst-case extrapolation) Penetration depth: 6.3 (6.1, 7.1) [mm]; Powerdrift: 0.07 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 0.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 21.1 SAR Tot [mW/g] 3.32E-2 9.96E-2 1.66E-1 2.32E-1 2.99E-1 09/26/02 COMPLIANCE CERTIFICATION SERVICES Toshiba, NIMBUS (Dualband Film Antenna); Frequency: 2412 MHz Frequency: 2450 MHz; Crest factor: 1.0 Medium: Muscle 2450 MHz: σ = 2.06 mho/m ε r = 51.1 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(4.10,4.10,4.10); SAR:: , , () Penetration depth: 6.1 (5.7, 7.2) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 23 Liquid Temperature (degree C): 21.1 09/26/02 COMPLIANCE CERTIFICATION SERVICES 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 Saarbrücken Telephone: +49 (0)681 598-0 Telefax: -9075 RSC14 issue test report consist of 74 Pages Page 1 (74) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM TTI-P-G-166/98-30 Accredited Bluetooth Test Facility (BQTF) Test report no.: 2-2730-1-4/01 FCC Part 15.247 Toshiba Wireless LAN Card PA3171U-1MPC FCC ID: CJ6PA3171WL CETECOM – ICT Services GmbH Untertürkheimerstr. 6-10 66117 Saarbrücken, Germany Telephone: + 49 (0) 681 / 598-0 Fax: + 49 (0) 681 / 9075 CETECOM ICT Services GmbH Test report nr.: 2-2730-1-4/01Issue date:27.12.01Page 2 (74) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. 1.2Testing laboratory CETECOM ICT Services GmbH 66117 Saarbrücken Untertürkheimer Straße 6 - 10 Deutschland Telefone: + 49 681 598 - 9100 Telefax : + 49 681 598 - 9075 E-mail : [email protected] Internet : www.cetecom.de Accredited testing laboratory DAR-registration number : TTI-P-G 166/98-30 CETECOM ICT Services GmbH Test report nr.: 2-2730-1-4/01Issue date:27.12.01Page 3 (74) 1.3Details of applicant Name : Toshiba Corporation, Digital Media Network Company Street : 1-1 Shibaura , 1-Chome City : Minato-ku, Tokyo 105-8001 Country : Japan Telephone : +81 (3) 3457 2565 Telefax : +81 (3) 5444 9404 Contact : Mr. Hideo Abe Telephone : +81 (3) 3457 2565 1.4Application details Date of receipt of application : 27.12.01 Date of receipt of test item : 27.12.01 Date of test : 27.12.01 1.5Test item Type of equipment : WLAN Module for laptops (Mini PCI card) Type designation : PA3171U-1MPC (identical to AGERE Ruby miniPCI 8U354) Manufacturer: - applicant - Street: City: Country: Serial number:MAC: 00022D35D35F Addit…

Text truncated - open the document above for the full version.
