CKENTG525-EULWireless Access System

WIPAS2 INSTRUCTION MANUAL (Point to Point) Rev. 1.3 20/Apr./2012 I Introduction x Read this instruction manual carefully before use. Be sure you fully understand the instructions in this manual before using the equipment. x After reading, save this instruction manual and refer to it as necessary. If you have any questions about or there is something wrong with the equipment, refer to this manual. Before use Warning Indications This manual and the product use some icons to help you use the product properly and prevent any damage to you and other people or property. The following icons classify the potential damage if the indications are ignored or the product is used improperly. When reading the manual, keep these in mind. Examples of icons A triangle is an alert to call your attention including a warning or danger indication. The graphics within the triangle differs depending on the caution. (The figure on the left shows a caution for electrical shocks.) icons indicate prohibition. A detailed prohibition description is given in the vicinity of the icon. (The figure on the left prohibits disassembly.) icons require you to perform the item. A detailed instruction is given in the vicinity of the icon. (The figure on the left instruct to unplug the equipment.) Warning labels Do not remove, damage or alter the warning labels. Warning Caution Wrong handling of this product may cause serious personal injury or death. Wrong handling of this product may cause personal injury or damage to properties. Dangerous voltages General prohibitions General advice Do not disassemble Unplug Precautions in Use Warning Don’t place containers having water, chemicals or cosmetics, such as vessels, flower pots and glasses, or small pieces of metals near or on top of this product. Liquids spilled over or into or small metal pieces getting into the product may cause fire, electrical shocks or failures. Turn off the power and stop using the unit immediately if something abnormal such as fumes or smoke is detected, and contact our sales department, branch or sales office. Continuing to use the product as is may cause fire or electrical shock. Cautions This manual describes important points to operate and maintain the equipment. Read the related sections when operating, maintaining and testing the unit. Do not try to carry out a test or maintenance not covered in this manual. This equipment is a precision machine. A failure may occur if you do not observe the following: Do not jar or subject this equipment and the units to shocks. Do not use this equipment in a place with excessive dirt or dust. Before touching a power-receiving terminal, turn the input power off to avoid electrical shocks. Do not touch the rack of the WT duirng operation because it becomes hot. When installing the WT, connect the ground wire to the ground terminal. If the equipment is not grounded properly, you may get electrical shocks when the equipment becomes faulty or shorted. When using a measuring instrument, connect the ground terminal of the measuring instrument to the ground terminal of this equipment. If the equipment is not grounded properly, you may get electrical shocks. To avoid shock hazards, do not open and touch the inside or adjustment points except for maintenance or inspection. If you modify the equipment illegally, you may be punished according to the Radio Law. Cautions Don’t use organic solvent for cleaning such as thinner and benzene because this may damage the coating. Just wipe the surface with a clean dry cloth. For the connection PoE PSE to WT and a cable suitable for outdoor use shall be installed. Avant usage Indications Préventives This manual and the product use some icons to help you use the product properly and prevent any damage to you and other people or property. The following icons classify the potential damage if the indications are ignored or the product is used improperly. When reading the manual, keep these in mind. Exemples d'icônes Un triangle est une alerte pour attirer votre attention en cas de danger ou de conseil de prudence. Le signe à l’interieur du triangle diffère selon le risque. (L’exemple de gauche signale un risque électrique.) Les deux icônes de gauche indiquent une interdiction. Une description plus détaillée est donnée près (la plus à gauche interdit le démontage.) Ce type d’icône exige que vous exécutiez l'action Une description plus détaillée est donnée près de l'icône (la plus à gauche exige de debrancher le matériel avant toute opération.) Attention N'enlevez jamais, n’endommagez jamais et ne changez jamais les signalisation de danger. (French) Danger Prudence Une mauvaise utilisation de ce produit peut causer de sérieux dommages corporels ou la mort. Une mauvaise utilisation de ce produit peut causer des dommages corporels ou endommager des biens. Le manuel d’utilisation et le produit utilisent des icônes pour vous aider à utiliser correctement le produit et prévenir tout dommages sur vous, sur des tiers ou sur des biens. Les icônes qui suivent, indiquent le niveau des dommages éventuels si les précautions indiquées sont ignorées ou si le produit est mal utilisé. Quand vous lirez le manuel d’utilisation, faites attention à ces indications. Danger électrique Débranchez Ne pas démonter Interdiction générale Conseil général Précautions d’utilisations (French) Ne placez pas de récipients contenant de l'eau, des produits chimiques ou des produits de beauté, tels que vaisselle, pots de fleur et verres, ou de petits morceaux de métal à coté ou sur ce produit. Les éclaboussures de liquides sur ou à l’intérieur du produit, ainsi que les petits morceaux de métal pénétrant le produit, peuvent provoquer le feu, des chocs électriques ou des pannes. Coupez l’alimentation électrique et cessez immédiatement toute utilisation du produit si quelque chose d'anormal tel que vapeurs ou fumées sont détectées, et contactez notre service commercial. Continuer à utiliser le produit dans ces conditions, peut pro…

Text truncated - open the document above for the full version.

1 WIPAS2 WT Management Tool Instruction Manual (Point to Point) Rev. 1.0 13/Nove./2011 2 CONTENTS CONTENTS 1.6.1. Event Log.............................................................................................................17 1.6.2. Radio Performance...............................................................................................23 1.6.3. Link Utilization......................................................................................................25 1.6.4. Traffic Counter......................................................................................................27 1.6.5. NE State Information............................................................................................30 1.7.1. Buffer Size and COS Assignment for Management Communication from Master to Slave 40 1.7.2. QoS Priority Class Configuration...........................................................................41 1.7.3. TDD Control.........................................................................................................42 1.7.4. QoS Priority Mapping...........................................................................................43 1.7.5. Policing and Shaping............................................................................................47 1.8.1. Antenna Alignment................................................................................................48 1.8.2. Packet Transmission Test.....................................................................................51 1.9.1. Radio...................................................................................................................53 1.9.2. Network................................................................................................................57 3 1.9.3. Boot Sector Selection and Initializations...............................................................63 1.9.4. Date and Time......................................................................................................67 1.9.5. Software Downloading..........................................................................................71 1.9.6. Configuration Backup...........................................................................................77 1.9.7. User Class Password...........................................................................................80 1.9.8. Frequency Table...................................................................................................82 2.6.1. Event Log.............................................................................................................97 2.6.2. NE State Information............................................................................................99 2.7.1. COS Assignment for Management Communication from Slave to Master............106 2.8.1. Antenna Alignment..............................................................................................107 2.8.2. Packet Transmission Test...................................................................................111 2.9.1. Radio.................................................................................................................113 2.9.2. Network..............................................................................................................116 4 2.9.3. Reset and Initialization........................................................................................119 2.9.4. Configuration Backup.........................................................................................122 2.9.5. User Class Password.........................................................................................124 2.9.6. Frequency Table.................................................................................................126 5 1. Management Tool (Master) 1.1. Overview of the Management Tool Management Tool (MT) is a Web server function integrated in the WT. It is for configuring and monitoring the device. Table 1 shows a functional overview of the MT. Table 1 Functional overview of the MT (Master) Item 1 Item 2 Contents Main Monitor Displays the transmission rates and radio links. Event Log Displays a log of events and a log of changes in the modulation scheme. Radio Performance Displays statistical information on the radio link. Link Utilization Displays the statistical information of the Ethernet frame counter. Traffic Counter Displays the Ingress Rate, Egress Rate and Byte Counter. Monitoring NE State Information Displays the Radio Link, Network Configuration, Inventory Information, Date and Time, QoS and Traffic Control. QoS and Traffic Control Specify the Buffer Size, QoS Priority Class Configuration, COS Assignment for Management Communication, DL/UL Ratio, QoS Priority Mapping, Policing, and Shaping. Antenna Alignment Performs the Antenna Alignment mode. Installation Packet Transmission Test Performs the Packet Transmission Test. Radio Makes configuration related to radio. Network Makes configuration of IP addresses and SNMP. Boot Sector Selection and Initializations Makes configuration of restart, bank switching, and initialization, and clears the log. Date and Time Makes configuration of time (NTP and manual). Configuration Backup Saves and writes to the configuration file. Software Downloading Downloads the software. User Class Password Makes configuration of passwords. Configuration Frequency Table Makes configuration of frequencies. Logout Logs you out. 6 1.2. Logging In [Operation] Connects the MT operation PC and the device over the LAN. Table 2 shows an recommended environment for the PC. Table 2 Recommended environment for the MT operation PC No. Item Specifications Remarks 1 Web browser Windows Internet Explorer Version 8 or higher 2 Monitor size 1024*768 Input the IP address of the device as the URL in the Windows Internet Explorer. The factory default IP address is "192.168.1.100". Figure 1 Inputting the I…

Text truncated - open the document above for the full version.

NTG-525EUL Photos (External View) External View surface No2 No2No2 No2 No1 No1No1 No1 N NN No3 o3o3 o3 No4 No4No4 No4 rear side (with a flat antenna of which model number is NAY-241R.) side surface: No1 (with a flat antenna of which model number is NAY-241R.) side surface: No2 (with a flat antenna of which model number is NAY-241R.) side surface: No3 (with a flat antenna of which model number is NAY-241R.) side surface: No4 (with a flat antenna of which model number is NAY-241R.)

ＮＴＧ-525ＥＵＬ Label Info MAC address Manufacture month Example: Nov Manufacturing year Example: 2012 Serial number The size of this CE mark is more than 5mm. Pasting position

NTG-525EUL Photos (Internal View) Internal View surface rear side (without antenna) rear side (with a flat antenna of which model number is NAY-241R.) Printed circuit assembly Parts Side Solder Side Antenna(model number: NAY-241R) surface backside

FCC ID: CKENTG525-EUL Produkte Products MPE Calculation: 12024642 003 Page 1 of 2 Client: Japan Radio Co., Ltd. 1-1, Shimorenjaku 5-chome, Mitaka-shi, Tokyo 181-8510, Japan Test item: Wireless Access System Identification: NTG-525EUL FCC Requirement According to FCC 1.1307, table 1, local multipoint distribution services operating in the 24GHz band under FCC 101 subpart G are subject to routine environment evaluation if the output power EIRP is larger than 1640W. In addition, the maximum permissible exposure (MPE) limit is specified in FCC 1.1310 and is given in the following table for: Equipment Use Frequency Range Power Density [mW/cm 2 ] Average Time [min] General Population / Uncontrolled Exposure 1.5 – 100GHz 1 30 Power Density Evaluation The maximum power densities for the different antennas to be used with the equipment are given in the following table: Antenna Type Maximum Antenna Gain G [dBi / num.] Antenna Diameter D [cm] Max. Conducted Output Power P [mW] Maximum Output Power EIRP P EIRP [W] Max. Power Density in Near-Field [mW/cm 2 ] Max. Power Density in Far-Field [mW/cm 2 ] Flat Antenna (NAY- 241R) 32.0dBi / 1584.9 16.0 (see Note) 28.84 45.71 0.512 0.219 Flat Antenna (NAY- 2500) 32.0dBi / 1584.9 16.0 (see Note) 28.84 45.71 0.512 0.219 Parabolic antenna 0.6m (HP2-26) 41.5dBi / 14125.4 62.2 28.84 407.38 0.020 0.009 Parabolic antenna 0.3m (HPCPE-26) 35.9dBi / 3890.5 35.3 28.84 112.20 0.053 0.023 Calculation formulas: Max. output power EIRP P EIRP = PG Max. power density in near-field: S nf = 16ηP / πD 2 OET Bulletin 65 (13) Aperture efficiency: η = (Gλ 2 /4π) / (πD 2 /4) OET Bulletin 65 (14) Max. power density in far-field: S ff = PG / 4πR ff 2 OET Bulletin 65 (18) Distance to beginning of far-field R ff = 0.6 D 2 / λ OET Bulletin 65 (16) Where: G = maximum gain [numeric] λ = wavelength at 25.15GHz (middle of operation band) in [cm] = 1.19cm D = antenna diameter in [cm] (see Note) P = maximum conducted output power in [mW] FCC ID: CKENTG525-EUL Produkte Products MPE Calculation: 12024642 003 Page 2 of 2 Note: The flat antennas have a square shape. For calculation purpose, the diameter D is considered as the diameter of the largest circle that can fit inside the antenna square surface, to consider worst case conditions. Conclusion The device complies with the FCC RF exposure requirements since the maximum transmitter power densities (both in near-field and in far-field) are below the FCC limit. No routine environment evaluation is needed since the maximum EIRP output power is below the threshold specified for multipoint distribution services operating in the 24GHz band under FCC 101 subpart G. Refer to test report 12024642 001 for more details. TÜV Rheinland Japan Ltd. – Global Technology Assessment Center 4-25-2 Kita-Yamata, Tsuzuki-ku, Yokohama 224-0021, Japan

FCC ID: CKENTG525-EUL Produkte Products Prüfbericht - Nr.: Test Report No.: 12024642 001 Seite 2 von 76 Page 2 of 76 TEST SUMMARY 5.1.1 MICROWAVE MODULATION RESULT: PASS 5.1.2 ANTENNA REQUIREMENTS RESULT: PASS 5.2.1 TRANSMITTER POWER LIMITATIONS RESULT: PASS 5.2.2 OCCUPIED BANDWIDTH RESULT: PASS 5.2.3 FREQUENCY STABILITY RESULT: PASS 5.2.4 EMISSION MASK RESULT: PASS 5.2.5 CONDUCTED SPURIOUS EMISSIONS OF TRANSMITTER RESULT: PASS 5.3.1 RADIATED SPURIOUS EMISSIONS OF TRANSMITTER RESULT: PASS FCC ID: CKENTG525-EUL Produkte Products Prüfbericht - Nr.: Test Report No.: 12024642 001 Seite 3 von 76 Page 3 of 76 Contents 1. GENERAL REMARKS ................................................................................................. 5 1.1 COMPLEMENTARY MATERIALS .................................................................................. 5 2. TEST SITES .............................................................................................................. 5 2.1 TEST FACILITIES ....................................................................................................... 5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS ....................................................... 6 2.3 MEASUREMENT UNCERTAINTY ................................................................................... 7 3. GENERAL PRODUCT INFORMATION ............................................................................ 8 3.1 PRODUCT FUNCTION AND INTENDED USE ................................................................... 8 3.2 SYSTEM DETAILS ...................................................................................................... 8 3.3 CLOCK FREQUENCIES ............................................................................................... 9 3.4 NOISE SUPPRESSING PARTS ..................................................................................... 9 4. TEST SET-UP AND OPERATION MODES .................................................................... 10 4.1 TEST METHODOLOGY .............................................................................................. 10 4.2 OPERATION MODES ................................................................................................ 10 4.3 PHYSICAL CONFIGURATION FOR TESTING ................................................................ 11 4.4 TEST SOFTWARE .................................................................................................... 11 4.5 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ................................................ 12 4.6 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE ............................................... 13 5. TEST RESULTS R AD I O ......................................................................................... 14 5.1 TECHNICAL REQUIREMENTS .................................................................................... 14 5.1.1 Microwave Modulation ............................................................................................................. 14 5.1.2 Antenna Requirements ............................................................................................................ 15 5.2 CONDUCTED MEASUREMENTS AT ANTENNA PORT .................................................... 16 5.2.1 Transmitter Power Limitations ................................................................................................. 16 5.2.2 Occupied Bandwidth ................................................................................................................ 23 5.2.3 Frequency Stability .................................................................................................................. 36 5.2.4 Emission Mask......................................................................................................................... 38 5.2.5 Conducted Spurious Emissions of Transmitter ........................................................................ 51 5.3 RADIATED MEASUREMENTS..................................................................................... 61 5.3.1 Radiated Spurious Emissions of Transmitter ........................................................................... 61 6. PHOTOGRAPHS OF THE TEST SETUP ........................................................................ 70 7. LIST OF TABLES ...................................................................................................... 74 8. LIST OF FIGURES .................................................................................................... 74 FCC ID: CKENTG525-EUL Produkte Products Prüfbericht - Nr.: Test Report No.: 12024642 001 Seite 4 von 76 Page 4 of 76 9. LIST OF PHOTOGRAPHS .......................................................................................... 76 FCC ID: CKENTG525-EUL Produkte Products Prüfbericht - Nr.: Test Report No.: 12024642 001 Seite 5 von 76 Page 5 of 76 1. General Remarks 1.1 Complementary Materials There is no attachment to this test report. 2. Test Sites 2.1 Test Facilities TÜV Rheinland Japan Ltd. – Global Technology Assessment Center 4-25-2 Kita-Yamata, Tsuzuki-ku, Yokohama 224-0021, Japan The used test equipment is in accordance with CISPR 16 for measurement of radio interference. The Federal Communications Commission has reviewed the technical characteristics of the radiated and conducted emission facilities and has found these test sites to be in compliance with the requirements of section 2.948 of the FCC rules. The description of the test facility is listed under FCC registration number 299054. TÜV Rheinland Japan Ltd. is accredited by the Federal Communications Commission as a Conformity Assessment Body under Designation Number JP0017 and Test Firm Registration Number 386498. FCC ID: CKENTG525-EUL Produkte Products Prüfbericht - Nr.: Test Report No.: 12024642 001 Seite 6 von 76 Page 6 of 76 2.2 List of Test and Measurement Instruments Table 1: List of Test and Measurement Equipment Kind of Equipment…

Text truncated - open the document above for the full version.

FCC ID: CKENTG525-EUL Produkte Products Prüfbericht - Nr.: Test Report No.: 12024642 001 Seite 70 von 76 Page 70 of 76 6. Photographs of the Test Setup Photograph 1: Set-up for Conducted Emissions at Antenna Port FCC ID: CKENTG525-EUL Produkte Products Prüfbericht - Nr.: Test Report No.: 12024642 001 Seite 71 von 76 Page 71 of 76 Photograph 2: Set-up for Frequency Stability, General View Photograph 3: Set-up for Frequency Stability, inside Temperature Chamber FCC ID: CKENTG525-EUL Produkte Products Prüfbericht - Nr.: Test Report No.: 12024642 001 Seite 72 von 76 Page 72 of 76 Photograph 4: Set-up for Radiated Emissions, Front View Photograph 5: Set-up for Radiated Emissions, Rear View FCC ID: CKENTG525-EUL Produkte Products Prüfbericht - Nr.: Test Report No.: 12024642 001 Seite 73 von 76 Page 73 of 76 Photograph 6: Set-up for Radiated Emissions, EUT Orientation H Photograph 7: Set-up for Radiated Emissions, EUT Orientation V
