Wi-Fi BacPac™ Brand: GoPro Model: AWIFI-001 GETTING STARTED WITH YOUR WI‐FI BACPAC HOW TO USE YOUR WI‐FI BACPAC The Wi‐Fi BacPac attaches to your HD HERO or later camera to enable long‐range video remote control via a Wi‐Fi Remote or a smartphone, tablet or computer running the GoPro App. BATTERY LEVEL AND CHARGING You should charge your Wi‐Fi BacPac for two hours before using it the first time. To charge the Wi‐Fi BacPac, connect it to a computer or USB power supply with the included USB cable. You can check the Wi‐Fi BacPac’s battery level on the Status Display. Tap [B icon] to illuminate the Status Display in low‐light conditions. PAIRING YOUR WI‐FI BACPAC FOR THE FIRST TIME Your Wi‐Fi BacPac can pair with one Wi‐Fi‐enabled device at a time, like a GoPro Wi‐Fi Remote, an Android or Apple smart device, or a home/office Wi‐Fi network. Devices running the GoPro App can use this connection to stream live video and control one ore more camera(s) remotely. To establish a new connection between the Wi‐Fi BacPac and a Wi‐Fi‐enabled device: 1. Make sure your Wi‐Fi BacPac is attached to the camera and powered ON. 2. Scroll through Camera Modes using [P icon] and select WIFI BACPAC SETTINGS using [S icon]. 3. From the Wi‐Fi Connection screen, press [S icon]. 4. Use [P ICON] to toggle between REMOTE or DEVICE, then press [S ICON]. 5. The Wi‐Fi Connection animation appears, indicating that the Wi‐Fi BacPac is searching for a connection. Press [S icon] at any time to cancel. While the Wi‐Fi BacPac is searching for a connection, follow the steps needed to direct your Wi‐Fi device to make a Wi‐Fi connection. Once both devices are actively seeking to connect, a connection will be established and the Wi‐Fi BacPac will return your camera to its default capture mode. USING YOUR WI‐FI BACPAC WITH A GOPRO WI‐FI REMOTE See the Getting Started With Your Wi‐Fi Remote quick‐start guide or online user manual at GoPro.com for more information. USING YOUR WI‐FI BACPAC WITH THE GOPRO APP You can use the GoPro App to live stream video from one or more cameras, then easily playback and share your photos and videos through sites like Facebook, Twitter and YouTube. See GoPro.com for more information about how to use the GoPro App to control one or more HD HERO or later cameras. CONNECTING TO A BLUETOOTH DEVICE The Wi‐Fi BacPac can connect to Bluetooth‐enabled devices like wireless headsets and microphones. See GoPro.com for more information. LEARN MORE AT GOPRO.COM To access the Wi‐Fi BacPac’s online user manual and watch how‐to videos, visit GoPro.com/support. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. This EUT is compliance with SAR for general population/uncontrolled exposure limits in ANSI/IEEE C95.1‐1999 and had been tested in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C. This device complies with Industry Canada licence‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This EUT is compliance with SAR for general population/uncontrolled exposure limits in IC RSS‐102 and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528. This equipment can be operated with direct touch with minimum distance 0cm between the radiator & your body.

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 2106 Date: March 19, 2012 Subject: FCC Application for FCC ID: CNF-WIFIBP-001 To Whom it may concern, We, the undersigned, would like to declare that the composite portion catagorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Applicant : Woodman Labs dba GoPro Address : 2450 Cabrillo Highway Ste 250, Half Moon Bay, California 94019 United States Signature : _________________________________ Name and Job Title. : John Wyatt / PQA Director E-mail : [email protected] Tel. : 415-738-2480-x7110

Date: March 19, 2012 Subject: Ad Hoc Mode Function Declaration FCC ID: CNF-WIFIBP-001 To Whom it may concern, We, Woodman Labs dba GoPro, declare that the device (FCC ID: CNF-WIFIBP-001) 1. is acting as slave and operating on 2.4GHz band. 2. Ad Hoc function is available. 3. does not work in non-US/Canada frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Applicant : Woodman Labs dba GoPro Address : 2450 Cabrillo Highway Ste 250, Half Moon Bay, California 94019 United States Signature : _________________________________ Name and Job Title. : John Wyatt / PQA Director E-mail : [email protected] Tel. : 415-738-2480-x7110

Confidentiality Request Letter Date: 2012/3/19 Federal Communications Commission Authorization and Evaluation Division FCC ID：CNF-WIFIBP-001 Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant : Woodman Labs dba GoPro Address : 2450 Cabrillo Highway Ste 250, Half Moon Bay, California 94019 United States Signature : _________________________________ Name and Job Title. : John Wyatt / PQA Director E-mail : [email protected] Tel. : 415-738-2480-x7110

Date: 2012/3/19 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Product Certification Representative Authorization Letter FCC ID: CNF-WIFIBP-001 Product name: WiFi BacPac To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model AWIFI-001 to the FCC Rules and Regulations. Sporton International Inc. Address : No. 52, Hwa Ya 1st Road., Kwei-Shan Hsiang, TaoYuan Hsien Taiwan R.O.C. Name : Wayne Hsu Job Title : Vice Manager e-mail : [email protected] We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : Woodman Labs dba GoPro Address : 2450 Cabrillo Highway Ste 250, Half Moon Bay, California 94019 United States Signature : _________________________________ Name and Job Title. : John Wyatt / PQA Director E-mail : [email protected] Tel. : 415-738-2480-x7110

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B1 OF B10 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 21, 2012 FAX : 886-2-2696-2255 APPENDIX B. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B2 OF B10 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 21, 2012 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B3 OF B10 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 21, 2012 FAX : 886-2-2696-2255

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B4 OF B10 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 21, 2012 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B5 OF B10 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 21, 2012 FAX : 886-2-2696-2255 Antenna FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B6 OF B10 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 21, 2012 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B7 OF B10 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 21, 2012 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B8 OF B10 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 21, 2012 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B9 OF B10 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 21, 2012 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B10 OF B10 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 21, 2012 FAX : 886-2-2696-2255

SPORTON INTERNATIONAL INC. Page Number : 1 of 29 TEL : 886-3-327-3456 Report Issued Date : Apr. 20, 2012 FAX : 886-3-328-4978 Report Version : Rev. 02 FCC ID : CNF-WIFIBP-001 FCC SAR Test Report Report No. : FA1D1003 FCC SAR Test Report APPLICANT : Woodman Labs dba GoPro EQUIPMENT : WIFI BacPac BRAND NAME : GoPro MODEL NAME : AWIFI-001 MARKETING NAME : WiFi BacPac FCC ID : CNF-WIFIBP-001 STANDARD : FCC 47 CFR Part 2 (2.1093) IEEE C95.1-1991 IEEE 1528-2003 FCC OET Bulletin 65 Supplement C (Edition 01-01) The product was received on Apr. 03, 2012 and completely tested on Apr. 03, 2012. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 29 TEL : 886-3-327-3456 Report Issued Date : Apr. 20, 2012 FAX : 886-3-328-4978 Report Version : Rev. 02 FCC ID : CNF-WIFIBP-001 FCC SAR Test Report Report No. : FA1D1003 Table of Contents 1. Statement of Compliance ............................................................................................................................................. 4 2. Administration Data ...................................................................................................................................................... 5 2.1 Testing Laboratory .................................................................................................................................................. 5 2.2 Applicant ................................................................................................................................................................ 5 2.3 Manufacturer .......................................................................................................................................................... 5 2.4 Application Details .................................................................................................................................................. 5 3. General Information ...................................................................................................................................................... 6 3.1 Description of Equipment Under Test (DUT) .......................................................................................................... 6 3.2 Product Photos....................................................................................................................................................... 7 3.3 Applied Standards .................................................................................................................................................. 7 3.4 Device Category and SAR Limits ........................................................................................................................... 7 3.5 Test Conditions ....................................................................................................................................................... 7 4. Specific Absorption Rate (SAR) ................................................................................................................................... 8 4.1 Introduction ............................................................................................................................................................ 8 4.2 SAR Definition ........................................................................................................................................................ 8 5. SAR Measurement System ........................................................................................................................................... 9 5.1 E-Field Probe ........................................................................................................................................................10 5.2 Data Acquisition Electronics (DAE) ....................................................................................................................... 11 5.3 Robot .................................................................................................................................................................... 11 5.4 Measurement Server .............................................................................................................................................12 5.5 Phantom ................................................................................................................................................................12 5.6 Device Holder........................................................................................................................................................13 5.7 Data Storage and Evaluation ................................................................................................................................15 5.8 Test Equipment List ...............................................................................................................................................17 6. Tissue Simulating Liquids ...........................................................................................................................................18 7. Uncertainty Assessment .............................................................................................................................................19 8. SAR Measurement Evaluation ....................................................................................................................................21 8.1 Purpose of System P…

Text truncated - open the document above for the full version.

SPORTON International Inc. Report Format Version: a FCC TEST REPORT Report No. : FR1D1003-01AN FCC RADIO TEST REPORT According to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : WIFI BacPac Brand Name : GoPro Model : AWIFI-001 Marketing Name : WiFi BacPac Filin g Type : New Application Applicant : Woodman Labs dba GoPro 2450 Cabrillo Highway Ste 250 Half Moon Bay California United States 94019 FCC ID : CNF-WIFIBP-001 Manufacturer : Chicony Electronics Co., Ltd No.25, Wugong 6th Rd., Wugu Dist., New Taipei Cit y 248, Taiwan (R.O.C.) Received Date : Dec. 30, 2011 Final Test Date : Jan. 10, 2012 Statement Test result included is only for the 802.11b/g/n part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON International Inc. Page No. : i of ii TEL : 886-3-327-3456 Issued Date : Mar. 21, 2012 FAX : 886-3-318-0055 FCC ID : CNF-WIFIBP-001 FCC TEST REPORT Report No. : FR1D1003-01AN Table of Contents 1 SUMMARY OF THE TEST RESULT ....................................................................................................................... 2 2 GENERAL INFORMATION ...................................................................................................................................... 3 2.1 Product Details .........................................................................................................................................................................................3 2.2 Table for Filed Antenna ............................................................................................................................................................................4 2.3 Table for Carrier Frequencies ..................................................................................................................................................................5 2.4 Table for Test Modes ...............................................................................................................................................................................5 2.5 Table for Testing Locations ......................................................................................................................................................................5 2.6 Table for Supporting Units .......................................................................................................................................................................5 2.7 Table for Parameters of Test Software Setting ........................................................................................................................................6 2.8 EUT Operation during Test ......................................................................................................................................................................6 2.9 Test Configuration ....................................................................................................................................................................................7 3 TEST RESULT ......................................................................................................................................................... 9 3.1 AC Power Line Conducted Emissions Measurement ..............................................................................................................................9 3.2 Maximum Peak Output Power Measurement ........................................................................................................................................13 3.3 Power Spectral Density Measurement ...................................................................................................................................................15 3.4 6dB Spectrum Bandwidth Measurement ...............................................................................................................................................23 3.5 Radiated Emissions Measurement ........................................................................................................................................................31 3.6 Band Edge and Fundamental Emissions Measurement ........................................................................................................................55 3.7 Antenna Requirements ..........................................................................................................................................................................62 4 LIST OF MEASURING EQUIPMENTS .................................................................................................................. 63 5 TEST LOCATION ................................................................................................................................................... 65 6 TAF CERTIFICATE OF ACCREDITATION ........................................................................................................... 66 APPENDIX A. TEST PHOTOS ................................................................................................................................. A7 APPENDIX B. PHOTOGRAPHS OF EUT .............................................................................................................. B10 SPORTON International Inc. Page No. : ii of ii TEL : 886-3-327-3456 Issued Date : Mar. 21, 2012 FAX : 886-3-318-0055 FCC ID : CNF-WIFIBP-001 FCC TEST REPORT Report No…

Text truncated - open the document above for the full version.

Page No. : A1 of A7 FCC ID : CNF-WIFIBP-001 FCC TEST REPORT Report No. : FR1D1003-01AN Appendix A. Test Photos Page No. : A2 of A7 FCC ID : CNF-WIFIBP-001 FCC TEST REPORT Report No. : FR1D1003-01AN 1 Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW Page No. : A3 of A7 FCC ID : CNF-WIFIBP-001 FCC TEST REPORT Report No. : FR1D1003-01AN SIDE VIEW Page No. : A4 of A7 FCC ID : CNF-WIFIBP-001 FCC TEST REPORT Report No. : FR1D1003-01AN 2 Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz FRONT VIEW REAR VIEW Page No. : A5 of A7 FCC ID : CNF-WIFIBP-001 FCC TEST REPORT Report No. : FR1D1003-01AN For radiated emissions 30MHz~1GHz FRONT VIEW REAR VIEW Page No. : A6 of A7 FCC ID : CNF-WIFIBP-001 FCC TEST REPORT Report No. : FR1D1003-01AN For radiated emissions above 1GHz FRONT VIEW REAR VIEW Page No. : A7 of A7 FCC ID : CNF-WIFIBP-001 FCC TEST REPORT Report No. : FR1D1003-01AN EUT take a close-up. FRONT VIEW REAR VIEW
