COF-AS01Azure Sphere Module

Universal Global Scientific Industrial Co., Ltd.
Azure Sphere Module - FCC ID COF-AS01 - Universal Global Scientific Industrial Co., Ltd.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Jun 22, 2020
Application Purpose
Original Equipment
Date of Application
Jun 21, 2020
Equipment Note
Azure Sphere Module
Frequency Range
2412.00000000 - 2462.00000000
Company
Universal Global Scientific Industrial Co., Ltd.
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Azure Sphere Module User Guide V1.0 Daniel Tu FAE WCS/WP1 Jun. 3rd, 2020 © USI. All rights reserved. Outline  MT3620 Setup  Nordic nRF52 BLE Setup  BLE-based Wi-Fi setup sample  Private Ethernet sample  Nordic BLE DFU  Additional -FTDI Programming Configuration -FCC/IC Cert Statement 1 © USI. All rights reserved. Azure Sphere Carrier Board MT3620_Guardian Rev:0.3 2 BLE External Antenna WiFi External Antenna © USI. All rights reserved. MT3620 Interface 3 LEDMT3620 GPIO APP REDGPIO45 APP GREENGPIO46 APP BLUEGPIO47 WIFI REDGPIO48 WIFI GREENGPIO14 WIFI BLUEGPIO11 BUTTONMT3620 GPIO S2GPIO12 S3GPIO13 MT3620_Guardian Rev:0.2 © USI. All rights reserved. MT3620 Interface 4 RS232 : RS485 Full Duplex :  RS485 Half Duplex : Link Pin1 and Pin2 of JR8. (GPIO2 need pull high) Link JP13 JR8 MT3620 GPIO PIN 1 GPIO67_MOSI3_RTS3_CLK3 PIN 2 (SP336E RS232 RTS/ RS485 Enable) PIN 3 GPIO2 Link Pin2 and Pin3 of JR8 Link Pin1 and Pin2 of JR8. (GPIO2 pull High for TX, pull low for RX ) Link JP13 Link JP14 © USI. All rights reserved. MT3620 UART Function MT3620 UART Description ISU0For Ethernet(ENC28J60) using ISU1Header J32 pin 13,14,15,16 ISU2FTDI(FT4232HQ) Port-A ISU3RS232/RS485 (SP336E) ISU4Nordic BLE nRF52 UART function 5 © USI. All rights reserved. MT3620 Setup Steps Follow steps let Visual Studio can download and run debugger to Azure Sphere (MT3620)  Install Azure Sphere SDK and Tools Verify Azure Sphere SDK Installation  Verify TAP-Windows Adapter Configuration  Create tenant and claim your device  Connect to Wi-Fi  Prepare MT3620 for development and debugging  Azure Sphere Application  Build and Run High-level Application  Set Up Hardware For Real-time App  Build a real-time capable application 6 © USI. All rights reserved.  Install FTDI driver https://www.ftdichip.com/Drivers/VCP.htm Install Visual Studio 2019 Enterprise, Professional, or Community version 16.04 or later; or Visual Studio 2017 version 15.9 or later. https://visualstudio.microsoft.com/  Install the Azure Sphere SDK Preview for Visual Studio  https://aka.ms/AzureSphereSDKDownload  Azure Sphere SDK only support on Windows 10, version 1607 Update or later  Read Microsoft Installation Guide for more details.  https://docs.microsoft.com/en-us/azure-sphere/install/install-sdk Install Azure Sphere SDK and Tools 7 © USI. All rights reserved.  After install SDK, connect the MT3620 guardian board to the PC by USB. Open Device Manager and look for TAP-Windows Adapter V9. And three new COM ports. The numbers on your COM ports may be different from those in the figure. Verify Azure Sphere SDK Installation 8 Reference : https://docs.microsoft.com/en-us/azure-sphere/install/install-sdk © USI. All rights reserved.  Check the Network connection Azure Sphere (TAP-Windows Adapter V9) is connected. Right-click on Azure Sphereand check it’s properties are as shown below: Verify TAP-Windows Adapter Configuration 9 © USI. All rights reserved.  Sign in to Azure Sphere, using aMicrosoft account:  azspherelogin  If you've never logged in to Azure Sphere before, add the --newuserparameter along with your Microsoft accountemail address:  azspherelogin --newuser<email-address>  Type the following command to create a tenant.  azspheretenant create --name <my-tenant>  For Example : azspheretenant create –name “USITenant”  Claim your device.  azspheredevice claim  You should see output like this: Create tenant and claim your device Reference : https://docs.microsoft.com/en-us/azure-sphere/install/claim-device Claiming attached device ID 'ABCDE082513B529C45098884F882B2CA6D832587CAAE1A90B1CEC4A376EA2F22A96C4E7E1FC4D2AFF5633B68 DB68FF4420A5588B420851EE4F3F1A7DC51399ED' into tenant ID 'd343c263-4aa3-4558-adbb-d3fc34631800'. Successfully claimed device ID Command completed successfully in 00:00:05.5459143. 10 © USI. All rights reserved.  Add your Wi-Fi network to the device by using the azspheredevice wifi add command as follows:  azspheredevice wifiadd --ssid<yourSSID> --psk<yourNetworkKey>  MT3620 do not support WEP.  Check the status of the WiFiconnection  azspheredevice wifishow-status  The following example shows successful results for a secure WPA2 connection: Connect to WiFi Reference : https://docs.microsoft.com/en-us/azure-sphere/install/configure-wifi SSID : NETGEAR21 Configuration state : enabled Connection state : connected Security state : psk Frequency : 2442 Mode : station Key management : WPA2-PSK WPA State : COMPLETED IP Address : 192.168.1.15 MAC Address : 52:cf:ff:3a:76:1b Command completed successfully in 00:00:01.3976308. 11 © USI. All rights reserved.  Make sure that your Azure Sphere device is connected to your PC, and your PC is connected to the internet.  In an Azure Sphere Developer Command Prompt window, type the following command:  azspheredevice enable-development  You should see output similar to the following: Prepare development and debugging Getting device capability configuration for application development. Downloading device capability configuration for device ID 'ABCDE082513B529C45098884F882B2CA6D832587CAAE1A90B1CEC4A376EA2F22A96C4E7E1FC4D2AFF5633B68DB68FF4420A5588B420851EE4F3F1A7DC51399ED'. Successfully downloaded device capability configuration. Successfully wrote device capability configuration file 'C:\Users\user\AppData\Local\Temp\tmpD732.tmp'. Setting device group ID 'a6df7013-c7c2-4764-8424-00cbacb431e5' for device with ID 'ABCDE082513B529C45098884F882B2CA6D832587CAAE1A90B1CEC4A376EA2F22A96C4E7E1FC4D2AFF5633B68DB68FF4420A5588B420851EE4F3F1A7DC51399ED'. Successfully disabled over-the-air updates. Enabling application development capability on attached device. Applying device capability configuration to device. Successfully applied device capability configuration to device. The device is rebooting. Installing debugging server to device. Installation started. Application development capability enabled. Successfully set up device 'ABCDE082513B529C45098884F882B2CA6D832587CAAE1A90B1C…

Text truncated - open the document above for the full version.

Cover Letter(s)

Date: June 16, 2020 Federal Communications Commission 7435 Oakland Mills Road - Gate A Columbia, Maryland 21046 Subject: Request for Confidentiality FCC ID: COF-AS01 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. l Schematic Diagram l Block Diagram l Operational Description l Software Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations. u External Photos u Internal Photos u Test Setup Photos u Users Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, Martin Shih / Manager Universal Global Scientific Industrial Co., Ltd. Tel: 886-49-235-0876 Fax: 886-49-233-2061 E-mail: [email protected]

Cover Letter(s)

FCC ID: COF-AS01 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch June 18, 2020 Dear Application Examiner, Universal Global Scientific Industrial Co., Ltd., Azure Sphere Module, FCC ID: COF-AS01 would like to have your authorization as a modu lar approval specific to the mobile RF exposure condition. The requirements of KDB996369 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip MT3620. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is MT3620. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a USB cable. Please see section Photographs of Test Configuration in the test report. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Amanda Wu / Senior Specialist Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Tel: 886-3-264-1929 Fax: 886-3-327 0892 Email: [email protected]

Cover Letter(s)

Date: June 16, 2020 To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, __Universal Global Scientific Industrial Co., Ltd.___ hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: COF-AS01 Product Description: Azure Sphere Module Model: AS-01 Sincerely, ------------------------------------------------------------- Martin Shih / Manager Universal Global Scientific Industrial Co., Ltd. Te l : 886-49-235-0876 Fax: 886-49-233-2061 E-mail: [email protected]

Cover Letter(s)

Date: June 16, 2020 Declaration We, Universal Global Scientific Industrial Co., Ltd. here declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. FCC ID: COF-AS01 If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ------------------------------------------------------- Martin Shih / Manager Universal Global Scientific Industrial Co., Ltd. Tel: 886-49-235-0876 Fax: 886-49-233-2061 E-mail: [email protected]

External Photos

Reference No.: 200508C22 Page No. 1 / 4 CONSTRUCTION PHOTOS OF EUT WiFi onboard ANT Reference No.: 200508C22 Page No. 2 / 4 Reference No.: 200508C22 Page No. 3 / 4 Reference No.: 200508C22 Page No. 4 / 4 EUT (Model: AS-01)

Internal Photos

Reference No.: 200508C22-1 Page No. 1 / 4 CONSTRUCTION PHOTOS OF EUT Reference No.: 200508C22-1 Page No. 2 / 4 BT Ant. Reference No.: 200508C22-1 Page No. 3 / 4 WiFi external ANT (AUX) (Optional) Reference No.: 200508C22-1 Page No. 4 / 4

RF Exposure Info

Report No.: SA200508C22 Page No. 1 / 6 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA200508C22 FCC ID: COF-AS01 Test Model: AS-01 Received Date: May. 08, 2020 Test Date: May 27 ~ May 29, 2020 Issued Date: Jun. 03, 2020 Applicant: UNIVERSAL GLOBAL SCIENTIFIC INDUSTRIAL CO., LTD Address: 141, Lane 351, Sec.1, Taiping Road, Tsaotuen, Nantou, 54261, Taiwan Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: SA200508C22 Page No. 2 / 6 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Calculation Result of Maximum Conducted Power ........................................................................... 6 Report No.: SA200508C22 Page No. 3 / 6 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA200508C22 Original release. Jun. 03, 2020 Report No.: SA200508C22 Page No. 4 / 6 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Azure Sphere Module Brand: Test Model: AS-01 Sample Status: Engineering sample Applicant: UNIVERSAL GLOBAL SCIENTIFIC INDUSTRIAL CO., LTD Test Date: May 27 ~ May 29, 2020 Standards: FCC Part 2 (Section 2.1091) IEEE C95.3 -2002 References Test Guidance: KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Prepared by : , Date: Jun. 03, 2020 Polly Chien / Specialist Approved by : , Date: Jun. 03, 2020 Bruce Chen / Senior Project Engineer Report No.: SA200508C22 Page No. 5 / 6 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA200508C22 Page No. 6 / 6 Report Format Version: 6.1.1 3 Calculation Result of Maximum Conducted Power Frequency Band (MHz) Max. AV Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) EUT with WiFi onboard ANT WLAN 2412~2462 16.42 0.19 20 0.009 1 WLAN 5180~5240 13.33 3.27 20 0.009 1 WLAN 5260~5320 13.41 3.27 20 0.009 1 WLAN 5500~5720 13.44 3.27 20 0.009 1 WLAN 5745~5825 13.31 3.27 20 0.009 1 EUT with WiFi external ANT WLAN 2412~2462 16.24 3.22 20 0.018 1 WLAN 5180~5240 13.39 3.43 20 0.010 1 WLAN 5260~5320 13.44 3.43 20 0.010 1 WLAN 5500~5720 13.42 3.43 20 0.010 1 WLAN 5745~5825 13.45 3.43 20 0.010 1 EUT with BT ANT BT LE 2402~2480 3.80 3.00 20 0.0005 1 Note: Determinin…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF200508C22-4 Page No. 1 / 30 Report Format Version: 6.1.1 FCC Test Report (Co-Located) Report No.: RF200508C22-4 FCC ID: COF-AS01 Test Model: AS-01 Received Date: May. 08, 2020 Test Date: Jun. 10 ~ Jun. 11, 2020 Issued Date: Jun. 19, 2020 Applicant: UNIVERSAL GLOBAL SCIENTIFIC INDUSTRIAL CO., LTD Address: 141, Lane 351, Sec.1, Taiping Road, Tsaotuen, Nantou, 54261, Taiwan Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF200508C22-4 Page No. 2 / 30 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 Summary of Test Results ..................................................................................................................... 5 2.1 Measurement Uncertainty ................................................................................................................... 5 2.2 Modification Record ............................................................................................................................ 5 3 General Information .............................................................................................................................. 6 3.1 General Description of EUT ................................................................................................................ 6 3.2 Description of Test Modes ................................................................................................................... 8 3.2.1 Test Mode Applicability and Tested Channel Detail ........................................................................... 10 3.3 Description of Support Units .............................................................................................................. 11 3.3.1 Configuration of System under Test ................................................................................................... 11 3.4 General Description of Applied Standards ......................................................................................... 11 4 Test Types and Results ...................................................................................................................... 12 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 12 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 12 4.1.2 Test Instruments ................................................................................................................................ 13 4.1.3 Test Procedures ................................................................................................................................. 14 4.1.4 Deviation from Test Standard ............................................................................................................ 14 4.1.5 Test Setup .......................................................................................................................................... 15 4.1.6 EUT Operating Conditions ................................................................................................................. 16 4.1.7 Test Results ....................................................................................................................................... 17 5 Pictures of Test Arrangements .......................................................................................................... 29 Appendix – Information of the Testing Laboratories ................................................................................. 30 Report No.: RF200508C22-4 Page No. 3 / 30 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued RF200508C22-4 Original release Jun. 19, 2020 Report No.: RF200508C22-4 Page No. 4 / 30 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Azure Sphere Module Brand: Test Model: AS-01 Sample Status: Engineering sample Applicant: UNIVERSAL GLOBAL SCIENTIFIC INDUSTRIAL CO., LTD Test…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF200508C22-3 Page No. 1 / 35 Report Format Version: 6.1.1 FCC Test Report Report No.: RF200508C22-3 FCC ID: COF-AS01 Test Model: AS-01 Received Date: May. 08, 2020 Test Date: May 28 ~ May 29, 2020 Issued Date: Jun. 03, 2020 Applicant: UNIVERSAL GLOBAL SCIENTIFIC INDUSTRIAL CO., LTD Address: 141, Lane 351, Sec.1, Taiping Road, Tsaotuen, Nantou, 54261, Taiwan Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF200508C22-3 Page No. 2 / 35 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 8 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................. 9 3.3 Duty Cycle of Test Signal .................................................................................................................. 10 3.4 Description of Support Units .............................................................................................................. 11 3.4.1 Configuration of System under Test ................................................................................................... 11 3.5 General Description of Applied Standards and References ............................................................... 11 4 Test Types and Results ...................................................................................................................... 12 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 12 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 12 4.1.2 Test Instruments ................................................................................................................................ 13 4.1.3 Test Procedures ................................................................................................................................. 14 4.1.4 Deviation from Test Standard ............................................................................................................ 14 4.1.5 Test Setup .......................................................................................................................................... 15 4.1.6 EUT Operating Conditions ................................................................................................................. 16 4.1.7 Test Results ....................................................................................................................................... 17 4.2 Conducted Emission Measurement .................................................................................................. 22 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 22 4.2.2 Test Instruments ................................................................................................................................ 22 4.2.3 Test Procedures ..............................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF200508C22 Page No. 1 / 74 Report Format Version: 6.1.1 FCC…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Martin Shih(Manager)
[email protected]886-49-235-0876Fax: 886-49-233-2061

Test Firm

Bureau Veritas CPS (H.K.) Ltd., Taoyuan BranchRichard Chen
[email protected]+886-3-260-0884Fax: +886-3-211-5834

Technical Specifications

#Rule PartsFrequency RangePower Output
215C2.41 GHz - 2.46 GHz312.00 mW
Modular Type
Single Modular Approval
Confidentiality
Long Term
Grant Notes
Power listed is maximum Conducted output power. Single Module Approval for mobile platform with max. allowed antenna gain 3.22dBi. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the FCC multi-transmitter procedures. The host integrator must follow the integration instructions provided by the module manufacturer and ensure that the composite-system end product complies with the FCC requirements by a technical assessment or evaluation to the FCC rules and to KDB Publication 996369. The module antenna(s) must be installed to meet the RF exposure compliance separation distance of 20cm and any additional testing and authorization process as required. The module grantee is responsible for providing the documentation to the system integrator on restrictions of use, for continuing compliance of the module. The host integrator installing this module into their product must ensure that the final composite product complies with the FCC requirements by a technical assessment or evaluation to the FCC rules, including the transmitter operation and should refer to guidance in KDB 996369.
