COF-WMBACAT49802.11a/b/g/n/ac 2x2 MIMO + BT 5.1 Combo Module

All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI. WM-BAC-AT-49 module, Wi-Fi/Bluetooth RF user manual, revision 1.0 Page 1 WM-BAC-AT-49 Wi-Fi/Bluetooth Module user manual Revision history Revision Date Change description 1.0 2020/12/07 First draft of the document. All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI. WM-BAC-AT-49 module, Wi-Fi/Bluetooth RF user manual, revision 1.0 Page 2 Table of Contents 1. Introduction ....................................................................................... 3 1.1 Brief Technology Features ................................................................... 3 1.2 Wireless Specification.......................................................................... 3 2. OEM Integrators Installation Manual ................................................. 4 2.1 Important Notice to OEM Integrators ................................................. 4 2.2 Antenna Configurations ....................................................................... 5 2.3 Antenna Specifications ........................................................................ 7 2.4 Note Information ................................................................................. 8 3. Federal Communication Commission Compliance Statement ............... 9 4. ISED Compliance Statement .............................................................. 13 5. CE RF Exposure Information .............................................................. 17 All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI. WM-BAC-AT-49 module, Wi-Fi/Bluetooth RF user manual, revision 1.0 Page 3 1. Introduction The WM-BAC-AT-49 combo module is one of the product families in USI’s product offering, targeting for system integration requiring a smaller form factor. It also provides the standard migration to high data rate for USI’s current SIP customers. The purpose of this document is defined the product specification for 802.11a/b/g/n/ac Wi-Fi with BT5.1 combo module. All the data in this document is based on Qualcomm QCN7606 datasheet and other documents provided from Qualcomm. The data will be updated after implementing the measurement of the module. This product is designated for using in embedded applications mainly in the IoT device, which required small size and high data rate wireless connectivity. 1.1 Brief Technology Features  Full IEEE 802.11a/b/g/n/ac legacy compatibility.  Support 20, 40 and 80MHz channels for the 2x2 5GHz radio, and 20 MHz channels for the 2x2 2.4GHz radio.  Lead Free design which supporting Green design requirement, RoHS Compliance, and halogen- free.  Small size suitable for low volume system integration. Low power consumption & excellent power management performance extend battery life.  2.412-2.484 GHz and 5.15 -5.9GHz two SKUs for worldwide market.  Easy for integrating into IoT device with flexible system configuration and antenna design. 1.2 Wireless Specification The WM-BAC-AT-49 module complies with the following features and standards; Features Description WLAN Standards IEEE 802 Part 11a/b/g/n/ac Bluetooth Bluetooth TM 5.1 compliance Antenna Port Support 2 streaming antennas 1. a single Dual-Band Antenna Port for Wi-Fi on WL_ANT1 2. a single Dual-Band Antenna Port for Wi-Fi on WL_ANT2 3. a single-Band Antenna Port for BT Frequency band 2.412 to 2.462GHz (1 to 11 channels ) 5.180 to 5.825GHz All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI. WM-BAC-AT-49 module, Wi-Fi/Bluetooth RF user manual, revision 1.0 Page 4 2. OEM Integrators Installation Manual 2.1 Important Notice to OEM integrators 1. This module is limited to OEM installation ONLY. 2. This module is limited to installation in mobile or fixed applications, according to Part 2.1091(b). 3. The separate approval is required for all other operating configurations, including portable configurations with respect to Part 2.1093 and different antenna configurations 4. For FCC Part 15.31 (h) and (k): The host manufacturer is responsible for additional testing to verify compliance as a composite system. When testing the host device for compliance with Part 15 Subpart B, the host manufacturer is required to show compliance with Part 15 Subpart B while the transmitter module(s) are installed and operating. The modules should be transmitting and the evaluation should confirm that the module's intentional emissions are compliant (i.e. fundamental and out of band emissions). The host manufacturer must verify that there are no additional unintentional emissions other than what is permitted in Part 15 Subpart B or emissions are complaint with the transmitter(s) rule(s). Antenna Installation (1) The antenna must be installed such that 20 cm is maintained between the antenna and users. (2) The transmitter module may not be co-located with any other transmitter or antenna. (3) To comply with FCC/IC regulations limiting both maximum RF output power and human exposure to RF radiation, the maximum antenna gain including cable loss in a mobile exposure condition must not exceed: Peak gain of WiFi Antenna: 。 3.18 dBi @ 2.4 GHz Band 。 2.67 dBi @ 5.15GHz – 5.25GHz 。 2.27 dBi @ 5.25GHz – 5.35GHz 。 2.07 dBi @ 5.47GHz – 5.725GHz 。 1.78 dBi @ 5.725GHz – 5.85GHz Peak gain of Bluetooth Antenna: 。 1.23 dBi @ 2.4 GHz Band In the event that these conditions cannot be met (for example certain laptop configurations or co- location with another transmitter), then the FCC/IC authorization is no longer considered valid and the FCC ID/IC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC/IC authorization. All rights are res…

Text truncated - open the document above for the full version.

DFS client device channel plan and software operational declaration Date: 2021-02-04 We, Universal Global Scientific Industrial Co., Ltd., declare that the device, FCC ID: COF-WMBACAT49 Model Name: WM-BAC-AT-49, does not have Ad Hoc on “non-US frequencies” and/or on“ DFS frequencies“. Also, the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons and support for ad-hoc peer-to-peer modes. Below is the channel / frequency plan for the device 2.4G Band 5G band 1 5G band 2 5G band 3 CH 1 2 3 4 5 6 7 8 9 10 11 Frequency (MHz) 2412 2417 2422 2427 2432 2437 2442 2447 2452 2457 2462 Scan Type Active Active Active Active Active Active Active Active Active Active Active CH 36 38 40 42 44 46 48 Frequency (MHz) 5180 5190 5200 5210 5220 5230 5240 Scan Type Active Active Active Active Active Active Active CH 52 54 56 58 60 62 64 Frequency (MHz) 5260 5270 5280 5290 5300 5310 5320 Scan Type Passive Passive Passive Passive Passive Passive Passive CH 100 102 104 106 108 110 112 116 118 120 122 Frequency (MHz) 5500 5510 5520 5530 5540 5550 5560 5580 5590 5600 5610 Scan Type Passive Passive Passive Passive Passive Passive Passive Passive Passive Passive Passive CH 124 126 128 132 134 136 138 140 142 144 Frequency (MHz) 5620 5630 5640 5660 5670 5680 5690 5700 5710 5720 Scan Type Passive Passive Passive Passive Passive Passive Passive Passive Passive Passive

FCC ID: COF-WMBACAT49 Report No.: RFBERD-WTW-P20110669-4, RFBERD-WTW-P20110669, RFBERD-WTW-P20110669-1, RFBERD-WTW-P20110669-2, RFBERD-WTW-P20110669-3,SABERD-WTW-P20110669 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch February 18, 2021 Dear Application Examiner, Universal Global Scientific Industrial Co., Ltd., WM-BAC-AT-49, FCC ID: COF-WMBACAT49 would like to have your authorization as a modular approval specific to the mobile RF exposure condition. The requirements of KDB996369 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip WM-BAC-AT-49. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is WM-BAC-AT-49. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a USB extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: COF-WMBACAT49 Report No.: RFBERD-WTW-P20110669-4, RFBERD-WTW-P20110669, RFBERD-WTW-P20110669-1, RFBERD-WTW-P20110669-2, RFBERD-WTW-P20110669-3,SABERD-WTW-P20110669 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Debby Lin Senior Specialist Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

Reference No.: BERD-WTW-P20110669_EXT 1 of 7 CONSTRUCTION PHOTOS OF EUT Brand: USI / Model: WM-BAC-AT-49 EUT BT Dipole Antenna WLAN Dipole Antenna A WLAN Dipole Antenna B Reference No.: BERD-WTW-P20110669_EXT 2 of 7 Reference No.: BERD-WTW-P20110669_EXT 3 of 7 Reference No.: BERD-WTW-P20110669_EXT 4 of 7 Reference No.: BERD-WTW-P20110669_EXT 5 of 7 Reference No.: BERD-WTW-P20110669_EXT 6 of 7 Reference No.: BERD-WTW-P20110669_EXT 7 of 7
