DGZALC24BProgrammable Switches

Intermatic Inc

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 17, 2024
Application Purpose: Original Equipment
Date of Application: Mar 17, 2024
Equipment Note: Programmable Switches
Frequency Range: 2402.00000000 - 2480.00000000
Company: Intermatic Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

Intermatic Inc Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Intermatic Inc Address: 7777 Winn Road, Spring Grove, Illinois 60081, United States Product Name: Programmable Switches FCC ID: DGZALC24B Model(s): ALC-4B-BT, ALC-2B-BT 2.911(d)(5)(i) Equipment Type We, [Intermatic Inc] certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Signature: Name: Kimberly Boland Date: 2024-01-26 Title and Company name: Director of Engineering and Intermatic Inc NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Attestation Statements

Intermatic Inc Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Intermatic Inc Address: 7777 Winn Road, Spring Grove, Illinois 60081, United States Product Name: Programmable Switches FCC ID: DGZALC24B Model(s): ALC-4B-BT, ALC-2B-BT 2.911(d)(5)(ii) Applicant filing We, [Intermatic Inc] certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Signature: Name: Kimberly Boland Date: 2024-01-26 Title and Company name: Director of Engineering and Intermatic Inc NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Attestation Statements

Intermatic Inc Section 2.911(d)(7) USA Agent for Service of Process Company name: Intermatic Inc Address: 7777 Winn Road, Spring Grove, Illinois 60081, United States Product Name: Programmable Switches FCC ID: DGZALC24B Model(s): ALC-4B-BT, ALC-2B-BT 2.911(d)(7) USA Designated Agent for Service of Process We, [Intermatic Inc] designate [Intermatic Inc] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent:We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation:We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email add ress for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Intermatic Inc USA Agent Company name: Intermatic Inc Address: 7777 Winn Road, Spring Grove, Illinois 60081, United States FRN: 0009224528 Contact Name: Kimberly Boland Telephone No: 815-675-7730 Email: [email protected] Applicant Company name: Intermatic Inc Address: 7777 Winn Road, Spring Grove, Illinois 60081, United States FRN: 0009224528 Contact Name: Kimberly Boland Telephone No: 815-675-7730 Email: [email protected] Signature: Title: Director of Engineering Signature: Title: Director of Engineering Date: 2024-01-26 Date: 2024-01-26 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Cover Letter(s)

Differences Declaration To whom concern, We company Intermatic Inc hereby declares: The product models ALC-4B-BT, ALC-2B-BT are identical in the same PCB layout, interior structure and electrical circuits, the difference is the for ALC-4B-BT for 4 key control, ALC-2B-BT for 2 key control. Authorized signature: Date: 2024-01-26

Cover Letter(s)

Intermatic Inc Agent Authorization Company: Intermatic Inc Address: 7777 Winn Road, Spring Grove, Illinois 60081, United States Product Name: Programmable Switches Model Number(s): ALC-4B-BT, ALC-2B-BT Product Description: Programmable Switches We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023-01-26 Name: Kimberly Boland Title: Director of Engineering Company: Intermatic Inc

ID Label/Location Info

遥控正面 ALC-4B-BT Battery: 3V,245 mA (CR2032) Ambient Operating Temperature: 0°C to +55°C Made in China 遥控正面遥控背面 INTERMATIC INC. FCC ID: DGZALC24B IC:4898A-ALC24B E490285 WWY TOPTOP 正面背面 ALC-4B-BT Power Input: 24VDC,2mA or 3V, 245 mA Battery (CR2032) Made in China INTERMATIC INC. Ambient Operating Temperature: 0°C to +55°C FCC ID: DGZALC24B IC:4898A-ALC24B 22-16AWG E490285 WWY Class 2 ALC-2B-BT Battery: 3V,245 mA (CR2032) Ambient Operating Temperature: 0°C to +55°C Made in China 遥遥控控正正面面遥控背面 INTERMATIC INC. FCC ID: DGZALC24B IC:4898A-ALC24B E490285 WWY TOPTOP 正面背面 ALC-2B-BT Power Input: 24VDC,2mA or 3V, 245 mA Battery (CR2032) Made in China INTERMATIC INC. FCC ID: DGZALC24B IC:4898A-ALC24B Ambient Operating Temperature: 0°C to +55°C 22-16AWG E490285 WWY Class 2

RF Exposure Info

FCC ID: DGZALC24B RF Exposure evaluation According to 447498 D04 Interim General RF Exposure Guidance v01 ERP/EIRP = P T +G T −L C ERP/EIRP is the equivalent (or effective) radiated power [in same units as P T , typically dBW, dBm, or power spectral density (psd)], relative to either a dipole antenna (ERP) or an isotropic antenna (EIRP). P T is the transmitter output power, in dBW, dBm, or psd (power over a specified reference bandwidth). G T is the gain of the transmitting antenna, in dBd (ERP) or dBi (EIRP). L C is the signal attenuation in the connecting cable between the transmitter and the antenna, in dB. For BLE mode Frequency (MHz) Output power to antenna (dBm) Ant gain(dBi) EIRP(dBm) ERP(dBm) ERP(mw) Distance (cm) P th (mW) 2440 6.39 -3.34 3.05 0.9 1.23 0.5 2.8 ERP = EIRP −2.15 dB WORSE CASE 1.23mW<2.8mW Remark: Then SAR evaluation is not required

Test Report

Report No.:GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 1 of 15 AppendixA: DTS Bandwidth Test Result Test Mode Antenna Frequency[MHz] DTS BW [MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.6784 0.5 PASS BLE_1M Ant1 2440 0.6778 0.5 PASS BLE_1M Ant1 2480 0.6897 0.5 PASS BLE_2M Ant1 2402 1.112 0.5 PASS BLE_2M Ant1 2440 1.124 0.5 PASS BLE_2M Ant1 2480 1.134 0.5 PASS Report No.:GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 15 Test Graphs BLE_1M-Ant1-2402 BLE_1M-Ant1-2440 BLE_1M-Ant1-2480 BLE_2M-Ant1-2402 BLE_2M-Ant1-2440 BLE_2M-Ant1-2480 Report No.:GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 15 AppendixB: Occupied Channel Bandwidth Test Result TestMode Antenna Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 1.0425 2401.5074 2402.5499 --- --- BLE_1M Ant1 2440 1.0504 2439.5003 2440.5507 --- --- BLE_1M Ant1 2480 1.0470 2479.5039 2480.5509 --- --- BLE_2M Ant1 2402 2.0332 2401.0198 2403.0530 --- --- BLE_2M Ant1 2440 2.0343 2439.0219 2441.0562 --- --- BLE_2M Ant1 2480 2.0385 2479.0195 2481.0580 --- --- Report No.:GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 15 Test Graphs BLE_1M-Ant1-2402 BLE_1M-Ant1-2440 BLE_1M-Ant1-2480 BLE_2M-Ant1-2402 BLE_2M-Ant1-2440 BLE_2M-Ant1-2480 Report No.:GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 5 of 15 AppendixC: Maximum conducted output power Test Result Test Mode Antenna Frequency[MHz] Conducted Peak Power[dBm] Conducted Limit[dBm] Gain [dBi] EIRP[dBm] EIRP Limit[dBm] Verdict BLE_1M Ant1 2402 6.3 ≤30 -3.34 2.96 -- PASS BLE_1M Ant1 2440 6.39 ≤30 -3.34 3.05 -- PASS BLE_1M Ant1 2480 5.73 ≤30 -3.34 2.39 -- PASS BLE_2M Ant1 2402 6.29 ≤30 -3.34 2.95 -- PASS BLE_2M Ant1 2440 6.34 ≤30 -3.34 3.00 -- PASS BLE_2M Ant1 2480 5.68 ≤30 -3.34 2.34 -- PASS Report No.:GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 6 of 15 Test Graphs BLE_1M-Ant1-2402 BLE_1M-Ant1-2440 BLE_1M-Ant1-2480 BLE_2M-Ant1-2402 BLE_2M-Ant1-2440 BLE_2M-Ant1-2480 Report No.:GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 7 of 15 AppendixD: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE_1M Ant1 2402 -9.53 ≤8.00 PASS BLE_1M Ant1 2440 -9.34 ≤8.00 PASS BLE_1M Ant1 2480 -10.03 ≤8.00 PASS BLE_2M Ant1 2402 -12.15 ≤8.00 PASS BLE_2M Ant1 2440 -12.03 ≤8.00 PASS BLE_2M Ant1 2480 -12.81 ≤8.00 PASS Report No.:GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 8 of 15 Test Graphs BLE_1M-Ant1-2402 BLE_1M-Ant1-2440 BLE_1M-Ant1-2480 BLE_2M-Ant1-2402 BLE_2M-Ant1-2440 BLE_2M-Ant1-2480 Report No.:GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 9 of 15 AppendixE:Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 Low 2402 5.97 -46.61 ≤-14.03 PASS BLE_1M Ant1 High 2480 5.16 -48.29 ≤-14.85 PASS BLE_2M Ant1 Low 2402 5.61 -27.29 ≤-14.39 PASS BLE_2M Ant1 High 2480 5.23 -48.46 ≤-14.77 PASS Test Graphs BLE_1M-Ant1-2402 BLE_1M-Ant1-2480 BLE_2M-Ant1-2402 BLE_2M-Ant1-2480 Report No.:GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 10 of 15 AppendixF:Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 0~Reference 5.93 5.93 --- PASS BLE_1M Ant1 2402 30~1000 5.93 -62.56 ≤-14.07 PASS BLE_1M Ant1 2402 1000~26500 5.93 -47.77 ≤-14.07 PASS BLE_1M Ant1 2440 0~Reference 5.87 5.87 --- PASS BLE_1M Ant1 2440 30~1000 5.87 -61.93 ≤-14.13 PASS BLE_1M Ant1 2440 1000~26500 5.87 -49.27 ≤-14.13 PASS BLE_1M Ant1 2480 0~Reference 5.36 5.36 --- PASS BLE_1M Ant1 2480 30~1000 5.36 -61.8 ≤-14.64 PASS BLE_1M Ant1 2480 1000~26500 5.36 -49.76 ≤-14.64 PASS BLE_2M Ant1 2402 0~Reference 5.75 5.75 --- PASS BLE_2M Ant1 2402 30~1000 5.75 -61.97 ≤-14.25 PASS BLE_2M Ant1 2402 1000~26500 5.75 -4…

Text truncated - open the document above for the full version.

Test Report

Global United Technology Services Co., Ltd. Report No.: GTS2024010241F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 47 TEST REPORT Applicant: Intermatic Inc Address of Applicant: 7777 Winn Road, Spring Grove, Illinois 60081, United States Manufacturer: Intermatic Inc Address of Manufacturer: 7777 Winn Road, Spring Grove, Illinois 60081, United States Equipment Under Test (EUT) Product Name: Programmable Switches Model No.: ALC-4B-BT, ALC-2B-BT FCC ID: DGZALC24B Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: January 18, 2024 Date of Test: January 19-26, 2024 Date of report issued: January 26, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 47 2 Version Version No. Date Description 00 January 26, 2024 Original Prepared By: Date: January 26, 2024 Project Engineer Check By: Date: January 26, 2024 Reviewer Report No.: GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 47 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 7 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.4 DEVIATION FROM STANDARDS ............................................................................................................. 7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................... 7 5.6 TEST FACILITY .................................................................................................................................... 7 5.7 TEST LOCATION ................................................................................................................................. 7 5.8 ADDITIONAL INSTRUCTIONS ................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA .................................................................................... 10 7.1 ANTENNA REQUIREMENT ................................................................................................................... 10 7.2 CONDUCTED EMISSIONS ................................................................................................................... 11 7.3 CONDUCTED OUTPUT POWER ........................................................................................................... 16 7.4 CHANNEL BANDWIDTH ...................................................................................................................... 17 7.5 POWER SPECTRAL DENSITY ............................................................................................................. 18 7.6 SPURIOUS EMISSION IN NON-RESTRICTED & RESTRICTED BANDS ....................................................... 19 7.6.1 Conducted Emission Method ..................................................................................................... 19 7.6.2 Radiated Emission Method ........................................................................................................ 20 8 TEST SETUP PHOTO ............................................................................................................................ 47 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 47 Report No.: GTS2024010241F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 47 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203/15.247 (c) Pass AC Power Line Conducted Emission 15.207 Pass Conducted Output Power 15.247 (b)(3) Pass Channel Bandwidth 15.247 (a)(2) Pass Power Spectral Density 15.247 (e) Pass Band Edge 15.247(d) Pass Spurious Emission 15.205/15.209 …

Text truncated - open the document above for the full version.
