DXACL22002.4GHz DSS Cordless Telephone

INCLUDED IN YOUR PACKAGE Cordless HandsetAC Adapter Base UnitUser Guide NiMH Battery10-foot, 4-wire RJ-11 Line Cord Rubber Battery Screw Cover15-foot, 8-wire RJ-45 Cable Phillips ScrewClear Plastic Overlay PREPARING TO USE THE CL1200 SERIES 1. Prepare to install the battery into the cordless handset by firmly pressing down on the top of the battery cover and sliding it off. If cover is secured with a screw, remove the screw first. 2. Locate the lightly embossed numbers “1” and “2” on the battery’s plastic connector. 3. Insert the battery connector into the handset’s connector with the embossed numbers facing up. Note: The handset may “beep” when the battery is connected. This is not an indication that the telephone is ready to use. To obtain optimal perform- ance of the telephone, be sure to charge the battery for 15 to 20 hours. 4. Replace the battery compartment cover and retaining screw. 5. Insert the provided rubber screw cover. 6. Turn the telephone base so the back panel is facing you. Insert either end of the RJ-45 cable into the jack on the back of the telephone labeled LINE. 7. Insert the other end of the cable into the jack on the AC adapter labeled PHONE. 8. Insert one end of the RJ-11 line cord into the jack on the AC adapter labeled LINE. 9. Insert the other end of this line cord into a telephone jack. 10. Plug the AC adapter into an unswitched electrical outlet. 11. Once your telephone is connected, remove the plastic overlay and place the paper faceplate over the keys. Replace the plastic overlay by hooking the tabs on the overlay into the recessed slots located on both sides. The overlay is easiest to insert when the left or right side tabs are inserted first, and the middle of the overlay is slightly bowed to allow for insertion of the other tabs. 12. Place the cordless handset on the base unit. CHARGING THE BATTERY The rechargeable Nickel Metal Hydride (NiMH) battery must be fully charged before using the phone for the first time. It is recom- mended that that battery pack be charged for approximately 15 to 20 hours, without interruption, before use. To charge the battery, place the handset, keypad down, in the base unit. Make sure the CHARGELED on the base lights. If the LED does not light: 1. Ensure that the AC adapter is plugged in. 2. Ensure that the AC adapter is not plugged into a switched electrical outlet. 3. Ensure that the handset charging contacts at the bottom of the handset are making good contact with the base unit’s charging contacts. CLEANING THE BATTERY CONTACTS To maintain a good charge, it is important to clean all charging contacts on the handset and base unit. Use a pencil eraser or other contact cleaner.Do not use any liquids or solvents . BATTERY SAFETY INSTRUCTIONS 1. Use only Teledex-approved battery replacements. 2. Dispose of used batteries according to local codes pertaining to NiMH batteries. 3. Do not dispose of batteries in fire, as they may explode 4. Charge the telephone's batteries only while in the telephone handset, and only by using the telephone base unit to charge. Do not attempt to remove the batteries and charge them in a separate charging unit. 5. Do not short-circuit the battery pack, as this may cause it to explode or catch fire. ADJUSTING THE RING VOLUME The up and down volume keys will adjust the ringer volume of the telephone. Additionally, the CL1200 series telephone has an optional “ascending” ring volume mode, where the ring volume begins at the lowest setting, then automatically rings louder with each successive ring during an incoming call. To select the ascending ring volume mode, follow these steps: Press the FLASHkey; then the 4key; then the STOREkey, then the number 1on the keypad. ADJUSTING SPEAKERPHONE VOLUME The speakerphone has eight (8) levels. When the speakerphone is activated, the volume is initially set at level six (6). To adjust the speakerphone volume, locate the volume up/down keys, located on the front surface of the phone below the keypad. Pressing the “down” arrow key will decrease the volume level, while pressing the “up” arrow key will increase it. ADJUSTING HANDSET RECEIVE VOLUME The handset has four (4) volume levels. The volume is initially set at level two (2). To adjust the handset volume, locate the volume up/down keys, located on the handset, below the “#”key. Pressing the “minus”(-)key will decrease the volume level, while pressing the “plus”(+)key will increase it. IMPORTANT SAFETY INSTRUCTIONS WHEN USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY PRECAU- TIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS, INCLUDING THE FOLLOWING: 1. READ AND UNDERSTAND ALL INSTRUCTIONS. 2. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE PRODUCT. 3. UNPLUG THE PRODUCT FROM THE WALL OUTLET BEFORE CLEANING. DO NOT USE LIQUID CLEANER OR AEROSOL CLEANERS. USE A DAMP CLOTH FOR CLEANING. 4. DO NOT USE THIS PRODUCT NEAR WATER, FOR EXAMPLE, NEAR A BATHTUB, WASH BOWL, KITCHEN SINK OR LAUNDRY TUB, IN A WET BASEMENT, OR NEAR A SWIMMING POOL. 5. DO NOT PLACE THIS PRODUCT ON AN UNSTABLE CART, STAND OR TABLE. THE PRODUCT MAY FALL, CAUSING SERIOUS DAMAGE TO THE PRODUCT. 6. SLOTS AND OPENINGS IN THE CABINET AND THE BACK OF BOTTOM ARE PROVIDED FOR VENTILATION, TO PROTECT IT FROM OVERHEATING. THESE OPENINGS MUST NOT BE BLOCKED OR COVERED. THE OPENINGS SHOULD NEVER BE BLOCKED BY PLACING THE PRODUCT ON THE BED, SOFA, RUG OR ANY OTHER SIMILAR SURFACE. THIS PRODUCT SHOULD NEVER BE PLACED NEAR OR OVER A RADIATOR OR HEAT REGISTER. THIS PRODUCT SHOULD NOT BE PLACED IN A BUILT-IN INSTALLATION UNLESS PROPER VENTILATION IS PROVIDED. 7. NEVER PUSH OBJECTS OF ANY KIND INTO THIS PRODUCT THROUGH CABINET SLOTS AS THEY MAY TOUCH DANGEROUS VOLTAGE POINTS OR SHORT OUT PARTS THAT COULD RESULT IN A RISK OF FIRE OR ELECTRIC SHOCK. NEVER SPILL LIQUID OF ANY KIND ON THE PRODUCT. 8. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT DISASSEMBLE THIS PRODUCT. BUT TAKE IT TO A QUALIFIED SERVICE FACILITY IF SERV…

Text truncated - open the document above for the full version.

9.6MHz

Chris Harvey From: Chris Harvey [[email protected]] Sent: Wednesday, March 10, 2004 7:27 AM To: 'Bandele Adepoju'; 'Chris Harvey' Cc: 'Mike Kuo' Subject: RE: Additional Information needed AN04T3649 Teledex FCC ID: DXACL2200 Sensitivity: Confidential Page 1 of 4Message 3/12/2004 Bandele, I should have asked you to define your term ‘data’ because I have always asked for the users RF exposure statements. I am sorry if I answered your question incorrectly. SAR testing documentation shows that you comply with the limits. The RF Exposure statements in the Users Manual are still required by the FCC Rules, as stated in FCC 15.247(b)(5) and mentioned in my original request. I have copied a sample of an appropriate RF Exposure statement below for your reference. Although the design of the phone in question did not require Body-worn testing or statements, I have included the example text for body-worn operation for your reference. FCC RF Exposure Information In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. This phone has been tested to and complies with the FCC guidelines and these international standards. Body-worn Operation: This device was tested for typical body-worn operations using the supplied belt-clip. The use of other belt-clip/holsters and other non-tested accessories may not comply with FCC RF Exposure requirements and should be avoided. P R E C A U T I O N S & I hope I have been much clearer. Please contact me if you have any further questions. Best regards, Chris Harvey [email protected] -----Original Message----- From: Bandele Adepoju [mailto:[email protected]] Sent: Wednesday, March 10, 2004 3:18 AM To: 'Chris Harvey' Cc: 'Mike Kuo' Subject: RE: Additional Information needed AN04T3649 Teledex FCC ID: DXACL2200 Sensitivity: Confidential Hello Chris, I thought that you had said that the RF Exposure data is not necessary if SAR data is provided, that the SAR testing/compliance would meet the requirement for RF Exposure compliance. Is there anything beyond the SAR testing that I need to provide? Regards, Bandele Adepoju ITC Engineering Services, Inc Engineering Services Company including Compliance Services 9959 Calaveras Road, Sunol, CA 94586-0543 Tel: +1 (925) 862-2944 Fax: +1 (925) 862-9013 website: www.itcemc.com <http://www.itcemc.com> ********************************************************************** This message and any files attached are intended only for the recipients above, and contain information that may be confidential, proprietary or privileged. If you are not the intended or correct recipient, you must not read, copy, distribute, use or disclose this message and its attachments. Please also notify the sender by replying to this message, and then delete all copies of it from your system. ********************************************************************* -----Original Message----- From: Chris Harvey [mailto:[email protected]] Sent: Monday, March 08, 2004 12:59 PM To: 'Bandele Adepoju'; Chris Harvey Cc: Mike Kuo Subject: RE: Additional Information needed AN04T3649 Teledex FCC ID: DXACL2200 Sensitivity: Confidential Bandele, I am in the process of reviewing the RF Exposure SAR reports submitted. Please note that I could not find any documentation regarding the end of that same paragraph (I am duplicating here). I will continue to review the SAR reports while you are gathering that RF Exposure Users information. Additionally, no documentation could be found to show compliance with FCC 15.247(b)(5) RF Exposure requirements, including documentation that would be provided to the user regarding RF Exposure concerns/guidance. Best regards, Chris Harvey [email protected] -----Original Message----- From: Bandele Adepoju [mailto:[email protected]] Sent: Thursday, March 04, 2004 10:06 PM To: 'Chris Harvey' Cc: 'Mike Kuo' Subject: RE: Additional Information needed AN04T3649 Teledex FCC ID: DXACL2200 Importance: High Sensitivity: Confidential Hello Chris, Please find attached documents as requested. Regards, Bandele Adepoju ITC Engineering Services, Inc Engineering Services Company including Compliance Services 9959 Calaveras Road, Sunol, CA 94586-0543 Page 2 of 4Message 3/12/2004 Tel: +1 (925) 862-2944 Fax: +1 (925) 862-9013 website: www.itcemc.com <http://www.itcemc.com> ********************************************************************** This message and any files attached are intended only for the recipients above, and contain information that may be confidential, proprietary or privileged. If you are not the intended or correct recipient, you must not read, copy, distribute, use or disclose this message and its attachments. Please also notify the sender by replying to this message, and then delete all copies of it from your system. ******************************************************************** -----Original Message----- From: Chris Harvey [mailto:[email protected]] Sent: Friday, February 13, 2004 10:37 AM To: '[email protected]' Cc: Mike Kuo Subject: FW: Additional Information needed AN04T3649 Teledex FCC ID: DXACL2200 Bandele, The application referenced above has been reviewed and the following items need to be addressed. The Internal Photographs of the Base Unit show an area of the PC Board that remains covered by an RF Shield. Please submit a photograph showing the components under the RF shield. The Label & Location exhibits were submitted only for the Base Unit. Please submit Label and Location exhibit(s) for the Handset Unit. The Handset is a Portable transmitter operating in the 2.4GHz band with a reported power of 17.26dBm, or 53mW. According to the FCC's TCB Exclusion List (dated June 2001) this …

Text truncated - open the document above for the full version.

EUT Photographs For FCC Test Report No. 20031028-01-FC15 (External) on 2.4 GHz DSS Cordless Telephone (Digital Spread Spectrum Technology) FCC ID: DXACL2200 For the CL1200, CL2200 and CL2400 Series Telephone Provided for evaluation by Teledex Corporation 6311 San Ignacio Drive San Jose CA 95119 United States report by ITC Engineering Services, Inc. 9959 Calaveras Road, Box 543 Sunol, California 94586-0543 Tel: (925) 862-2944 Fax: (925) 862-9013 Email: [email protected] Web Site: www.itcemc.com  EN45001 Accredited Compliance Laboratory (RES-GmbH) Lab Code 200172-0 Registration number: TTI-P-G 159/98-00 (RES-GmbH) Manufacturer: Teledex Corporation Report No.: 20031028-01-FC15 Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Sunol, California 94586-0543 Tel: +1(925) 862-2944 Fax: +1(925) 862-9013 Email: [email protected] Web: www.itcemc.com Teledex Cordless Telephone CL2200 Series FCC ID DXACL2200 Table of Contents TABLE OF CONTENTS............................................................................................................................................2 TABLE OF FIGURES................................................................................................................................................3 PART 1: DOCUMENTATION.............................................................................................................................4 GENERAL INFORMATION...........................................................................................................................................4 PART 2: EUT PHOTOS......................................................................................................................................5 Page 2 of 7 Manufacturer: Teledex Corporation Report No.: 20031028-01-FC15 Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Sunol, California 94586-0543 Tel: +1(925) 862-2944 Fax: +1(925) 862-9013 Email: [email protected] Web: www.itcemc.com Teledex Cordless Telephone CL2200 Series FCC ID DXACL2200 Table of Figures Figure 1: EUT and Power Supply Surface View........................................................................................................5 Figure 2: EUT and Power Supply Bottom View.........................................................................................................5 Figure 3: EUT Base and Handset..............................................................................................................................6 Figure 4: EUT and Power Supply Top View..............................................................................................................6 Figure 5: EUT Under Side.........................................................................................................................................7 Page 3 of 7 Applicant: Teledex Corporation Report No.: 20031028-01-FC15 Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Teledex Cordless Telephone CL2200 Series PART 1: DOCUMENTATION General Information Product Name Model(s) 2.4GHZ DSS Cordless Telephone CL1205, CL1210, CL2205 & CL2210 Manufacturer’s Name Manufacturer’s Address Contact Teledex Corporation 6311 San Ignacio Ave San Jose, CA 95119 United States Tel: +1(408) 363-3100 Maxim Bakaleynik Fax: +1(408) 363-3136 [email protected] Test Laboratory ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Sunol, CA 94586-0543 Email: [email protected] Web Site: http://www.itcemc.com Tel: +1(925) 862-2944 Fax: +1(925) 862-9013 Test Number and Report Numbers 20031028-01 20031028-01-FC15 Test Date(s) & Issue Date November 4,5,11 & 14, 2003 January 23, 2004 Test Engineer(s) Lan Vu and Bandele Adepoju Documentation Gurjit Khosa Total Number of Pages 7 The CL1200 and CL2200 Series Telephones include the following configurations: . CL2210 Cordless 2.4GHz 2 line with 10 speed dial buttons (Color Ash). CL2205 Cordless 2.4GHz 2 line with 5 speed dial buttons (Color Ash). CL1210 Cordless 2.4GHz 1 line with 10 speed dial buttons (Color Ash). CL1205 Cordless 2.4GHz 1 line with 5 speed dial buttons (Color Ash). CL2210 Cordless 2.4GHz 2 line with 10 speed dial buttons (Color Black). CL2205 Cordless 2.4GHz 2 line with 5 speed dial buttons (Color Black). CL1210 Cordless 2.4GHz 1 line with 10 speed dial buttons (Color Black). CL1205 Cordless 2.4GHz 1 line with 5 speed dial buttons (Color Black). The electronics circuitry is identical for all of models. The CL2400 series telephone is the OEM version of the CL2200 series telephone. There is no difference in electronics circuitry between the two telephones. All models are identical. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications specified in this report for compliance must be implemented in all production units for compliance to be maintained. Sunol, California 94586-0543 Tel: +1(925) 862-2944 Fax: +1(925) 862-9013 Email: [email protected] Web: www.itcemc.com FCC ID DXACL2200 Page 4 of 7 Applicant: Teledex Corporation Report No.: 20031028-01-FC15 PART 2: EUT PHOTOS Figure 1: EUT and Power Supply Surface View Figure 2: EUT and Power Supply Bottom View Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Teledex Cordless Telephone CL2200 Series Sunol, California 94586-0543 Tel: +1(925) 862-2944 Fax: +1(925) 862-9013 Email: [email protected] Web: www.itcemc.com FCC ID DXACL2200 Page 5 of 7 Applicant: Teledex Corporation Report No.: 20031028-01-FC15 EUT Photos (cont.) Figure 3: EUT Base and Handset Figure 4: EUT and Power Supply Top View Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Teledex Cordless Telephone CL2200 Series Sunol, California 94586-0543 Tel: +1(925) 862-2944 Fax: +1(925) 862-9013 Email: [email protected] Web: www.itcemc.com FCC ID DXACL2200 Page 6 of 7 Applicant: Teledex Corporation Report N…

Text truncated - open the document above for the full version.

TELEDEX CORPORATION 6311 SAN IGNACIO AVE. SAN JOSE, CA 95119 U.S.A. APPROVALS SIZE A SHEET 1 OF 1 DWG NO. 950-1995-00 SPECIFICATION CONTROL DRAWING INIT DATE DRAWN ______ _______ APPROVED SOURCES MFR COMMENTS MFR P/N REV DESCRIPTION DATE APPROVED UNLESS OTHERWISE NOTED DIMENSIONS ARE IN INCHES TOLERANCES: .XX .XXX .001 < FRACT ELEC. ______ _______ MECH. ______ _______ ENG. ______ _______ MFG. ______ _______ Q/A ______ _______ PRODUCT LINE REV 1. 3 GIS 7/ 18/03 LABEL FCC CL2.4 GHz FAMILY (FTI) PMIS + - 1.1 Modify table 1 according to new PN scheme for CL2.4GHz 10/22/03 IS pre-released 1.2 Add Teledex FCC ID number US:DXA 11/13/03 IS pre-released 1.3 Add FCC reg #, FCC ID# IC Canada # 12/4/03 IS 2.140 0.180 1.300 0.180 3 TABLE 1 CL2210 950-1995-10 CL2205 950-1995-05 CL1210 950-1996-10 CL1205 950-1996-05 MODEL LABEL P/N This product meets the applicable Industry of Canada technical specifications. This device complies with FCC rules Part 15 Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference including interference that may cause undesired operation. San Jose, CA, USA Model: This unit complies with FCC part 68 Rules as of Date of Manufacture FCC Registration No: US:DXA-WI-07B-CL2200 FCC ID: DXACL2200 IC: 617A-CL2200 Ringer Equivalence No: 0.7B Tel Co. Jack Type U S O C RJ11C Made in China "HAC"/ "VC" CONFORMS TO ANSI/UL STD. 1950 2002170 US C

Document title : Label Location Diagram Product :CL2210, CL2205, CL1210, CL1205 Document No : 016-2210-00 Revision : 1 DATE CODE LABEL (2) DAMAGE / WARRANTY LABEL (4) MANUFACTURE LABEL (5) FCC LABEL (1) PRODUCTION SERIES LABEL (3) TELEDEX LLC 6311 San Ignacio Ave. San Jose, California 95119 DATE : 11/12/2003 NOTE: Q. C. PASSED LABEL IS PLACED ON THIS BOTTOM SURFACE WHEN APPROPRIATE. CANADA LABEL (6)

Document title : Label Location Product :CL2210, CL2205, CL1210, CL1205 Document No : Revision : 1 MODEL LABEL 016-2210-00 TELEDEX LLC 6311 San Ignacio Ave. San Jose, California 95119 DATE : 11/12/2003 CL2210 CL2205 CL1210 CL1205 MODEL No: SERIAL NUMBER MODEL LABEL PAGE 2

EUT Photographs For FCC Test Report No. 20031028-01-FC15 (Internal) on 2.4 GHz DSS Cordless Telephone (Digital Spread Spectrum Technology) FCC ID: DXACL2200 For the CL1200, CL2200 and CL2400 Series Telephone Provided for evaluation by Teledex Corporation 6311 San Ignacio Drive San Jose CA 95119 United States report by ITC Engineering Services, Inc. 9959 Calaveras Road, Box 543 Sunol, California 94586-0543 Tel: (925) 862-2944 Fax: (925) 862-9013 Email: [email protected] Web Site: www.itcemc.com  EN45001 Accredited Compliance Laboratory (RES-GmbH) Lab Code 200172-0 Registration number: TTI-P-G 159/98-00 (RES-GmbH) Manufacturer: Teledex Corporation Report No.: 20031028-01-FC15 Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Sunol, California 94586-0543 Tel: +1(925) 862-2944 Fax: +1(925) 862-9013 Email: [email protected] Web: www.itcemc.com Teledex Cordless Telephone CL2200 Series FCC ID DXACL2200 Table of Contents TABLE OF CONTENTS............................................................................................................................................2 TABLE OF FIGURES................................................................................................................................................3 PART 1: DOCUMENTATION.............................................................................................................................4 GENERAL INFORMATION...........................................................................................................................................4 PART 2: EUT PHOTOS......................................................................................................................................5 Page 2 of 11 Manufacturer: Teledex Corporation Report No.: 20031028-01-FC15 Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Sunol, California 94586-0543 Tel: +1(925) 862-2944 Fax: +1(925) 862-9013 Email: [email protected] Web: www.itcemc.com Teledex Cordless Telephone CL2200 Series FCC ID DXACL2200 Table of Figures Figure 1: Base Unit – Antenna View..........................................................................................................................5 Figure 2: Handset Unit – Antenna View....................................................................................................................5 Figure 3: Base Unit – Overhead View.......................................................................................................................6 Figure 4: Base Unit – Main PCB Bottom View..........................................................................................................6 Figure 5: Base Unit – Top View - with Antenna Circuit Cover...................................................................................7 Figure 6: Base Unit – Main PCB Top View - without Antenna Circuit Cover............................................................7 Figure 7: Handset Unit – Main PCB Bottom View.....................................................................................................8 Figure 8: Handset Unit – Main PCB Overhead View.................................................................................................8 Figure 9: Handset Unit – Main PCB Top View - with Antenna Circuit Cover............................................................9 Figure 10: Handset Unit – Main PCB Top View - without Antenna Circuit Cover.....................................................9 Figure 11: Base Unit – Keypad and PCB Bottom View...........................................................................................10 Figure 12: Base Unit – Keypad PCB Bottom View..................................................................................................10 Figure 13: Base Unit – Keypad PCB Top View.......................................................................................................11 Page 3 of 11 Applicant: Teledex Corporation Report No.: 20031028-01-FC15 Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Teledex Cordless Telephone CL2200 Series PART 1: DOCUMENTATION General Information Product Name Model(s) 2.4GHZ DSS Cordless Telephone CL1205, CL1210, CL2205 & CL2210 Manufacturer’s Name Manufacturer’s Address Contact Teledex Corporation 6311 San Ignacio Ave San Jose, CA 95119 United States Tel: +1(408) 363-3100 Maxim Bakaleynik Fax: +1(408) 363-3136 [email protected] Test Laboratory ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Sunol, CA 94586-0543 Email: [email protected] Web Site: http://www.itcemc.com Tel: +1(925) 862-2944 Fax: +1(925) 862-9013 Test Number and Report Numbers 20031028-01 20031028-01-FC15 Test Date(s) & Issue Date November 4,5,11 & 14, 2003 January 23, 2004 Test Engineer(s) Lan Vu and Bandele Adepoju Documentation Gurjit Khosa Total Number of Pages 11 The CL1200 and CL2200 Series Telephones include the following configurations: . CL2210 Cordless 2.4GHz 2 line with 10 speed dial buttons (Color Ash). CL2205 Cordless 2.4GHz 2 line with 5 speed dial buttons (Color Ash). CL1210 Cordless 2.4GHz 1 line with 10 speed dial buttons (Color Ash). CL1205 Cordless 2.4GHz 1 line with 5 speed dial buttons (Color Ash). CL2210 Cordless 2.4GHz 2 line with 10 speed dial buttons (Color Black). CL2205 Cordless 2.4GHz 2 line with 5 speed dial buttons (Color Black). CL1210 Cordless 2.4GHz 1 line with 10 speed dial buttons (Color Black). CL1205 Cordless 2.4GHz 1 line with 5 speed dial buttons (Color Black). The electronics circuitry is identical for all of models. The CL2400 series telephone is the OEM version of the CL2200 series telephone. There is no difference in electronics circuitry between the two telephones. All models are identical. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications specified in this …

Text truncated - open the document above for the full version.

EUT Photographs (Internal) for FCC Test Report No. 20031028-01-FC15 on 2.4 GHz DSS Cordless Telephone (Digital Spread Spectrum Technology) FCC ID: DXACL2200 For the CL1200, CL2200 and CL2400 Series Telephone Provided for evaluation by Teledex Corporation 6311 San Ignacio Drive San Jose CA 95119 United States report by ITC Engineering Services, Inc. 9959 Calaveras Road, Box 543 Sunol, California 94586-0543 Tel: (925) 862-2944 Fax: (925) 862-9013 Email: [email protected] Web Site: www.itcemc.com  EN45001 Accredited Compliance Laboratory (RES-GmbH) Lab Code 200172-0 Registration number: TTI-P-G 159/98-00 (RES-GmbH) Manufacturer: Teledex Corporation Report No.: 20031028-01-RS210 Prepared By: International Technology Company 9959 Calaveras Road, PO Box 543 Sunol, California 94586-0543 Tel: [925] 862-2944 Fax: [925] 862-9013 Email: [email protected] Web: www.itcemc.com Teledex Cordless Telephone CL2200 Series IC: 617A-CL2200 EUT Photographs Figure 1: Base Unit – Top View - with RF Circuit Covers Figure 2: Base Unit – Main PCB Top View - without RF Circuit Covers

TELEDEX LLC 6311 San Ignacio Avenue, San Jose, California 95119 Tel: 408-363-3100, Fax: 408-363-3136 www.teledex.com Theory of operations Cordless 22XX Phones Teledex LLC TELEDEX LLC 6311 San Ignacio Avenue, San Jose, California 95119 Tel: 408-363-3100, Fax: 408-363-3136 www.teledex.com Operational Theory The CL22XX family is a cordless telephone for residential or business use. It is designed for analog PSTN interface. Main blocks are System Controller, Baseband Controller, Audio Codec, DSS Transceiver, Power Amplifier and Antenna. The base unit powered by 9V wall adapter, handset is powered by 3 sell NiMN rechargeable battery. Block Diagram System Controller The system controller handles all of the phone features, the DSS engine, the RF module settings, and the link between the base station and the handset. The system controller provides a microcontroller with interrupt, wait-state, and system timer support. The system controller also provides General Purpose I/O (GPIO) and serial ports for peripheral control, a baseband modem (DSS engine) for signal processing of the received and transmitted data, and an audio modem for ADPCM conversion. Baseband Controller TELEDEX LLC 6311 San Ignacio Avenue, San Jose, California 95119 Tel: 408-363-3100, Fax: 408-363-3136 www.teledex.com The baseband modem section performs all of the spread spectrum modulation and demodulation, data timing recovery, AFC, AGC, framing, and rate adaptation required for a DSS system. Transmit/Receive Data Paths The transmit data path comprises a parallel-to-serial converter, scrambler, differential encoder, spreader, and modulator. The receive data path comprises analog-to- digital converters, matched filter with frequency compensation insertion, data demodulator, descrambler and serial-to-parallel converter. Scrambler/Descrambler The scrambler/descrambler is a 16-bit maximum length PN sequence generator. Its output is XOR’ed with TX data for scrambling and XOR’ed with RX data for descrambling. The voice and supervisory bits are scrambled. The PN sequence generator’s starting location is programmable using one memory mapped register along with the two ID registers. This starting location is used to initialize the PN generator at the start of each link. The MSB of the PN generator is used to scramble/descramble. The first frame bit scrambled/descrambled uses the initialized value of the MSB. Spread Spectrum Spreader A 1 2-chip spreading code is used to meet FCC part 15.247 requirements for a DSS system. The spreading code cyclic duration is 1 2 times that of the encoded data. The code starts and stops on encoded bit boundaries. The spreading code may be configured by the controller. The data from the differential encoder is input to the modulator. An analog block exists at th…
