E9MWX1wireless microphone for harmonica

WX1 Transmitter Module User Instructions . . . . . . . . . . . . . . . . . . . . . p. 2 Please read the manual before using the equipment! Modo de empleo . . . . . . . . . . . . . . . . . . . . . p. 7 Antes de utilizar el equipo, sírvase leer el manual! Mode d’emploi . . . . . . . . . . . . . . . . . . . . . . p. 12 Veuillez lire cette notice avant d’utiliser le système! Istruzioni per l’uso . . . . . . . . . . . . . . . . . . . p. 17 Prima di utilizzare l’apparecchio, leggere il manuale! Instruções de uso . . . . . . . . . . . . . . . . . . . p. 22 Favor leia este manual antes de usar o equipamento! Bedienungshinweise . . . . . . . . . . . . . . . . . S. 27 Bitte vor Inbetriebnahme des Gerätes lesen! WX1-Hex 10/06/05 17:38 Uhr Seite 1 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 74 of the FCC Rules. These limits are designed to provide reasonable protec- tion against harmful interference in a res- idential installation. This equipment gen- erates, uses, and can radiate radio fre- quency energy and, if not installed and used in accordance with the instruc- tions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfer- ence to radio or television reception, which can be determined by turning the equipment off and on, the user is encour- aged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving an- tenna. •Increase the separation between the equipment and the receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Shielded cables and I/O cords must be used for this equipment to comply with the relevant FCC regulations. Changes or modifications not expressly approved in writing by HARMONIX may void the user’s authority to operate this equipment. 1.1 Safety 1.Do not expose the equipment to direct sunlight, excessive dust, mois- ture, rain, mechanical vibrations, or shock. 1.2 Environment 1. Be sure to dispose of used batteries as required by local waste disposal rules. Never throw batteries into a fire (risk of explosion) or garbage bin. 2.When scrapping the equipment, remove the batteries, separate the case, circuit boards, and cables, and dispose of all components in accord- ance with local waste disposal rules. 3. The packaging of the equipment is recyclabe. To dispose of the packag- ing, make sure to use a collection/ recycling system provided for that 2 WX1 FCC Statement1 Safety and Environment WX1-Hex 10/06/05 17:38 Uhr Seite 2 purpose and observe local legislation relating to waste disposal and recy- cling. 2.1 Introduction Dear Customer: Thank you for purchasing a HARMONIX product. This Manual contains important instructions for setting up and operating your equipment. Please take a few minutes to read the instructions below carefully before operating the equip- ment.Please keep the Manual for future reference. Have fun and impress your audience! 2.2 Unpacking Check that the package contains all the parts listed below. If any item is missing, please contact your HARMONIX dealer. 2.3 Description The WX1 is a miniature transmitter with an integrated C 407 omnidirectional con- denser microphone. The transmitter has been specifically designed for use with the SR 40 HARMONIX UHF receiver. The WX1 operates on a single fixed, quartz stabilized carrier frequency in the 710 MHz to 865 MHz UHF band and uses a dipole antenna integrated in the transmitter body. Using tried and tested AKG technology, the WX1 ensures both excellent audio quality and uncommonly reliable recep- tion. 2.4 Controls 3 WX1 2 Description 1 WX1 transmitter 1 AAA size battery Manual Supplement Fig. 1: WX1 controls. WX1-Hex 10/06/05 17:38 Uhr Seite 3 Refer to fig. 1 on page 3: 1ON/MUTE/OFF:This slide switch provides three positions: ON:Power to the transmitter is on. M: The signal delivered by the micro- phone is muted while power and the RF carrier frequency remain on. This prevents the receiver from respond- ing to interference from other trans- mitters. OFF:Power to the transmitter is off. 2Status LED:Indicates battery status. LED flashes momentarily upon switching ON and extinguishes: the battery is OK. LED lights constantly: the battery will be dead in about 60 minutes. 3Input Gain:This rotary pot sets the sensitivity (gain) of the transmitter’s audio section. 4Battery compartmentfor one 1.5-V AAA size battery (supplied). 5Carrier frequency label:Lists the carrier frequency band and the carri- er frequency in MHz of your transmit- ter. You will also find these data on the transmitter packaging and in the Manual Supplement. 3.1 Inserting/Replacing and Testing the Battery 4 WX1 Fig. 2: Inserting the battery. 3 Setting Up WX1-Hex 10/06/05 17:38 Uhr Seite 4 Refer to fig. 2 on page 4: 1. Depress the locating buttons (6) at each end of the WX1 module. The module will drop out easily. The battery compartment has no cover. 2. If there is a dead or defective battery inside the battery compartment, re- move the battery. 3. Insert the supplied battery or a new AAA battery (7) into the battery com- partment as shown in fig. 2, making sure to align the battery with the "+" and "-" polarity symbols. 4. Set the ON/MUTE/OFF switch (1) to ON. (Refer to fig. 1.) •The status LED (2) will flash momen- tarily. If the battery is in good condi- tion, the status LED (2) will extin- guish. •If the status LED (2) remains lit con- stantly the battery will be dead within about 60 minutes. Replace the bat- tery with a new one as soon as possi- ble. •If the status LED (2) fails to flash at all, the battery is dead or inserted the wrong way. Insert a new battery or align the battery correctly with the "+" and "-" polarity symbols. 5. Insert the transmitter m…

Text truncated - open the document above for the full version.

Coverletter: AKG Acoustics US wants to get FCC-Certification for the following product: wireless microphone for harmonicas WX1. The unit will get the following FCC-ID: E9MWX1 List of documents: Exhibit Thema File Exhibit 01 Label and placement label_05-123.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern_05-123.pdf * Exhibit 04 Block Diagrams 2891BSch2_MicroTools.pdf * Exhibit 05 Schematic Diagrams 2891SCH04xx_10.pdf 2891SCH0301_30.pdf Exhibit 06 Testreport 05-123.pdf Exhibit 07 Test Set-up Photos setup_05-123.pdf Exhibit 08 User Manual WX1-Hex.pdf Exhibit 09 Internal Photos intern_05-123.pdf Exhibit 10 Informations CDF_US_FUNK_WX1.DOC Exhibit 11 RF exposure RF exposure compliance issues.doc * Exhibit 12 Operational Description Short description Micro-Tools.pdf Exhibit 13 Cover letter Request for confidentiality This file request for confidentiality.pdf For the Exhibits marked with ‘*’ AKG Acoustics US requested Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos is not the actual status. The correct labelling you can see on the photo “label” in Exhibit 1.

CONSTRUCTIONAL DATAFORM FOR TESTING OF RADIO EQUIPMENT Licence holder: AKG Acoustics, U.S. Address: 914 Airpark Center Dr.,Nashville, TN 37217,U.S.A. Manufacturer: Vtech Communications Ltd Address: Vtech Science Park, Xia Ling Bei Management Zone, Liabou, Dongguan Guangdong 523411 Type: WX1 Model: Serial-No.: Protection class: Additional informations to the above named model: Antenna: transmitter: Type: integral Length/size: dipole receiver: Type: Length/size: Power supply of the transmitter: Type: 1 AAA Cell or NiCd nominal voltage: 1.5 V lowest voltage: 1.05 V highest voltage: 1.6 V current consumption [email protected] Power supply of the receiver: Type: nominal voltage: V current consumption A Ancillary equipment: Description: Type: Serial-no.: Description: Type: Serial-no.: Description: Type: Serial-no.: Extreme temperature range in which the approval test should be performed: O Category I: General (-20°C to +55°C) X Category II: Portable (-10°C to +55°C) O Category III: Equipment for normal indoor use (0°C to +55°C) Connectable cables: Name of the cable Digital Length/m shielded O yes O no O yes O no O yes O no O yes O no O yes O no O yes O no O yes O no O yes O no O yes O no O yes O no Applicant: _______AKG________________Model-name: ____ WX1_________________ Type designation: WX1 Name and type designation of individual units comprising the radio equipment: Type of equipment: … Radiotelephone equipment … Remote-control equipment … Radiomaritime equipment … LPD … One-way radiotelephone equipment … Inductive loop system … Inland waterways equipment … RLAN … Personal paging system … Radio-relay system … Radionavigation equipm. X wireless microphone … Satellite earth station … CB radiotelephone equipment … Antenna … … Data transmission equipment … Movement detector … Aeronautical equipment … Technical characteristics: Transmitter-receiver Transmitter Receiver Frequency range 734.6..750.9MHz FCC (734.6..864.375 Europe) Maximum no. of channels Channel spacing 200k Class of emission (type of modulation) 200KF3E Maximum RF output power Maximum effective radiated power (ERP) 5mW+-3dB Output power variable no Channel switching frequency range 1 channel Method of frequency generation … Synthesizer X Crystal … Other Frequency generation TX Crystal/ multiplier Frequency generation RX IF 1st IF 2nd IF 3rd IF Integral selective calling no Audio-frequency interface level at external data socket 1.2Vrms for 60% of maximum deviation at 1kHz; impedance 4k7ohms / 3,8DC , capsule included audio bandwidth 50Hz-20kHz Modes of operation … Duplex mode … Semi-duplex mode X Simplex mode Power source … Mains … Vehicle-regulated x Integral Antenna socket … BNC … TNC … N … M … UHF … Adapter X None … … Test specifications: FCC Part 74 Applicant: _______AKG________________Model-name: ____ WX1_________________ Declarations: „ We declare that the above information are correct and the named model was supplied with the maximum configuration to the accredited test laboratory. Nashville, 27.10.05 ____________________________, date______________ ______________________________________________________ place of issue Seal and signature of applicant issued: Peter Tiefenthaler

RF exposure compliance issues: According to FCC Part 2.1093 this kind of transmitter is categorically excluded from routine SAR evaluation.
