QUATECH, INC. 5675 Hudson Industrial Parkway Hudson, Ohio 44236-5012 Toll free: 1-800-553-1170 http://www.quatech.com Quatech Device Server User’s Manual P/N: 940-0183-150 CONNECT WITH RELIABILITY Serial Device Server User’s Manual Copyright Copyright © 2005 Quatech, Inc. All rights are reserved. The information contained in this document cannot be reproduced in any form without the written consent of Quatech, Inc. Any software programs that might accompany this document can be used only in accordance with any license agreement(s) between the purchaser and Quatech, Inc. Quatech, Inc. reserves the right to change this documentation or the product to which it refers at any time and without notice. Trademarks QUATECHÆ is a registered trademark of Quatech, Inc. Other product and brand names listed in this manual may be trademarks of their respective owners. Disclaimer The information in this manual is believed to be accurate and reliable at the time of posting. Notwithstanding the foregoing, Quatech assumes no responsibility for any damage or loss resulting from the use of this manual, and expressly disclaims any liability or damages for loss of data, loss of use, and property damage of any kind, direct, incidental or consequential, in regard to or arising out of the performance or form of the materials presented herein or in any software program(s) that may accompany this document. Changes or modifications to this device not explicitly approved by Quatech will void the user's authority to operate this device. Feedback Quatech, Inc. encourages and appreciates feedback concerning this document. Please send any written comments to the Technical Support department at the address listed on the cover page of this manual. Quatech SDS User’s Manual Table of contents Rev 1.50 (3/13/2005) Page i Table of contents Introduction ----------------------------------------------------------------------------------------------------------------------- 1 Understanding how virtual communication ports work-------------------------------------------------------- 2 Understanding MAC and IP addresses and port numbers ----------------------------------------------- 2 Identifying operating modes--------------------------------------------------------------------------------------- 3 Identifying Quatechís SDS product line ----------------------------------------------------------------------------- 4 System requirements ----------------------------------------------------------------------------------------------------- 4 Features ---------------------------------------------------------------------------------------------------------------------- 5 Protocol support------------------------------------------------------------------------------------------------------- 5 Wi-Fi implementation ----------------------------------------------------------------------------------------------- 6 TCP socket services ñ IntelliSockô ----------------------------------------------------------------------------- 6 Getting started-------------------------------------------------------------------------------------------------------------- 7 Unpacking your SDS ------------------------------------------------------------------------------------------------ 7 Identifying parts ------------------------------------------------------------------------------------------------------ 8 Understanding LED codes ----------------------------------------------------------------------------------------- 9 Locating serial and network ports ------------------------------------------------------------------------------ 10 Making connections------------------------------------------------------------------------------------------------------------13 Enabling Wi-Fi Device Servers---------------------------------------------------------------------------------------------14 Installing the device drivers ------------------------------------------------------------------------------------------------16 Win NT Device Manager------------------------------------------------------------------------------------------------28 Win NT ñ Changing port numbers ----------------------------------------------------------------------------- 28 Uninstalling your SDS --------------------------------------------------------------------------------------------------28 Uninstalling from Windows XP/2000 -------------------------------------------------------------------------- 28 Uninstalling from Windows NT4 ------------------------------------------------------------------------------- 29 Alternative installation steps -----------------------------------------------------------------------------------------30 Configuring the SDS using the Web interface -------------------------------------------------------------------------44 Setting network parameters -------------------------------------------------------------------------------------------45 Setting TCP/IP (LAN) and Wi-Fi (Wireless) parameters ------------------------------------------------ 45 Setting SNMP parameters ---------------------------------------------------------------------------------------- 49 Viewing the serial port parameters----------------------------------------------------------------------------------52 Setting serial port parameters ----------------------------------------------------------------------------------------52 Setting Normal operating mode parameters ---------------------------------------------------------------- 52 Setting Tunneling operating mode parameters ------------------------------------------------------------ 55 Setting Raw TCP operating mode parameters-------------------------------------------------------------- 58 Setting Auto TCP operating mode parameters ------------------------------------------------------------- 61 Setting Raw UDP operating mode parameters ------------------------------------------------------------- 65 Running diagnostic tests-----------------------…

Text truncated - open the document above for the full version.

CONNECT WITH RELIABILITY Serial Device Server User’s Manual QUATECH, INC. 5675 Hudson Industrial Parkway Hudson, Ohio 44236-5012 Toll free: 1-800-553-1170 http://www.quatech.com Quatech Device Server User’s Manual P/N: 940-0183-151 Manual Revision 1.51 Copyright Copyright © 2005 Quatech, Inc. All rights are reserved. The information contained in this document cannot be reproduced in any form without the written consent of Quatech, Inc. Any software programs that might accompany this document can be used only in accordance with any license agreement(s) between the purchaser and Quatech, Inc. Quatech, Inc. reserves the right to change this documentation or the product to which it refers at any time and without notice. Trademarks QUATECH® is a registered trademark of Quatech, Inc. Other product and brand names listed in this manual may be trademarks of their respective owners. Disclaimer The information in this manual is believed to be accurate and reliable at the time of posting. Notwithstanding the foregoing, Quatech assumes no responsibility for any damage or loss resulting from the use of this manual, and expressly disclaims any liability or damages for loss of data, loss of use, and property damage of any kind, direct, incidental or consequential, in regard to or arising out of the performance or form of the materials presented herein or in any software program(s) that may accompany this document. Changes or modifications to this device not explicitly approved by Quatech will void the user's authority to operate this device. Feedback Quatech, Inc. encourages and appreciates feedback concerning this document. Please send any written comments to the Technical Support department at the address listed on the cover page of this manual. Quatech SDS User’s Manual Table of contents Table of contents Introduction----------------------------------------------------------------------------------------------------------------------- 1 Understanding how virtual communication ports work-------------------------------------------------------- 2 Understanding MAC and IP addresses and port numbers----------------------------------------------- 2 Identifying operating modes--------------------------------------------------------------------------------------- 3 Identifying Quatech’s SDS product line----------------------------------------------------------------------------- 4 System requirements----------------------------------------------------------------------------------------------------- 4 Features---------------------------------------------------------------------------------------------------------------------- 5 Protocol support------------------------------------------------------------------------------------------------------- 5 Wi-Fi implementation----------------------------------------------------------------------------------------------- 6 TCP socket services – IntelliSock™----------------------------------------------------------------------------- 6 Getting started-------------------------------------------------------------------------------------------------------------- 7 Unpacking your SDS------------------------------------------------------------------------------------------------ 7 Identifying parts------------------------------------------------------------------------------------------------------ 8 Understanding LED codes----------------------------------------------------------------------------------------- 9 Locating serial and network ports------------------------------------------------------------------------------ 10 Making connections------------------------------------------------------------------------------------------------------------13 Enabling Wi-Fi Device Servers---------------------------------------------------------------------------------------------14 Installing the device drivers------------------------------------------------------------------------------------------------16 Win NT Device Manager------------------------------------------------------------------------------------------------28 Win NT – Changing port numbers----------------------------------------------------------------------------- 28 Uninstalling your SDS--------------------------------------------------------------------------------------------------28 Uninstalling from Windows XP/2000-------------------------------------------------------------------------- 28 Uninstalling from Windows NT4------------------------------------------------------------------------------- 29 Alternative installation steps-----------------------------------------------------------------------------------------30 Configuring the SDS using the Web interface-------------------------------------------------------------------------44 Setting network parameters-------------------------------------------------------------------------------------------45 Setting TCP/IP (LAN) and Wi-Fi (Wireless) parameters------------------------------------------------ 45 Setting SNMP parameters---------------------------------------------------------------------------------------- 49 Viewing the serial port parameters----------------------------------------------------------------------------------52 Setting serial port parameters----------------------------------------------------------------------------------------52 Setting Normal operating mode parameters---------------------------------------------------------------- 52 Setting Tunneling operating mode parameters------------------------------------------------------------ 55 Setting Raw TCP operating mode parameters-------------------------------------------------------------- 58 Setting Auto TCP operating mode parameters------------------------------------------------------------- 61 Setting Raw UDP operating mode parameters------------------------------------------------------------- 65 Running diagnostic tests--------------------------------------------------------…

Text truncated - open the document above for the full version.

scott From: scott [[email protected]] Sent: Thursday, March 10, 2005 3:18 PM To: '[email protected]' Cc: '[email protected]'; '[email protected]' Subject: FCC ID: F4ATHINQ1 3/10/2005 Mr. Fujimoto: In order for processing of this application (FCC ID: F4ATHINQ1) to continue, the following issue(s) will have to be addressed: 1) The userʹs manual suggests (on page 51 of the pdf) that the device is capable of operating on channels 12‐14 as is allowed in Europe. Although it is stated that only channels 1 through 11 can be used in the United States, please indicate whether the user has the ability to operate on, and whether the user is given instructions for configuring the device to operate on, channels 12, 13, or 14, through a software and/or hardware change. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is F4ATHINQ1. Best regards, Scott McCutchan Operations Manager Compatible Electronics TCB 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Fax (714) 579-1850 [email protected] Correspondence by Project Project Number: 324926868 Correspondence Number Memo F4ATHINQ1 1. I am uploading an updated user manual. Also, the device is hard-coded at the factory with a limited range of channels 1-11.

DSEW-400D This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Part # 990-7001-01J Batch: 123456Rev: A QUATECH www.quatech.com 1234568 FCC ID: F4ATHINQ1 IC: 3913A-THINQ1 This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. DCDRxDTxDDTRGND DSRRTSCTSRI In-RxD+TxD+Out-RxD-Out+In+TxD- PIN: RS232 RS422 RS485 1234 5 6789 Data+Data- GND GND

MPE Calculations For RF Exposure Requirements ThinQ SDS Model: SSE/DSE-100/400 Page 1 of 1 MAXIMUM PERMISSIBLE EXPOSURE FOR SUBPART C 2.4 GHz BAND Calculations Power density at the specific separation: S = PG/(4R 2 π) S = (54.83 * 1.660) / (4 * 20 2 * π) S = 0.01811 mW/cm 2 where S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) – 17.39 dBm G = Numeric power gain of the antenna R = distance to the center of the radiation of the antenna (20 cm = limit for MPE) The maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density at 20 cm does not exceed the 1 mW/cm 2 . Therefore, the exposure condition is compliant with FCC rules. The numeric gain (G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain/10) G = Log -1 (2.2 dBi/10) G = 1.660

Report Number: B50211D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report ThinQ SDS Model: SSE/DSE-100/400 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 21 FCC PART 15, SUBPART B and C TEST REPORT for ThinQ SDS MODEL: SSE/DSE-100/400 Prepared for QUATECH, INC. 5675 HUDSON INDUSTRIAL PARKWAY HUDSON, OHIO 44236 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ MICHAEL CHRISTENSEN COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: FEBRUARY 14, 2005 REPORT APPENDICES TOTAL BODY A B C D E PAGES 21 2 2 2 20 73 120 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B50211D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report ThinQ SDS Model: SSE/DSE-100/400 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 21 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment 12 5.3 EMI Test Equipment Continued 13 6. TEST SITE DESCRIPTION 14 6.1 Test Facility Description 14 6.2 EUT Mounting, Bonding and Grounding 14 7. CHARACTERISTICS OF THE TRANSMITTER 15 7.1 Antenna Gain 15 8. TEST PROCEDURES 16 8.1 RF Emissions 16 8.1.1 Conducted Emissions Test 16 8.1.2 Radiated Emissions (Spurious and Harmonics) Test 17 8.2 6 dB and 20 dB Bandwidth 19 8.3 Peak Output Power 19 8.4 RF Antenna Conducted Test 19 8.5 Spectral Density Output 20 8.6 RF Band Edges 20 9. CONCLUSIONS 21 Report Number: B50211D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report ThinQ SDS Model: SSE/DSE-100/400 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 21 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map and Layout of 3 Meter Radiated Site 3 Plot Map and Layout of 10 Meter Radiated Site Report Number: B50211D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report ThinQ SDS Model: SSE/DSE-100/400 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 21 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST, or any other agency of the U.S. Government. Device Tested: ThinQ SDS Model: SSE/DSE-100/400 S/N: Prototype Product Description: See Expository Statement. Modifications: The EUT was modified during the testing. Please see the list located in Appendix B of this test report. Manufacturer: Quatech, Inc. 5675 Hudson Industrial Parkway Hudson, Ohio 44236 Test Dates: February 7, 8, and 9, 2005 Test Specifications : EMI requirements Limits: CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.247 Test Procedure: ANSI C63.4: 2003 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B50211D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report ThinQ SDS Model: SSE/DSE-100/400 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 21 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; and Subpart C, section 15.207 2 Spurious Radiated RF Emissions for the Receiver Portion, 10 kHz - 25000 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and CFR Title 47, Part 15, Subpart C, section 15.247(d) 3 Spurious Radiated RF Emissions for the Digital Portion, 30 MHz – 25000 MHz Complies with the Class A limits of CFR Title 47, Part 15, Subpart B 4 Fundamental and Emissions produced by the intentional radiator in non-restricted…

Text truncated - open the document above for the full version.

A Unit dBm TRG Ref Lvl 15 dBm Ref Lvl 15 dBm RF Att 40 dB P0 TDF Center 2.437 GHzSpan 50 MHz5 MHz/ RBW 100 kHz VBW 300 kHz SWT 12.5 ms IN1 1AP1VIEW 2VIEW2MA 10.Feb 2005 16:16 -80 -70 -60 -50 -40 -30 -20 -10 0 10 -85 15 1 T1 T2 Marker 1 [T2 ndB] ndB 6.00 dB BW 8.11623246 MHz 1 [T2] 3.85 dBm 2.43534669 GHz ndB 6.00 dB BW 8.11623246 MHz T1 [T2] -2.25 dBm 2.43314228 GHz T2 [T2] -2.33 dBm 2.44125852 GHz FCC_BF Date: 10.FEB.2005 16:16:05 -6 dB Bandwidth – Channel 6 Report Number: B50211D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report ThinQ SDS Model: SSE/DSE-100/400 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E1 APPENDIX E DATA SHEETS Report Number: B50211D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report ThinQ SDS Model: SSE/DSE-100/400 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E2 RADIATED EMISSIONS DATA SHEETS for the TRANSMITTER PORTION FCC 15.247 Quatech, Inc.Date: 02/08/05 ThinQ SDSLab: B Model: SSE/DSE-100/400Tested By: Kyle Fujimoto X-Axis Channel 1 Transmit Mode Freq. (MHz) Level (dBuV) Pol (v/h) LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 482441.38V74-32.62Peak2.31225 482433.58V54-20.42Avg2.31225 723640.26V74-33.74Peak2.31180 723628.75V54-25.25Avg2.31180 964849.09V----Peak1.45225 Not in Restricted Band 964834.49V----Avg1.45225Not in Restricted Band 1206049.21V74-24.79Peak1.45225 1206036.28V54-17.72Avg1.45225 1447251.18V74-22.82Peak1.45315 1447238.3V54-15.7Avg1.45315 1688450.54V----Peak1.45225Not in Restricted Band 1688437.83V----Avg1.45225Not in Restricted Band 19296V74-74PeakNo Emissions 19296V54-54AvgDetected 21708V----PeakNo Emissions 21708V----AvgDetected 24120V----PeakNo Emissions 24120V----AvgDetected FCC 15.247 Quatech, Inc.Date: 02/08/05 ThinQ SDSLab: B Model: SSE/DSE-100/400Tested By: Kyle Fujimoto X-Axis Channel 1 Transmit Mode Freq. (MHz) Level (dBuV) Pol (v/h)LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 482441.27H74-32.73Peak2.64315 482431.96H54-22.04Avg2.64315 723643.86H74-30.14Peak2.6445 723628.95H54-25.05Avg2.6445 964848.39H----Peak1.84180 Not in Restricted Band 964836.7H----Avg1.84180Not in Restricted Band 1206049.28H74-24.72Peak1.8445 1206036.45H54-17.55Avg1.8445 1447251.16H74-22.84Peak2.06225 1447238.35H54-15.65Avg2.06225 1688450.56H----Peak2.06270 Not in Restricted Band 1688437.75H----Avg2.06270Not in Restricted Band 19296H74-74PeakNo Emissions 19296H54-54AvgDetected 21708H----PeakNo Emissions 21708H----AvgDetected 24120H----PeakNo Emissions 24120H----AvgDetected FCC 15.247 Quatech, Inc.Date: 02/08/05 ThinQ SDSLab: B Model: SSE/DSE-100/400Tested By: Kyle Fujimoto Y-Axi s Channel 1 Transmit Mode Freq. (MHz) Level (dBuV) Pol (v/h) LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 482441.61V74-32.39Peak1.75180 482434.21V54-19.79Avg1.75180 723641.51V74-32.49Peak2.17225 723628.78V54-25.22Avg2.17225 964846.28V----Peak1.88225 Not in Restricted Band 964833.83V----Avg1.88225Not in Restricted Band 1206048.78V74-25.22Peak1.65180 1206036.24V54-17.76Avg1.65180 1447251.11V74-22.89Peak1.88180 1447238.39V54-15.61Avg1.88180 1688451.32V----Peak1.87270 1688437.85V----Avg1.87270 19296V74-74Peak No Emissions 19296V54-54AvgDetected 21708V----PeakNo Emissions 21708V----AvgDetected 24120V----PeakNo Emissions 24120V----AvgDetected FCC 15.247 Quatech, Inc.Date: 02/08/05 ThinQ SDSLab: B Model: SSE/DSE-100/400Tested By: Kyle Fujimoto Y-Axis Channel 1 Transmit Mode Freq. (MHz) Level (dBuV) Pol (v/h) LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 482442.36H74-31.64Peak1.68225 482435.35H54-18.65Avg1.68225 723643.25H74-30.75Peak1.68225 723631.36H54-22.64Avg1.68225 964848.35H----Peak2.45225 Not in Restricted Band 964835.34H----Avg2.45225Not in Restricted Band 1206051.52H74-22.48Peak2.45225 1206038.98H54-15.02Avg2.45225 1447253.26H74-20.74Peak1.78180 1447239.54H54-14.46Avg1.78180 16884H----Peak No Emissions 16884H----AvgDetected 19296H74-74PeakNo Emissions 19296H54-54AvgDetected 21708H----PeakNo Emissions 21708H----AvgDetected 24120H----PeakNo Emissions 24120H----AvgDetected FCC 15.247 Quatech, Inc.Date: 02/08/05 ThinQ SDSLab: B Model: SSE/DSE-100/400Tested By: Kyle Fujimoto Z-Axis Channel 1 Transmit Mode Freq. (MHz) Level (dBuV) Pol (v/h) LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 482440.89V74-33.11Peak1.68225 482433.17V54-20.83Avg1.68225 723641.35V74-32.65Peak1.68225 723629.05V54-24.95Avg1.68225 964846.38V----Peak2.45225 Not in Restricted Band 964833.58V----Avg2.45225Not in Restricted Band 1206049.43V74-24.57Peak2.45225 1206036.25V54-17.75Avg2.45225 1447252.82V74-21.18Peak1.78180 1447238.29V54-15.71Avg1.78180 16884V----Peak No Emissions 16884V----AvgDetected 19296V74-74PeakNo Emissions 19296V54-54AvgDetected 21708V----PeakNo Emissions 21708V----AvgDetected 24120V----PeakNo Emissions 24120V----AvgDetected FCC 15.247 Quatech, Inc.Date: 02/08/05 ThinQ SDSLab: B Model: SSE/DSE-100/400Tested By: Kyle Fujimoto Z-Axi s Channel 1 Transmit Mode Freq. (MHz) Level (dBuV) Pol (v/h) LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 482440.23H74-33.77Peak2.52225 482431.86H54-22.14Avg2.52225 723641.92H74-32.08Peak2.52135 723628.79H54-25.21Avg2.52135 964848.66H----Peak1.83135 Not in Restricted Band 964833.97H----Avg1.83135Not in Restricted Band 1206048.88H74-25.12Peak1.83180 1206036.27H54-17.73Avg1.83180 1447252.34H74-21.66Peak1.83180 1447238.28H54-15.72Avg1.83180 1688450.78H----Peak1.83270 Not in Restricted Band 1688437.73H----Avg1.83270Not in Restricted Band 19296H74-74PeakNo Emissi…

Text truncated - open the document above for the full version.

HOW THE EUT MEETS THE REQUIREMENTS OF 15.31 (e) FOR THE QUATECH, INC. ThinQ SDS Model: SSE/DSE-100/400 The fundamental was maximized on the Lab B test site using a normal test setup with the EUT’s AC Adapter connected directly to the AC public mains (115 Vac). Next, the EUT’s AC Adapter was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The Variable Auto Transformer allows the Vac input to be varied. The EUT’s AC Adapter was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The AC input was then dropped to 85% (97.75 Vac) and raised to 115% (132.25 Vac). The actual AC input was measured using a calibrated Fluke Multimeter Model: 87, Serial Number: 956410240, Calibration Due Date: December 7, 2005. The fundamental was then verified again to see that the amplitude did not change. Test Result: The EUT does NOT change amplitude at the fundamental when the AC input voltage is varied between 85% and 115% of the input nominal rated supply voltage.
