F6OINBODYFITBody Composition Analyzer

Thank you for purchasing the Inbody product. This user manual details all the features of the product in an easy- to-understand manner. Familiarize yourself with and follow the instructions to use the product more effectively. Keep the manual well for future reference. User's Guide Contact Us InBody Headquarters Co., Ltd 06106 In-Body Building, 625 Eonju-ro, Gangnam-gu, Seoul TEL: 02-501-3939 FAX: 02-578-5669 Customer Service: 1899-5841 Website: inbody.com E-mail: [email protected] InBody Europe B.V. Gyroscoopweg 122, 1042 AZ, Amsterdam, The Netherlands TEL: +31-20-238-6080 FAX: +31-6-5734-1858 Website: nl.inbody.com E-mail: [email protected] Copyright Under copyright law, this User's Manual may not be copied, reproduced, translated or otherwise replaced in whole or in part without the written consent of Inbody Co., Ltd. This User's Guide may be a typographical error and may be subject to change without prior notice. INBODY Co., Ltd. is not responsible for any damage caused by failure to comply with the contents of this user manual. The appearance, specifications, etc. of the product are subject to change without notice to improve performance. ©2022 InBody Co., Ltd. All rights reserved. Test Posture Lift the handle to the navel height as shown above and straighten it out so that your arms don't touch your waist. Put your thumb on the square electrode. Align the heel with the tip of the foot electrode. For more information on the examination position, see "4.3 Examination Position" Table of Contents 1 Safety....................................................................5 1.1 Safety symbol used in the User's Manual .....................................5 1.2 Precautions for Use ..........................................................................5 2 Product ................................................................6 2.1 Component ........................................................................................6 2.2 Name and function of each part ....................................................6 3 Installing the product ........................................7 3.1 Installation Environment .................................................................7 3.2 Installing the InBody App ................................................................7 3.3 InBody 앱 설치하기 ............................................................................8 3.4 Registering nicknames, adding users ............................................8 4 Prepare for InBody Teset ...................................9 4.1 Precautions for InBody Test ............................................................9 4.2 Precautions for Handle Use ............................................................9 4.3 InBody Test Posture ........................................................................10 5 InBody Test ........................................................12 5.1 Starting with weighing ...................................................................12 5.2 Start after entering the height ......................................................12 5.3 Inspection in conjunction with the InBody app ........................13 6 To check the test results ..................................14 6.1 Progress and completion of inspection ......................................14 6.2 Result Screen Configuration .........................................................14 6.3 Understanding Results ...................................................................15 6.4 Weight, Muscle Weight Standard Range Graph .........................16 7 Manage and archive ........................................17 7.1 Manage .............................................................................................17 7.2 Cleaning ...........................................................................................17 7.3 Keep ..................................................................................................17 8 Troubleshooting ...............................................18 8.1 Error Message ..................................................................................18 8.2 Simple Troubleshooting ................................................................19 8.3 Frequently Asked Questions ........................................................20 9 Product Specifications ....................................22 5 1 Safety 1.1 Safety symbols used in the user manual Warning Failure to follow these instructions may result in serious injury to the user. Caution Failure to follow this instruction may result in damage to the product or inaccurate inspection results. 1.2 Precautions for Use Warning • Do not use implantable medical devices such as pacemakers or life-sustaining medical devices such as patient surveillance devices. During the InBody examination, the instrument (artificial pacemaker) may malfunction due to a fine current flowing, which may be life- threatening. Inbody Co., Ltd. is not liable for any damage to any person or device caused by failure to comply with the above precautions. • Bioelectrical Impedance Analysis (BIA) uses fine currents and does not harm the human body.If a pregnant woman uses it, consult with your doctor or expert before using it. • If you have any infectious or infectious diseases, do not contact or use this product as much as possible. After use, the instrument must be cleaned with a soft cloth and disinfectant such as ethyl alcohol. • Do not pour liquid into the product when cleaning the product using a sterilizer. Electric shock may occur due to product failure or short circuit. • Do not use this product for purposes other than body composition analysis or weight measurement. • This product cannot determine the presence or absence of a disease. Consult your doctor to determine if you have a disease. • If you have metal prostheses such as iron cores or prosthetics in your body, you may not get accurate measurement results or errors may occur. CA…

Text truncated - open the document above for the full version.

Model name: InbodyFit Item Contents Frequency 2400 ㎒ ~ 2485 ㎒ Antenna Type Chip Antenna Antenna peak gain 5.06 ㏈i Manufacturer / Model name Partron / SDBTPTR3015 Address of manufacturer 22, Samsung 1-ro 2-gil, Hwaseong-si, Gyeonggi-do, Republic Test Laboratory Partron Antenna Length 1.5 mm Antenna Width 3 mm Antenna Information Length Width Chip Antenna SDBTPTR3015 Ver 1.0 (2022.05.18) 5/38 Page Technical specification Item Value Frequency Range [MHz]2400 ~ 2485 SWR [Max]2.8 : 1 (Typ 2.3 : 1) Input Impedance [ Ω ]50 Ohm PolarizationLinear Gain [dBi] Total Gain ( Peak / Avg ) [dBi]0.2 / -6.0 Azimuth Theta Peak -3.66 Average -8.40 Phi Peak 5.06 Average -2.59 Elevation 1 Theta Peak-0.13 Average-6.29 Phi Peak 0.84 Average -4.31 Elevation 2 Theta Peak -5.00 Average -9.78 Phi Peak-6.64 Average-10.37 SDBTPTR3015 Ver 1.0 (2022.05.18) 6/38 Page 항 목특 성 Frequency Range [MHz]2400 ~ 2485 Lower frequency(2400MHz) SWR [Min~Max] 1.0 ~ 2.5 : 1 (Typ 2.0 : 1) Upper frequency(2485MHz) SWR [Min~Max] 1.0 ~ 2.5 : 1 (Typ 2.0 : 1) SDBTPTR3015 Ver 1.0 (2022.05.18) 7/38 Page 4.5 Antenna Passive Gain Passive Gain SDBTPTR3015 Ver 1.0 (2022.05.18) 8/38 Page 4.6 방사 패턴 Azimuth PlaneElevation1 PlaneElevation2 Plane ThetaVertical field of measured plane PhiHorizontal field of measured plane Azimuth Theta SDBTPTR3015 Ver 1.0 (2022.05.18) 9/38 Page Azimuth Phi Elevation1 Theta SDBTPTR3015 Ver 1.0 (2022.05.18) 10/38 Page Elevation1 Phi Elevation2 Theta SDBTPTR3015 Ver 1.0 (2022.05.18) 11/38 Page Elevation2 Phi 5. 시험 방법 5.1 SWR / Return Loss Network Analyzer 를 이용하여 SWR / Return Loss 를 측정하며 표본 샘플을 선별 수동 측정 지그 또는 자동화 검사장비를 이용하여 양품과 불량품을 선별한다. 시료 측정 조건수동 지그 측정 조건 Network Analyzer Agilent HP8753E or Advantest R3765CHAgilent HP8753E or Advantest R3765CH CableRF cable (300 mm)RF cable (300 mm) Test condition

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Inbody Co., Ltd. Address InBody Bldg., 625, Eonju-ro, Gangnam-gu, Seoul, Republic of Korea, 06106 Grantee Code F6O FCC ID F6OINBODYFIT Authorized Contact Name Min seok, Lee Contact Email [email protected] Contact Phone +82-02-2182-8918 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accordance w ith 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c)if the Appli cant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept t hat they are the responsible party and agree to abide by t heir responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the Applicant has r ead, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Inbody Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Inbody Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date:2023-07 -24 Print Name: Min seok, Lee Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed i n the FCC database

UNI TED STATES DESIGNATED AGENT LETTER D ate: 07.23.2023 T O: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Biospace, Inc., DBA InBody Applicant Company Name: InBody Co., Ltd. Grantee Code: F6O U.S. designated agent Company Name: FRN: 0033752262 Contact Name: Min-seok Lee Contact Name: ByungJae David Yoo Address: InBody Bldg., 625, Eonju-ro, Gangnam-gu, Seoul, Republic of Korea Address: 13850 Cerritos Corporate Drive, Unit C Cerritos, California 90703 City/Province/Zip: 06106 City/Province/Zip: 90703 Telephone: +82-10-3464-6996 Telephone: 1-323-932-6503 ext 2 Fax: Fax: 1-323-952-5009 Email: N/A [email protected] Email: [email protected] A pplicable Equipment: FCC ID: <F6OINBODYFIT> A TTN: Director of Certification: We, <InBody Co., Ltd.> and <BIOSPACE Inc. DBA InBody> understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, <InBody Co., Ltd.> and <BIOSPACE Inc. DBA InBody> acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): David Byungjae Yoo Name (Printed): Min-seok Lee Title: Manager Title: Head of Product Signature: Signature:

Inbody Co., Ltd. InBody Bldg., 625, Eonju-ro, Gangnam-gu, Seoul, Republic of Korea July 24, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: I, the undersigned, hereby authorize SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In auth orizing SGS Korea as our agent, we still recognize that we are responsible to: a)comply with the relevant provisions of the certification program; b)make a ll necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)make c laims regarding certification only in respect of the scope for which certification has been granted; d)do no t use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e)upon s uspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f)use certification only to indicate the products are certified as being in conformity with specified standards; g)endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h)ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i)keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j)take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k)document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely yours, (Sign) Name/Title : M in se ok, Le e / Manager C ompany Name : InBody Co ., Lt d. Inbody Co., Ltd. InBody Bldg., 625, Eonju-ro, Gangnam-gu, Seoul, Republic of Korea

July 24, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Request of Confidentiality for FCC ID : F6OINBODYFIT To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Inbody Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Inbody Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The reque sted Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIA L LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics 4 - Short-Te r m 5 External Photos 6 Internal Photos 7 Te s t-Setup Photos 8 User’s Manual Inbody Co., Ltd. InBody Bldg., 625, Eonju-ro, Gangnam-gu, Seoul, Republic of Korea, 06106 The A pplicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely yours, (Sign) Name / Title : Min seok, Lee / Manager Company Name : InBody Co., Ltd. Inbod y Co., Ltd. InBody Bldg., 625, Eonju-ro, Gangnam-gu, Seoul, Republic of Korea, 06106

Model name: InBodyFit External photos of EUT Model name: InBodyFit Top view of EUT Bottom view of EUT Model name: InBodyFit Side view of EUT Model name: InBodyFit

InBodyFit S2-미국-107-A-23XXXX 13850 Cerritos Corporate Dr. Unit C Cerritos, CA 90703 USA TEL: +1-323-932-6503 FAX: +1-323-952-5009 Website: inbody.com E-mail: [email protected] 15, Heugam-gil, Ipjang-myeon, Seobuk-gu, Cheonan-si Chungcheongnam-do 31025 Republic of Korea TEL: +82-2-501-3939 FAX: +82-2-578-5669 Website: inbody.com E-mail: [email protected] InBody USA Complies with UL �����-� CSA C��.� No. �����-� E������ Name of product : Body Composition Analyzer Name of model : InBodyFit Weight: �.�kg Rated : DC �V (AA Type Battery, �.�V x �ea) / �.�AMADE IN KOREA FCC ID : F6OINBODYFIT IC : 22967-INBODYFIT F��INBODYFIT This device complies with part �� of the FCC Rules. Operation is subject to the following two conditions: (�) This device may not cause harmful interference, and (�) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications (including the antennas) to this device that are not expressly approved by the manufacturer may void the user's authority to operate the equipment. <Bottom of EUT>

Model name: InBodyFit Internal photos of EUT Model name: InBodyFit Internal view of EUT Model name: InBodyFit Top view of Main PCB Bottom view of Main PCB Model name: InBodyFit Top View of Sub PCB1 Bottom View of Sub PCB1 Model name: InBodyFit View of Antenna Chip Antenna

FCC ID: F6OINBODYFIT According to KDB 447498 D04 Interim General RF Exposure Guidance v01 1. 1-mW Test Exemption Per § 1.1307(b)(3)(i)(A), a single RF source is exempt RF device (from the requirement to show data demonstrating compliance to RF exposure limits, as previously mentioned) if the available maximum time-averaged power is no more than 1 ㎽, regardless of separation distance. This exemption applies to all operating configurations and exposure conditions, for the frequency range 100 ㎑ to 100 ㎓, regardless of fixed, mobile, or portable device exposure conditions. This is a standalone exemption, and it cannot be applied in conjunction with any other test exemption. 2. Test Result Mode Frequency Range (㎒) Minimum Separation Distance (㎝) Maximum Average Target Power (㏈m) Maximum Tune up (㏈) Maximum Average Output Power (㏈m) Limit Result (㏈m) (㎽) (㎽) Bluetooth Low Energy 2 402 ~ 2 480 0.5 -2.2 1 -1.2 0.759 1 Pass Note ; - Maximum average target power is the manufacturer’s declared rated power. - Maximum average output power = Maximum average target power ( ㏈m) + Maximum tune up (㏈). 3. Conclusion: No SAR is required.

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003887 Page: 2 of 34 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) INDEX Table of contents 1. General Information -------------------------------------------------------------------------------------- 3 2. Transmitter Radiated Spurious Emissions and Conducted Spurious Emissions --------- 8 3. 6 ㏈ Bandwidth & 99 % Bandwidth ----------------------------------------------------------------- 23 4. Maximum Peak Conducted Output Power --------------------------------------------------------- 28 5. Power Spectral Density --------------------------------------------------------------------------------- 31 6. Antenna Requirement ----------------------------------------------------------------------------------- 34 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003887 Page: 3 of 34 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil , Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No. : +82 31 688 0901 Fax No. : +82 31 688 0921 1.2. Details of Applicant Applicant : InBody Co., Ltd. Address : InBody Bldg., 625, Eonju-ro, Gangnam-gu, Seoul, South Korea, 06106 Contact Person : Lee, Min-seok Phone No. : +82 2 300 2241 1.3. Details of Manufacturer Company : Same as applicant Address : Same as applicant 1.4. Description of EUT Kind of Product Body Composition Analyzer Model Name InBodyFit Serial Number Conducted Sample: 001 Radiated Sample: 002 Power Supply DC 6 V Frequency Range 2 402 ㎒ ~ 2 480 ㎒ (Bluetooth Low Energy) Modulation Technique GFSK Number of Channels 40 channels (Bluetooth Low Energy) Antenna Type Chip Antenna Antenna Gain ※ 5.06㏈i H/W Version 1.0 S/W Version 1.0 FVIN N/A 1.5. Declaration by the Manufacturer The Bluetooth version of the EUT is 5.2 and only 37 bytes of PHY 1M are supported. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003887 Page: 4 of 34 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.6. Test Equipment List Equipment Manufacturer Model S/N Cal. Date Cal. Interval Cal. Due Signal Generator R&S SMA100B 106887 Oct. 13, 2022 Annual Oct. 13, 2023 Signal Generator R&S SMBV100A 255834 May 25, 2022 Annual May 25, 2023 Spectrum Analyzer R&S FSV30 103210 Dec. 07, 2022 Annual Dec. 07, 2023 Spectrum Analyzer Agilent N9020A MY53421758 Aug. 26, 2022 Annual Aug. 26, 2023 Attenuator AEROFLEX / INMET 40AH2W-10 40G-1 Jun. 08, 2022 Annual Jun. 08, 2023 High Pass Filter Wainwright Instrument GmbH WHKX3.0/18G-6SS 21 Jun. 09, 2022 Annual Jun. 09, 2023 High Pass Filter Wainwright Instrument GmbH WHNX7.5/26.5G-6SS 11 Oct. 24, 2022 Annual Oct. 24, 2023 Low Pass Filter Mini-Circuits NLP-1200+ V 8979400903-2 Feb. 09, 2023 Annual Feb. 09, 2024 Power Sensor R&S NRP-Z81 100669 May 06, 2022 Annual May 06, 2023 DC Power Supply R&S HMP2020 102130 Apr. 22, 2022 Annual Apr. 22, 2023 Preamplifier H.P. 8447F 2944A03909 Aug. 04, 2022 Annual Aug. 04, 2023 Signal Conditioning Unit R&S SCU-18 10117 Jun. 13, 2022 Annual Jun. 13, 2023 Preamplifier TESTEK TK-PA1840H 130016 Jan. 11, 2023 Annual Jan. 11, 2024 Loop Antenna Schwarzbeck Mess-Elektronik FMZB 1519 1519-039 Aug. 23, 2021 Biennial Aug. 23, 2023 Bilog Antenna Schwarzbeck Mess-Elektronik VULB9163 01126 Feb. 09, 2023 Annual Feb. 09, 2024 Horn Antenna R&S HF906 100326 Feb. 28, 2023 Annual Feb. 28, 2024 Horn Antenna Schwarzbeck Mess-Elektronik BBHA 9170 9170-540 Nov. 30, 2022 Annual Nov. 30, 2023 Test Receiver R&S ESU 26 100109 Jan. 18, 2023 Annual Jan. 18, 2024 Turn Table Innco systems GmbH DS 1200 S N/A N.C.R. N/A N.C.R. Controller Innco systems GmbH CONTROLLER CO3000-4P CO3000/963/38 330516/L N.C.R. N/A N.C.R. Antenna Mast Innco systems GmbH MA4640-XP-ET MA4640/536/38 330516/L N.C.R. N/A N.C.R. Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/A N.C.R. N/A N.C.R. Coaxial Cable RFONE MWX221-NMSNMS (4 m) J1023142 Oct. 04, 2022 Semi- Annual Apr. 04, 2023 Coaxial Cable Qualwave Inc. QA500-18-NN-10 (10 m) 22200114 Oct. 04, 2022 Semi- Annual Apr. 04, 2023 Coaxial Cable RFONE PL360P-292M292M-1.5 M-A 20200324002 Feb. 18, 2023 Semi- Annual Aug. 18, 2023 Note; For equipment listed above that has a calibration date or calibration due date that falls within the test date range, care was taken to ensure that this equipment was used after the calibration date and before the calibraition due date. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003887 Page: 5 of 34 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.7. Summary of Test Results The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part15 Subpart C, RSS-247 Issue 2, RSS-Gen Issue 5 Section in FCC Section in IC Test Item(s) Result 15.205(a) 15.209 15.247(d) RSS-247 Issue 2 5.5 RSS-Gen Issue 5 8.9 Transmitter Radiated Spurious Emissions and Conducted Spurious Emission Complied 15.247(a)(2) RSS-247 Issue 2 5.2(a) RSS-Gen Issue 5 6.7 6 ㏈ Bandwidth & 99 % Bandwidth Complied 15.247(b)(3) RSS-247 Issue 2 5.4(d) Maximum Peak Conducted Output Power Complied 15.247(e) RSS-247 Issue 2 5.2(b) Power Spectral Density Complied 15.207 RSS-Gen Issue 5 8.8 AC Power Line Conducted Emission N/A 1) Note; 1) The AC power line test was not performed because the EUT use battery po…

Text truncated - open the document above for the full version.

Model name: InBodyFit Test setup photos of EUT Model name: InBodyFit 1. Orthogonal plane of EUT - The testing was set in the three orthogonal planes and measured for each position (X, Y, Z). X-axis Y-axis Model name: InBodyFit Z-axis Model name: InBodyFit 2. Photos of Radiated Spurious Emission Test (Below 1㎓) Model name: InBodyFit 3. Photo of Radiated Spurious Emission Test (Above 1㎓) Model name: InBodyFit 4. Photo of Conducted Test
