FDI-09101746-0AirStation Compact Flash 802.11b Adapter

Wireless LAN Card WLI2-CF-S11 User's Manual Before Operation 1 Windows CE Settings 2 Windows Me/98 3 Windows 2000 Settings 4 Troubleshooting 5 Glossary 6 Specifications 7 WLI-CF-S11G.book i ページ ２００２年２月２７日 水曜日 午後９時１０分 ■ Precautions for radio signals ● The wireless LAN card WLI2-CF-S11has been approved for conformity to the engineering standards as the wireless facility for a radio station with the low power data communication system based on the Wireless Telegraphy Act. Therefore, use of this LAN card does not require any radio station license. ● Never use the WLI2-CF-S11 near the magnetic field around a microwave oven or in an area where static electricity and/or radio noise is generated. The radio signals may not be normally transmitted in these areas. * When the WLI2-CF-S11 is used near a wireless printer buffer (BUFFALO's RYP-G or similar products by other manufacturers) that use radio signals around 2.4 GHz, the processing speed of both devices may be adversely affected. ● As the WLI2-CF-S11 has been approved for conformity to the engineering standards, the following may be regarded as unlawful. • Disassembling/remodeling the WLI2-CF-S11 • Removing the approval label from the rear of the WLI2-CF-S11 ● When it is necessary to set a radio channel other than the initial setting in the WLI2-CF-S11, use the same frequency band as the following equipment or wireless stations • Industrial, scientific, or medical equipment • Radio station for mobile identification used such as on a manufacture line in a factory ①On-premise radio station (requiring a license) ②Specific low power radio station (requiring no license) ● Operating the WLI2-CF-S11 may cause interference with the above equipment or radio stations. Thus, take precautions for the following points 1 Before using the WLI2-CF-S11, verify that no on-premise radio station for mobile identification or no specific low power radio station is operating near the WLI2-CF-S11. 2 If an event of interference should be taken place by the WLI2-CF -S11 with an on-premise radio station for mobile identification, WLI-CF-S11G.book 0 ページ ２００２年２月２７日 水曜日 午後９時１０分 WLI2-CF-S11 User's Manual 1 immediately change the frequency for this product to prevent the interference. 3If you notice any trouble such as an event of interference caused by the WLI2-CF-S11 with a specific radio station for mobile identification, contact your nearest sales representative. Operating frequency band 2.4GHz Modulation method DS-SS Assumed interference distance 40 m or less Frequency changeability Uses the entire bandwidth, and can avoid the "on-premise radio station" and "specific lower power radio station" bands. WLI-CF-S11G.book 1 ページ ２００２年２月２７日 水曜日 午後９時１０分 WLI2-CF-S11 User's Manual 2 Foreword Thank you for purchasing BUFFALO's wireless LAN card WLI2-CF-S11. The WLI2-CF-S11 is installed for wireless LAN communication in computers equipped with a CompactFlash slot (type II) or PC card slot (type II). Read this manual carefully before using the wireless LAN card to ensure correct operation. ■ For your safety, be sure to follow the instructions given below. The following describes the instructions to avoid harming yourself, other people, and properties, and to ensure safe operation of this product. Be sure to read and understand them thoroughly before using this product. This manual also contains instructions concerning general operation of the computer system to which this product is connected as well as those concerning the product. Please take note that our warranty will not cover any failures and problems of the computer, any losses and failures of data, or failures and problems of this product caused by misuse. Meanings of warning signs Warning Failure to follow the instructions shown with this sign may result in a hazard or serious injury to the user. CAUTION Failure to follow the instructions shown with this sign may result in injury to the user or property damage. WLI-CF-S11G.book 2 ページ ２００２年２月２７日 水曜日 午後９時１０分 WLI2-CF-S11 User's Manual 3 ■ Meanings of symbols This indicates warnings and cautions. Specific instructions are given in or around △. (E.g., Exercise care to avoid an electric shock.) This indicates prohibited matters. Specific instructions are given in or around ○. (E.g., Do not disassemble.) This indicates compulsory rules. Specific instructions are given in or around ●. (E.g., Disconnect the plug from the receptacle.) WARNING No disassembly Do not disassemble or modify the product. It may cause fire or electric shock. Unplugging Turn off the power to the computer and peripheral devices immediately and unplug them if you drop the product or it receives a severe physical shock. If you continue using them under such circumstances, a short circuit resulting in fire or electric shock may occur. Please contact your nearest sales representative. Compulsory Be sure to observe instructions by manufacturers of personal computers and peripherals when installing and using this product. Unplugging Turn off the power to the computer and peripheral devices immediately and unplug them if smoke or heat is generated. If you continue using them under such circumstances, a short circuit resulting in fire or electric shock may occur. Please contact your nearest sales representative. WLI-CF-S11G.book 3 ページ ２００２年２月２７日 水曜日 午後９時１０分 WLI2-CF-S11 User's Manual 4 CAUTION Compulsory Never touch this product with wet hands when the power cable of this product is connected to the power outlet. It will cause electric shock. Compulsory Touch something made of metal (a door knob or aluminum window frame, for example) and release static electricity before touching the product to avoid damage caused by static electricity. Static electricity generated around the human body may damage this product or delete or damage digital data. Compulsory Follow the local rules or regulations when disposing of this product. Inquire of your local government about the applicable rules or regulations. Compulsory Be sure …

Text truncated - open the document above for the full version.

3 Windows Me/98 WLI2-CF-S11 User's Manual 69 WLI-CF-S11G.book 69 ページ ２００２年２月２７日 水曜日 午後９時１０分 WLI2-CF-S11 User's Manual 70 WLI-CF-S11G.book 70 ページ ２００２年２月２７日 水曜日 午後９時１０分 3 Windows Me/98 WLI2-CF-S11 User's Manual 71 WLI-CF-S11G.book 71 ページ ２００２年２月２７日 水曜日 午後９時１０分 WLI2-CF-S11 User's Manual 72 WLI-CF-S11G.book 72 ページ ２００２年２月２７日 水曜日 午後９時１０分 3 Windows Me/98 WLI2-CF-S11 User's Manual 73 WLI-CF-S11G.book 73 ページ ２００２年２月２７日 水曜日 午後９時１０分 MEMO WLI2-CF-S11 User's Manual 74 WLI-CF-S11G.book 74 ページ ２００２年２月２７日 水曜日 午後９時１０分 ■Overview Chapter 4 Capter 4 Windows 2000 Settings This chapter describes how to make the settings for connecting your Windows 2000 computer to a wireless LAN. 4.1 Making the Wireless LAN Card Available Step 1 Before installing the wireless LAN card ...78page Step 2 Installing the wireless LAN card ................83page Step 3 Installing the wireless LAN card drivers ..........................................................85page Step 4 Confirming that the installed wireless LAN card is normally operating ...................88page 4.2 Preparing for Connecting to the Network Step 5 Making the network settings ......................91page Step 6 Installing Client Manager ...........................91page 4.3 Connecting to the Network Step 7 -a Communicating via AirStation ..............95page Step 7 -bCommunicating with wireless LAN computers ..........................................97page Step 8 Starting communication .............................99page WLI-CF-S11G.book 75 ページ ２００２年２月２７日 水曜日 午後９時１０分 WLI2-CF-S11 User's Manual 76 Follow the procedure in the illustration below to connect your Windows 2000 computer to a wireless LAN. Windows2000Operation Flow Making the wireless LAN card available Preparing for connecting to the network Connecting to the network Check the configuration of the drives on your Windows computer and confirm that its PC card driver operates normally. Install the wireless LAN card in the Windows computer. Make the settings for connecting the Windows computer to the network. Step 1Step 2 Step 7 Step 5 Make the settings for access to the network. a...AirStation b...Wireless LAN computers -a, b （from page 78） （from page 91） （from page 95） WLI-CF-S11G.book 76 ページ ２００２年２月２７日 水曜日 午後９時１０分 4 WLI2-CF-S11 User's Manual 77 Install the wireless LAN card drivers in the Windows com- puter. Confirm that the in- stalled wireless LAN card operates nor- mally. Communicate with other computers on the network. Install Client Man- ager for communi- cating with other wireless LAN com- puters. Step 3Step 4 Step 8 Step 6 To make the Air- Station settings, refer to the AirSta- tion manual. WLI-CF-S11G.book 77 ページ ２００２年２月２７日 水曜日 午後９時１０分 WLI2-CF-S11 User's Manual 78 4.1Making the Wireless LAN Card Available Install the wireless LAN card to connect your Windows 2000 computer to a wireless LAN. Step 1Before installing the wireless LAN card Checking the configuration of your drives Follow the procedure below to check the configuration of the drivers on your Windows computer in which the wireless LAN card will be installed. 1 Turn on the computer to boot Windows 2000. Log in with the log- in name having the administrator authority (Administrator, etc.). 2 Double-click [My Computer] on Desktop. 3 These displayed drive names will be necessary in the subsequent procedures. Be sure to take note of these drive names in the table on the upper right of the next page. Select [View]-[Detail]. Check the drive names listed in the window. WLI-CF-S11G.book 78 ページ ２００２年２月２７日 水曜日 午後９時１０分 4 WLI2-CF-S11 User's Manual 79 Drive names on your computer Checking the PC card driver Follow the procedure below to verify that the PC card driver on the computer in which the wireless LAN card will be installed is operating normally. 1 Right-click [My Computer] on Desktop. Click [Properties]. 2 Click [Hardware]-[Device Manager]. 3 Click the "+" mark on the left of [PCMCIA adapters]. 4 The displayed PCMCIA controller name varies with the computer model. ⇒ Continued on next page Drive TypeIcon Drive Name (e.g.) 3.5" FDD （A:） HDD (local disk) （C:） CD-ROM （D:） Confirm that the "x" mark is not indicated for the icon under [PCMCIA adapters]. WLI-CF-S11G.book 79 ページ ２００２年２月２７日 水曜日 午後９時１０分 WLI2-CF-S11 User's Manual 80 If such an error mark as "!" or "x" is not indicated, the PC card driver is operating normally. If the icon displayed under [PCMCIA adapters] appears with the ! or x mark, refer to the manual included in the computer and activate the PC card driver. Checking the browser settings (only for using the AirStation) When you use the AirStation, invalidate the dial-up settings and proxy settings under the browser settings. The following procedure uses Internet Explorer 5.0 or later for example. 1 Select [Start]-[Settings]-[Control Panel]. 2 Double-click [Internet Option]. 3 Double-click the [Connections] tab. 4 When the provider information is listed in the [Dial-up settings] area, click the ○ mark on the left side of [Never dial a connection] below the area to put a dot mark. Click [LAN setings] in the "Local Area Network(LAN) settings" area. WLI-CF-S11G.book 80 ページ ２００２年２月２７日 水曜日 午後９時１０分 4 WLI2-CF-S11 User's Manual 81 5 Confirm the items with a checkmark. For memorandum, put a checkmark for the same items below. □ Automatically detect settings □ Use automatic configuration script □ Use a proxy server □ Bypass proxy server for local addresses 6 Upon completion of confirming the items with the checkmark, remove the checkmark from all the items. Checking the network adapter Confirm the current settings of the network function. 1 Select [Start]-[Settings]-[Control Panel]. 2 Double-click [System]. 3 Click [Hardware]-[Device Manager]. 4Click the "+" mark on the left side of [Network adapters], showing the current adapter as listed in the illustration. ⇒ Continued on next page WLI-CF-S11G.book 81 ページ ２００２年２月２７日 水曜日 午後９時１０分 WLI2-CF-S11 User's Manual 82 5 Disable a LAN board or card if any name. If there is no LAN board or card na…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

0560 MAC: XXXXXXXXXXXX With FCC Standards Tested To Comply For Home Or Office Use 0560 MAC: XXXXXXXXXXXX With FCC Standards Tested To Comply For Home Or Office Use

Page 4 Page 5

FCC ID: FDI-09101746-0 ADT No.920510R01 Operational Description The transmitter of the EUT (AirStation Compact Flash 11b adapter) is powered by host equipment. The antenna types are chip and loop antennas without antenna connector. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: FDI-09101746-0 ADT No.: 920510R01 FCC TEST REPORT REPORT NO.: RF920510R01 MODEL NO.: WLI2-CF-S11 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:Melco Inc. ADDRESS:1704 4-Chome Shimad Tempaku-ku Nagoya City, Aichi Prefecture, Japan ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: FDI-09101746-0 ADT No.: 920510R01 RF Exposure Measurement (Portable Device) 1. Introduction 2.4GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: FDI-09101746-0 ADT No.: 920510R01 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 2.5cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: FDI-09101746-0 ADT No.: 920510R01 5. Test Results 5.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is -2dBi or 0.63(numeric). 5.2 Output Power Into Antenna & MPE value at distance 2.5cm : Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241218.840.151.0 6243719.280.151.0 11246219.010.151.0

FCC ID: FDI-09101746-0 Report No.: RF920510R01 1 Issued: May 26, 2003 FCC TEST REPORT REPORT NO.: RF920510R01 MODEL NO.: WLI2-CF-S11 RECEIVED: Apr. 28, 2003 TESTED: Apr. 30, 2003 ~ May 5, 2003 APPLICANT:Melco Inc. ADDRESS:1704 4-Chome Shimad Tempaku-ku Nagoya City, Aichi Prefecture, Japan ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: FDI-09101746-0 Report No.: RF920510R01 2 Issued: May 26, 2003 Table of Contents 1CERTIFICATION ..................................................................................................................... 4 2SUMMARY OF TEST RESULTS ............................................................................................ 5 3GENERAL INFORMATION ..................................................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ....................................................................................... 6 3.2DESCRIPTION OF TEST MODES ......................................................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................................ 7 3.4DESCRIPTION OF SUPPORT UNITS ................................................................................... 8 4TEST TYPES AND RESULTS ................................................................................................ 9 4.1CONDUCTED EMISSION MEASUREMENT ......................................................................... 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................................... 9 4.1.2TEST INSTRUMENTS ............................................................................................................ 9 4.1.3TEST PROCEDURES...........................................................................................................10 4.1.4DEVIATION FROM TEST STANDARD................................................................................. 10 4.1.5TEST SETUP .........................................................................................................................11 4.1.6EUT OPERATING CONDITIONS ..........................................................................................11 4.1.7TEST RESULT ...................................................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT............................................................................. 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT .......................................................... 18 4.2.2TEST INSTRUMENTS ..........................................................................................................19 4.2.3TEST PROCEDURES...........................................................................................................20 4.2.4DEVIATION FROM TEST STANDARD................................................................................. 20 4.2.5TEST SETUP ........................................................................................................................ 21 4.2.6EUT OPERATING CONDITIONS ......................................................................................... 21 4.2.7TEST RESULT ...................................................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .................................................................................... 26 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................. 26 4.3.2TEST INSTRUMENTS ..........................................................................................................26 4.3.3TEST PROCEDURE .............................................................................................................27 4.3.4DEVIATION FROM TEST STANDARD................................................................................. 27 4.3.5TEST SETUP ........................................................................................................................ 27 4.3.6EUT OPERATING CONDITIONS ......................................................................................... 27 4.3.7TEST RESULT ...................................................................................................................... 28 4.4MAXIMUM PEAK OUTPUT POWER.................................................................................... 32 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT .................................... 32 4.4.2TEST INSTRUMENTS ..........................................................................................................32 4.4.3TEST PROCEDURES...........................................................................................................33 4.4.4DEVIATION FROM TEST STANDARD................................................................................. 33 4.4.5TEST SETUP ........................................................................................................................ 33 4.4.6EUT OPERATING CONDITIONS ......................................................................................... 33 4.4.7TEST RESULT ...................................................................................................................... 34 4.5POWER SPECTRAL DENSITY MEASUREMENT ............................................................... 35 4.5.1LIMITS OF POWE…

Text truncated - open the document above for the full version.

FCC ID: FDI-09101746-0 Report No.: RF920510R01 46 Issued: May 26, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: FDI-09101746-0 Report No.: RF920510R01 47 Issued: May 26, 2003 RADIATED EMISSION TEST
