FDI000000024AirStation

AirStation WMR-433 User Manual www.buffalotech.com 35020438-01 2014-04 2 Contents Chapter 1 - Product Overview ..........................................4 Package Contents .................................................................................4 Diagrams and Layout ...........................................................................4 Chapter 2 - Installation ......................................................6 Initial Setup ..........................................................................................6 Chapter 3 - Configuration .................................................7 Accessing Settings ...............................................................................7 Setup Wizard ........................................................................................8 Update Firmware ..................................................................................9 Status ....................................................................................................9 Change AirStation’s Settings .............................................................10 Notice for 2.4 GHz Bandwidth ...........................................................13 Chapter 4 - Troubleshooting ...........................................14 Cannot Access Settings ......................................................................14 Cannot Connect to the Network Wirelessly .....................................14 Cannot Connect to the Network with 5 GHz ....................................14 Forgot AirStation’s SSID, Encryption Key, or Password ...................15 How to Configure TCP/IP ...................................................................15 3 Windows 8.1/Windows 8 ..............................................................................15 Windows 7 .....................................................................................................16 Windows Vista ...............................................................................................17 Windows XP ...................................................................................................18 Mac OS ...........................................................................................................18 Other Tips ...........................................................................................19 Appendix A - Supplemental Information ......................20 Default Configuration Settings .........................................................20 Technical Specifications ....................................................................20 Environmental Information ..............................................................22 GPL Information .................................................................................22 Appendix B - Regulatory Compliance Information .......23 Company Information .......................................................................23 FCC Statement ....................................................................................23 IC statement (IC déclaration) .............................................................24 4 Chapter 1 - Product Overview Package Contents The following items are included in your AirStation package. If any of the items are missing, please contact your vender. AirStation.................................................1 USB cable.................................................1 Setup card................................................1 Quick setup guide................................1 Warranty statement.............................1 Diagrams and Layout 1 Internet Port 10 Mbps and 100 Mbps connections are supported. Do not connect Ethernet cable from here to your PC. 2 WPS Button To initiate WPS, hold down this button until The power LED flashes red (about 3 seconds). Then, push or click the WPS button on your wireless client device to complete the connection. Both devices must be powered on for this to work. 3 USB Port Connect the attached USB cable to AC adapter or PC’s USB port to supply power. 4 Reset Button 5 To restart the AirStation, hold down this button until the power LED glows red (2–5 seconds). To initialize all AirStation settings to factory defaults, hold down this button until the LED blinks red (about 6 seconds). The power must be on for this to work. 5 5 GHz/2.4 GHz Selector Switch 5 GHz: Enables 5 GHz bandwidth (802.11ac/n/a). 2.4 GHz: Enables 2.4 GHz bandwidth (802.11n/g/b). 6 Link/Active LED (Green) On: Internet side is linked. Blinking: Transmitting data on the Internet side. Off: Internet side is not linked. 7 Power LED (Green or Red) On (Green): Power is on. Blinking (Green): Transmitting data on the LAN side. Blinking (Red): AirStation is waiting for a WPS security key or initializing. Note: Do not disconnect the USB cable while the power LED is blinking red or the AirStation is updating firmware. 6 Chapter 2 - Installation Initial Setup To configure your AirStation, follow the procedure below. 1 Connect the AirStation to a LAN port with an Ethernet cable. 2 Turn on the power. Power for the AirStation can come from a USB port on your PC or from an outlet with a USB power adapter. 3 Connect your PC or mobile device to the AirStation wirelessly to use the Internet. 4 Open a web browser. Note: You may need to register information to connect to the Internet depending on the hotel. For more information, please contact hotel staff. 7 Chapter 3 - Configuration Configuration of the AirStation is done from Settings, the web-based configuration GUI. Accessing Settings To configure the AirStation’s settings manually, log in to Settings as shown below. 1 Open a browser. 2 Enter the AirStation’s LAN-side IP address in the address field and press the enter key. Notes: • The AirStation’s default LAN-side IP address is 192.168.13.1. • If you changed the IP address of the AirStation, use the new IP address. 3 Enter “admin” for the username and the encryption key f…

Text truncated - open the document above for the full version.

Project No.: EP421803 Page No. : 1 of 9 Photographs of EUT Project No.: EP421803 Page No. : 2 of 9 Project No.: EP421803 Page No. : 3 of 9 Project No.: EP421803 Page No. : 4 of 9

WMR-433Model: Made in China 5VInput: CAN ICES-3 (B)/NMB-3 (B) IC: 6102A-059 FCC ID: FDI000000024 WMR-433Model: Made in China 5VInput: CAN ICES-3 (B)/NMB-3 (B) IC: 6102A-059 FCC ID: FDI000000024 Password / Key / PIN: XXXXXXXX Username: adminB0A0 SSID (a): Buffalo-A-XXXX SSID (g): Buffalo-G-XXXX MAC: XXXXXXXXXXXX IP Address: 192.168.13.1 WMR-433Model: Made in China 5VInput: CAN ICES-3 (B)/NMB-3 (B) IC: 6102A-059 FCC ID: FDI000000024 Password / Key / PIN: XXXXXXXX Username: adminB0A0 SSID (a): Buffalo-A-XXXX SSID (g): Buffalo-G-XXXX MAC: XXXXXXXXXXXX IP Address: 192.168.13.1 PANTONE Coolgray 8C Color 1 PANTONE BLACK Color 2 Label Location

Project No.: EP421803 Page No. : 5 of 9 Project No.: EP421803 Page No. : 6 of 9 Project No.: EP421803 Page No. : 7 of 9 Project No.: EP421803 Page No. : 8 of 9 Project No.: EP421803 Page No. : 9 of 9

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/3/21 System Check_Body_2450MHz_140321 DUT: D2450V2-SN:924 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: MSL_2450_140321 Medium parameters used: f = 2450 MHz; σ = 2.015 S/m; ε r = 53.957; ρ = 1000 kg/m 3 23.5 22.5 DASY5 Configuration: - Probe: EX3DV4 - SN3954; ConvF(7.34, 7.34, 7.34); Calibrated: 2013/11/4; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2014/1/30 - Phantom: ELI v4.0; Type: QDOVA001BB; Serial: 1173 - Measurement SW: DASY52, Version 52.8 (6); SEMCAD X Version 14.6.9 (7117) Configuration/Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 19.7 W/kg Configuration/Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 98.106 V/m; Power Drift = 0.06 dB Peak SAR (extrapolated) = 27.1 W/kg SAR(1 g) = 12.4 W/kg; SAR(10 g) = 5.65 W/kg Maximum value of SAR (measured) = 19.5 W/kg 0 dB = 19.5 W/kg = 12.90 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/3/20 System Check_Body_5200MHz_140320 DUT: D5GHzV2-1128 Communication System: CW; Frequency: 5200 MHz;Duty Cycle: 1:1 Medium: MSL_5G_140320 Medium parameters used: f = 5200 MHz; σ = 5.284 S/m; ε r = 47.499; ρ = 1000 kg/m 3 23.6 22.6 DASY5 Configuration: - Probe: EX3DV4 - SN3954; ConvF(4.52, 4.52, 4.52); Calibrated: 2013/11/4; - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2014/1/30 - Phantom: ELI v4.0; Type: QDOVA001BB; Serial: 1173 - Measurement SW: DASY52, Version 52.8 (6); SEMCAD X Version 14.6.9 (7117) Configuration/Pin=100mW/Area Scan (71x71x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 19.4 W/kg Configuration/Pin=100mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 64.573 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 29.3 W/kg SAR(1 g) = 7.47 W/kg; SAR(10 g) = 2.1 W/kg Maximum value of SAR (measured) = 18.2 W/kg 0 dB = 18.2 W/kg = 12.60 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/3/20 System Check_Body_5800MHz_140320 DUT: D5GHzV2-1128 Communication System: CW; Frequency: 5800 MHz;Duty Cycle: 1:1 Medium: MSL_5G_140320 Medium parameters used: f = 5800 MHz; σ = 6.179 S/m; ε r = 46.434; ρ = 1000 kg/m 3 23.6 22.6 DASY5 Configuration: - Probe: EX3DV4 - SN3954; ConvF(4.08, 4.08, 4.08); Calibrated: 2013/11/4; - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2014/1/30 - Phantom: ELI v4.0; Type: QDOVA001BB; Serial: 1173 - Measurement SW: DASY52, Version 52.8 (6); SEMCAD X Version 14.6.9 (7117) Configuration/Pin=100mW/Area Scan (71x71x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 20.1 W/kg Configuration/Pin=100mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 63.117 V/m; Power Drift = -0.08 dB Peak SAR (extrapolated) = 32.3 W/kg SAR(1 g) = 7.43 W/kg; SAR(10 g) = 2.07 W/kg Maximum value of SAR (measured) = 19.3 W/kg 0 dB = 19.3 W/kg = 12.86 dBW/kg

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/3/21 #01_WLAN 2.4GHz_802.11b 1Mbps_Back_1.5cm_Ch6 Communication System: 802.11b; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium: MSL_2450_140321 Medium parameters used: f = 2437 MHz; σ = 1.996 S/m; ε r = 53.979; ρ = 1000 kg/m 3 23.5 22.5 DASY5 Configuration: - Probe: EX3DV4 - SN3954; ConvF(7.34, 7.34, 7.34); Calibrated: 2013/11/4; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2014/1/30 - Phantom: ELI v4.0; Type: QDOVA001BB; Serial: 1173 - Measurement SW: DASY52, Version 52.8 (6); SEMCAD X Version 14.6.9 (7117) Configuration/Ch6/Area Scan (61x61x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.206 W/kg Configuration/Ch6/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.937 V/m; Power Drift = 0.00 dB Peak SAR (extrapolated) = 0.270 W/kg SAR(1 g) = 0.149 W/kg; SAR(10 g) = 0.087 W/kg Maximum value of SAR (measured) = 0.204 W/kg 0 dB = 0.204 W/kg = -6.90 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/3/20 #02_WLAN 5GHz_802.11a 6Mbps_Right Side_1.5cm_Ch161 Communication System: 802.11a; Frequency: 5805 MHz;Duty Cycle: 1:1 Medium: MSL_5G_140320 Medium parameters used: f = 5805 MHz; σ = 6.192 S/m; ε r = 46.422; ρ = 1000 kg/m 3 23.6 22.6 DASY5 Configuration: - Probe: EX3DV4 - SN3954; ConvF(4.08, 4.08, 4.08); Calibrated: 2013/11/4; - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2014/1/30 - Phantom: ELI v4.0; Type: QDOVA001BB; Serial: 1173 - Measurement SW: DASY52, Version 52.8 (6); SEMCAD X Version 14.6.9 (7117) Configuration/Ch161/Area Scan (71x71x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 1.13 W/kg Configuration/Ch161/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 14.504 V/m; Power Drift = -0.18 dB Peak SAR (extrapolated) = 1.84 W/kg SAR(1 g) = 0.453 W/kg; SAR(10 g) = 0.195 W/kg Maximum value of SAR (measured) = 1.01 W/kg 0 dB = 1.01 W/kg = 0.04 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/3/20 #03_WLAN 5GHz_802.11ac-HT80 MCS0_Back_1.5cm_Ch42 Communication System: 802.11ac; Frequency: 5210 MHz;Duty Cycle: 1:1 Medium: MSL_5G_140320 Medium parameters used: f = 5210 MHz; σ = 5.29 S/m; ε r = 47.467; ρ = 1000 kg/m 3 23.6 22.6 DASY5 Configuration: - Probe: EX3DV4 - SN3954; ConvF(4.52, 4.52, 4.52); Calibrated: 2013/11/4; - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2014/1/30 - Phantom: ELI v4.0; Type: QDOVA001BB; Serial: 1173 - Measurement SW: DASY52, Version 52.8 (6); SEMCAD X Version 14.6.9 (7117) Configuration/Ch42/Area Scan (81x81x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 1.27 W/kg Configuration/Ch42/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 15.668 V/m; Power Drift = 0.05 dB Peak SAR (extrapolated) = 1.76 W/kg SAR(1 g) = 0.505 W/kg; SAR(10 g) = 0.220 W/kg Maximum value of SAR (measured) = 1.08 W/kg 0 dB = 1.08 W/kg = 0.33 dBW/kg

SPORTON INTERNATIONAL INC. Page 1 of 22 Issued Date : Apr. 03, 2014 TEL : 886-3-327-3456 / FAX : 886-3-328-4978 Form version. : FAA140305 FCC ID : FDI000000024 FCC SAR Test Report Report No. : FA422815 FCC SAR Test Report APPLICANT : Buffalo Inc. EQUIPMENT : AirStation BRAND NAME : Buffalo Inc. MODEL NAME : WMR-433 FCC ID : FDI000000024 STANDARD : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2003 We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager SPORTON INTERNATIONAL INC. Page 2 of 22 Issued Date : Apr. 03, 2014 TEL : 886-3-327-3456 / FAX : 886-3-328-4978 Form version. : FAA140305 FCC ID : FDI000000024 FCC SAR Test Report Report No. : FA422815 Table of Contents 1. Statement of Compliance ............................................................................................................................................. 4 2. Administration Data ...................................................................................................................................................... 4 3. Guidance Standard ....................................................................................................................................................... 5 4. Equipment Under Test (EUT) ....................................................................................................................................... 5 4.1 General Information ............................................................................................................................................... 5 4.2 Maximum Tune-up Limit ......................................................................................................................................... 5 5. RF Exposure Limits....................................................................................................................................................... 6 5.1 Uncontrolled Environment ...................................................................................................................................... 6 5.2 Controlled Environment .......................................................................................................................................... 6 6. Specific Absorption Rate (SAR) ................................................................................................................................... 7 6.1 Introduction ............................................................................................................................................................ 7 6.2 SAR Definition ........................................................................................................................................................ 7 7. System Description and Setup .................................................................................................................................... 8 8. Measurement Procedures ............................................................................................................................................ 9 8.1 Spatial Peak SAR Evaluation ................................................................................................................................. 9 8.2 Power Reference Measurement............................................................................................................................10 8.3 Area Scan .............................................................................................................................................................10 8.4 Zoom Scan ............................................................................................................................................................ 11 8.5 Volume Scan Procedures ...................................................................................................................................... 11 8.6 Power Drift Monitoring ........................................................................................................................................... 11 9. Test Equipment List .....................................................................................................................................................12 10. System Verification ....................................................................................................................................................13 10.1 Tissue Verification ...............................................................................................................................................13 10.2 System Performance Check Results ...................................................................................................................14 11. Conducted RF Output Power (Unit: dBm) ................................................................................................................15 12. Antenna Location .......................................................................................................................................................17 13. SAR Test Results .......................................................................................................................................................18 13.1 Body SAR ...........................................................................................................................................................18 14. Uncertainty Assessment ..…

Text truncated - open the document above for the full version.

Report No.: FR421803AI Page : 1 of 54 Report Version: Rev. 01 FCC Test Report FCC ID : FDI000000024 Equipment : AirStation Model No. : WMR-433 Brand Name : Buffalo Inc. Applicant : Buffalo Inc. Address : Akamon-dori Bldg, 30-20, Ohsu 3-chome, Naka-ku, Nagoya 460-8315, Japan Standard : 47 CFR FCC Part 15.247 Received Date : Feb. 18, 2014 Tested Date : Feb. 24 ~ Mar. 06, 2014 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FR421803AI Page : 2 of 54 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 7 1.3 Test Setup Chart .................................................................................................................................... 7 1.4 The Equipment List ................................................................................................................................ 8 1.5 Test Standards ....................................................................................................................................... 9 1.6 Measurement Uncertainty ...................................................................................................................... 9 2 TEST CONFIGURATION ..................................................................................................................... 10 2.1 Testing Condition ................................................................................................................................. 10 2.2 The Worst Test Modes and Channel Details ....................................................................................... 10 3 TRANSMITTER TEST RESULTS ........................................................................................................ 11 3.1 Conducted Emissions ........................................................................................................................... 11 3.2 6dB and Occupied Bandwidth .............................................................................................................. 14 3.3 RF Output Power .................................................................................................................................. 17 3.4 Power Spectral Density ........................................................................................................................ 20 3.5 Unwanted Emissions into Restricted Frequency Bands ...................................................................... 22 3.6 Unwanted Emissions into Non-Restricted Frequency Bands .............................................................. 44 4 TEST LABORATORY INFORMATION ............................................................................................... 54 Report No.: FR421803AI Page : 3 of 54 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR421803AI Rev. 01 Initial issue Apr. 03, 2014 Report No.: FR421803AI Page : 4 of 54 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions [dBuV]: 0.186MHz 48.59 (Margin -5.61dB) - AV Pass 15.247(d) 15.209 Radiated Emissions [dBuV/m at 3m]: 178.51MHz 40.07 (Margin -3.43dB) - QP Pass 15.247(b)(3) Fundamental Emission Output Power Power [dBm]: 11a: 23.65 HT20: 23.19 HT40: 23.22 VHT20: 23.26 VHT40: 23.29 VHT80: 22.17 Pass 15.247(a)(2) 6dB Bandwidth Meet the requirement of limit Pass 15.247(e) Power Spectral Density Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass Report No.: FR421803AI Page : 5 of 54 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information IEEE Std. 802.11 Frequency Range (MHz) Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) Data Rate / MCS a 5725-5850 5745-5825 149-165 [5] 1 6-54 Mbps n (HT20) 5725-5850 5745-5825 149-165 [5] 1 MCS 0-7 n (HT40) 5725-5850 5755-5795 151-159 [2] 1 MCS 0-7 ac (VHT20) 5725-5850 5745-5825 149-165 [5] 1 MCS 0-8 ac (VHT40) 5725-5850 5755-5795 151-159 [2] 1 MCS 0-9 ac (VHT80) 5725-5850 5775 155 [1] 1 MCS 0-9 Note 1: RF output power specifies that Maximum Conducted Output Power. Note 2: 802.11a/n uses a combination of OFDM-BPSK, QPSK, 16QAM, 64QAM, 256QAM modulation. 1.1.2 Antenna Details Ant. No. Model Type Connector Operating Frequencies (MHz) / Antenna Gain (dBi) 2400~2483.5 5150~5250 5250~5350 5470~5725 5725~5850 1 ALA140-222020 PIFA Murata 2.55 2.68 2.68 2.81 2.96 1.1.3 Power Supply Type of Equipment under Test (EUT) Power Supply Type 5Vdc from host 1.1.4 Accessories Accessories No. Equipment Description 1 USB Cable 0.3m shielded w/o core. Report No.: FR421803AI Page : 6 of 54 Report Version: Rev. 01 1.1.5 Channel List Frequency band (MHz) 5725~5850 802.11 a / HT20 / VHT20 HT40 / VHT40 Channel Frequency(MHz) Channel Frequency(MHz) 149 5745 151 5755 153 5765 159 5795 157 5785 VHT 80 161 5805 155 5775 165 5825 --- --- 1.1.6 Test Tool and Duty Cycle Test Tool MP_TEST, V1.3.8.0 Duty Cycle and Duty Factor Mode Duty cycle (%) Duty factor (dB) 11a 100.00% 0.00 VHT20 100.00% 0.00 VHT40 100.00% 0.00 VHT80 100.00% 0.00 1.1.7 Power Setting Modulation Mode Test Frequency (MHz…

Text truncated - open the document above for the full version.

Report No.: FR421803AC Page : 1 of 62 Report Version: Rev. 01 FCC Test Report FCC ID : FDI000000024 Equipment : AirStation Model No. : WMR-433 Brand Name : Buffalo Inc. Applicant : Buffalo Inc. Address : Akamon-dori Bldg, 30-20, Ohsu 3-chome, Naka-ku, Nagoya 460-8315, Japan Standard : 47 CFR FCC Part 15.247 Received Date : Feb. 18, 2014 Tested Date : Feb. 24 ~ Mar. 06, 2014 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FR421803AC Page : 2 of 62 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 7 1.3 Test Setup Chart .................................................................................................................................... 7 1.4 The Equipment List ................................................................................................................................ 8 1.5 Test Standards ....................................................................................................................................... 9 1.6 Measurement Uncertainty ...................................................................................................................... 9 2 TEST CONFIGURATION ..................................................................................................................... 10 2.1 Testing Condition ................................................................................................................................. 10 2.2 The Worst Test Modes and Channel Details ....................................................................................... 10 3 TRANSMITTER TEST RESULTS ........................................................................................................ 11 3.1 Conducted Emissions ........................................................................................................................... 11 3.2 6dB and Occupied Bandwidth .............................................................................................................. 14 3.3 RF Output Power .................................................................................................................................. 17 3.4 Power Spectral Density ........................................................................................................................ 19 3.5 Unwanted Emissions into Restricted Frequency Bands ...................................................................... 21 3.6 Emissions in Non-Restricted Frequency Bands ................................................................................... 49 4 TEST LABORATORY INFORMATION ............................................................................................... 62 Report No.: FR421803AC Page : 3 of 62 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR421803AC Rev. 01 Initial issue Apr. 03, 2014 Report No.: FR421803AC Page : 4 of 62 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions [dBuV]: 0.153MHz 47.96 (Margin -7.86dB) - AV Pass 15.247(d) 15.209 Radiated Emissions [dBuV/m at 3m]: 2390.00MHz 51.70 (Margin -2.30dB) - AV Pass 15.247(b)(3) Fundamental Emission Output Power Power [dBm]: 11b: 20.54 11g: 24.43 HT20: 24.34 HT40: 24.14 Pass 15.247(a)(2) 6dB Bandwidth Meet the requirement of limit Pass 15.247(e) Power Spectral Density Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass Report No.: FR421803AC Page : 5 of 62 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Num…
