Page 1 PHOTOS OF EUT

Page 1 PHOTOS OF EUT FCC Label Location Page 1 PHOTOS OF EUT FCC Label Location

Page 2 Page 3

FCC ID: FDI-09101761-0 ADT No.920107R04B Operational Description The transmitter of the EUT is powered by host equipment. The antenna is IFA antenna without antenna connector. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: FDI-09101761-0 Report No.: SA920107R04B1Issued: Aug. 5, 2003 Reference No.: SA920107R04 SAR TEST REPORT REPORT NO.: SA920107R04B MODEL NO.: WLI-CB-B11 RECEIVED: July 31, 2003 TESTED: Jan. 10, 2003 APPLICANT: Melco INC. ADDRESS:15. Shibata Hondori 4-chome, Minami- ku,Nagoya 457-8520, Japan ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 14 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by any government agencies. The test results in the report only apply to the tested sample. FCC ID: FDI-09101761-0 Report No.: SA920107R04B2Issued: Aug. 5, 2003 Reference No.: SA920107R04 Table of Contents 1.CERTIFICATION...........................................................................................3 2.GENERAL INFORMATION............................................................................4 2.1GENERAL DESCRIPTION OF EUT..............................................................4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS...............................4 2.3GENERAL INOFRMATION OF THE TEST SYSTEM....................................5 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS......................7 4.DESCRIPTION OF SUPPORT UNITS..........................................................8 5.TEST RESULTS............................................................................................9 5.1TEST PROCEDURES...................................................................................9 5.2MEASURED SAR RESULT...........................................................................9 5.3SAR LIMITS................................................................................................10 5.4EUT CONDUCTED POWER VARIATION...................................................10 5.5TISSUE.......................................................................................................11 5.6TEST EQUIPMENT FOR TISSUE PROPERTY..........................................11 6.SYSTEM VALIDATION................................................................................12 7.MEASUREMENT UNCERTAINTIES...........................................................13 8.INFORMATION ON THE TESTING LABORATORIES................................14 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: FDI-09101761-0 Report No.: SA920107R04B3Issued: Aug. 5, 2003 Reference No.: SA920107R04 1. CERTIFICATION PRODUCT : 802.11b WLAN Cardbus Adapter MODEL NO. : WLI-CB-B11 BRAND : Melco INC. APPLICANT : Melco INC. STANDARDS : 47 CFR Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on 10 th Jan. 2003. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts for the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: FDI-09101761-0 Report No.: SA920107R04B4Issued: Aug. 5, 2003 Reference No.: SA920107R04 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT802.11b WLAN Cardbus Adapter MODEL NO.WLI-CB-B11 POWER SUPPLY3.6VDC powered by host MODULATION TYPE BPSK, QPSK, CCK RADIO TECHNOLOGY DSSS TRANSFER RATE 1/2/5.5/11Mbps FREQUENCY RANGE2412MHz ~ 2462MHz NUMBER OF CHANNEL11 CONDUCTED OUTPUT POWER 47.09 mW ANTENNA TYPEInverted-F Antenna PEAK SAR0.367 W/kg DATA CABLENA I/O PORTSPCMCIA ASSOCIATED DEVICESNA 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS According to the specifications of the manufacturer, this product must comply with the requirements of the following standards: FCC CFR 47 Part 2 (2.1093) FCC OET Bulletin 65, Supplement C (01- 01) RSS-102 All tests have been performed and recorded as per the above standards. FCC ID: FDI-09101761-0 Report No.: SA920107R04B5Issued: Aug. 5, 2003 Reference No.: SA920107R04 2.3 GENERAL INOFRMATION OF THE TEST SYSTEM ET3DV6 ISOTROPIC E-FIELD PROBE Construction Symmetrical design with triangular core. Built-in optical fiber for surface detection system. Built-in shielding against static charges. PEEK enclosure material (resistant to organic solvents, e.g., glycolether). Calibration Basic Broad Band Calibration in air: 10-2500 MHz Conversion Factors (CF) for HSL 900 and HSL 1800 CF-Calibration for other liquids and frequencies upon request Frequency 10 MHz to 3 GHz; Linearity: ± 0.2 dB (30 MHz to 3 GHz) Directivity ± 0.2 dB in HSL (rotation around probe axis) ± 0.4 dB in HSL (rotation normal to probe axis) Dynamic Range 5 μW/g to > 100 mW/g; Linearity: ± 0.2 dB Optical Surface Detection ± 0.2 mm repeatability in air and clear liquids over diffuse reflecting surfaces Dimensions Overall length: 337 mm (Tip Length: 10 mm) Tip diameter: 7.0 mm (Body diameter: 10 mm) Distance from probe tip to dipole centers: 2.7 mm Application General dosimetric measurements up to 3 GHz Compliance tests of mobile phones Fast automatic scanning in arbitrary phantoms (ET3DV6) FCC ID: FDI-09101761-0 Report No.: SA920107R04B6Issued: Aug. 5, 2003 Reference No.: SA920107R04 TWIN SAM V4.0 Construction The shell corresponds to the specifications of the Specific Anthropomorphic Mannequin (SAM) phantom defined in IEEE 1528- 200X, CENELEC 50361 and IEC 62209. It enables the dosimetric evaluation of left and right hand phone usage as well as body mounted usage at the flat phantom region. A cover prevents evaporation of the liquid. Reference markings on the phantom allow the complete setup of all predefined phantom positions and measurement grids by manually teaching three points with the rob…

Text truncated - open the document above for the full version.

D3: DOSIMETRIC E-FILED PROBE ET3DV6 SN:1687 June 5, 2002 Isotropy Error (Φ), θ = 0 ̊ ET3DV6 SN:1687 June 5, 2002 Frequency Response of E-Field (TEM – Cell:ifi110, Waveguide R22) Dynamic Range f (SAR brain ) (Waveguide R22) 1.E+7 1.E+6 1.E+5 1.E+4 1.E+3 1.E+2 1.E+1 1.E+0 mW/cm 3 not compensated compensated μ μμ μV 0.0001 0.001 0.01 0.1 1 10 100 ET3DV6 SN:1687September 28, 2002 Conversion Factor Assessment

For FCC ID: FDI-09101761-0 Question: Please provide information regarding the distance of the PCMCIA card from the phantom during Mode 1 testing for SAR. Answer: The distance is 1cm

FCC ID: FDI-09101761-0 Report No.: RF920107R04B1Issued: Aug. 5, 2003 Reference No.: RF920107R04 FCC TEST REPORT REPORT NO.: RF920107R04B MODEL NO.: WLI-CB-B11 RECEIVED: Jul. 31, 2003 TESTED: Jan. 8 ~ Jan. 10, 2003 APPLICANT: Melco INC. ADDRESS: 1704 4-Chome, Shimard Tempaku-ku, Nagoya City, Aichi Prefecture, Japan ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 50 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: FDI-09101761-0 Report No.: RF920107R04B2Issued: Aug. 5, 2003 Reference No.: RF920107R04 Table of Contents 1CERTIFICATION.......................................................................................................4 2SUMMARY OF TEST RESULTS............................................................................5 3GENERAL INFORMATION.....................................................................................6 3.1GENERAL DESCRIPTION OF EUT......................................................................6 3.2DESCRIPTION OF TEST MODES........................................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS...................................7 3.4DESCRIPTION OF SUPPORT UNITS..................................................................8 4TEST TYPES AND RESULTS................................................................................9 4.1CONDUCTED EMISSION MEASUREMENT.......................................................9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT..................................9 4.1.2TEST INSTRUMENTS.............................................................................................9 4.1.3TEST PROCEDURES...........................................................................................10 4.1.4DEVIATION FROM TEST STANDARD...............................................................10 4.1.5TEST SETUP..........................................................................................................11 4.1.6EUT OPERATING CONDITIONS........................................................................12 4.1.7TEST RESULTS......................................................................................................13 4.2RADIATED EMISSION MEASUREMENT..........................................................19 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT......................................19 4.2.2TEST INSTRUMENTS...........................................................................................20 4.2.3TEST PROCEDURES...........................................................................................21 4.2.4DEVIATION FROM TEST STANDARD...............................................................21 4.2.5TEST SETUP..........................................................................................................22 4.2.6EUT OPERATING CONDITIONS........................................................................22 4.2.7TEST RESULTS......................................................................................................23 4.2.8TEST RESULTS......................................................................................................25 4.36dB BANDWIDTH MEASUREMENT..................................................................28 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT..............................................28 4.3.2TEST INSTRUMENTS...........................................................................................28 4.3.3TEST PROCEDURE..............................................................................................29 4.3.4DEVIATION FROM TEST STANDARD...............................................................29 4.3.5TEST SETUP..........................................................................................................29 4.3.6EUT OPERATING CONDITIONS........................................................................29 4.3.7TEST RESULTS......................................................................................................30 4.4MAXIMUM PEAK OUTPUT POWER..................................................................34 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.............34 FCC ID: FDI-09101761-0 Report No.: RF920107R04B3Issued: Aug. 5, 2003 Reference No.: RF920107R04 4.4.2TEST INSTRUMENTS...........................................................................................34 4.4.2 TEST PROCEDURES..............................................................................................35 4.4.3DEVIATION FROM TEST STANDARD...............................................................35 4.4.4TEST SETUP..........................................................................................................35 4.4.5EUT OPERATING CONDITIONS........................................................................35 4.4.6TEST RESULTS......................................................................................................36 4.5POWER SPECTRAL DENSITY MEASUREMENT...........................................37 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT.......................37 4.5.2TEST INSTRUMENTS...........................................................................................37 4.5.3TEST PROCEDURE..............................................................................................38 4.5.4DEVIATION FROM TEST STANDARD...............................................................38 4.5.5TEST SETUP.............................................................................…

Text truncated - open the document above for the full version.

FCC ID: NKRCB200B Report No.: RF920107R04 48 Issued: Jan. 16, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: NKRCB200B Report No.: RF920107R04 49 Issued: Jan. 16, 2003 RADIATED EMISSION TEST
