FDI-09102002-0High Power Dual A+G Wireless USB 2.0 Adapter

USB Adapter with Antenna Interface WLI2-USB-G54 www.buffalotech.com v. 1.1 AirStation WLI-U2-AG108HP High Power Dual A+GWireless USB 2.0 Adapter USB AdapterUSB Adapter with Antenna Interfacewith Antenna Interface 2 Congratulations on your purchase! The AirStation WLI-U2-AG108HP High-Power Dual A+G Wire less USB 2.0 Adapter connects to 2.4ghz 802.11g networks, 2.4ghz 802.11b networks, an d 5ghz 802.11a networks. System Requirements •A compatable A, B, or G band access point. •A PC running Windows XP, 2000, ME, or 98se. AirStation WHR-HP-AG108 Package Contents • WLI-U2-AG108HP USB Adapter • Stand • 5 foot USB Cable • Utility CD with Manual • Quick Setup Guides • Warranty Statement Introduction 3 Antenna The WLI-U2-AG108 includes a directional antenna. For best performance, point the an tenna so that the word “BUFFALO” on the front faces your access point. TheWLI-U2-AG108 may also be removed from its stand and clipped to the top of your notebook computer. Li ft the tabs gently to open the clamp, an d slip the unit onto the edge of your computer screen. 4 Getting Started 1. Installing Drivers: Insert the AirNavigator CD into the CD-ROM drive of the PC. If setup.exe does not launch automatically, click Start and selectRun. Enter D:\Setup.exein the Open ÀHOGZKHUH'LVWKHOHWWHU assigned to your CD-ROM. Click theOK button toK launch the wizard. 5 SelectInstall Wireless Adapter. ClickOK.KK The Software License Agreement will appear. ClickYes to continues installation, or No to aborto the installation process. AirNavigator 6 Installing Drivers 2. Installing the Wireless USB Adapter with Windows XP: Power on the notebook PC and let it boot into Windows XP. Plug the Wireless USB A dapter or stand into an available USB port on your PC. The Found New Hardware Wizar d will launch automatically. I f this screen doesn’t appear, remove the Wireless USB Adapter and restart the notebook. Reinsert t he Wireless USB Adapter once the notebook has rebooted. SelectInstall the software automatically. Click the Next button.t 7 Installing Drivers A list of drivers will appear. Choose WLI-U2-AG108HP from the list and click PNext.t If Windows warns you that this driver does not pass Windows Logo testing, click Continue Anyway:KHQLQVWDOODWLRQLVÀQLVKHGFOLFNFinish. Restart your PC if prompted. 8 3. Using Wireless Zero Configuration: Normally, Windows XP will scan for available wireless access points once the Wireless Notebook Adapter is installed. If Windows detects an access point, a networking icon appears on the task bar. One or more wireless networks are available appears as a caption accompanying t he icon. 1RWHV,I:LUHOHVV=HUR&RQÀJXUDWLRQLVQRWUXQQLQJ click Start>Control Panel>Administrative Tools>Services. Select AutomaticLQWKH6WDUWXS7\SHÀHOGRIWKH:LUHOHVV =HUR&RQÀJXUDWLRQ6HUYLFHWRVWDUWLW ,I\RXGRQ·WZDQWWRXVH:LUHOHVV=HUR&RQÀJDQG wou ld rather use Buffalo’s client utility, or if you have a Windows 98 or 2000 computer, turn to page 12. Right click the networking icon in the taskbar and select View Available Wireless Networks to display a list of s available wireless networks. Select a network and click Connect. If the network that you are connecting to is unsecured, you may nee d to check the box allowing you to connect to an unsecured network. Wireless Zero Configuration 9 Click theAdvanced button to enter an SSID network name or WEP/WPA encryption key d manually. To add an SSID network name that is not listed, click the Add button.d Connecting 10 Connecting To enter an encryption key, select the appropriate wireless network and click the &RQÀJXUH button.H From the pull down menu, select the appropriate type of Data encryption for the wireless network. Enter DQGFRQÀUPWKH1HWZRUN.H\ HQFU\SWLRQNH\ &OLFN theOKEXWWRQZKHQÀQLVKHGK 11 Installation with Windows 98/ME/2000 Windows 98/ME/2000 1. Installing the Wireless USB Adapter: Power on the notebook PC and let it boot into Windows. Plug the Wireless USB Adapter into an available USB port on your PC. The Found New Hardware Wizard will launch automatically. If this screen doesn’t appear, remove the Wireless USB Adapter and restart the notebook. Reinsert the Wireless USB Adapter once the notebook has rebooted. SelectInstall the software automatically. Click theNext button.t 12 Installation / Setup 2. Installing the Wireless USB Adapter Drivers: Insert the AirNavigator CD. Click Next at the Welcome to the Found New Hardware t Wizard. SelectSearch for a suitable driver for my device. Click Next to continue.t Check only the CD-ROM drives checkbox, and clear any other checkboxes that are selected. ClickNext to continue.t 13 Installation / Setup Windows will display a driver you can use with the Wireless USB Adapter. ClickNext. In Windows 2000, if the'LJLWDO6LJQDWXUH Not Found page opens as shown, clickd Yes to continue the installation process.s When the Wireless USB Adapter is success fully installed, click Finish. Restart your computer if prompted. See the next page to install the Client Manager. 14 8VH&OLHQW0DQDJHUWRFRQÀJXUH\RXUZLUHOHVVQHWZRUNVXUYH\DQGFRQQHFWWRDYDLODEOH DFFHVVSRLQWVHQDEOHDQGXVH:(3HQFU\SWLRQDQGFUHDWHFRQQHFWLRQSURÀOHV 1RWH&OLHQW0DQDJHUGRHVQRWIXQFWLRQSURSHUO\LIWKH:LQGRZV;3:LUHOHVV=HUR &RQÀJXUDWLRQ6HUYLFHLVHQDEOHG Installing Client Manager Insert the AirNavigator CD. The AirNavigator dialog box will open automatically. If the AirNavigator dialog box does not open DXWRPDWLFDOO\VHOHFW6WDUWª5XQDQGHQWHU'? 6HWXSH[HLQWKH2SHQÀHOGWRRSHQWKHGLDORJ ER[PDQXDOO\'UHSUHVHQWVWKHOHWWHUDVVLJQHG to the CD-ROM drive. If another letter is assigned to the CD-ROM drive, your command VKRXOGUHÁHFWWKDWGLIIHUHQFH&OLFNWKHOK button. Select,QVWDOO&OLHQW0DQDJHU to launchU the InstallShieldWizard. Once the InstallShield Wizard launches, click the Next button to begin the softwaret installation. Client Manager 15 Client Manager Once the Installer Wizard launches…

Text truncated - open the document above for the full version.

Mike Kuo From: Generic Office of Engineering Technology [[email protected]] Sent: Friday, February 24, 2006 12:13 PM To: Mike Kuo Subject: Response to Inquiry to FCC (Tracking Number 583882)  4/19/2006 Inquiry: Please consider this inquiry is confidential and not for public. CCS/TCB received a 802.11 a/b/g client device for FCC equipment authorization. Attached please find the user manual. Based upon the user manual, this 802.11 a/b/g client device can be used by the user in the following two ways : 1) by using supplied USB cable and stand, this 802.11 a/b/g client device can be placed on the tablet top and maintain at least 20 cm separation distance to the end user. ( Stand photo ) 2) By using supplied USB cable, this 802.11 a/b/g client device can be clipped on the top of LCD panel of notebook computer and maintain at least 20 cm separation distance to the end user. ( Clipped on photo) However, due to this 802.11 a/b/g client device is equipped with standard USB 2.0 connector, the end user may directly connect to notebook USB connector without using supplied USB cable. ( Direct connection photo ). Due to this device is not by design to prevent this client device to be used only in a mobile configuration, CCS / TCB requests this client device to be tested for SAR evaluation and submit to FCC for approval due to 5 GHz SAR evaluation. The applicant ( Buffalo ) would like to have second opinion from FCC to determine the RF exposure condition. Question #1: Shall this device be classified as mobile device ( 2.1091 ) or portable device ( 2.1093) ? Best Regards Mike Kuo Response: Due to clear description in text, for this reply we did not look at attachments. Based on description, this seems to fall within scope of TCB info-meeting and/or Conf. Call notes from several years ago where it was said that devices with standard USB plug and marketed with removable extende r-cable are considered to operate in portable RF exposure conditions. Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry.

IN ACCORDANCE WITH THE REQUIREMENTS OF FCC REPORT AND ORDER: ET DOCKET 93-62, AND OET BULLETIN 65 SUPPLEMENT C FOR High Power Dual A+G Wireless USB 2.0 Adapter MODEL: WLI-U2-AG108HP FCC ID: FDI-09102002-0 REPORT NUMBER: 06J10094-10 ISSUE DATE: MARCH 2, 2006 Prepared for BUFFALO INC. 15, SHIBATA HONDORI 4-CHOME, MINAMI-KU NAGOYA 457-8520, JAPAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 06J10094-10 DATE: March 2, 2006 FCC ID: FDI-09102002-0 COMPLIANCE CERTIFICATION SERVICES Page: 2 of 39 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issued date Revisions Revised By A March 2, 2006 Initial issue HS REPORT NO: 06J10094-10 DATE: March 2, 2006 FCC ID: FDI-09102002-0 COMPLIANCE CERTIFICATION SERVICES Page: 3 of 39 This report shall not be reproduced except in full, without the written approval of CCS. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: March 1 & 2, 2006 APPLICANT: ADDRESS: Buffalo Inc. 15, shibata Hondori 4-chome, Minami-ku, Nagoya 457-8520,Japan FCC ID: MODEL: FDI-09102002-0 WLI-U2-AG108HP DEVICE CATEGORY: EXPOSURE CATEGORY: Portable Device General Population/Uncontrolled Exposure The EUT is an 802.11abg USB Adapter with High Gain Antenna connected to the host laptops through USB ports. Test Sample is a: Production unit Modulation type: Direct Sequence Spread Spectrum (DSSS) for 802.11b Orthogonal Frequency Division Multiplexing (OFDM) for 802.11ag Host Device(s): Host # 1: Dell, Inspiron 600m Host # 2: Dell, Inspiron 6000 Host # 3: Toshiba, Satellite Antenna(s) Dual-Band Directional Antenna, BUF05-221210, Buffalo FCC Rule Parts Frequency Range [MHz] The Highest SAR Values [1g_mW/g] Collocation SAR Values [1g_mW/g] 15.247 2412 – 2462 Host # 1: 0.200 Host # 2: 0.213 Host # 3: 0.238 N/A N/A N/A 15.401 5180 - 5320 Host # 3: 0.044 N/A This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (Edition 01-01). Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: Hsin Fu Shih Ninous Davoudi Senior Engineer EMC Engineer Compliance Certification Services Compliance Certification Services REPORT NO: 06J10094-10 DATE: March 2, 2006 FCC ID: FDI-09102002-0 COMPLIANCE CERTIFICATION SERVICES Page: 4 of 39 This report shall not be reproduced except in full, without the written approval of CCS. Table Of Contents 1 EQUIOMENT UNDER TEST (EUT) DESCRIPTION ........................................................................... 5 2 FACILITIES AND ACCREDITATION ...................................................................................................5 3 SYSTEM DESCRIPTION ..................................................................................................................... 6 3.1 SYSTEM COMPONANTS ........................................................................................................... 6 3.1.1 DASY4 MEASURMENT SERVER ............................................................................................ 6 3.1.2 DATA ACQUISITION ELECTRONICS (DAE)........................................................................... 6 3.1.3 EX3DV3 ISOTROPIC E-FIELD PROBE FOR DOSIMETRIC MEASURMENTS ..................... 6 3.1.4 LIGHT BEAM UNIT ................................................................................................................... 6 3.1.5 SAM PHAMTOM (V4.0) ............................................................................................................ 6 3.2 COMPOSITION OF INGREDIANTS FOR TISSUE SIMULATIG LIQUIDS ................................. 7 4 SIMULATING LIQUID PARAMETERS CHECK ................................................................................... 8 4.1 SIMULATING LIQUID PARAMETER CHECK RESULT............................................................ 10 5 SYSTEM PERFORMANCE CHECK .................................................................................................. 12 5.1 SYSTEM PERFORMANCE CHECK RESULTS........................................................................ 14 6 SAR MEASURMENT PROCEDURE ................................................................................................. 15 6.1 DASY4 SAR MEASURMENT PROCEDURE............................................................................ 16 7 PROCEDURE USED TO ESTABLISH TEST SIGNAL ...................................................................... 17 8 SAR MEASURMENT RESULTS (2.4GHZ)........................................................................................ 18 8.1 POSITION 1 (DELL INSPIRON 600M) ...................................................................................... 18 8.2 POSITION 1 (DELL INSPIRON 6000) ....................................................................................... 19 8.3 POSITION 1 (TOSHIBA SATELLITE) ....................................................................................... 20 8.4 POSITION 2 (TOSHIBA LAPTOP) ............................................................................................ 21 8.5 POSITION 3 (TOSHIBA LAPTOP) .......................................................…

Text truncated - open the document above for the full version.

() 2006/03/01 50S() 5620 R1/C1 WLI-U2-AG108HPUSPMBU-31107-D000-01 PANTONE Cool Gray 7c

IN ACCORDANCE WITH THE REQUIREMENTS OF FCC REPORT AND ORDER: ET DOCKET 93-62, AND OET BULLETIN 65 SUPPLEMENT C FOR High Power Dual A+G Wireless USB 2.0 Adapter MODEL: WLI-U2-AG108HP FCC ID: FDI-09102002-0 REPORT NUMBER: 06J10094-10 ISSUE DATE: MARCH 2, 2006 Prepared for BUFFALO INC. 15, SHIBATA HONDORI 4-CHOME, MINAMI-KU NAGOYA 457-8520, JAPAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 06J10094-10 DATE: March 2, 2006 FCC ID: FDI-09102002-0 COMPLIANCE CERTIFICATION SERVICES Page: 2 of 39 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issued date Revisions Revised By A March 2, 2006 Initial issue HS REPORT NO: 06J10094-10 DATE: March 2, 2006 FCC ID: FDI-09102002-0 COMPLIANCE CERTIFICATION SERVICES Page: 3 of 39 This report shall not be reproduced except in full, without the written approval of CCS. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: March 1 & 2, 2006 APPLICANT: ADDRESS: Buffalo Inc. 15, shibata Hondori 4-chome, Minami-ku, Nagoya 457-8520,Japan FCC ID: MODEL: FDI-09102002-0 WLI-U2-AG108HP DEVICE CATEGORY: EXPOSURE CATEGORY: Portable Device General Population/Uncontrolled Exposure The EUT is an 802.11abg USB Adapter with High Gain Antenna connected to the host laptops through USB ports. Test Sample is a: Production unit Modulation type: Direct Sequence Spread Spectrum (DSSS) for 802.11b Orthogonal Frequency Division Multiplexing (OFDM) for 802.11ag Host Device(s): Host # 1: Dell, Inspiron 600m Host # 2: Dell, Inspiron 6000 Host # 3: Toshiba, Satellite Antenna(s) Dual-Band Directional Antenna, BUF05-221210, Buffalo FCC Rule Parts Frequency Range [MHz] The Highest SAR Values [1g_mW/g] Collocation SAR Values [1g_mW/g] 15.247 2412 – 2462 Host # 1: 0.200 Host # 2: 0.213 Host # 3: 0.238 N/A N/A N/A 15.401 5180 - 5320 Host # 3: 0.044 N/A This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (Edition 01-01). Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: Hsin Fu Shih Ninous Davoudi Senior Engineer EMC Engineer Compliance Certification Services Compliance Certification Services REPORT NO: 06J10094-10 DATE: March 2, 2006 FCC ID: FDI-09102002-0 COMPLIANCE CERTIFICATION SERVICES Page: 4 of 39 This report shall not be reproduced except in full, without the written approval of CCS. Table Of Contents 1 EQUIOMENT UNDER TEST (EUT) DESCRIPTION ........................................................................... 5 2 FACILITIES AND ACCREDITATION ...................................................................................................5 3 SYSTEM DESCRIPTION ..................................................................................................................... 6 3.1 SYSTEM COMPONANTS ........................................................................................................... 6 3.1.1 DASY4 MEASURMENT SERVER ............................................................................................ 6 3.1.2 DATA ACQUISITION ELECTRONICS (DAE)........................................................................... 6 3.1.3 EX3DV3 ISOTROPIC E-FIELD PROBE FOR DOSIMETRIC MEASURMENTS ..................... 6 3.1.4 LIGHT BEAM UNIT ................................................................................................................... 6 3.1.5 SAM PHAMTOM (V4.0) ............................................................................................................ 6 3.2 COMPOSITION OF INGREDIANTS FOR TISSUE SIMULATIG LIQUIDS ................................. 7 4 SIMULATING LIQUID PARAMETERS CHECK ................................................................................... 8 4.1 SIMULATING LIQUID PARAMETER CHECK RESULT............................................................ 10 5 SYSTEM PERFORMANCE CHECK .................................................................................................. 12 5.1 SYSTEM PERFORMANCE CHECK RESULTS........................................................................ 14 6 SAR MEASURMENT PROCEDURE ................................................................................................. 15 6.1 DASY4 SAR MEASURMENT PROCEDURE............................................................................ 16 7 PROCEDURE USED TO ESTABLISH TEST SIGNAL ...................................................................... 17 8 SAR MEASURMENT RESULTS (2.4GHZ)........................................................................................ 18 8.1 POSITION 1 (DELL INSPIRON 600M) ...................................................................................... 18 8.2 POSITION 1 (DELL INSPIRON 6000) ....................................................................................... 19 8.3 POSITION 1 (TOSHIBA SATELLITE) ....................................................................................... 20 8.4 POSITION 2 (TOSHIBA LAPTOP) ............................................................................................ 21 8.5 POSITION 3 (TOSHIBA LAPTOP) .......................................................…

Text truncated - open the document above for the full version.

Date/Time: 3/1/2006 9:36:38 AM Test Laboratory: Compliance Certification Services System Performance Check @ 2450 MHz DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:748 Communication System: CW - 2450 MHz; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 2.03 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 23.0deg. C; Liquid Temperature: 21.0 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(8.29, 8.29, 8.29); Calibrated: 7/21/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 d=10mm, Pin=250mW/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 14.8 mW/g d=10mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 85.7 V/m; Power Drift = -0.012 dB Peak SAR (extrapolated) = 27.0 W/kg SAR(1 g) = 13 mW/g; SAR(10 g) = 5.92 mW/g Maximum value of SAR (measured) = 14.4 mW/g 0 dB = 14.4mW/g Date/Time: 3/1/2006 9:47:18 AM Test Laboratory: Compliance Certification Services System Performance Check @ 2450 MHz DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:748 Communication System: CW - 2450 MHz; Frequency: 2450 MHz;Duty Cycle: 1:1 d=10mm, Pin=250mW/Z Scan (1x1x41): Measurement grid: dx=20mm, dy=20mm, dz=2.5mm Maximum value of SAR (measured) = 7.23 mW/g Date/Time: 3/2/2006 9:40:40 AM Test Laboratory: Compliance Certification Services SystemPerformanceCheck-D5GHz-uniform DUT: Dipole 5200-5800MHz; Type: D5GHzV2; Serial: 1003 Communication System: 5200 - 5800MHz; Frequency: 5200 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5200 MHz; σ = 5.44 mho/m; ε r = 47.5; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 23.0 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(5.2, 5.2, 5.2); Calibrated: 7/21/2005 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 1; Type: SAM 1; Serial: 1185 - Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 d=10mm, Pin=250mW, f=5200 MHz/Area Scan (10x10x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 24.5 mW/g d=10mm, Pin=250mW, f=5200 MHz/Zoom Scan (4.3x4.3x3mm), dist=2mm (8x8x8)/Cube 0: Measurement grid: dx=4.3mm, dy=4.3mm, dz=3mm Reference Value = 73.8 V/m; Power Drift = 0.211 dB Peak SAR (extrapolated) = 61.2 W/kg SAR(1 g) = 16.9 mW/g; SAR(10 g) = 4.86 mW/g Maximum value of SAR (measured) = 32.5 mW/g 0 dB = 32.5mW/g Date/Time: 3/2/2006 10:06:14 AM Test Laboratory: Compliance Certification Services SystemPerformanceCheck-D5GHz-uniform DUT: Dipole 5200-5800MHz; Type: D5GHzV2; Serial: 1003 Communication System: 5200 - 5800MHz; Frequency: 5200 MHz;Duty Cycle: 1:1 d=10mm, Pin=250mW, f=5200 MHz/Z Scan (1x1x41): Measurement grid: dx=20mm, dy=20mm, dz=2.5mm Maximum value of SAR (measured) = 18.3 mW/g

Date/Time: 3/1/2006 6:58:23 PM Test Laboratory: Compliance Certification Services Position 1 Dell Inspiron 600m DUT: Buffalo; Type: WLAN; Serial: SN: 01671 Communication System: 802.11bg; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 2.01 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 23.0deg. C; Liquid Temperature: 21.0 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(8.29, 8.29, 8.29); Calibrated: 7/21/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 b mode M-ch/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.075 mW/g b mode M-ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 5.65 V/m; Power Drift = -0.195 dB Peak SAR (extrapolated) = 0.160 W/kg SAR(1 g) = 0.082 mW/g; SAR(10 g) = 0.044 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.089 mW/g b mode M-ch/Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 5.65 V/m; Power Drift = -0.195 dB Peak SAR (extrapolated) = 0.118 W/kg SAR(1 g) = 0.070 mW/g; SAR(10 g) = 0.038 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.076 mW/g Date/Time: 3/1/2006 6:14:57 PM Test Laboratory: Compliance Certification Services Position 1 Dell Inspiron 600m DUT: Buffalo; Type: WLAN; Serial: SN: 01671 Communication System: 802.11bg; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 2.01 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 23.0deg. C; Liquid Temperature: 21.0 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(8.29, 8.29, 8.29); Calibrated: 7/21/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 g mode M-ch/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.123 mW/g g mode M-ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 6.61 V/m; Power Drift = 0.113 dB Peak SAR (extrapolated) = 0.257 W/kg SAR(1 g) = 0.134 mW/g; SAR(10 g) = 0.071 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.146 mW/g g mode M-ch/Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 6.61 V/m; Power Drift = 0.113 dB Peak SAR (extrapolated) = 0.189 W/kg SAR(1 g) = 0.111 mW/g; SAR(10 g) = 0.060 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.119 mW/g Date/Time: 3/1/2006 6:37:53 PM Test Laboratory: Compliance Certification Services Position 1 Dell Inspiron 600m DUT: Buffalo; Type: WLAN; Serial: SN: 01671 Communication System: 802.11bg; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 2.01 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 23.0deg. C; Liquid Temperature: 21.0 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(8.29, 8.29, 8.29); Calibrated: 7/21/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 Turbo g mode M-ch/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.185 mW/g Turbo g mode M-ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 8.29 V/m; Power Drift = 0.078 dB Peak SAR (extrapolated) = 0.385 W/kg SAR(1 g) = 0.200 mW/g; SAR(10 g) = 0.106 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.215 mW/g Turbo g mode M-ch/Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 8.29 V/m; Power Drift = 0.078 dB Peak SAR (extrapolated) = 0.283 W/kg SAR(1 g) = 0.167 mW/g; SAR(10 g) = 0.090 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.180 mW/g Date/Time: 3/1/2006 7:18:33 PM Test Laboratory: Compliance Certification Services Position 1 Dell Inspiron 6000 DUT: Buffalo; Type: WLAN; Serial: SN: 01671 Communication System: 802.11bg; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 2.01 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 23.0deg. C; Liquid Temperature: 21.0 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(8.29, 8.29, 8.29); Calibrated: 7/21/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 b mode M-ch/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters us…

Text truncated - open the document above for the full version.

Date/Time: 3/2/2006 3:54:57 PM Test Laboratory: Compliance Certification Services Position 1 DUT: Buffalo; Type: WLAN; Serial: SN: 01671 Communication System: 802.11a; Frequency: 5260 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 5260 MHz; σ = 5.53 mho/m; ε r = 47.3; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 23.0 deg. C DASY4 Configuration: - Area Scan setting - Fi…
