IN ACCORDANCE WITH THE REQUIREMENTS OF FCC OET BULLETIN 65 SUPPLEMENT C FOR 802.11A+B+G CARDBUS ADAPTER MODEL: WLI-CB-AG108HP FCC ID: FDI-09102021-0 REPORT NUMBER: 06J10304-5 ISSUE DATE: MAY 30, 2006 Prepared for BUFFALO INC. 15, SHIBATA HONDORI 4-CHOME, MINAMI-KU, NAGOYA 457-8520, JAPAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 06J10304-5 DATE: May 30, 2006 FCC ID: FDI-09102021-0 COMPLIANCE CERTIFICATION SERVICES Page: 2 of 34 Revision History Rev. Issued date Revisions Revised By -- May 30, 2006 Initial issue HS This report shall not be reproduced except in full, without the written approval of CCS. REPORT NO: 06J10304-5 DATE: May 30, 2006 FCC ID: FDI-09102021-0 COMPLIANCE CERTIFICATION SERVICES Page: 3 of 34 CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: May 25 and 26, 2006 APPLICANT: ADDRESS: Buffalo Inc. 15, Shibata Hondori 4-chome, Minami-ku, Nagoya 457-8520, Japan FCC ID: MODEL: FDI-09102021-0 WLI-CB-AG108HP DEVICE CATEGORY: EXPOSURE CATEGORY: Portable Device General Population/Uncontrolled Exposure 802.11abg cardbus adapter is installed in three host laptops. Test Sample is a: Production unit Modulation type: Direct Sequence Spread Spectrum (DSSS) for 802.11b Orthogonal Frequency Division Multiplexing (OFDM) for 802.11ag Host Device(s): Host # 1 - Toshiba Satellite Host # 2 - HP Pavilion xt155 Host # 2 - Dell Inspiron 6000 FCC Rule Parts Frequency Range [MHz] The highest SAR values (1g) 15.247 2412 - 2462 Host # 1: 0.500 mW/g Host # 2: 0.339 mW/g Host # 3: 0.292 mW/g 15.401 5180 - 5320 Host # 1: 0.283 mW/g Host # 2: 0.196 mW/g Host # 3: 0.167 mW/g This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (Edition 01-01). Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: Hsin Fu Shih Ninous Davoudi Senior Engineer EMC Engineer Compliance Certification Services Compliance Certification Services This report shall not be reproduced except in full, without the written approval of CCS. REPORT NO: 06J10304-5 DATE: May 30, 2006 FCC ID: FDI-09102021-0 COMPLIANCE CERTIFICATION SERVICES Page: 4 of 34 TABLE OF CONTENTS 1 EQUIPMENT UNDER TEST (EUT) DESCRIPTION............................................................................5 2 FACILITIES AND ACCREDITATION...................................................................................................5 3 SYSTEM DESCRIPTION.....................................................................................................................6 3.1 COMPOSITION OF INGREDIENTS FOR TISSUE SIMULATIG LIQUIDS.................................7 4 SIMULATING LIQUID PARAMETERS CHECK...................................................................................8 4.1 SIMULATING LIQUID PARAMETER CHECK RESULT............................................................ 10 5 SYSTEM PERFORMANCE CHECK..................................................................................................12 5.1 SYSTEM PERFORMANCE CHECK RESULTS........................................................................14 6 SAR MEASURMENT PROCEDURE.................................................................................................15 6.1 DASY4 SAR MEASURMENT PROCEDURE............................................................................16 7 PROCEDURE USED TO ESTABLISH TEST SIGNAL......................................................................17 8 SAR MEASURMENT RESULTS........................................................................................................18 8.1 2.4GHZ BAND............................................................................................................................18 8.1.1 TOSHIBA SATELLITE ANTENNA COMPARISON..........................................................18 8.1.2 TOSHIBA SATELLITE.................................................................................................19 8.1.3 HP PAVILION XT155...................................................................................................20 8.1.4 DELL INSPIRON 6000.................................................................................................21 8.2 5GHZ BAND...............................................................................................................................22 8.2.1 TOSHIBA SATELLITE ANTENNA COMPARISON..........................................................22 8.2.2 TOSHIBA SATELLITE.................................................................................................23 8.2.3 HP PAVILION XT155...................................................................................................24 8.2.4 DELL INSPIRON 6000.................................................................................................25 9 MEASURMENT UNCERTAINTY.......................................................................................................26 9.1 MEASURMENT UNCERTAINTY FOR 300 MHZ – 3000 MHZ.................................................26 9.2 MEASURMENT UNCERTAINTY 3 GHZ – 6 GHZ....................................................................27 10 EQUIPMENT LIST …

Text truncated - open the document above for the full version.

Date/Time: 5/25/2006 9:59:11 AM Test Laboratory: Compliance Certification Services System Performance Check @ 2450 MHz DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:748 Communication System: CW - 2450 MHz; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 2.05 mho/m; ε r = 52; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 22.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(8.29, 8.29, 8.29); Calibrated: 7/21/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.7 Build 21; Postprocessing SW: SEMCAD, V1.8 Build 170 d=10mm, Pin=250mW/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 14.9 mW/g d=10mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 85.7 V/m; Power Drift = -0.056 dB Peak SAR (extrapolated) = 27.5 W/kg SAR(1 g) = 13 mW/g; SAR(10 g) = 5.92 mW/g Maximum value of SAR (measured) = 14.6 mW/g 0 dB = 14.6mW/g Date/Time: 5/25/2006 10:09:46 AM Test Laboratory: Compliance Certification Services System Performance Check @ 2450 MHz DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:748 Communication System: CW - 2450 MHz; Frequency: 2450 MHz;Duty Cycle: 1:1 d=10mm, Pin=250mW/Z Scan (1x1x41): Measurement grid: dx=20mm, dy=20mm, dz=2.5mm Maximum value of SAR (measured) = 7.23 mW/g Date/Time: 5/26/2006 9:14:51 AM Test Laboratory: Compliance Certification Services SystemPerformanceCheck-D5GHz-uniform DUT: Dipole 5200-5800MHz; Type: D5GHzV2; Serial: 1003 Communication System: 5200 - 5800MHz; Frequency: 5200 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5200 MHz; σ = 5.46 mho/m; ε r = 47.4; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 23.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(5.2, 5.2, 5.2); Calibrated: 7/21/2005 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 1; Type: SAM 1; Serial: 1185 - Measurement SW: DASY4, V4.7 Build 21; Postprocessing SW: SEMCAD, V1.8 Build 170 d=10mm, Pin=250mW, f=5200 MHz/Area Scan (10x10x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 20.9 mW/g d=10mm, Pin=250mW, f=5200 MHz/Zoom Scan (4.3x4.3x3mm), dist=2mm (8x8x8)/Cube 0: Measurement grid: dx=4.3mm, dy=4.3mm, dz=3mm Reference Value = 76.3 V/m; Power Drift = -0.091 dB Peak SAR (extrapolated) = 65.7 W/kg SAR(1 g) = 18 mW/g; SAR(10 g) = 5.09 mW/g Maximum value of SAR (measured) = 33.8 mW/g 0 dB = 33.8mW/g Date/Time: 5/26/2006 9:41:09 AM Test Laboratory: Compliance Certification Services SystemPerformanceCheck-D5GHz-uniform DUT: Dipole 5200-5800MHz; Type: D5GHzV2; Serial: 1003 Communication System: 5200 - 5800MHz; Frequency: 5200 MHz;Duty Cycle: 1:1 d=10mm, Pin=250mW, f=5200 MHz/Z Scan (1x1x41): Measurement grid: dx=20mm, dy=20mm, dz=2.5mm Maximum value of SAR (measured) = 8.11 mW/g

Date/Time: 5/25/2006 4:56:18 PM Test Laboratory: Compliance Certification Services Toshiba Satellite DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11bg; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 2.03 mho/m; ε r = 52.1; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 22.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(8.29, 8.29, 8.29); Calibrated: 7/21/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.7 Build 21; Postprocessing SW: SEMCAD, V1.8 Build 170 b mode M ch/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.209 mW/g b mode M ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 10.2 V/m; Power Drift = -0.130 dB Peak SAR (extrapolated) = 0.394 W/kg SAR(1 g) = 0.224 mW/g; SAR(10 g) = 0.125 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.245 mW/g Date/Time: 5/25/2006 5:20:22 PM Test Laboratory: Compliance Certification Services Toshiba Satellite DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11bg; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 2.03 mho/m; ε r = 52.1; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 22.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(8.29, 8.29, 8.29); Calibrated: 7/21/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.7 Build 21; Postprocessing SW: SEMCAD, V1.8 Build 170 b mode M ch Antenna b/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.240 mW/g b mode M ch Antenna b/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 10.6 V/m; Power Drift = -0.053 dB Peak SAR (extrapolated) = 0.396 W/kg SAR(1 g) = 0.225 mW/g; SAR(10 g) = 0.127 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.246 mW/g Date/Time: 5/25/2006 7:54:57 PM Test Laboratory: Compliance Certification Services Toshiba Satellite DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11bg; Frequency: 2412 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2412 MHz; σ = 1.99 mho/m; ε r = 52.2; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 22.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(8.29, 8.29, 8.29); Calibrated: 7/21/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.7 Build 21; Postprocessing SW: SEMCAD, V1.8 Build 170 g mode L ch/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.264 mW/g g mode L ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 11.6 V/m; Power Drift = -0.098 dB Peak SAR (extrapolated) = 0.454 W/kg SAR(1 g) = 0.269 mW/g; SAR(10 g) = 0.155 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.295 mW/g Date/Time: 5/25/2006 5:54:18 PM Test Laboratory: Compliance Certification Services Toshiba Satellite DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11bg; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 2.03 mho/m; ε r = 52.1; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 22.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(8.29, 8.29, 8.29); Calibrated: 7/21/2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 2; Type: SAM 2; Serial: 1050 - Measurement SW: DASY4, V4.7 Build 21; Postprocessing SW: SEMCAD, V1.8 Build 170 g mode M ch/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.273 mW/g g mode M ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 11.7 V/m; Power Drift = -0.061 dB Peak SAR (extrapolated) = 0.534 W/kg SAR(1 g) = 0.303 mW/g; SAR(10 g) = 0.169 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.332 mW/g Date/Time: 5/25/2006 5:36:47 PM Test Laboratory: Compliance Certification Services Toshiba Satellite DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11bg; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 2.03 mho/m; ε r = 52.1; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 22.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV…

Text truncated - open the document above for the full version.

Date/Time: 5/26/2006 10:05:37 AM Test Laboratory: Compliance Certification Services Toshiba Satellite DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11a; Frequency: 5260 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 5260 MHz; σ = 5.55 mho/m; ε r = 47.3; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0 deg. C; Liquid Temperature: 23.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(5.2, 5.2, 5.2); Calibrated: 7/21/2005 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 1; Type: SAM 1; Serial: 1185 - Measurement SW: DASY4, V4.7 Build 21; Postprocessing SW: SEMCAD, V1.8 Build 170 a mode M ch/Area Scan (11x10x1): Measurement grid: dx=10mm, dy=10mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.490 mW/g a mode M ch/Zoom Scan (8x8x8)/Cube 0: Measurement grid: dx=4.3mm, dy=4.3mm, dz=3mm Reference Value = 4.63 V/m; Power Drift = -0.115 dB Peak SAR (extrapolated) = 0.810 W/kg SAR(1 g) = 0.276 mW/g; SAR(10 g) = 0.124 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.482 mW/g Date/Time: 5/26/2006 10:33:34 AM Test Laboratory: Compliance Certification Services Toshiba Satellite DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11a; Frequency: 5260 MHz;Duty Cycle: 1:1 a mode M ch/Z Scan (1x1x41): Measurement grid: dx=20mm, dy=20mm, dz=2.5mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.071 mW/g Date/Time: 5/26/2006 10:45:33 AM Test Laboratory: Compliance Certification Services Toshiba Satellite DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11a; Frequency: 5260 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 5260 MHz; σ = 5.55 mho/m; ε r = 47.3; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 23.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(5.2, 5.2, 5.2); Calibrated: 7/21/2005 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 1; Type: SAM 1; Serial: 1185 - Measurement SW: DASY4, V4.7 Build 21; Postprocessing SW: SEMCAD, V1.8 Build 170 a mode M ch antenna b/Area Scan (11x12x1): Measurement grid: dx=10mm, dy=10mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.067 mW/g a mode M ch antenna b/Zoom Scan (8x8x8)/Cube 0: Measurement grid: dx=4.3mm, dy=4.3mm, dz=3mm Reference Value = 1.49 V/m; Power Drift = 0.164 dB Peak SAR (extrapolated) = 0.118 W/kg SAR(1 g) = 0.040 mW/g; SAR(10 g) = 0.020 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.070 mW/g Date/Time: 5/26/2006 2:14:49 PM Test Laboratory: Compliance Certification Services Toshiba Satellite DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11a; Frequency: 5250 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5250 MHz; σ = 5.54 mho/m; ε r = 47.3; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 23.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(5.2, 5.2, 5.2); Calibrated: 7/21/2005 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 1; Type: SAM 1; Serial: 1185 - Measurement SW: DASY4, V4.7 Build 21; Postprocessing SW: SEMCAD, V1.8 Build 170 a turbo mode M ch/Area Scan (10x10x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 0.330 mW/g a turbo mode M ch/Zoom Scan (8x8x8)/Cube 0: Measurement grid: dx=4.3mm, dy=4.3mm, dz=3mm Reference Value = 4.51 V/m; Power Drift = -0.123 dB Peak SAR (extrapolated) = 0.551 W/kg SAR(1 g) = 0.195 mW/g; SAR(10 g) = 0.088 mW/g Maximum value of SAR (measured) = 0.338 mW/g Date/Time: 5/26/2006 12:56:01 PM Test Laboratory: Compliance Certification Services HP Pavilion xt155 DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11a; Frequency: 5260 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 5260 MHz; σ = 5.55 mho/m; ε r = 47.3; ρ = 1000 kg/m 3 Phantom section: Flat Section Room Ambient Temperature: 24.0deg. C; Liquid Temperature: 23.5 deg. C DASY4 Configuration: - Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Probe: EX3DV3 - SN3531; ConvF(5.2, 5.2, 5.2); Calibrated: 7/21/2005 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 SN558; Calibrated: 1/20/2006 - Phantom: SAM 1; Type: SAM 1; Serial: 1185 - Measurement SW: DASY4, V4.7 Build 21; Postprocessing SW: SEMCAD, V1.8 Build 170 a mode M ch/Area Scan (10x10x1): Measurement grid: dx=10mm, dy=10mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.325 mW/g a mode M ch/Zoom Scan (8x8x8)/Cube 0: Measurement grid: dx=4.3mm, dy=4.3mm, dz=3mm Reference Value = 5.51 V/m; Power Drift = -0.158 dB Peak SAR (extrapolated) = 0.575 W/kg SAR(1 g) = 0.189 mW/g; SAR(10 g) = 0.079 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.340 mW/g Date/Time: 5/26/2006 1:31:53 PM Test Laboratory: Compliance Certification Services HP Pavilion xt155 DUT: 802.11abg Cardbus; Type: Cardbus; Serial: SN: 01743 Communication System: 802.11a; Frequency: 5250 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5250 MHz; σ = 5.54 mho/m; ε r = 47.3; ρ …

Text truncated - open the document above for the full version.

FCC CFR47 PART 15 SUBPART C CERTIFICATION TEST REPORT FOR 802.11abg CARDBUS ADAPTER MODEL NUMBER: WLI-CB-AG108HP FCC ID: FDI-09102021-0 REPORT NUMBER: 06J10304-1 ISSUE DATE: JUNE 02, 2006 Prepared for BUFFALO INC. 15, SHIBATA HONDORI 4-CHOME, MINAMI-KU NAGOYA 457-8520, JAPAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 06J10304-1 DATE: JUNE 02, 2006 EUT: 802.11abg CARDBUS ADAPTER FCC ID: FDI-09102021-0 Page 2 of 92 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issue Date Revisions Revised By -- 6/2/2006 Initial Issue A. Ilarina REPO…
