FDI04604022-011n/a&11n/g/b Concurrent Smart model; 11n/a,11n/g/b Single Smart model

www.buffalotech.com User Manual 11n/a & 11n/g/b Concurrent Smart model WAPS-APG600H 11n/a, 11n/g/b Single Smart model WAPS-AG300H - 1 - Contents Chapter 1 - Product Overview .........................................3 Package Contents .....................................................................3 Hardware Overview ..................................................................4 Front Panel LEDs ...........................................................................4 Back Panel .....................................................................................6 Chapter 2 - Placing Your AirStation ................................8 Antenna Placement ...................................................................8 Installation .................................................................................8 Connecting Power Sourcing Equipment (Sold Separately) ...........8 Connecting the AC Adapter (Sold Separately) ...............................10 Initial Setup ...............................................................................11 Installing the AirStation Configuration Tool ....................................11 Setting the AirStation IP Address ...................................................12 Accessing the Web-based Configuration Interface ........................14 Enabling the Wireless LAN Functions and Making the Encryption Settings ........................................................................16 Setting the Password in the Configuration Interface ......................18 Mounting to a Ceiling or Wall ....................................................20 Mounting the Security Case (Sold Separately) .........................22 Removing the AirStation ...........................................................24 Chapter 3 - Connect to a Wireless Network ...................25 Automatic Secure Setup (AOSS/WPS) .....................................25 Windows 7/Vista (Client Manager V) .............................................26 Windows XP (Client Manager 3) ....................................................27 Mac OS X (AOSS Assistant) ..........................................................28 - 2 - Manual Setup ............................................................................29 Windows 7 (WLAN AutoConfig) .....................................................29 Windows Vista (WLAN AutoConfig) ...............................................30 Windows XP (Wireless Zero Configuration) ...................................33 Mac OS X (Wi-Fi) ...........................................................................34 Chapter 4 - Checking Wireless Signal Quality ...............35 Chapter 5 - Default Configuration Settings ....................38 Appendix A - Specifications ............................................43 Appendix B - TCP/IP Settings ..........................................45 Windows 7 ................................................................................45 Windows Vista ...........................................................................46 Windows XP ..............................................................................47 Mac OS X ..................................................................................48 Appendix C - Restoring the Default Configuration .......49 Appendix D - Regulatory Compliance Information .......50 Appendix E - Environmental Information .......................56 Appendix F - GPL Information .........................................57 - 3 - Chapter 1 - Product Overview Package Contents The following items are included in your AirStation package. If any of the items are missing, please contact your vender. • Wireless LAN access point ........................................................................................................1 • Antennas (Dual band 2.4 GHz / 5 GHz) ...............................................................................2 • Antenna cap (already attached to antenna) .....................................................................2 • Wall-mounting fixture ...............................................................................................................1 • Ceiling-mounting wooden screws (large) ..........................................................................4 • Wall-mounting wooden screws (medium) ........................................................................4 • Wall-mounting anchor (for medium-size wooden screws)..........................................4 • Screws (Small: Length 5 mm *) ...............................................................................................2 • Screws (Small: Length 4 mm *) ...............................................................................................4 • Spacers (Ring-shaped metal part) .........................................................................................2 • Ejector (L-shaped part) ..............................................................................................................1 • AirNavigator CD ...........................................................................................................................1 • Serial number sticker .................................................................................................................2 • Quick Setup Guide ......................................................................................................................1 • Warranty Statement ...................................................................................................................1 * The “length” here refers to the length of the section shown in the figure. An AC adapter is not included with this AirStation unit, and so please order an AC adapter (WLE-OP-AC12, sold separately) or use separate PoE-enabled power sourcing equipment. 1 2 3 4 5 6 - 4 - Chapter 1 Product Overview Hardware Overview Front Panel LEDs 1 Power LED On: Power is on. Off:Power is off. This …

Text truncated - open the document above for the full version.

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B1 OF B8 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 APPENDIX B. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B2 OF B8 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B3 OF B8 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B4 OF B8 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B5 OF B8 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B6 OF B8 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B7 OF B8 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B8 OF B8 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B1 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 APPENDIX B. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B2 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B3 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B4 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B5 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B6 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B7 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B8 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B9 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B10 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B11 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B12 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B13 OF B13 TEL : 886-3-327-3456 ISSUED DATE : Aug. 10, 2012 FAX : 886-3-327-0973

SPORTON INTERNATIONAL INC. Page No. : 1 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR262610AI 1 Human Exposure Assessment 1.1 Maximum Permissible Exposure 1.1.1 Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310 SPORTON INTERNATIONAL INC. Page No. : 2 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR262610AI RF Field Strength Limits for Controlled Use Devices (Controlled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 600 4.9 - 6 1-10 600/ƒ 4.9/ƒ - 6 10-30 60 4.9/ƒ - 6 30-300 60 0.163 10* 6 300-1500 3.54 ƒ 0.5 0.0094 ƒ 0.5 ƒ/30 6 1500-15000 137 0.364 50 6 15000-150000 137 0.364 50 616000/ƒ 1.2 150000-300000 0.354 ƒ 0.5 9.4 x 10-4 ƒ 0.5 3.33 x 10-4 ƒ 616000/ƒ 1.2 RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 280 2.19 - 6 1-10 280/ƒ 2.19/ƒ - 6 10-30 28 2.19/ƒ - 6 30-300 28 0.073 2* 6 300-1500 1.585 ƒ 0.5 0.0042 ƒ 0.5 ƒ/150 6 1500-15000 61.4 0.163 10 6 15000-150000 61.4 0.163 10 616000/ƒ 1.2 150000-300000 0.158 ƒ 0.5 4.21 x 10 -4 ƒ 0.5 6.67 x 10 -5 ƒ 616000/ƒ 1.2 Note 1: ƒ is frequency in MHz. Note 2: For the applicable limit, see IC RSS-102 1.1.2 MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric field (V/m) P = RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d377 GP30   SPORTON INTERNATIONAL INC. Page No. : 3 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR262610AI 1.1.3 Result of Maximum Permissible Exposure Transmitter Chains & Receiver Chains Information IEEE Std. 802.11 Protocol Number of Transmit Chains (N TX ) Number of Receive Chains (N RX ) Correlation Signals with Multiple N TX RF Output Power (dBm) Co-location a 2 2 Correlated 14.55 N/A n (HT20) 2 2 Uncorrelated 14.44 N/A n (HT40) 2 2 Uncorrelated 14.56 N/A Note 1: Co-location, Co-location is generally defined as simultaneously transmitting (co-transmitting) antennas within 20 cm of each other. (i.e., EUT has simultaneously co-transmitting that operating 2.4GHz and 5GHz.) Note 2: RF output power specifies that Maximum Conducted (Average) Output Power. Worst Maximum RF Output Power Result Exposure Environment General Population / Uncontrolled Exposure Separation Distance (cm) 20 Power Level 1 RF Output Power (dBm) Modulation Mode N TX Chain- Port 1 Chain- Port 2 - - Sum Chain Gain (dBi) EIRP Power PD (S) (mW/cm²) 11A5.8G-20M 2 11.50 11.57 - - 14.55 5.9 20.45 0.0220 11N5.8G-20M 2 11.44 11.47 - - 14.44 2.89 17.33 0.0108 11N5.8G-40M 2 11.56 11.54 - - 14.56 2.89 17.45 0.0111 Maximum Permissible Exposure Limit (mW/cm²) 1 Note 1: N TX = Number of Transmit Chains

SPORTON INTERNATIONAL INC. Page No. : 1 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR262610AC 1 Human Exposure Assessment 1.1 Maximum Permissible Exposure 1.1.1 Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310 SPORTON INTERNATIONAL INC. Page No. : 2 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR262610AC RF Field Strength Limits for Controlled Use Devices (Controlled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 600 4.9 - 6 1-10 600/ƒ 4.9/ƒ - 6 10-30 60 4.9/ƒ - 6 30-300 60 0.163 10* 6 300-1500 3.54 ƒ 0.5 0.0094 ƒ 0.5 ƒ/30 6 1500-15000 137 0.364 50 6 15000-150000 137 0.364 50 616000/ƒ 1.2 150000-300000 0.354 ƒ 0.5 9.4 x 10-4 ƒ 0.5 3.33 x 10-4 ƒ 616000/ƒ 1.2 RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 280 2.19 - 6 1-10 280/ƒ 2.19/ƒ - 6 10-30 28 2.19/ƒ - 6 30-300 28 0.073 2* 6 300-1500 1.585 ƒ 0.5 0.0042 ƒ 0.5 ƒ/150 6 1500-15000 61.4 0.163 10 6 15000-150000 61.4 0.163 10 616000/ƒ 1.2 150000-300000 0.158 ƒ 0.5 4.21 x 10 -4 ƒ 0.5 6.67 x 10 -5 ƒ 616000/ƒ 1.2 Note 1: ƒ is frequency in MHz. Note 2: For the applicable limit, see IC RSS-102 1.1.2 MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric field (V/m) P = RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d377 GP30   SPORTON INTERNATIONAL INC. Page No. : 3 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR262610AC 1.1.3 Result of Maximum Permissible Exposure Transmitter Chains & Receiver Chains Information IEEE Std. 802.11 Protocol Number of Transmit Chains (N TX ) Number of Receive Chains (N RX ) Correlation Signals with Multiple N TX RF Output Power (dBm) Co-location b 1 1 N/A 18.19 N/A g 2 2 Correlated 16.28 N/A n (HT20) 2 2 Uncorrelated 13.05 N/A n (HT40) 2 2 Uncorrelated 11.26 N/A Note 1: Co-location, Co-location is generally defined as simultaneously transmitting (co-transmitting) antennas within 20 cm of each other. (i.e., EUT has simultaneously co-transmitting that operating 2.4GHz and 5GHz.) Note 2: RF output power specifies that Maximum Conducted (Average) Output Power. Worst Maximum RF Output Power Result Exposure Environment General Population / Uncontrolled Exposure Separation Distance (cm) 20 Power Level 1 RF Output Power (dBm) Modulation Mode N TX Chain- Port 1 Chain- Port 2 - - Sum Chain Gain (dBi) EIRP Power PD (S) (mW/cm²) 11B-20M 2 16.20 13.85 - - 18.19 4.9 23.09 0.0405 11G-20M 2 14.11 12.23 - - 16.28 4.9 21.18 0.0261 11N2.4G-20M 2 11.01 8.80 - - 13.05 1.89 14.94 0.0062 11N2.4G-40M 2 9.25 6.946 - - 11.26 1.89 13.15 0.0041 Maximum Permissible Exposure Limit (mW/cm²) 1 Note 1: N TX = Number of Transmit Chains

SPORTON INTERNATIONAL INC. Page No. : 1 of 63 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR262610AI FCC Test Report Equipment : 11n/a&11n/g/b Concurrent Smart model 11n/a,11n/g/b Single Smart model Brand Name : BUFFALO Model No. : WAPS-APG600H/WAPS-AG300H FCC ID : FDI04604022-0 Standard : 47 CFR FCC Part 15.247 Frequency Range : 5725 MHz – 5850 MHz Applicant : Buffalo Inc. AKAMONDORI Bldg, 30-20, Ohsu 3-chome, Naka-ku, Nagoya,460-8315, Japan Manufacturer : EDIMAX TECHNOLOGY CO., LTD. No.3, Wu Chuan 3rd Road, Wu-Ku Industrial Park.Taipei Hsien, Taiwan The product sample received on Jun. 27, 2012 and completely tested on Aug. 01, 2012. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2009 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Wayne Hsu / Assistant Manager SPORTON INTERNATIONAL INC. Page No. : 2 of 63 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR262610AI Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Accessories and Support Equipment ..................................................................................................... 8 1.3 Testing Applied Standards ..................................................................................................................... 8 1.4 Testing Location Information .................................................................................................................. 9 1.5 Measurement Uncertainty .................................................................................................................... 10 2 TEST CONFIGURATION OF EUT ...................................................................................................... 11 2.1 The Worst Case Modulation Configuration .......................................................................................... 11 2.2 Test Channel Frequencies Configuration ............................................................................................. 11 2.3 The Worst Case Power Setting Parameter .......................................................................................... 12 2.4 The Worst Case Measurement Configuration ...................................................................................... 13 2.5 Test Setup Diagram ............................................................................................................................. 15 3 TRANSMITTER TEST RESULT .......................................................................................................... 17 3.1 AC Power-line Conducted Emissions .................................................................................................. 17 3.2 6dB Bandwidth ..................................................................................................................................... 20 3.3 RF Output Power .................................................................................................................................. 23 3.4 Power Spectral Density ........................................................................................................................ 30 3.5 Transmitter Radiated Bandedge Emissions ......................................................................................... 34 3.6 Transmitter Radiated Unwanted Emissions ......................................................................................... 40 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 62 5 CERTIFICATION OF TAF ACCREDITATION ..................................................................................... 63 APPENDIX A. TEST PHOTOS .............................................................................................................. A1 ~ A7 APPENDIX B. PHOTOGRAPHS OF EUT ........................................................................................... B1 ~ B21 SPORTON INTERNATIONAL INC. Page No. : 3 of 63 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR262610AI Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.2 15.203 Antenna RequirementAntenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions 0.72MHz: 28.24dBuV (17.76dB) - AV 27.89dBuV (28.11dB) - QP FCC 15.207 Complied 3.2 15.247(a) 6dB Bandwidth 6dB Bandwidth [MHz] 5745-5825MHz(20M): 17.44 5755-5795MHz(40M): 35.28 ≥500kHz Complied 3.3 15.247(b) RF Output Power (Maximum Peak Conducted Output Power) Power [dBm] 5745-5825MHz: 22.45 5755-5795MHz: 22.64 Power [dBm] 5745-5825MHz: 30 5755-5795MHz: 30 Complied 3.4 15.247(d) Power Spectral Density PSD [dBm/3kHz] 5745-5825MHz: -14.86 5755-5795MHz: -17.57 PSD [dBm/3kHz] 5745-5825MHz: 8 5755-5795MHz: 8 Complied 3.5 15.247(c) Transmitter Radiated Bandedge Emissions Non-Restricted Bands: 5720.60MHz: 22.45dB Bandedge emissions not fall in restricted bands. Non-Restricted Bands: > 20 dBc Restricted Bands: FCC 15.209 Complied 3.6 15.247(c) Transmitter Radiated Unwanted Emissions Restricted Bands [dBuV/m at 3m]: 43.58MHz: 36.85 (Margin 3.15dB) - PK Non-Restricted Bands: > 20 dBc Restricted Bands: FCC 15.209 Complied SPORTON INTERNATIONAL INC. Page No. : 4 of 63 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page No. : 1 of 73 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR262610AC FCC Test Report Equipment : 11n/a&11n/g/b Concurrent Smart model 11n/a,11n/g/b Single Smart model Brand Name : BUFFALO Model No. : WAPS-APG600H/WAPS-AG300H FCC ID : FDI04604022-0 Standard : 47 CFR FCC Part 15.247 Applicant : Buffalo Inc. AKAMONDORI Bldg, 30-20, Ohsu 3-chome, Naka-ku, Nagoya,460-8315, Japan Manufacturer : EDIMAX TECHNOLOGY CO., LTD. No.3, Wu Chuan 3rd Road, Wu-Ku Industrial Park.Taipei Hsien, Taiwan The product sample received on Jun. 27, 2012 and completely tested on Jul. 17, 2012. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2009 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Wayne Hsu / Assistant Manager SPORTON INTERNATIONAL INC. Page No. : 2 of 73 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR262610AC Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Accessories and Support Equipment ..................................................................................................... 8 1.3 Testing Applied Standards ..................................................................................................................... 8 1.4 Testing Location Information .................................................................................................................. 9 1.5 Measurement Uncertainty ...................................................................................................................... 9 2 TEST CONFIGURATION OF EUT ...................................................................................................... 10 2.1 The Worst Case Modulation Configuration .......................................................................................... 10 2.2 Test Channel Frequencies Configuration ............................................................................................. 10 2.3 The Worst Case Power Setting Parameter .......................................................................................... 11 2.4 The Worst Case Measurement Configuration ...................................................................................... 12 2.5 Test Setup Diagram ............................................................................................................................. 14 3 TRANSMITTER TEST RESULT .......................................................................................................... 16 3.1 AC Power-line Conducted Emissions .................................................................................................. 16 3.2 6dB Bandwidth ..................................................................................................................................... 19 3.3 RF Output Power .................................................................................................................................. 22 3.4 Power Spectral Density ........................................................................................................................ 30 3.5 Transmitter Radiated Bandedge Emissions ......................................................................................... 34 3.6 Transmitter Radiated Unwanted Emissions ......................................................................................... 42 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 72 5 CERTIFICATION OF TAF ACCREDITATION ..................................................................................... 73 APPENDIX A. TEST PHOTOS .............................................................................................................. A1 ~ A7 APPENDIX B. PHOTOGRAPHS OF EUT ........................................................................................... B1 ~ B21 SPORTON INTERNATIONAL INC. Page No. : 3 of 73 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR262610AC Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.2 15.203 Antenna RequirementAntenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions 0.72MHz: 28.24dBuV (17.76dB) - AV 27.89dBuV (28.11dB) - QP FCC 15.207 Complied 3.2 15.247(a) 6dB Bandwidth 6dB Bandwidth Unit [MHz] 2412-2462MHz: 12.08-DSSS 2412-2462MHz: 17.50-OFDM 2422-2452MHz: 36.04-OFDM 500kHz Complied 3.3 15.247(b) RF Output Power (Maximum Peak Conducted Output Power) Power [dBm] 2412-2462MHz: 21.23-DSSS 2412-2462MHz: 24.00-OFDM 2422-2452MHz: 19.27-OFDM Power [dBm] 2412-2462MHz: 30 2422-2452MHz: 30 Complied 3.4 15.247(d) Power Spectral Density PSD [dBm/3kHz] 2412-2462MHz: -8.72-DSSS 2412-2462MHz: -13.88-OFDM 2422-2452MHz: -22.36-OFDM PSD [dBm/3kHz] 2412-2462MHz: 8 2422-2452MHz: 8 Complied 3.5 15.247(c) Transmitter Radiated Bandedge Emissions Non-Restricted Bands: 2400.00MHz: 31.60dB Restricted Bands [dBuV/m at 3m]: 2483.60MHz: 66.41 (Margin 7.59dB) – PK 52.97 (Margin 1.03dB) - AV Non-Restricted Bands: > 20 dBc Restricted Bands: FCC 15.209 Complied 3.6 15.247(c) Transmitter Radiated Unwanted Emissions Restricted Bands [dBuV/m at 3m]: 7311MHz: 58.72 (Margin 15.28dB) - PK 51.34 (Margin 2.66dB) - AV Non-Restricted Bands: > 20 dBc Restr…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page No. : 1 of 11 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR262610 Co-location Report SPORTON INTERNATIONAL INC. Page No. : 2 of 11 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR262610 1 TEST RESULT 1.1 Radiated Emissions Measurement 1.1.1 Limit 20dBc in any 100 kHz bandwidth outside the operating frequency band. In case the emission fall within the restricted band specified on 15.205(a), then the 15.209(a) limit in the table below has to be followed. Frequencies (MHz) Field Strength (micorvolts/meter) Measurement Distance (meters) 0.009~0.490 2400/F(kHz) 300 0.490~1.705 24000/F(kHz) 30 1.705~30.0 30 30 30~88 100 3 88~216 150 3 216~960 200 3 Above 960 500 3 1.1.2 Measuring Instruments and Setting Please refer to section 2 of equipments list in this report. The following table is the setting of spectrum analyzer and receiver. Spectrum Parameter Setting Attenuation Auto Start Frequency 1000 MHz Stop Frequency 10th carrier harmonic RB / VB (Emission in restricted band) 1MHz / 1MHz for Peak, 1 MHz / 10Hz for Average RB / VB (Emission in non-restricted band) 1MHz / 1MHz for peak Receiver Parameter Setting Attenuation Auto Start ~ Stop Frequency 9kHz~150kHz / RB 200Hz for QP Start ~ Stop Frequency 150kHz~30MHz / RB 9kHz for QP S…
