FFMLST2200

CDMA Fixed Wireless Terminal Owner’s Manual Model: LST-200 & 2200 LGIC CDMA Fixed Wireless Terminal LST-200/2200 3 REVISED HISTORY DATEISSUECONTENTS OF CHANGESS/W VERSION 1999/01ISSUE 1 Initial release Please read this manual before you use this product. This manual is based on the production version of LST-200/2200 FWT. Software changes may have occurred after this printing. LGIC reserves the right to make changes in technical and product specifications without prior notice. LGIC CDMA Fixed Wireless Terminal LST-200/2200 4 Table of Contents 1. Before You Start...................................................................................................6 Safety Information............................................................................................................................6 Optimal Phone Performance............................................................................................................6 Care and Service..............................................................................................................................7 2. Introduction...........................................................................................................8 Front View of the Terminal................................................................................................................9 3 LEDs Indicators...........................................................................................................................10 Installation......................................................................................................................................11 STEP I. Check Components...................................................................................................11 STEP II. Place the Terminal....................................................................................................11 STEP III. Connect Components.............................................................................................11 STEP IV. Check LED indicators.............................................................................................11 STEP V. Wall Mounting Bracket...........................................................................................11 3. Basic Operation..................................................................................................13 Power On.......................................................................................................................................13 Placing a call..................................................................................................................................13 Receiving a call..............................................................................................................................13 Ending a call...................................................................................................................................13 Dial Tone after Remote Disconnect................................................................................................13 Dial Delay.......................................................................................................................................13 Emergency Call..............................................................................................................................14 4. System Features................................................................................................15 Hookflash.......................................................................................................................................15 Dial Time........................................................................................................................................15 ROH (Receiver Off Hook)...............................................................................................................15 Special Cellular Services................................................................................................................15 Applications....................................................................................................................................16 5. Programming......................................................................................................17 Speed Dial......................................................................................................................................17 Storing the Speed Dial Number................................................................................................17 Enable or Disable Speed Dial...................................................................................................17 Operation...................................................................................................................................18 Emergency Call..............................................................................................................................18 Entering the emergency phone number....................................................................................18 Enable or Disable emergency call.............................................................................................18 Hot Line..........................................................................................................................................18 Programming the Hot Line number...........................................................................................18 Enable the Hot Line Feature.....................................................................................................18 Disable the Hot Line Feature....................................................................................................19 Programming the Hot Line Time...............................................................................................19 Alarm..................................…

Text truncated - open the document above for the full version.

LG Information &Communications, Ltd. 459-9, Kasan-dong, Kemchun-ku Seoul 153-023. Korea Tel : 82-2-850-3850 Fax : 82-2-850-386 1 htip:llwww.harrisi~lgic.co.kr March, 10, 1999 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 In re : LG Information & Communication, Ltd FCC ID: FFMLST2200 PCS CDMA WLL Phone Part 24 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, LG Information & communications, Ltd. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams attachment, Antenna Specifications attachment, Operational Description attachment, and Parts List/Tune-Up Procedure attachment for the above-referenced application. These documents contain detailed system and equipment description and related information about the product which LG Information & Communications, Ltd. Considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Information& Communications, Ltd. considers this information to be of benefit to its competitors, such that the disclosure of the information in these documents would give competitors an unfair- advantage in the market. Harris Ahn Principal Engineer Communication Terminal Research Lab LG Information & Communications, Ltd

March 19, 1999 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:LG Information & Communications, Ltd. FCC ID: FFMLST2200 Part 24 Certification Gentlemen: Attached herewith, on behalf of LG Information & Communications, Ltd., is an application for Part 24 certification of the following PCS CDMA WLL Terminal (Wireless Local Loop): FCC ID:FFMLST2200 TRADE / MODEL(s):LGIC LST-2200 EUT TYPE:PCS CDMA WLL Terminal (Wireless Local Loop) Tx Freq. Range:1851.25 – 1908.75 MHz Max. Output Power:0.2 Watts (EIRP) Attached is the Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), schematic diagrams & circuit description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Harris Ahn, Principal Engineer Communications Terminal & Research Lab LG Information & Communications, Ltd.

Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd.

© 1999 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. Fig 12. Sample label (SEE NEXT PAGE) LG Information & Communications, Ltd. LGIC LG Information & Communications, Ltd. LGIC Model No. : LST-2200 FCC ID : FFMLST2200 S/N : Made in Korea

Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 24.990310146.FFMFCC Part 24 Test Date(s): March 15-17, 1999Certfication © 1998 PCTEST LabFCC ID: FFMLST2200 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd.

© 1999 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B 6660-B DobbinDobbin Road Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE (Part 24 Certification) LG Information & Communications, Ltd.Dates of Tests: March 15-17, 1999 60-39, Kasan-dong, Keumchun-kuTest Report S/N: 24.990310146.FFM Seoul 153-023, KoreaTest Site: PCTEST Lab, Columbia MD U.S.A. Attn: Harris Ahn, Principal Engineer Communication Terminal Research Lab FCC ID FFMLST2200 APPLICANT LG Information & Communications, Ltd. Classification:Licensed Base Station for Part 24 (PCB) FCC Rule Part(s):§§§§24(E), 2.983, 2.987 EUT Type:PCS CDMA WLL Terminal (Wireless Local Loop) Trade Name/Model(s):LGIC LST-2200 Frequency Range:Tx: 1851.25 – 1908.75MHz Rx: 1931.25 – 1988.75MHz Max Output Power:0.2 Watts (EIRP) Frequency Tolerance:0.00025% (2.5 ppm) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947 with the following remarks (Note Codes): * (BC) The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a) 990310146.FFM Certification © 1999PCTEST Engineering Laboratory, Inc.FCC Part 24 TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 INSERTS PER §2.983 3 DESCRIPTION OF TESTS 4-6 TEST DATA (RADIATED) 7-9 TEST DATA (FREQUENCY STABILITY) 10-11 PLOTS OF EMISSIONS 12 LIST OF TEST EQUIPMENT 13 SAMPLE CALCULATIONS 14 RECOMMENDATION / CONCLUSION 15 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT L:OPERATIONAL DESCRIPTION ATTACHMENT M:USER’S MANUAL Test Report S/N: 24.990310146.FFMFCC Part 24 Dates of Tests: March 15-17, 1999Certification © 1999 PCTEST LabFCC ID: FFMLST2200 (Model: LST-2200)1 LGIC PCS CDMA WLL Terminal (1851.25-1908.75 MHz) MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2983(a) General Information Applicant Name:LG Information & Communications, Ltd. Address:60-39, Kasan-dong, Keumchun-ku Seoul 153-023 Korea Attention:Harris Ahn, Principal Engineer Communication Terminal Research Lab • §2983(b) FCC ID:FFMLST2200 • §2983(c) Quantity:Quantity production is planned • §2.983(d) Emission Designator:1M25F9W • §2.983(d) Maximum Power Rating:0.2 W (EIRP) • Battery Pack:8.4 VDC 2300 mAh Ni-MH Battery Pack • AC Power Adapter:120 VAC LGIC Model: TPS-H110 • FCC Classification:Licensed Base Station for Part 24 (PCB) • Equipment (EUT) Type:PCS CDMA WLL Terminal (Wireless Local Loop) • Modulation:CDMA • Tx Frequency Range: 1851.25 – 1908.75 MHz • Rx Frequency Range:1931.25 – 1988.75 MHz • Frequency Tolerance:± 2.5 ppm • FCC Rule Part(s):§§§ 24, 2.983, 2.987 • Dates of Tests:March 15-17, 1999 • Place of Tests:PCTEST Lab, Columbia, MD U.S.A. 980615425.CKL Test Report S/N: 24.990310146.FFMFCC Part 24 Dates of Tests: March 15-17, 1999Certification © 1999 PCTEST LabFCC ID: FFMLST2200 (Model: LST-2200)2 LGIC PCS CDMA WLL Terminal (1851.25-1908.75 MHz) 1.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. PCTEST Lab is recognized under the National Voluntary Laboratory Accreditation Program for satisfactory compliance with criteria established in Title 15, Part 285 Code of Federal Regulations. These criteria encompass the requirements of ISO/IEC Guide 25 and the relevant requirements of ISO 9002 (ANSI/ASQC Q92-1987) as suppliers of calibration or test results. The Scope of PCTEST Accreditation are for Electromagnetic Compatibility and Telecommunications and FCC. 1.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore- Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: 24.990310146.FFMFCC Part 24 Dates of Tests: March 15-17, 1999Certification © 1999 PCTEST LabFCC ID: FFMLST2200 (Model: LST-2200)3 LGIC PCS CDMA WLL Terminal (1851.25-190…
