FFMLST2300PCS CDMA WLL Terminal

LGIC CDMA Fixed Wireless Terminal LST-230(F) / 2300(F) 2 CDMA Fixed Wireless Terminal User Guide Model: LST-230(F) & 2300(F) LGIC CDMA Fixed Wireless Terminal LST-230(F) / 2300(F) 3 REVISED HISTORY DATEISSUECONTENTS OF CHANGESS/W VERSION 2000.02ISSUE 1Initial Release Please read this manual before you use this product. This manual is based on the production version of LST- 230(F)/2300(F) FWT. Software changes may have occurred after this printing. LGIC reserves the right to make changes in technical and product specifications without prior notice. LGIC CDMA Fixed Wireless Terminal LST-230(F) / 2300(F) 4 Blank Page LGIC CDMA Fixed Wireless Terminal LST-230(F) / 2300(F) 5 Table of Contents 1. Before You Start.....................................................................................................7 1.1 Safety Information.....................................................................................................................7 1.2 Optimal Phone Performance....................................................................................................7 1.3 Care and Service......................................................................................................................8 2. Introduction............................................................................................................9 2.1 Front View of the Terminal......................................................................................................10 2.2 3 LEDs Indicators.....................................................................................................................11 STEP I. Check Components.....................................................................................................11 STEP II. Place the Terminal.....................................................................................................12 STEP III. Connect Components...............................................................................................12 STEP IV. Check LED indicators...............................................................................................12 STEP V. Install of Wall Mounting.............................................................................................12 2.3 Installation Steps.....................................................................................................................14 3. Basic Operation....................................................................................................15 3.1 Power On................................................................................................................................15 3.2 Placing a call...........................................................................................................................15 3.3 Receiving a call.......................................................................................................................15 3.4 Ending a call...........................................................................................................................15 3.5 Warning Tone after Remote Disconnect.................................................................................15 3.6 Dial Delay(Enblock mode only)...............................................................................................15 3.7 Emergency Call(Enblock mode only)......................................................................................16 4. System Features..................................................................................................17 4.1 Hook flash...............................................................................................................................17 4.2 Dial Delay Time(Enblock mode only)......................................................................................17 4.3 ROH (Receiver Off Hook).......................................................................................................17 4.4 Special Cellular Services........................................................................................................17 4.5 Applications.............................................................................................................................18 5. Programming........................................................................................................19 5.1 Speed Dial(Enblock mode only).............................................................................................19 Storing the Speed Dial Number................................................................................................19 Enable or Disable Speed Dial...................................................................................................19 Operation..................................................................................................................................20 5.2 Emergency Call(Enblock mode only)......................................................................................20 Entering the emergency phone number...................................................................................20 Enable or Disable emergency call............................................................................................20 5.3 Hot Line(Enblock mode only)..................................................................................................20 Programming the Hot Line number..........................................................................................20 Enable the Hot Line Feature.....................................................................................................20 Disable the Hot Line Feature....................................................................................................21 Programming the Hot Line Time...............................................................................................21 5.4 Alarm(Enblock mode only)............…

Text truncated - open the document above for the full version.

@ LG Information & Communications, Ltd. March 31, 2000 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory, Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to the application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Sincerely, General Manager of New York Office LG Information & Communications, Ltd.

LG Information & Communications, Ltd. March 31, 2000 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 U.S.A. In re : LG Information & Communications, Ltd. FCC ID : FFMLST2300 PCS CDMA WLL Terminal Part 24 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, LG Information & Communications, Ltd. Hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagram & Circuit Description attachment, Antenna Specifications attachment, Operational Description attachment, and Parts List/Tune-Up Procedure attachment for the above-referenced application. These documents contain detailed system and equipment description and related information about the product which LG Information & Communications, Ltd. Considers to be proprietary, confidential, and a custom design and , otherwise, would not release to the general public. Since this design is a basic from which future technological products will evolve, LG Information & Communications, Ltd. Considers this information to be of benefit to its competitors an unfair advantage in the market. Sincerely yours, D.S.KIM / Quality Engineering Dept. LG Information & Communications, Ltd. LGIC LG Kangseo B/D 36, Munlae-Dong, 6-Ga, Youngdungpo-Gu, Seoul, 150-096, Korea Youngdungpo P.O Box101, Seoul, Korea Telephone : 82-2-2630-3651~2 Fax : 82-2-2630-3669

April 10, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:LG Information & Communications, Ltd. FCC ID: FFMLST2300 Part 24 Certification Gentlemen: Attached herewith, on behalf of LG Information & Communications, Ltd. is an application for Part 24 Certification of the following: FCC ID:FFMLST2300 TRADE / MODEL(s):LGIC LST-2300 Equipment Class:Licensed Base Station for Part 24 (PCB) Equipment Type:PCS CDMA WLL Terminal Tx Freq. Range:1851.25 – 1908.75 MHz Rx Freq. Range:1931.25 – 1988.75 MHz Max. RF Output Power:0.266 W EIRP (24.25 dBm) Attached is the Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report & photographs, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & description (confidential), operational description (confidential), parts list & tune- up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Yu-Sung, Sim, Approval Engineer Quality Engineering Dept, / Research Laboratory

© 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd.

© 2000 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) LGIC CDMA Fixed Access Unit LST-2300 Technical Documents

© 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd.

© 2000 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B 6660-B DobbinDobbin Road Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) LG Information & Communications, Ltd.Dates of Tests: April 03-07, 2000 LG Kangeo B/D 36, Munlae-Dong, 6-Ga,Test Report S/N: SAR.200329125.FFM Youngdungpo-Gu, Seoul, 150-096, KoreaTest Site: PCTEST Lab, Columbia MD U.S.A. Attention: Mr. Yu-Sung, Sim, Approvals Engineer Quality Engineering Dept. / Research Laboratory FCC ID FFMLST2300 APPLICANT LG INFORMATION & COMMUNICATIONS, LTD. EUT Type:PCS CDMA WLL Terminal Tx Frequency:1851.25 – 1908.75 MHz Rx Frequency:1931.25 – 1988.75 MHz Max. RF Output Power:0.266 W EIRP (24.25 dBm) Trade Name/Model:LGIC LST-2300 FCC Classification:Licensed Base Station for Part 24 (PCB) Application Type:Certification Serial Number:n/a (pre-production) FCC Rule Part(s):2.1093; ET Docket 96.326 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). 200329125.FFM SAR Measurement ReportFCC Part 24 Certification © 2000 PCTEST Labi Table of Contents 1.1 SCOPE1 2.1 INTRODUCTION / SAR DEFINITION2 3.1 SAR MEASUREMENT SET-UP3 4.1 E-FIELD PROBE SYSTEM4 5.1 E-FIELD PROBE CALIBRATION PROCESS5-6 6.1 PHANTOM & EQUIVALENT TISSUE7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS9 9.1 EUT TEST POSITION10 10.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS11 11.1 MEASUREMENT UNCERTAINTIES12 12.1 SAR TEST DATA SUMMARY13 13.1 SAR TEST EQUIPMENT LIST14 14.1 CONCLUSION / REFERENCES15 Test Report S/N: SAR.200329125.FFMSAR Measurement Report Test Dates: April 03-07, 2000FCC Part 24 Certification LGIC FCC ID: FFMLST2300 (Tx 1851.25 – 1908.75 MHz) © 2000 PCTEST LabPCS CDMA WLL Terminal (Model: LST-2300)1 SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Applicant Name:LG Information & Communications, Ltd. Address:LG Kangeo B/D 36, Munlae-Dong, 6-Ga Youngdungpo-Gu, Seoul, 150-096, Korea Attention:Yu-Sung Sim, Approvals Engineer Quality Engineering Dept. / Research Laboratory • EUT Type:PCS CDMA WLL Terminal • FCC IDENTIFIER:FFMLST2300 • Trade Name:LGIC • Model:LST-2300 • S/N:Pre-production • Tx Frequency Range:1851.25 – 1908.75 MHz • Rx Frequency Range:1931.25 – 1988.75 MHz • Application Type: Certification • FCC Classification:Licensed Base Station for Part 24 (PCE) • FCC Rule Part(s):§ 2.1093, Docket 96-326 • Max. RF Output Power:0.266 W EIRP ( 24.25 dBm) • Modulation:CDMA • Antenna Type:Dipole (λ/2) • Antenna Dimensions:16.5 cm. (Length) • Dates of Tests:April 03-07, 2000 • Place of Tests:PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.:SAR.200329125.FFM 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Figure 1. SAR Test Set-up Test Report S/N: SAR.200329125.FFMSAR Measurement Report Test Dates: April 03-07, 2000FCC Part 24 Certification LGIC FCC ID: FFMLST2300 (Tx 1851.25 – 1908.75 MHz) © 2000 PCTEST LabPCS CDMA WLL Terminal (Model: LST-2300)2 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects and Exposure Criteria for Radiofrequency Electromagnetic Fields,” NCRP Report No. 86 (c) NCRP, 1986, Bethesda, MD 20814.[4] SAR is a measure of the rate of energy absorption due to exposure to an RF transmitting source. SAR values have been related to threshold levels for potential biological hazards. 2.2 SAR Definition Specific Absorption Rate (SAR) is defined as the time derivative (rate) of the incremental energy (dU) absorbed by (dissipa…

Text truncated - open the document above for the full version.

File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00040304_ZOOM.VLT Start : 3-Apr-100 11:51:31 am End : 3-Apr-100 12:00:06 pm FCC ID : FFMLST2300 Model Number : LST-2300 Serial Number : 0001 Frequency : 1851.25 MHz Peak Trans. Pwr : 0.200 W Start Trans. Pwr: 0.200 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Body Phantom Posn. : Abdomen Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 54.200 Mixture Conductivity = 1.850 Comment : PCS CDMA MODE 2 CM SPACING CHAN. 0025 BODY SAR 23.0 dBm CONDUCTED LGIC PCS WLL Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 1.378 PCTEST Amplifier Channel Settings : 0.245 0.231 0.224 Max Location : X = -4.250, Y = -2.750, Z = 0.000 (cm) Value = 10.043 Measured Values (volts) = 9.711E-003 8.189E-003 5.875E-003 4.170E-003 3.361E-003 2.588E-003 2.009E-003 1.516E-003 1.116E-003 9.287E-004 8.577E-004 6.572E-004 3.766E-004 2.991E-004 3.727E-004 4.460E-004 3.988E-004 3.144E-004 2.100E-004 6.792E-005 1.373E-004 Calc. Voltage @ Surface (Vs) = 0.0125 Voltage @ 1.00 cm (Vt) = 0.0042 Ave. Voltage (Vs+Vt)/2 = 0.0083 Ave. SAR over 1 g (mW/g) = 1.0652 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 mW/g -1012345 Z centimeters SAR Scan File : 00040304_ZOOM Start : 3-Apr-100 11:51:31 am End : 3-Apr-100 12:00:06 pm FFMLST2300/LST-2300/0001;1851.25MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/54.200/1.850 File : 00040304_ZOOM Start : 3-Apr-100 11:51:31 am End : 3-Apr-100 12:00:06 pm FFMLST2300/LST-2300/0001;1851.25MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/54.200/1.850 1.281 1.200 1.118 1.036 0.954 0.873 0.791 0.709 0.627 0.545 File : 00040304_ZOOM Start : 3-Apr-100 11:51:31 am End : 3-Apr-100 12:00:06 pm FFMLST2300/LST-2300/0001;1851.25MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/54.200/1.850 1.281 1.200 1.118 1.036 0.954 0.873 0.791 0.709 0.627 0.545 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00040312_ZOOM.VLT Start : 3-Apr-100 04:00:59 pm End : 3-Apr-100 04:11:45 pm FCC ID : FFMLST2300 Model Number : LST-2300 Serial Number : 0001 Frequency : 1880 MHz Peak Trans. Pwr : 0.200 W Start Trans. Pwr: 0.200 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Body Phantom Posn. : Abdomen Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 54.200 Mixture Conductivity = 1.850 Comment : PCS CDMA MODE 2 CM SPACING CHAN. 0600 BODY SAR 23.0 dBm CONDUCTED LGIC PCS WLL Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 1.378 PCTEST Amplifier Channel Settings : 0.245 0.231 0.224 Max Location : X = -4.250, Y = -2.500, Z = 0.000 (cm) Value = 9.590 Measured Values (volts) = 9.520E-003 8.417E-003 5.755E-003 4.179E-003 3.285E-003 2.645E-003 1.972E-003 1.466E-003 1.086E-003 9.760E-004 8.559E-004 6.267E-004 4.323E-004 2.447E-004 2.974E-004 4.147E-004 3.763E-004 2.794E-004 1.166E-004 1.108E-004 1.028E-004 Calc. Voltage @ Surface (Vs) = 0.0123 Voltage @ 1.00 cm (Vt) = 0.0042 Ave. Voltage (Vs+Vt)/2 = 0.0083 Ave. SAR over 1 g (mW/g) = 1.0542 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 mW/g -1012345 Z centimeters SAR Scan File : 00040312_ZOOM Start : 3-Apr-100 04:00:59 pm End : 3-Apr-100 04:11:45 pm FFMLST2300/LST-2300/0001;1880MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/54.200/1.850 File : 00040312_ZOOM Start : 3-Apr-100 04:00:59 pm End : 3-Apr-100 04:11:45 pm FFMLST2300/LST-2300/0001;1880MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/54.200/1.850 1.224 1.140 1.057 0.974 0.891 0.808 0.725 0.641 0.558 0.475 File : 00040312_ZOOM Start : 3-Apr-100 04:00:59 pm End : 3-Apr-100 04:11:45 pm FFMLST2300/LST-2300/0001;1880MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/54.200/1.850 1.224 1.140 1.057 0.974 0.891 0.808 0.725 0.641 0.558 0.475 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00040314_ZOOM.VLT Start : 3-Apr-100 04:27:20 pm End : 3-Apr-100 04:36:47 pm FCC ID : FFMLST2300 Model Number : LST-2300 Serial Number : 0001 Frequency : 1908.75 MHz Peak Trans. Pwr : 0.200 W Start Trans. Pwr: 0.200 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Body Phantom Posn. : Abdomen Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 54.200 Mixture Conductivity = 1.850 Comment : PCS CDMA MODE 2 CM SPACING CHAN. 1175 BODY SAR 23.0 dBm CONDUCTED LGIC PCS WLL Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 1.378 PCTEST Amplifier Channel Settings : 0.245 0.231 0.224 Max Location : X = -4.250, Y = -2.250, Z = 0.000 (cm) Value = 9.283 Measured Values (volts) = 9.227E-003 7.339E-003 5.351E-003 3.908E-003 3.096E-003 2.542E-003 1.910E-003 1.418E-003 1.083E-003 9.500E-004 8.421E-004 6.540E-004 3.924E-004 2.996E-004 3.429E-004 4.596E-004 3.030E-004 2.600E-004 1.490E-004 8.072E-005 1.034E-004 Calc. Voltage @ Surface (Vs) = 0.0121 Voltage @ 1.00 cm (Vt) = 0.0039 Ave. Voltage (Vs+Vt)/2 = 0.0080 Ave. SAR over 1 g (mW/g) = 1.0230 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 mW/g -1012345 Z centimeters SAR Scan File : 00040314_ZOOM Start : 3-Apr-100 04:27:20 pm End : 3-Apr-100 04:36:47 pm FFMLST2300/LST-2300/0001;1908.75MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/54.200/1.850 File : 00040314_ZOOM Start : 3-Apr-100 04:27:20 pm End : 3-Apr-100 04:36:47 pm FFMLST2300/LST-2300/0001;1908.75MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/54.200/1.850 1.184 1.110 1.035 0.960 0.885 0.810 0.735 0.661 0.586 0.511 File : 00040314_ZOOM Start : 3-Apr-100 04:27:20 pm End : 3-Apr-100 04:36:47 pm FFMLST2300/LST-2300/0001;1908.75MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/54.200/1.850 1.184 1.110 1.035 0.960 0.885 0.…

Text truncated - open the document above for the full version.

© 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communication, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communication, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communication, Ltd. © 2000 PCTEST Lab FCC ID: FFMLST2300 NVLAP Lab Code: 100431-0 LG Information & Communication, Ltd.

© 2000 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B 6660-B DobbinDobbin Road Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 24 Certification LG Information & Communications, Ltd.Dates of Tests: April 03-07, 2000 LG Kangseo B/D 36, Munlae-Dong, 6-GaTest Report S/N: 24.200329124.FFM Youngdungpo-Gu, Seoul, 150-096, KoreaTest Site: PCTEST Lab, Columbia MD U.S.A. Attention: Mr. Yu-Sung, Sim, Approvals Engineer Quality Engineering Dept. / Research Laboratory FCC ID FFMLST2300 APPLICANT LG Information & Communications, Ltd. Classification:Licensed Base Station for Part 24 (PCB) FCC Rule Part(s):§24(E), §2 EUT Type:PCS CDMA WLL Terminal Trade Name/Model(s):LGIC LST-2300 Tx Frequency Range:1851.25 ~ 1908.75 MHz Rx Frequency Range:1931.25 ~ 1988.75 MHz Max. RF Output Power:0.266 W EIRP (24.25 dBm) Frequency Tolerance:0.00025% (2.5 ppm) Emission Designator:1M25F9W This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947 with the following remarks (Note Codes): * (BC) The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). 200329124.FFM Certification © 2000PCTEST Engineering Laboratory, Inc.FCC Part 24 TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 1 2.1 INTRODUCTION (SITE DESCRIPTION) 2 3.1 INSERTS PER §2.1033 3 4.1 DESCRIPTION OF TESTS 4-5 5.1 TEST DATA (Equivalent Isotropic Radiated Power) 6 6.1 TEST DATA (RADIATED) 7-9 7.1 TEST DATA (FREQUENCY STABILITY) 10-11 8.1 PLOTS OF EMISSIONS 12 9.1 LIST OF TEST EQUIPMENT 13 10.1 SAMPLE CALCULATIONS 14 11.1 CONCLUSION 15 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: CIRCUIT DIAGRAMS & DESCRIPTION ATTACHMENT K: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT L:OPERATIONAL DESCRIPTION ATTACHMENT M:USER’S MANUAL ATTACHMENT N:SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P:SAR TEST SETUP PHOTOGRAPHS Test Report S/N: 24.200329124.FFMFCC Part 24 Test Dates: April 03-07, 2000Certification © 2000 PCTEST LabLGIC FCC ID: FFMLST2300 (Tx 1851.25-1908.75 MHz)1 PCS CDMA WLL Terminal (Model: LST-2300) MEASUREMENT REPORT 1.1 Scope Product Evaluation and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033(d) General Information Applicant Name:LG Information & Communications, Ltd. Address:LG Kangseo B/D 36, Munlae-Dong, 6-Ga Youngdungpo-Gu, Seoul, 150-096, Korea Attention:Yu-Sung Sim, Approvals Engineer Quality Engineering Dept. / Research Laboratory • FCC ID:FFMLST2300 • Trade Name:LGIC • Model(s):LST-2300 • Quantity:Quantity production is planned • Emission Designator:1M25F9W • Tx Freq. Range:1851.25 – 1908.75 MHz Rx Freq. Range:1931.25 – 1988.75 MHz • Equipment Class:Licensed Base Station for Part 24 (PCB) • Equipment Type:PCS CDMA WLL Terminal • Modulation:CDMA • Frequency Tolerance:± 0.00025% (2.5 ppm) • Max. RF Output Power:0.266 W EIRP (24.25 dBm) • FCC Rule Part(s):§24(E), §2 • AC/DC Charger:120 VAC LGIC Model: TPS-110H 120 VAC LGIC Model: BPA-24W • Battery Pack:8.4 VDC NiCD 2100 mAh • Dates of Tests:April 03-07, 2000 • Place of Tests:PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N:24.200329124.FFM Test Report S/N: 24.200329124.FFMFCC Part 24 Test Dates: April 03-07, 2000Certification © 2000 PCTEST LabLGIC FCC ID: FFMLST2300 (Tx 1851.25-1908.75 MHz)2 PCS CDMA WLL Terminal (Model: LST-2300) 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Col…
