FFMSD500Single-Mode 800MHz CDMA Phone

LG-SD500 Operator’s Guide December 08, 1999 jong-gil Lee i FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 0.79 inches (2 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79 inches (2 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories containing metallic components should not be used. Body-worn accessories that cannot maintain 0.79 inch (2 cm) separation distance between the user’s body and the back of the phone, and have not been tested for typical body-worn operations may not comply with FCC RF exposure limits and should be avoided. Vehicle Mounted External Antenna (optional, if available.) A minimum separation distance of 7.9 inches (20 cm) must be maintained between the user/bystander and the vehicle mounted external antenna to satisfy FCC RF exposure requirements. For more information about RF exposure, please visit the FCC website at www.fcc.gov WARNING! Read this information before using your phone Terminal Development Center 1 LGIC Call Status Functions 1. Memo (Memo Soft Key 2) * Function to store a telephone number while calling l Select Memo and enter the telephone number to store. l Press Store (Soft Key 1) key. (Name is not stored) 2. Record While Calling (Menu Soft Key 1 + 1) * Function to record the conversation while calling 3. Send Own No. (Menu Soft Key 1+2) * When you leave behind your phone number when using a pager or voice mail, you can use this function to simply send your own phone number without having to press each digit of the number. Also, you can send, during a call (when using pager or voice mail), your phone number to other parties. 4. MIC Volume Control (Menu Soft Key 1 + 3) * Function to control the sensitivity of MIC while calling l You can select ‘High’ or ‘Low’ 5. Volume Control (Side Keys) * Function to control the volume while calling l You can control the volume by pressing Side Keys. 6. Mute Feature (Clear key) * Function to mute the speech voice while calling l If you press CLR key, the speech tone is muted immediately. If you want to deactivate this mute function, press CLR key again. Terminal Development Center 2 LGIC Stand-by Status Menu Set-up and Its Functions PIM 1. PHONE BOOK (Cion Secretary) [Menu + 1] * Telephone Directory / Scheduler / Alarm / Call Reserve / World Time 1.1 Contact Secretary [Menu + 1 + 1 ] 1.1.1 NEW ENTRY (Telephone Directory Register) [Menu + 1 + 1 + 1 ] 1.1.2 FIND ENTRY (Telephone Directory Search) [Menu + 1 + 1 + 2 ] 1.1.3 DELETE ENTRY (Telephone Directory Delete) [Menu + 1 + 1 + 3 ] - See the manual on the telephone directory function. 1.2 Calendar (Schedule Management Secretary) [Menu + 1 + 2 ] - See the manual on the diary function 1.2.1 Calendar : You can search the calendar by entering the month and year you want to find. * Menu +1 +2 + Menu +1 1.2.2 ADD NEW * Menu +1 +2 + Menu +2 1.2.3 SEARCH : Used to check if there is schedule,memo,anniversary on the date for your search * Menu +1 +2 +Menu +3 1.2.4 DELETE ALL : Used to delete the schedule saved in the phone. * Menu +1 +2 +Menu +4 1.2.5 DELETE OLD : Used to delete old records which are now unnecessary because their dates have expired * Menu +1 +2 +Menu +5 1.3 Alarm Secretary [Menu + 1 + 3 ] Alarm Time * User can set an alarm to the desired time. l Select one of ‘Release / Once / Daily’. l If you select ‘Release’, it becomes the state of stand-by. In case an alarm time was set previously, that setting time will be deleted. l When ‘Once / Daily’ is selected, you just enter the alarm time in the order of hour and minute. l In case the alarm time has been set already, the set alarm time and the soft keys of EDIT/OK are displayed. - If you select EDIT here, the soft key 1 of EDIT is displayed in ‘AM’ or ‘PM” mode for editing the input. Terminal Development Center 3 LGIC l ‘AM’ and ‘PM’ mode can be switched with Soft Key1[AM/PM] l You can edit the entered contents using DEL key. l Press OK key to store the entered alarm time. Note: The alarm bell is triggered at the set alarm time with the message of “Alarming Now” displayed on the display. Note: In case ‘Once’ is selected, if the END key is pressed or 1minute is passed, the alarm time is deleted. 1.4 Call Reservation Secretary [Menu + 1 + 4 ] Call Reserve * Function to originate a call to the reserved number automatically at the reserved time. l Enter the reservation time in the order of “Hour : Minute”. l ‘AM’ and ’PM’ mode can be switched with Soft Key 1[AM/PM]. l Press OK key to store the entered reserved call time. l Enter the reservation telephone number. [Up to 32 characters acceptable] l Store the entered telephone number using STORE key. Note: Telephone rings at the reserved time with the message of “Time for Reserved Call” on the display. Note: If the END key is pressed or one minute is passed, the reserved call time is automatically deleted and stored in the last call list. 1.5 World Time Secretary [Menu …

Text truncated - open the document above for the full version.

@ LG Information & Communications, Ltd. May 1, 1999 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory, Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to the application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Sincerely, General Manager of New York Office LG Information & Communications, Ltd.

December 31, 1999 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG Information & Communications, Ltd. FCC ID: FFMSD500 Part 22 Certification Gentlemen: Attached herewith, on behalf of LG Information & Communications, Ltd. is an application for Part 22 Certification of the following Single-Mode Cellular CDMA Phone: FCC ID: FFMSD500 TRADE / MODEL(s): LGIC LG-SD500, LG-SD505, LG-SD508 EUT TYPE: Single-Mode Cellular CDMA Phone Classification: Non-Broadcast Transmitter Held to Ear (TNE) Tx Freq. Range: 824.70 – 848.31 MHz Rx Freq. Range: 869.70 – 893.31 MHz Max. RF Output Power: 0.32 W ERP (25.0 dBm) Attached is the Letter of Authorization, Confidentiality Request, ESN Affidavit, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune- up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Harris Ahn Principal Engineer LGIC Communication Terminal Research Lab

March 13, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Frank Coprich / Kwok Chan SUBJECT:LG Information & Communications, Ltd. FCC ID: FFMSD500 731 Confirmation Number: EA96417 Correspondence Reference No.: 12699 Request for Additional Info.: March 13, 2000 Dear Frank / Kwok: Submitted herewith, on behalf of LG Information & Communications, Ltd., is an amendment in response to your e-mail dated March 13, 2000 requesting additional information for the subject application. 1. Attached is the revised RF exposure compliance statement. We trust this information is sufficient to issue the grant asap. If you have any further questions, please do not hesitate to contact us. Thank you. Sincerely, cc:Mr. Harris Ahn Principal Engineer Communication Terminal Research Lab LG Information & Communications, Ltd.

Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd.

© 1999 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) LG Information & Communication 99-12- 11 10/10 LG Information & Communications, Ltd. LGIC Model No. : LG-SD500 FCC ID : FFMSD500 S/N : Made in Korea

Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd. Test Report S/N: 22.991213672.FFMFCC Part 22 Test Date(s): December 13-17, 1999Certification © 1999 PCTEST Lab FCC ID: FFMSD500 NVLAP Lab Code: 100431-0 LG Information & Communications, Ltd.

i FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 0.79 inches (2 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79 inches (2 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories containing metallic components should not be used. Body-worn accessories that cannot maintain 0.79 inch (2 cm) separation distance between the user’s body and the back of the phone, and have not been tested for typical body-worn operations may not comply with FCC RF exposure limits and should be avoided. Vehicle Mounted External Antenna (optional, if available.) A minimum separation distance of 7.9 inches (20 cm) must be maintained between the user/bystander and the vehicle mounted external antenna to satisfy FCC RF exposure requirements. For more information about RF exposure, please visit the FCC website at www.fcc.gov WARNING! Read this information before using your phone

© 1999 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B 6660-B DobbinDobbin Road Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) LG Information & Communications, Ltd.Dates of Tests: December 13-17, 1999 Communication Terminal Research LabTest Report S/N: SAR.991213673.FFM 459-9, Kasan-dong, Keumchun-kuTest Site: PCTEST Lab, Columbia, MD Seoul 153-023, Korea Attn: Harris Ahn, Principal Engineer FCC ID FFMSD500 APPLICANT LG Information & Communications, Ltd. EUT Type:Single-Mode Cellular CDMA Phone Tx Frequency:824.70 – 848.31 MHz Rx Frequency:869.70 – 893.31 MHz Max. RF Output Power:0.32W ERP (25.0 dBm) Trade Name/Model(s):LGIC LG-SD500, LG-SD505, LG-SD508 FCC Classification:Non-Broadcast Transmitter Held to Ear (TNE) Application Type:Certification Serial Number:n/a (pre production) FCC Rule Part(s):2.1093; ET Docket 96.326; 22.901(d) This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). 991213673.FFM SAR Measurement ReportFCC Part 22 Certification © 1999 PCTEST Labi Table of Contents 1.1 SCOPE1 2.1 INTRODUCTION / SAR DEFINITION2 3.1 SAR MEASUREMENT SET-UP3 4.1 ISOTROPIC E-FIELD PROBE SYSTEM4 5.1 E-FIELD PROBE SYSTEM5-6 6.1 PHANTOM & EQUIVALENT TISSUES7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS9 9.1 TEST POSITION OF THE PHONE10 10.1 BODY-WORN CONFIGURATION TEST SETUP11 11.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS12 12.1 MEASUREMENT UNCERTAINTIES13 13.1 TEST DATA SUMMARY14-15 14.1 SAR TEST EQUIPMENT LIST16 15.1 CONCLUSION / REFERENCES17 Test Report S/N: SAR.991213673.FFMSAR Measurement Report Test Dates: December 13-17, 1999FCC Part 22 Certification CDMA Phone FCC ID: FFMSD500 (Tx 824-849 MHz) © 1999 PCTEST LabLGIC Models: LG-SD500, LG-SD505, LG-SD5081 Figure 1. SAR Test Set-up SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Applicant:LG Information & Communications, Ltd. Communication Terminal Research Lab Address:459-9, Kasan-dong, Keumchun-ku Seoul 153-023, Korea Attention:Harris Ahn, Principal Engineer • EUT Type:Single-Mode Cellular CDMA Phone • FCC Rule Part(s):§ 2.1093, Docket 96-326; § 22.901(d) • Trade Name:LGIC • FCC IDENTIFIER:FFMSD500 • Model(s):LG-SD500, LG-SD505, LG-SD508 • S/N:Pre-production • Tx Frequency:824.70 ~ 848.31 MHz • Rx Frequency:869.70 ~ 893.31 MHz • Application Type: Certification • FCC Classification:Non-Broadcast Transmitter Held to Ear (TNE) • Max. RF Output Power:0.32W ERP (25.0 dBm) • Modulation:CDMA • Antenna Type:Helical (λ/2) • Antenna Dimensions:9.3 cm. (Length) • Dates of Tests:December 13-17, 1999 • Place of Tests:PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.:SAR.991213673.FFM 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Test Report S/N: SAR.991213673.FFMSAR Measurement Report Test Dates: December 13-17, 1999FCC Part 22 Certification CDMA Phone FCC ID: FFMSD500 (Tx 824-849 MHz) © 1999 PCTEST LabLGIC Models: LG-SD500, LG-SD505, LG-SD5082 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects and Exposure Criteria for Radiofrequency Electromagnetic Fields,” NCRP Report No. 86 (c) NCRP, 1986, Bethesda, MD 20814.[4] SAR is a measure of the rate of energy absorption due to exposure to an RF transmitting source. SAR values have been related to threshold levels for potential biological hazards. 2.2 SAR Definition Specific Absorption Rate (SAR) is defined as the time derivative (rate) of the incre…

Text truncated - open the document above for the full version.

File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/99121307_ZOOM.VLT Start : 13-Dec-99 12:08:12 pm End : 13-Dec-99 12:09:39 pm Radio Type : LGIC LG-SD500 FCC ID : FFMSD500 Serial Number : U4 Frequency : 824.70 MHz Peak Trans. Pwr : 0.285 W Start Trans. Pwr: 0.285 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 43.400 Mixture Conductivity = 0.900 Comment : LGIC SINGLE MODE PHONE - CHAN. 1013 MODE +24.50 dBM CONDUCTED Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.790 PCTEST Amplifier Channel Settings : 0.168 0.136 0.132 Max Location : X = 4.000, Y = -5.500, Z = 0.000 (cm) Value = 15.019 Measured Values (volts) = 1.681E-002 1.530E-002 1.339E-002 1.187E-002 1.043E-002 8.552E-003 7.021E-003 5.846E-003 4.594E-003 4.086E-003 4.069E-003 4.392E-003 4.997E-003 5.619E-003 6.012E-003 5.927E-003 5.120E-003 3.295E-003 1.481E-003 5.551E-004 2.787E-004 Calc. Voltage @ Surface (Vs) = 0.0188 Voltage @ 1.00 cm (Vt) = 0.0119 Ave. Voltage (Vs+Vt)/2 = 0.0153 Ave. SAR over 1 g (mW/g) = 1.1228 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 mW/g -1012345 Z centimeters SAR Scan File : 99121307_ZOOM Start : 13-Dec-99 12:08:12 pm End : 13-Dec-99 12:09:39 pm LGIC/FFMSD500/U4;824.70MHz;W;Helical/In; Head/Left Ear;SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00011211_ZOOM.VLT Start : 12-Jan-100 04:26:51 pm End : 12-Jan-100 04:40:10 pm Radio Type : LGIC LG-SD500 FCC ID : FFMSD500 Serial Number : U4 Frequency : 824.70 MHz Peak Trans. Pwr : 0.285 W Start Trans. Pwr: 0.285 W Antenna Type : Helical Antenna Posn. : Out Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 43.400 Mixture Conductivity = 0.900 Comment : CDMA MODE PHONE CHAN. 1013 SINGLE BAND HAND SAR Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.790 PCTEST Amplifier Channel Settings : 0.168 0.136 0.132 Max Location : X = 2.000, Y = -1.250, Z = 0.000 (cm) Value = 19.915 Measured Values (volts) = 1.936E-002 1.520E-002 1.287E-002 1.146E-002 1.034E-002 9.204E-003 7.994E-003 6.644E-003 5.525E-003 4.210E-003 3.211E-003 2.340E-003 1.838E-003 1.600E-003 1.740E-003 2.054E-003 2.477E-003 2.857E-003 2.935E-003 2.685E-003 1.816E-003 Calc. Voltage @ Surface (Vs) = 0.0238 Voltage @ 1.00 cm (Vt) = 0.0115 Ave. Voltage (Vs+Vt)/2 = 0.0176 Ave. SAR over 1 g (mW/g) = 1.2883 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 mW/g -1012345 Z centimeters SAR Scan File : 99121311_ZOOM Start : 13-Dec-99 12:57:36 pm End : 13-Dec-99 01:04:29 pm LGIC/FFMSD500/U4;835.89MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/99121718_ZOOM.VLT Start : 17-Dec-99 05:49:03 pm End : 17-Dec-99 05:58:54 pm Radio Type : LGIC LG-SD500 FCC ID : FFMSD500 Serial Number : U4 Frequency : 835.89 MHz Peak Trans. Pwr : 0.285 W Start Trans. Pwr: 0.285 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 43.400 Mixture Conductivity = 0.900 Comment : LGIC DUAL CDMA PHONE CHAN. 363 CDMA MODE +24.50 dBM CONDUCTED Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.790 PCTEST Amplifier Channel Settings : 0.168 0.136 0.132 Max Location : X = 3.250, Y = -4.000, Z = 0.000 (cm) Value = 19.715 Measured Values (volts) = 1.850E-002 1.691E-002 1.434E-002 1.262E-002 1.137E-002 1.006E-002 8.764E-003 7.382E-003 6.152E-003 4.801E-003 3.664E-003 2.904E-003 2.308E-003 2.114E-003 2.139E-003 2.317E-003 2.571E-003 2.581E-003 2.480E-003 2.030E-003 1.114E-003 Calc. Voltage @ Surface (Vs) = 0.0210 Voltage @ 1.00 cm (Vt) = 0.0126 Ave. Voltage (Vs+Vt)/2 = 0.0168 Ave. SAR over 1 g (mW/g) = 1.2303 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 mW/g -1012345 Z centimeters SAR Scan File : 99121718_ZOOM Start : 17-Dec-99 05:49:03 pm End : 17-Dec-99 05:58:54 pm LGIC/FFMSD500/U4;835.89MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/99121311_ZOOM.VLT Start : 13-Dec-99 12:57:36 pm End : 13-Dec-99 01:04:29 pm Radio Type : LGIC LG-SD500 FCC ID : FFMSD500 Serial Number : U4 Frequency : 835.89 MHz Peak Trans. Pwr : 0.285 W Start Trans. Pwr: 0.285 W Antenna Type : Helical Antenna Posn. : Out Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 43.400 Mixture Conductivity = 0.900 Comment : LGIC SINGLE MODE PHONE - CHAN. 363 MODE +24.5 dBM CONDUCTED Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.790 PCTEST Amplifier Channel Settings : 0.168 0.136 0.132 Max Location : X = 4.000, Y = -5.500, Z = 0.000 (cm) Value = 20.330 Measured Values (volts) = 1.937E-002 1.787E-002 1.580E-002 1.358E-002 1.199E-002 9.778E-003 8.121E-003 6.304E-003 5.187E-003 4.438E-003 4.380E-003 4.770E-003 5.428E-003 6.230E-003 6.762E-003 6.725E-003 5.969E-003 4.211E-003 1.917E-003 1.047E-003 4.621E-004 Calc. Voltage @ Surface (Vs) = 0.0215 Voltage @ 1.00 cm (Vt) = 0.0136 Ave. Voltage (Vs+Vt)/2 = 0.0175 Ave. SAR over 1 g (mW/g) = 1.2812 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 mW/g -1012345 Z centimeters SAR Scan File : 99121311_ZOOM Start : 13-Dec-99 12:57:36 pm End : 13-Dec-99 01:04:29 pm LGIC/FFMSD500/U4;835.89MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00010817_ZOOM.VLT Start : 8-Jan-100 03:30:07 pm End : 8-Jan-100 03:44:10 pm Radio Type : LGIC LG-SD500 FCC ID : FFMSD500 Serial Number : U4 Frequency : 848.31 MHz Peak Trans. Pw…

Text truncated - open the document above for the full version.

File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00011202_SAR.VLT Start : 12-Jan-100 09:02:53 am End : 12-Jan-100 09:09:30 am Radio Type : LGIC LG-SD500 FCC ID : FFMSD500 Serial Number : U4 Frequency : 848.31 MHz Peak Trans. Pwr : 0.285 W Start Trans. Pwr: 0.285 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR 10g Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 51.700 Mixture Conductivity = 1.100 Comment : CDMA MODE PHONE CHAN. 777 SINGLE BAND HAND SAR Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.895 PCTEST Amplifier Channel Settings : 0.168 0.136 0.132 Max Location : X = 2.250, Y = -1.000, Z = 0.000 (cm) Value = 44.823 Ave. SAR over 10 g (mW/g) = 1.0371 0.60 0.70 0.80 0.90 Ave SAR over 2 cm 1.31.41.51.61.71.81.92.02.12.22.32.42.52.62.72.82.93.03.13.2 X centimeters X-Z Plane Slice Y=-1.000 File : 00011202_SAR Start : 12-Jan-100 09:02:53 am End : 12-Jan-100 09:09:30 am LGIC/FFMSD500/01;848.31MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR 10g;PCTEST/E Field/0 DegreesMuscle/51.700/1.100 File : 00011202_SAR Start : 12-Jan-100 09:02:53 am End : 12-Jan-100 09:09:30 am LGIC/FFMSD500/01;848.31MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR 10g;PCTEST/E Field/0 DegreesMuscle/51.700/1.100 1.64 1.52 1.39 1.27 1.15 1.02 0.90 0.78 0.65 0.53 File : 00011202_SAR Start : 12-Jan-100 09:02:53 am End : 12-Jan-100 09:09:30 am LGIC/FFMSD500/01;848.31MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR 10g;PCTEST/E Field/0 DegreesMuscle/51.700/1.100 1.64 1.52 1.39 1.27 1.15 1.02 0.90 0.78 0.65 0.53 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00011201_SAR.VLT Start : 12-Jan-100 08:39:17 am End : 12-Jan-100 08:45:54 am Radio Type : LGIC LG-SD500 FCC ID : FFMSD500 Serial Number : U4 Frequency : 848.31 MHz Peak Trans. Pwr : 0.285 W Start Trans. Pwr: 0.285 W Antenna Type : Helical Antenna Posn. : Out Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR 10g Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 51.700 Mixture Conductivity = 1.100 Comment : CDMA MODE PHONE CHAN. 777 SINGLE BAND HAND SAR Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.895 PCTEST Amplifier Channel Settings : 0.168 0.136 0.132 Max Location : X = 2.250, Y = -1.000, Z = 0.000 (cm) Value = 46.138 Ave. SAR over 10 g (mW/g) = 1.0419 0.60 0.70 0.80 0.90 Ave SAR over 2 cm 1.31.41.51.61.71.81.92.02.12.22.32.42.52.62.72.82.93.03.13.2 X centimeters X-Z Plane Slice Y=-1.000 File : 00011201_SAR Start : 12-Jan-100 08:39:17 am End : 12-Jan-100 08:45:54 am LGIC/FFMSD500/01;848.31MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR 10g;PCTEST/E Field/0 DegreesMuscle/51.700/1.100 File : 00011201_SAR Start : 12-Jan-100 08:39:17 am End : 12-Jan-100 08:45:54 am LGIC/FFMSD500/01;848.31MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR 10g;PCTEST/E Field/0 DegreesMuscle/51.700/1.100 1.62 1.50 1.38 1.26 1.14 1.01 0.89 0.77 0.65 0.53 File : 00011201_SAR Start : 12-Jan-100 08:39:17 am End : 12-Jan-100 08:45:54 am LGIC/FFMSD500/01;848.31MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR 10g;PCTEST/E Field/0 DegreesMuscle/51.700/1.100 1.62 1.50 1.38 1.26 1.14 1.01 0.89 0.77 0.65 0.53

File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00011005_ZOOM.VLT Start : 10-Jan-100 09:08:57 am End : 10-Jan-100 09:22:27 am Radio Type : LGIC LG-SD500 FCC ID : FFMSD500 Serial Number : U4 Frequency : 824.70 MHz Peak Trans. Pwr : 0.285 W Start Trans. Pwr: 0.285 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Body Phantom Posn. : Abdomen Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 51.700 Mixture Conductivity = 1.100 Comment : CDMA MODE PHONE CHAN. 1013 BODY (FLIP) 2 cm SINGLE BAND 24.5 dB CONDUCTED Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.895 PCTEST Amplifier Channel Settings : 0.168 0.136 0.132 Max Location : X = -0.750, Y = -2.500, Z = 0.000 (cm) Value = 15.191 Measured Values (volts) = 1.474E-…

Text truncated - open the document above for the full version.
