5634RCS User’s Manual 1 Congratulations on purchasing the most sophisticated modem available. Your modem combines advanced technology with state-of-the-art features to bring you the modern advanced communications device available today! This modem provides the following features. n Modem Capabilities ® K56Flex, V.90, 56000bps, 33600bps, 31200bps ® ITU-T V.34, V.32bis, V.32, V.23, V.22bis, V.22, V.21, Bell 212A, and 103 ® V.42LAPM and MNP 2-4, and MNP 10 error correction ® V.42bis and MNP 5 data compression n Fax Capabilities ® ITU-T V.33, V.17, V.29, V.27ter, and V.21 Channel 2, 300 to 14400bps. ® TIA/EIA 578 Class 1 Fax n Voice Capabilities ® Concurrent DTMF and tone detection ® Remote or local telephone answering machine/ voice mail control ® Enhanced ADPCM compression/decompression ® Record/playback via handset or mic/speaker n Caller ID n Speakerphone Capabilities ® Full-duplex speakerphone (acoustic and line echo cancellation) ® Microphone gain and muting ® Speaker volume control and muting ® Room Monitor n ASVD (Analog simultaneous voice and data) or AudioSpan (simultaneous audio/voice and data) ® ITU-T V.61 modulation (4.8 kbps data plus audio) ® Handset, headset, or half-duplex speakerphone n Voice View Protocol Support ® Voice mode (local handset and FDSP) ® Voice View data mode (V.17,V.29,V.27ter,and V.21 ch2) n Video Ready Modem ® Follows H.324, V.80,V.70 DSVD standard Trademark Windows and MS-DOS are trademarks of Microsoft Corporation. IBM PC/AT is a trademark of International Business Machines. Other product or company names are trademarks or registered trademarks of their respective holders. 5634RCS User’s Manual 2 Table of Contents CHAPTER 1 INSTALLING THE MODEM.............................................................4 1.1 C HECKING YOUR COMPONENTS .................................................................................................4 1.2 W HAT ELSE YOU NEED .............................................................................................................4 1.3 I NSTALLING THE MODEM ...........................................................................................................4 1.4 P REREQUISITES ......................................................................................................................4 1.5 C ONNECTING TO A COMPUTER OR TERMINAL ...............................................................................5 1.6 C ONNECTING TO THE TELEPHONE LINE .......................................................................................5 1.7 C ONNECTING TO YOUR TELEPHONE ...........................................................................................6 1.8 C ONNECTING TO AN AC OUTLET ...............................................................................................6 1.9 U SING A EXTERNAL MIC AND SPEAKER ......................................................................................6 1.10 V ERIFYING YOUR CONNECTION ................................................................................................6 1.11 M ODEM LED S .......................................................................................................................8 CHAPTER 2 TYPING COMMANDS AND RECEIVING RESPONSES.................10 2.1 T YPING A COMMAND .................................................................................................................10 2.2 T O TYPE A COMMAND LINE ........................................................................................................10 2.3 C ORRECTING A TYPING MISTAKE ................................................................................................10 2.4 R EADABILITY ...........................................................................................................................10 2.5 T YPING MORE THAN 40 CHARACTERS .........................................................................................11 2.6 O MITTING A PARAMETER ...........................................................................................................11 2.7 R EPEATING A COMMAND LINE ....................................................................................................11 2.8 M ODEM RESPONSES ................................................................................................................11 2.9 W ORD OR NUMERIC RESPONSES ...............................................................................................12 2.9.1 X0 response set..............................................................................................................12 2.9.2 X1 response set..............................................................................................................12 2.9.3 X2 response set..............................................................................................................12 2.9.4 X3 response set..............................................................................................................13 2.9.5 X4 response set..............................................................................................................13 2.10 C ORRECTION & COMPRESSION RESPONSES ..............................................................................13 CHAPTER 3 USING CONFIGURATION PROFILES............................................19 3.1 S TORING A PROFILE .................................................................................................................19 3.2 R ECALLING A PROFILE ..............................................................................................................19 3.3 R ESET AND RECALLING PROFILE ................................................................................................20 CHAPTER 4 ERROR CORRECTION AND DATA COMPRESSION....................22 4.1 E RROR - CORRECTION PROTOCOLS .............................................................................................22 4.2 V.42...................…

Text truncated - open the document above for the full version.

MAX LIGHT Report Number: MLT9901P15003 FCC ID: FI7MRCES56 Technology Lab MAX LIGHT Report Number: MLT9901P15003 FCC ID: FI7MRCES56 Technology Lab MAX LIGHT Report Number: MLT9901P15003 FCC ID: FI7MRCES56 Technology Lab MAX LIGHT Report Number: MLT9901P15003 FCC ID: FI7MRCES56 Technology Lab

MAX LIGHT Report Number: MLT9901P15003 FCC ID: FI7MRCES56 Technology Lab MAX LIGHT Report Number: MLT9901P15003 FCC ID: FI7MRCES56 Technology Lab MAX LIGHT Report Number: MLT9901P15003 FCC ID: FI7MRCES56 Technology Lab MAX LIGHT Report Number: MLT9901P15003 FCC ID: FI7MRCES56 Technology Lab

MAX LIGHT Report Number: MLT9901P15003 FCC ID: FI7MRCES56 Technology Lab Label Format: Label Position: This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,and (2) This device must accept any interference received ,including. Interference that may cause undesired operation. Model: 5634RCS FCC ID: FI7MRCES56 MADE IN TAIWAN Equipment Lable 7CMX2.5CM Rear View

8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 1 DD CC BB AA + ACTIVE SPK 24.9k 10k300 AUDIO A 5634RCS ARCHTEK TELECOM CORPORATION B 26Monday, March 01, 1999 Title SizeDocument NumberRev Date:Sheet of MIC_IN SPKR_O VC +12VA AVDD +12VA _12VA J1 STEREO JACK 5 4 3 2 1 J2 MIC 5 4 3 2 1 - U1 LM386 2 3 5 61 48 7 LS1 BUZZER R3 5.6K R4 1K C3 0.1UF C4 0.1UF C17 10UF C18 10UF C19 10UF + C20 10UF C34 0.1UF C35 0.1UF C36 0.1UF C40 22UF C41 22UF R8 0 R9 0 L3BEAD 12 L4 BEAD 1 2 L8 BEAD 12 C47 0.1UF + - U10A 1458 3 2 1 8 4 C48 0.1UF C49 0.1UF R12 0 *L15 CHOKE R2 0

8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 1 DD CC BB AA LINE PHONE DAAA 5634RCS ARCHTEK TELECOM CORPORATION B 36Monday, March 01, 1999 Title SizeDocument NumberRev Date:Sheet of TXA1 RXA RING /OH TXA2 /VOICE LCS VCC VCC VCC VCC T1 TRANS. 61 43 C520.047UF/250V Q2 BC517 2 3 1 C53 4.7UF/50V CNT1B RJ-11 7 6 5 8 CNT1A RJ-11 3 2 1 4 L10 BEAD 12 L11 BEAD 1 2 L12 BEAD 1 2 C54 0.47U/250V D12 24V 2 1 D13 1N4148 D14 24V 2 1 R16 7.5K U12 4N35 6 4 5 1 3 2 R18 18.2 RV1 V250LC4 R19 10 1% R21100 1% R22 0 R23 39.2K 1% R24 59K 1% R25 1.33K R26 165 R27 442 D16 4.3V 2 1 D17 4.3V 2 1 C56 47UF C58 1000PF C59 1000PF D18 24V 2 1 C60 1000PF L13 BEAD 1 2 C61 1000PF C62 1000PF C63 47UF D19 1N4148 D20 1N4004 21 D21 1N4004 2 1 D22 1N4004 21 D23 1N4004 2 1 K2 1A05 1 7 5 3 R46 18.2 R31 0 R41 0 R440 R450 R30 0 R42 0 R17 10K R29 20 *L9 CHOKE 1 4 2 3 *L14 CHOKE 1 4 2 3 *U11 PC814 2 1 3 4 *K1 RLY-2D2P 139 1 16 11 6 84 *D11 1N4148 2 1 *Q1 3906 *R43 27K *R20 2.7K *LA1 EMI *CA1 EMI *C55 0.1UF *R28 120 *D15 8.2V 2 1 R15 10K CR57 0

8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 1 DD CC BB AA DSPA 5634RCS ARCHTEK TELECOM CORPORATION B 46Monday, March 01, 1999 Title SizeDocument NumberRev Date:Sheet of CLKOUT /HRESET /HRESET RING /RLSD/RLSDIND /TXCLK CLKOUT /DSR /CTSRING /RLSDNVMDATA /TXD/DPRXD /AAIND/TXCLK/RXCLK /RI/RXCLK /DPRXD /RDL/RXD NVMCLK /DTRIND /DTR A0 /RTSA1 /HRESETA2 A3 A0A4 A1/DPSEL A2/WRITE A3/READ A4 A5D0 A6D1 A7D2 A8/OHD3 A9/VOICED4 A10D5 A11D6 A12LCSD7 A13 A14VC A15 A16SPKR_O A17D0RXA /READD1 /WRITED2 /RAMSELD3 /ROMSELD4 /DPSELD5TXA1 D6TXA2 D7 MIC_IN AVDD VCC VCC VCC 3_3V VCC VCC VCC 3_3V R1 10K C1 10UF C2 10UF D1 1N4148 2 1 C5 10UF C6 0.1UF L1 BEAD 12 C7 10UF C8 0.1UF C11 0.1UF C12 0.1UF C16 0.1UF R710K U7 24C02 1 3 8 6 2 45 7 A0 A2 VCC SCL A1 GNDSDA TEST U8 R6764-51P 28 40 49 63 68 85 71 58 78 64 98 79 80 9 67 1 11 12 13 14 15 38 47 61 66 70 72 73 74 75 76 77 83 84 96 97 2 3 4 5 6 7 88 89 90 91 92 93 94 95 48 39 16 65 81 99 100 86 87 24 44 18 43 62 41 17 36 60 55 23 46 56 69 21 51 20 45 8 82 50 59 52 10 53 19 54 22 42 37 34 31 30 27 26 35 29 33 32 57 25 VA&MAVDD IAVDD GND VDD VDD VDD VGG IA2CLK PB2 GP01 PLLVDD PB3 PB5 WKRESP PA6 PF7 RLSD TDCLK TXD XYCNT PF6 M_DIG_SP M_RELAYA CSP A4 A3 A2 A1 A0 YCLK XCLK DSPIRQ DSPWTP DSPRDP PD0 PD1 PD2 PD3 PD4 PD5 PD6 PD7 PC0 PC1 PC2 PC3 PC4 PC5 PC6 PC7 IAGND IAGND GND GND GND GND PLLGND XTLI/CLKIN XTLO IA1CLK M_SCK SR4OUT M_TXSIN SR1IO M_CTRL_SIN RESP POR SR2IO V_CTRL_SIN SA1CLK M_STROBE V_SLEEP PF5 SR3IN V_RXOUT SR4IN M_RXOUT RDCLK GPO0 V_STROBE SA2CLK V_SCK SR2CLK TXSIN SR3OUT V_CLKIN PB0 M_CLKIN M_MIC_IN V_MIC_IN M_LINEOUTM M_LINEOUTP V_LINEOUT V_LINE_IN M_LINE_IN M_SPKR_OUT VC VREF TESTP IAGND U9 L2800-38 32 33 34 35 36 37 38 39 73 74 75 76 77 78 79 80 51 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 811 53 12 29 52 72 2 1 40 7 9 10 4 3 70 71 5 6 30 31 49 50 41 42 43 44 45 46 47 48 PA0 PA1 PA2 PA3 PA4 PA5 PA6 PA7 A16 PB1 PB2 PB3 A17 PB5 PB6 PB7 VDD PC0 PC1 PC2 PC3 PC4 PC5 PC6 PC7 PD0 PD1 PD2 PD3 PD4 PD5 PD6 PD7 A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 VDDVD3 GND GND GND GND GND NMIP RESP TSTP PSC XTL1 XTL0 ~READ ~WRITE PE0 PE1 PE2 PE3 PE4 CLKOUT PE6 PE7 D0 D1 D2 D3 D4 D5 D6 D7 R10 5.1 C45 0.1UF C66 0.1UF C67 0.1UF C68 0.1UF C69 10UF C70 4700PF Y1 28.224MHZ 12 L16 BEAD 12 R3651 L17BEAD 12 C71 0.22UF C72 0.1UF C73 0.1UF C74 10uF L18BEAD 12 R38 51 C77 0.1UF L23 BEAD R39 0 R14 0 R35 0 R37 0 *L7 4.7UH *C46 56PF *C44 20PF *R13 0 *R32 0 *C43 20PF C75 18PF C76 18PF

8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 1 DD CC BB AA MEMORRYA 5634RCS ARCHTEK TELECOM CORPORATION B 56Monday, March 01, 1999 Title SizeDocument NumberRev Date:Sheet of A0D0 A1D1 A2D2 A3D3 A4D4 A5D5 A6D6 A7D7 A8 A9 A10A17 A11 A12 A13 A14 A15 A16 /WRITE /ROMSEL /READ A0D0 A1D1 A2D2 A3D3 A4D4 A5D5 A6D6 A7D7 A8 A9 A10 A11 A12 A13 A14 A15 A16 /WRITE /RAMSEL /READ VCC VCC VCC VCC VCC VCC R5 10K C9 0.1UF C10 0.1UF U2 SRAM 12 11 10 9 8 7 6 5 27 26 23 25 4 28 3 29 22 24 13 14 15 17 18 19 20 21 32 16 31 2 30 1 A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 ~WE ~CS ~OE D0 D1 D2 D3 D4 D5 D6 D7 VCC GND A15 A16 ~CS2 NC U3 FLASH 12 11 10 9 8 7 6 5 27 26 23 25 4 28 29 3 2 31 22 24 13 14 15 17 18 19 20 21 32 1 30 16 A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 A16 ~WE ~CE ~OE D0 D1 D2 D3 D4 D5 D6 D7 VCC VPP NC GND

8 8 7 7 6 6 5 5 4 4 3 3 2 2 1 1 DD CC BB AA POWERA 5634RCS ARCHTEK TELECOM CORPORATION B 66Monday, March 01, 1999 Title SizeDocument NumberRev Date:Sheet of _12V +12V VCC _12V +12V VCC +12VVCC +12VA _12VA +12V +12V S1 POWER_SW 3 2 U6 LM2575 1 35 4 2 VIN GNDON/OFF FB OUTPUT L2 100uH + C13 220UF + C14 220UF + C15 220UF C38 0.1UF P2 JACK-9VAC 31 2 + C39 2200uF + C42 470UF L5 BEAD L6 BEAD C64 10NF/50V D24 1N4004 21 D25 1N4004 21 D26 1N4004 21 D27 1N4004 21 D28 1N4004 21 D29 1N4004 21 D30 1N4004 21 D31 1N4004 21 L20 4.7UH L21 4.7UH D32 1N5819 2 1 R11 0 R40 0 CTOSC Q S R ISENSE - + 1.25 *U13 AMC7660 1 8 24 5 76 3 *R47 200K *C65 470PF *R50 2.2M *R49 470 *D33 1N4148 21 *R48 0.33 *L22 300UH *C81 1UF/35V *D35 1N5819 2 1 *C80 0.1UF + *C82 470UF *D34 1N4148 2 1 *R33 1.2K *R34 3.6K *C79 2NF *L19 CHOKE 14 23 *C78 330PF/50V *F1 FUSE 2A/250V *C50 1nF/50V *C51 1nF/50V *R51 0

Product : 56K Data / Fax FDSP External Modem Manufacture : Archtek Telecom Corporation FCC ID : FI7MRCES56 Model : 5634RCS Report No. : MLT9901P15003 Test Date : 01/20/1999 Test By Max Light Technology Co.,Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 MAX LIGHT MEASUREMENT REPORT Page:2/21 Report Number: MLT9901P15003FCC ID: FI7MRCES56 Technology Lab Table of Contents : I. General 4. II. Conducted Emissions Requirements 9. III. Radiated Emissions Requirements 13. Appendix I (EUT Test Setup) 18. MAX LIGHT MEASUREMENT REPORT Page:3/21 Report Number: MLT9901P15003FCC ID: FI7MRCES56 Technology Lab CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-1992. All test were conducted by MLT(Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with Class B radiated and conducted emission limit of FCC Rules Part 15 Subpart B. EUT: 56K Data / Fax FDSP External Modem Applicant: Archtek Telecom Corporation . 4F. No.9, Lane 130, Min-Chyuan Rd., Hsin-Tien , Taipei ,Taiwan Manufacturer: Archtek Telecom Corporation . 4F. No.9, Lane 130, Min-Chyuan Rd., Hsin-Tien , Taipei ,Taiwan Model No: 5634RCS FCC ID: FI7MRCES56 Prepared by :Approved by : Country Huang Roger Chen MAX LIGHT MEASUREMENT REPORT Page:4/21 Report Number: MLT9901P15003FCC ID: FI7MRCES56 Technology Lab I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Archtek Telecom Corporation. In support of a Class B Digital Device certification in accordance with Part2 Subpart J and Part 15 Subpart A And B of the Commission’s and Regulations. 1.2 Description of EUT EUT: 56K Data / Fax FDSP External Modem Applicant: Archtek Telecom Corporation . 4F. No.9, Lane 130, Min-Chyuan Rd., Hsin-Tien , Taipei ,Taiwan Manufacturer: Archtek Telecom Corporation . 4F. No.9, Lane 130, Min-Chyuan Rd., Hsin-Tien , Taipei ,Taiwan Model No: 5634RCS FCC ID : FI7MRCES56 Power Type: Powered by AC Adpator Phone Cable: RJ-11Cx2(Nonshielded, 7’ long ,Plastic hoods) During testing the EUT was operated at Tx or Rx mode for each emission measured. This was done in order to ensure that maximum emission levels were attained. MAX LIGHT MEASUREMENT REPORT Page:5/21 Report Number: MLT9901P15003FCC ID: FI7MRCES56 Technology Lab 1.3 Description of Support Equipment In order to construct the minimum system which required by the ANSI C63.4-1991, following equipments were used as the support units. Computer: COMPAQ Model No.: 3284 Serial No.: L708BKTB4154 FCC ID: EJH3284 Keyboard: COMPAQ Model No.: KPQ-E99ZC-13 Serial No.: 237743-334 FCC ID: CMYKPQ7285 Monitor: COMPAQ Model No.: 303U Serial No.: 704AG19TG099 FCC ID: BJMCM14UH Mouse: COMPAQ Model No.: 196694-301 Serial No.: 1SH67CHE03360 FCC ID: EMJMUSJJ Printer: PANASONIC Model No.: KX-P1080I Serial No.: 7CKAKE98933 FCC ID: ACJ5Z6KX-P10801 PSTN Simulator: MLT Model No.: 101 Serial No.: N/A MAX LIGHT MEASUREMENT REPORT Page:6/21 Report Number: MLT9901P15003FCC ID: FI7MRCES56 Technology Lab Telephone: GE Model No.: 2-9240A Serial No.: 1943K Speaker: KAKA Model No.: 2K-A01 Serial No.: 189665 Microphone: Ever Power Model No.: TC-944 Serial No.: N/A MAX LIGHT MEASUREMENT REPORT Page:7/21 Report Number: MLT9901P15003FCC ID: FI7MRCES56 Technology Lab 1.4 Configuration of System Under Test During testing the EUT(External Data/Fax Modem with voice) was connected to the Compaq PC. So there is no need for additional I/O card. A mouse was connected to the mouse port and a printer was connected to the parallel port. A telephone set was connected to the Phone Jack of EUT and the Line Jack of EUT was connected to a simulator of PSTN. And the Speaker Jack and Microphone Jack were connected with a small microphone and a external speaker. Power Supply PC Monitor Printer Keyboard Mouse Mic. Speaker EUT Telephone RJ11C Cables RS-232RS-232 To PSTN Speaker MAX LIGHT MEASUREMENT REPORT Page:8/21 Report Number: MLT9901P15003FCC ID: FI7MRCES56 Technology Lab 1.5 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4-1992 "Measurement of unIntentional Radiators." 1.6 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests was chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. The system's radiated and conducted emissions were investigated while the computer alternately transferred data to the EUT as well as to the monitor and printer. Using a test program which sent a continuous stream of “H” characters to monitor and transferred data to and from the EUT was proven to worst case emissions. The system's physical layout and cabling was randomly arranged to ensure that maximum emission levels were attained. MAX LIGHT MEASUREMENT REPORT Page:9/21 Report Number: MLT9901P15003FCC ID: FI7MRCES56 Technology Lab II. Conducted Emissions Requirements 2.1 General & Setup : The power line conducted emission measurements were performed in a shielded enclosure. The EUT was assembled on a wooden table which is 80 centimeters high, was placed 40 centimeters from the backwall and at least 1 meter from the sidewall. Power was fed to the EUT from the public utility power grid through a line filter and EMCO Model 3825/2 Line Impedance Stabilization Networks (LISN). The LISN housing, measuring instrumentation case, ground plane, etc., were electrically bo…
