FIH-2000BVehicle Reporting System

LEON-G100 / LEON-G200 quad-band GSM/GPRS Data and Voice Modules System Integration Manual 29.5 x 18.9 x 3.0 mm www.u-blox.com locate, communicate, accelerate Abstract This document describes the features and integration of the LEON-G100/G200 quad-band GSM/GPRS data and voice modules. The LEON-G100/G200 are complete and cost efficient solutions, bringing full feature quad-band GSM/GPRS data and voice transmission technology in a compact form factor. LEON-G100 / LEON-G200 - System Integration Manual GSM.G1-HW-09002-G3 Page 2 of 125 Document Information Title LEON-G100 / LEON-G200 Subtitle quad-band GSM/GPRS Data and Voice Modules Document type System Integration Manual Document number GSM.G1-HW-09002-G3 Document status Preliminary Document status information Objective Specification This document contains target values. Revised and supplementary data will be published later. Advance Information This document contains data based on early testing. Revised and supplementary data will be published later. Preliminary This document contains data from product verification. Revised and supplementary data may be published later. Released This document contains the final product specification. This document applies to the following products: Name Type number Firmware version PCN / IN LEON-G100 LEON-G100-04S-00 LEON-G100-05S-00 LEON-G100-06S-00 LEON-G100-06S-01 LEON-G100-07S-00 LEON-G100-08S-00 LEON-G100-06A-00 LEON-G100-07A-00 07.40.00 07.50.00 07.60.00 07.60.02 07.70 07.83 07.60.00 07.70 GSM.G1-SW-10007 GSM.G1-SW-10008 GSM.G1-SW-10012 GSM.G1-SW-10013 GSM.G1-SW-12002 UBX-TN-13001 GSM.G1-SW-10012 GSM.G1-SW-12002 LEON-G100 ECALL LEON-G100-71S-00 TBD TBD LEON-G200 LEON-G200-04S-00 LEON-G200-05S-00 LEON-G200-06S-00 LEON-G200-06S-01 07.40.00 07.50.00 07.60.00 07.60.02 GSM.G1-SW-10007 GSM.G1-SW-10008 GSM.G1-SW-10012 GSM.G1-SW-10013 This document and the use of any information contained therein, is subject to the acceptance of the u-blox terms and conditions. They can be downloaded from www.u-blox.com. u-blox makes no warranties based on the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. u-blox reserves all rights to this document and the information contained herein. Reproduction, use or disclosure to third parties without express permission is strictly prohibited. Copyright © 2013, u-blox AG. u-blox® is a registered trademark of u-blox Holding AG in the EU and other countries. Trademark Notice Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. All other registered trademarks or trademarks mentioned in this document are property of their respective owners. LEON-G100 / LEON-G200 - System Integration Manual GSM.G1-HW-09002-G3 Preliminary Preface Page 3 of 125 Preface u-blox Technical Documentation As part of our commitment to customer support, u-blox maintains an extensive volume of technical documentation for our products. In addition to our product-specific technical data sheets, the following manuals are available to assist u-blox customers in product design and development. AT Commands Manual: This document provides the description of the supported AT commands by the LEON GSM/GPRS Voice and Data Modules to verify all implemented functionalities. System Integration Manual: This Manual provides hardware design instructions and information on how to set up production and final product tests. Application Note: document provides general design instructions and information that applies to all u-blox Wireless modules. See Section Related documents for a list of Application Notes related to your Wireless Module. How to use this Manual The LEON-G100 / LEON-G200 System Integration Manual provides the necessary information to successfully design in and configure these u-blox wireless modules. This manual has a modular structure. It is not necessary to read it from the beginning to the end. The following symbols are used to highlight important information within the manual: An index finger points out key information pertaining to module integration and performance. A warning symbol indicates actions that could negatively impact or damage the module. Questions If you have any questions about u-blox Wireless Integration, please:  Read this manual carefully.  Contact our information service on the homepage http://www.u-blox.com  Read the questions and answers on our FAQ database on the homepage http://www.u-blox.com Technical Support Worldwide Web Our website (www.u-blox.com) is a rich pool of information. Product information, technical documents and helpful FAQ can be accessed 24h a day. By E-mail Contact the nearest of the Technical Support offices by email. Use our service pool email addresses rather than any personal email address of our staff. This makes sure that your request is processed as soon as possible. You will find the contact details at the end of the document. Helpful Information when Contacting Technical Support When contacting Technical Support please have the following information ready:  Module type (e.g. LEON-G100) and firmware version  Module configuration  Clear description of your question or the problem  A short description of the application  Your complete contact details LEON-G100 / LEON-G200 - System Integration Manual GSM.G1-HW-09002-G3 Preliminary Contents Page 4 of 125 Contents Preface ................................................................................................................................ 3 Contents .............................................................................................................................. 4 1 System description ....................................................................................................... 7 1.1 Overview ..........................................................................................…

Text truncated - open the document above for the full version.

6/20/2014LMU-2000 Hardware & Installation Guide - PULS Wiki https://puls.calamp.com/wiki/LMU-2000_Hardware_%26_Installation_Guide1/35 LMU-2000 Hardware & Installation Guide Contents 1 Introduction 1.1 About This Manual 1.2 About The Reader 1.3 About CalAmp 1.4 About the CalAmp Location Messaging Unit-LMU-2000™ 2 System Overview 2.1 Overview 2.2 Component Descriptions 2.2.1 Wireless Data Network 2.2.2 LMU-2000™ 2.2.3 LM Direct™ Server 2.2.4 Backend Software 2.2.5 PULS™ 2.2.6 LMU Manager™ 3 Hardware Overview 3.1 Location Messaging Unit-LMU-2000™ 3.1.1 LMU-2000™ Handling Precautions 3.1.2 Battery Back-up devices 3.1.3 Environmental Specifications 3.2 LMU-2000™ Connectors 3.2.1 Primary Connector 3.2.2 Serial Adapter 3.2.3 Accessories 3.3 I/O Descriptions 3.3.1 3-Axis Accelerometer Input 3.3.2 Status LEDs 4 Configuration and Activation 4.1 Quick Start - General Config 4.2 Auto provisioning of GSM or HSPA LMUs 4.3 Activating GSM or HSPA LMU using AT Commands 4.4 Accessing the SIM 4.5 Activating a CDMA LMU-2000™ 4.5.1 Activating a CDMA LMU-2000™ – Verizon 4.5.2 Activating a CDMA LMU-2000™ – Sprint 5 Installing the LMU 5.1 Preventing Accidental or Unauthorized Modification 5.2 Installing the LMU in a vehicle 5.3 Installation Verification 6/20/2014LMU-2000 Hardware & Installation Guide - PULS Wiki https://puls.calamp.com/wiki/LMU-2000_Hardware_%26_Installation_Guide2/35 5.3.1 Comm Verification 5.3.2 GPS Verification 5.3.3 Inbound Verification 5.3.4 Verification via SMS 6 License Agreement 7 Limited Warranty 8 Regulatory Information LMU-2000™ Hardware and Installation Guide IMPORTANT: DO NOT INSTALL OR USE THE SOFTWARE OR DOCUMENTATION UNTIL YOU HAVE READ AND AGREED TO THE LICENSE AGREEMENT AND REVIEWED THE LIMITED WARRANTY AND REGULATORY INFORMATION. 1 Introduction Welcome to the LMU-2000™ Hardware and Installation Guide. This manual is intended to give you information on the basic setup and installation of the CalAmp LMU-2000™ product(s) including hardware descriptions, environmental specifications, wireless network overviews and device installation. 1.1 About This Manual The LMU-2000™ is one of the most flexible economy mobile tracking hardware products available. In order to accurately describe the functionality of these units we have broken this manual into the following sections: System Overview – A basic description of a CalAmp LMU-2000™ based tracking system. 6/20/2014LMU-2000 Hardware & Installation Guide - PULS Wiki https://puls.calamp.com/wiki/LMU-2000_Hardware_%26_Installation_Guide3/35 This includes a description of roles and responsibilities of each of the CalAmp components as well as a brief overview of the wireless data technologies used by the LMU-2000™. Hardware Overview – Describes the physical characteristics and interfaces of the LMU- 2000™. Installation and Verification – Provides guidance for the installation of the LMU-2000™ in a vehicle and instructions on how to verify the installation is performing adequately. 1.2 About The Reader In order to limit the size and scope of this manual, the following assumptions have been made about the reader. You are familiar with GPS concepts and terminology You have some experience with installing equipment in vehicles You are familiar with the use of AT Commands You are familiar with the use of terminal programs such as HyperTerminal or PuTTY 1.3 About CalAmp CalAmp is a leading provider of wireless communications products that enable anytime/anywhere access to critical information, data and entertainment content. With comprehensive capabilities ranging from product design and development through volume production, CalAmp delivers cost-effective high quality solutions to a broad array of customers and end markets. CalAmp is the leading supplier of Direct Broadcast Satellite (DBS) outdoor customer premise equipment to the U.S. satellite television market. The Company also provides wireless data communication solutions for the telemetry and asset tracking markets, private wireless networks, public safety communications and critical infrastructure and process control applications. For additional information, please visit the Company’s website at www.calamp.com (http://www.calamp.com/) . 1.4 About the CalAmp Location Messaging Unit-LMU-2000™ The CalAmp Location and Messaging Unit-LMU-2000™ (LMU-2000™) is a mobile device that resides in private, commercial or government vehicles. The LMU-2000™ is a single box enclosure incorporating a processor, a GPS receiver, a wireless data modem, and a vehicle-rated power supply. The LMU-2000™ also supports inputs and outputs to monitor and react to the vehicular environment and/or driver actions. Flexibility The LMU-2000™ features CalAmp's industry leading advanced on-board alert engine that monitors vehicle conditions giving you the most flexible tracking device in its class. The PEG™ (Programmable Event Generator) application supports hundreds of customized exception-based rules to help meet customers' dynamic requirements. Customers can modify the behavior of the device to meet with a range of applications 6/20/2014LMU-2000 Hardware & Installation Guide - PULS Wiki https://puls.calamp.com/wiki/LMU-2000_Hardware_%26_Installation_Guide4/35 preprogrammed before shipment or in the field. Combining affordability and device intelligence with your unique application can give you distinct advantages over your competition. Over-the-Air Serviceability The LMU-2000™ also incorporates CalAmp's industry leading over-the-air device management and maintenance system software, PULS™ (Programming, Updates, and Logistics System). Configuration parameters, PEG rules, and firmware can all be updated over the air. Our web-based maintenance server, PULS™ scripts, and firmware, can all be updated over-the-air. PULS™ offers out-of-the-box hands free configuration and automatic post-installation upgrades. You can also monitor unit health status across your customers' fleets to quickly identify issues before they become expen…

Text truncated - open the document above for the full version.

TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 TÜV SÜD America Inc. (San Diego) June 06, 2014 TUV SUD BABT Octagon House, Concorde Way Segensworth Rd N, Fareham PO15 5RL RE: FCC ID FIH-2000B IC: 1584A-2000B M/N: LMU-2000B By my signature below, I attest: That Model LMU-2000B and LMU-3000 uses the same radio and antenna. The difference between the two models is the vehicle bus. LMU-3000 reads the bus info while LMU-2000B does not. Antenna details exhibit presented in this filing is from LMU-3000 which is identical and applicable to LMU- 2000B. Sincerely, Ferdinand S. Custodio EMC/Senior Wireless Test Engineer

TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 TÜV SÜD America Inc. (San Diego) June 06, 2014 TUV SUD BABT Octagon House, Concorde Way Segensworth Rd N, Fareham PO15 5RL RE: FCC ID FIH-2000B IC: 1584A-2000B M/N: LMU-2000B By my signature below, I attest: That the original test data from CCS Inc. Report T131118W01-RP, according to FCC Part 22H/24E and RSS-132/133 remain valid and applicable to Model LMU-2000B and is/are representative of the compliance for this device. The product remains compliant with all the applicable rules and requirements and the integrated module with FCC ID: XPYLEONG100N and IC: 8595A-LEONG100N is being installed/operated according to the original approval. Sincerely, Ferdinand S. Custodio EMC/Senior Wireless Test Engineer

FCC ID FIH-2000B IC: 1584A-2000B See updated Label Exhibit for detail See updated Label Exhibit for detail See updated Label Exhibit for detail

See updated Label Exhibit for detail See updated Label Exhibit for detail See updated Label Exhibit for detail

FCC ID FIH-2000B IC: 1584A-2000B

SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 1 CALAMP LMU3000 1 st Evaluation San Diego Design Center (SDC) <January 4,2011> SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 2 Revision History RevisionDateDescription of changes Rev. A 04-Jan-2011 1 st Evaluation SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 3 Summary •Received 2D drawing and a plastic housing from Calamp. •Created a mockup according to the 2D drawing. •Design GSM antenna with cable on the plastic housing. •Currently the antenna is placed on the out side of the housing for easy antenna development. •Data Taken: –Return Loss –Efficiency SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 4 Test Condition SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 5 Test Configuration Top (GPS) board (31.8mm*31.8mm) Middle board (44.45mm*38.10mm) Bottom (GSM) board (44.45mm*38.10mm) Ground Position between Top and Middle board Ground Position between Bottom and Middle board GSM connector position SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 6 Test Configuration PCB and Housing Assembly Cable through out here Test Antenna Plastic housing received from Calamp SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 7 Return Loss SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 8 GSM850/900/1800/1900 -20 -18 -16 -14 -12 -10 -8 -6 -4 -2 0 750950115013501550175019502150 Freq in MHz Return Loss (dB) 1#GSM850EGSM900DCS/PCS SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 9 Efficiency SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 10 Low Band 0% 10% 20% 30% 40% 50% 60% 800810820830840850860870880890900910920930940950960 Freq in MHz Efficiency 1#GSM850EGSM900 SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 11 High Band 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 17001750180018501900195020002050210021502200 Freq in MHz Efficiency 1#DCS/PCS SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 12 Conclusion and next steps •The low band bandwidth is a bit narrow due to its short ground size. The average efficiency of Low band is around 30%. •High band average efficiency is around 50%. •For better antenna development and production assembly , top and bottom types of housing is recommended. •ET would need more input from Calamp regarding the mechanical housing design. •Suggest to modify Calamp’s existing top and bottom types housing for the next antenna design cycle. SRFF0003 Rev A© 2010, Ethertronics; Confidential & Proprietary1/5/2011Page 13 Thank You!

LMU TC Operational Description The “LMU-TC” or “LMU-2000 Beacon” adds a new 2.4GHz radio onto an existing LMU-2000 design. The original LMU-2000 design contains a GSM radio that is already certified with FCCID: XPYLEONG100 and ICID: 8595A-LEONG100 The original LMU-2000 is a mobile device that resides in private, commercial or government vehicles used for asset tracking. It is a single box enclosure incorporating a processor, a GPS receiver, a wireless data modem, and a vehicle- rated power supply. The LMU also supports inputs and outputs to monitor and react to the vehicular environment and/or driver actions. The new Beacon radio feature is designed by Transcore Amtech Inc and operates on 2452, 2472, 2477 and 2482 MHz bands.The new embedded radio that will receive “PING” requests from another Transcore product to provide location information directly from the LMU-2000 design. When it receives a “PING” it will send the requested data back to the product that issued the “PING”.

133543-2000B - PWA, LMU2000, BEACON, APP/GSM LAYER (Rev: G) ItemPart NumberQtyUOMRefdesFindDescriptionRevAlternateNotesSpecial 1133542/F1A1PWB, OBD3000 APP-GSMF 2 1CF148-1044C6,C17,C31,C53 CAP, CHIP, 0.1 UF, +/-10%, 50V, X7R, 0603 (WAS: 73721-104)B 3 1CF557-2212C10,C11 CAP, CHIP, 220 PF, +/-5%, 25V, NPO, 0402 (WAS: 73685-221)A1 4 1CF559-10413 C25,C26,C34,C43,C44,C51,C54,C55,C56,C57, C60,C64,C65 CAP, CHIP, 0.1 UF, +/-10%, 10V, X5R, 0402 (WAS: 73555)B 5 1CF563-1001C37CAP, CHIP, 10 PF, +/-0.5 PF, 50V, NPO, 0402 B 6 1CF568-1541C4 CAP, CHIP, 0.15 UF, +80%/-20%, 50V, Y5V, 0603A 71CF599-1802C40,C41CAP, CHIP, 18 PF, +/-5%, 50V, NPO, 0402A 81CF599-4705C27,C28,C29,C30,C36CAP, CHIP, 47 PF, +/-5%, 50V, NPO, 0402A 91CF599-8201C18CAP, CHIP, 82 PF, +/-5%, 50V, NPO, 0402A 10 1CF661-4711C21 CAP, CHIP, 470 PF, +/-10%, 25V, X7R, 0402 (WAS: 73554-471)A 11 1CF664-1066C7,C9,C48,C50,C52,C58CAP, CHIP, 10 UF, +/-20%, 6.3V, X5R, 0603 A 121CF664-2251C63CAP, CHIP, 2.2 UF, 6.3V, X5R, 0603A 13 1CF722-10215 C39,C42,C45,C46,C47,C66,C67,C68,C69,C70, C71,C72,C73,C74,C75CAP, CER, 1000 PF, +/-10%, 100V, X7R, 0402 A 14 1CF723-1035C8,C35,C49,C61,C62CAP, CHIP, 0.01 UF, +/-10%, 50V, X7R, 0402 B 15 1CF751-2267C19,C20,C32,C33,C80,C81,C82CAP, CHIP, 22 UF, +/-20%, 6.3V, X5R, 0805 C 16 1CF755-1065C15,C76,C77,C78,C79 CAP, CHIP, 10 UF, +80%/-20%, 50V, Y5V, 1210A1 17 1CF766-2251C16 CAP, CHIP, 2.2 UF, +80%/-20%, 50V, Y5V, 1206A 18 1CF790-1051C38CAP, CHIP, 1.0 UF, +/-10%, 6.3V, X5R, 0402 A 19 1DF145-3601D1 DIODE, RECTIFIER, 600V, 3.0A, GALSS PASSIVATED, SMTA1 20 1DF145-SMBJ33A1D2 TRANSIENT VOLTAGE SUPPRESSOR, DO- 214AA (WAS: 71964-SMBJ33A)C1 21 1DF149-AZ23C3V31D9 DIODE, ZENER, COMMON ANODE, 3.3V, 300MW, SOT-23A 221DF149-B340A2D3,D11DIODE, SCHOTTKY, 3A, SMA, B340AA 23 1DF248-121UD1D5 LED, SUPERBRIGHT ORANGE, WATER CLEAR LENS, RT ANGLE, SMDC 24 1DF248-121USD1D7 LED, ULTRA BRIGHT RED, WATER CLEAR LENS, RT ANGLE, SMDB 25 1DF248-121UYG1D6 LED, SUPERBRIGHT YELLOW GREEN, WATER CLEAR LENS, RT ANGLE, SMDB 261DF374-4148SE3D4,D8,D10DIODE, SMALL SIGNAL, MMBD4148SEA 27 1JF155-53048-0410 1J2 CONN, 4P, THRU-HOLE, PICO BLADE, 1.25MM, RT ANGLE, 53048A 28 1JF465-202791J11 CONN, RF, RECEPTACLE, MHF SERIES MICRO COAXIAL, SMDC 291JF724-089651J4CONN, SIM CARD HOLDERA 30 1JF724-SIMSHIELD1SHD1 SIM SHIELD, CARD, WIDE SLOT OPENING, ID 15.35 INB 31 1LF176-1N81L2INDTR, 1.8NH, +/-0.2NH, FIXED, 0603 SMD A 32 1LF627-472TY1L3 INDTR, SMT POWER, 4.7UH, 2.7A, 6028, NR TYPEA 33 1LF627-4731L4 INDTR, SMT POWER, 47UH, 10%, 280MA, 1812, LQH43CA 34 1QF122-32F103REY6 1U5 IC, ARM 32-BIT MCU, 512KB FLASH, WLCSP64, STM32F103A 351QF123-25Q32CVSSIG1U7FLASH, SPI, SERIAL, 32 MBIT, 8-SOPA1 36 1QF126-NC7SZ001U9 IC, SINGLE, 2 INPUT NAND GATE, SOT23-5, NC7SZ00M5XA 37 1QF126-LIS3DH1U8 IC, SENSOR, ACCELEROMETER, MEMS, LOW POWER, 3 AXIS, LGA16-3X3A 38 1QF127-AP139332U1 U6 IC, LDO, LOW NOISE CMOS, 3.3V, 300MA, SOT23-5B1 39 1QF127-MIC51591U4IC, LDO, ADJUSTABLE, EXT PFET, SOT23-6 A 40 1QF127-MP2565Q1U2 IC, STEP-DOWN CONVERTER, 2.5A, 4 MHZ, 50V, QFN10C 41 1QF158-63751Q5 XSTR, MOSFET, P-CHANNEL, 2.5V, -8A SMD, S08A 42 1RF103-0001R66 RES, CHIP, 00 OHM, +/-5%, 1206 (WAS: 75232)B 43 1RF105-0002R12,R157 RES, CHIP, 00 OHM, +/-5%, 0603 (WAS: 75361; C806-0000-001; 1R105-0R0)A 44 1RF560-0001R70 RES, CHIP, 00 OHM, +/-5%, 0402 (WAS: 75906-000)A 45 1RF560-1013R11,R16,R22 RES, CHIP, 100 OHM, +/-5%, 0402 (WAS: 75906-101)A1 46 1RF560-1025R14,R19,R33,R37,R51 RES, CHIP, 1.0K OHM, +/-5%, 0402 (WAS: 75906-102)A 47 1RF560-1034R9,R15,R20,R28 RES, CHIP, 10K OHM, +/-5%, 0402 (WAS: 75906-103)A 48 1RF560-1051R13 RES, CHIP, 1M OHM, +/-5%, 0402 (WAS: 75906-105) 491RF560-2041R32RES, CHIP, 200K OHM, +/-5%, 0402B 50 1RF560-2201R1 RES, CHIP, 22 OHM, +/-5%, 0402 (WAS: 75729)A 51 1RF560-3316R29,R30,R31,R41,R43,R45 RES, CHIP, 330 OHM, +/-5%, 0402 (WAS: 75888)B 521RF560-5601R25RES, CHIP, 56 OHM, +/-5%, 0402A 53 1RF786-100334 R2,R7,R8,R10,R17,R21,R23,R24,R26,R34,R35 ,R36,R38,R39,R40,R42,R47,R48,R49,R50,R52 ,R54,R55,R56,R57,R58,R59,R60,R61,R62,R63 ,R64,R65,R68 RES, CHIP, 100K OHM, +/-1%, 0402 (WAS: 75708)A 541RF786-15031R44RES, CHIP, 150K OHM, +/-1%, 0402A 551RF786-20531R3RES, CHIP, 205K OHM, +/-1%, 0402A 56 1RF786-22121R27 RES, CHIP, 22.1K OHM, +/-1%, 0402 (WAS: 75876-2212A 571RF786-39022R4,R6RES, CHIP, 39K OHM, +/-1%, 0402A 581RF786-51011R46RES, CHIP, 5.1K OHM, +/-1%, 0402A 591RF786-90921R5RES, CHIP, 90.9K OHM, +/- 1%, 0402A 60 1TF153-BSS1385Q1,Q2,Q4,Q7,Q9 XSTR, N-CHANNEL, 50V, 220 MA, SMD, SOT- 23 (WAS: 77189-BSS138)A1 61 1TF158-BSS841Q3 XSTR, P-CHANNEL, ENHANCED-MODE, DMOS, SOT-23A 62 1XF415-MSMF1501F1FUSE, PTC, RESETABLE, 3A, 24V, SMD, 1812 B1 63 1YF496-12.00001Y1 CRYSTAL, 12.0000 MHZ, 30 PPM, 18PF,-40 TO +85, SMT 3.2X2.5MM CERAMICB 644GF546-LEONG6S1U3UBLOX, IC, GPS MODULE, LEONG6SB 6579-003191SEE ASSEMBLY DRAWING NOTE 6ADH, LOCTITE 3609B

TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 May 29, 2014 TUV SUD BABT Octagon House, Concorde Way Segensworth Rd N, Fareham PO15 5RL Attention: Director of Certification RE: Analysis of RF Exposure for Portable use per Title 47, Part 1 Subpart I, §1.1310, Title 47, Part 2 Subpart J, §2.1091 and RSS-102 Issue 4 March 2010. FCC ID: FIH-2000B IC: 1584A-2000B 1. Mobile MPE Calculation Summary using a 20cm separation distance: Mode Output Power Power Density (mW/m 2 ) GSM/GPRS 850 33.20 dBm 0.1857 GSM/GPRS 1900 30.20 dBm 0.0659 2.4GHz Beacon Radio 94.0 dBμV/m @ 3 meters 0.000150 2. Co-Located Transmitters transmission table: Transmitter type Transmitter type that can transmit at the same time N/A The Cellular radio and the 2.4GHz Beacon Radio does not transmit at the same time 3. Mobile MPE Calculation using a 20cm separation distance (GSM/GPRS 850): Using Power Density formula: S= PG 4πR 2 where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to isotropic R = distance to the center of radiation of the antenna TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Maximum peak output power at antenna input terminal: 33.20 (dBm) Maximum peak output power at antenna input terminal: 2089.30 (mW) Antenna gain(typical): -3.5 (dBi) Maximum antenna gain: 0.447 (numeric) Prediction distance: 20 (cm) Sourse Based Time Average Duty Cycle: 100 (%) Prediction frequency: 824.2 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 0.549 (mW/cm 2 ) Power density at prediction frequency: 0.1857 (mW/cm 2 ) Power density at prediction frequency: 1.857 (W/m 2 ) Margin of Compliance: -4.71 (dB) 4. Mobile MPE Calculation using a 20cm separation distance (GSM/GPRS 1900): Maximum peak output power at antenna input terminal: 30.20 (dBm) Maximum peak output power at antenna input terminal: 1047.13 (mW) Antenna gain(typical): -5.0 (dBi) Maximum antenna gain: 0.316 (numeric) Prediction distance: 20 (cm) Sourse Based Time Average Duty Cycle: 100 (%) Prediction frequency: 1850.2 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.000 (mW/cm 2 ) Power density at prediction frequency: 0.0659 (mW/cm 2 ) Power density at prediction frequency: 0.659 (W/m 2 ) Margin of Compliance: -11.81 (dB) 5. Mobile MPE Calculation using a 20cm separation distance (2.4GHz Beacon Radio): Measured Field Strength --Radiated: 94.00 (dBuV/m) Maximum peak output power --Radiated: 0.0007536 (W) Antenna gain(typical): 0.00 (dBi) Maximum antenna gain: 1.00 (numeric) Prediction distance: 20.00 (cm) Prediction frequency: 2452.00 (MHz) Limit from table below: 1.00 (mW/cm 2 ) Power density at prediction frequency: 0.000150 (mW/cm 2 ) Margin of Compliance: -38.24 (dB) TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Notes: Power level and worst case channel information for the cellular radio were derived from the MPE exhibit of the original filing. Antenna gains information of the cellular radio were also derived from this exhibit as well as the CTIA Over The Air Performance Summation Test Report (7 layers, Inc. Project Name: MUS_CALAMP_1102) provided by the client. Sincerely, Ferdie S. Custodio Name Authorized Signatory Title: EMC/ Senior Wireless Test Engineer

Compliance Certification Services Inc. FCC ID: XPYLEONG100N IC: 8595A-LEONG100N Report No.: T131118W01-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 73 Rev.00 FCC 47 CFR PART 22 SUBPART H AND PART 24 SUBPART E & INDUSTRY CANADA RSS-132 & RSS-133 TEST REPORT For Module Model: LEON-G100N Trade Name: u-blox Issued to u-blox AG ZÜRCHERSTRASSE 68 Issued by Compliance Certification Services Inc. No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: December 3, 2013 Compliance Certification Services Inc. FCC ID: XPYLEONG100N IC: 8595A-LEONG100N Report No.: T131118W01-RP Page 2 Rev.00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 December 3, 2013 Initial Issue ALL Angel Cheng Compliance Certification Services Inc. FCC ID: XPYLEONG100N IC: 8595A-LEONG100N Report No.: T131118W01-RP Page 3 Rev.00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ............................................................................................. 4 2. EUT DESCRIPTION .................................................................................................................... 5 3. TEST METHODOLOGY ............................................................................................................. 6 3.1 EUT CONFIGURATION .............................................................................................................. 6 3.2 EUT EXERCISE ......................................................................................................................... 6 3.3 GENERAL TEST PROCEDURES .................................................................................................. 6 3.4 DESCRIPTION OF TEST MODES ................................................................................................. 7 4. INSTRUMENT CALIBRATION ................................................................................................. 8 4.1 MEASURING INSTRUMENT CALIBRATION ........................................................................... 8 4.2 MEASUREMENT EQUIPMENT USED .............................................................................. 8 4.3 MEASUREMENT UNCERTAINTY .................................................................................... 9 5. FACILITIES AND ACCREDITATIONS ................................................................................. 10 5.1 FACILITIES ............................................................................................................................ 10 5.2 EQUIPMENT ........................................................................................................................... 10 5.3 LABORATORY ACCREDITATIONS AND LISTING ..................................................................... 10 5.4 TABLE OF ACCREDITATIONS AND LISTINGS .......................................................................... 11 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................ 12 6.1 SETUP CONFIGURATION OF EUT ............................................................................................ 12 6.2 SUPPORT EQUIPMENT ..................................................................................................... 12 7. FCC PART 22 & 24 REQUIREMENTS & INDUSTRY CANADA RSS-132 & RSS-133 ... 13 7.1 99% BANDWIDTH ............................................................................................................. 13 7.2 PEAK POWER ......................................................................................................................... 21 7.3 AVERAGE POWER ............................................................................................................... 23 7.4 ERP & EIRP MEASUREMENT .......................................................................................... 25 7.5 OUT OF BAND EMISSION AT ANTENNA TERMINALS .............................................. 28 7.6 FIELD STRENGTH OF SPURIOU…

Text truncated - open the document above for the full version.
